Crestron TPS-6L Isys® 5.
This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2008 Crestron Electronics, Inc.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Contents Isys® 5.7” Wall Mount Touchpanel: TPS-6L 1 Introduction ..........................................................................................................1 Features and Functions...........................................................................1 Applications ...........................................................................................3 Internal Block Diagram...........................................................
Isys® 5.7-Inch Wall Mount Touchpanel Crestron TPS-6L ® Isys 5.7” Wall Mount Touchpanel: TPS-6L Introduction Features and Functions This guide describes multiple models; differences are noted where applicable. • • • • • • • • • • • • • • 5.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Isys® Isys power and beauty are infused throughout Crestron’s entire touchpanel lineup. Under the hood, the Isys engine combines a 32-bit Freescale ColdFire® microprocessor with an ingenious and ultra efficient operating system to produce astonishing full color graphics and high res images with lightning fast performance. Capabilities include dynamic graphics and text, full motion animations, multimode objects and PNG translucency.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Light Sensor A light sensor is built into the TPS-6L to automatically adjust the display brightness for optimal visibility under varying light conditions. High Speed Connectivity Both Cresnet® and high speed Ethernet are standard on the TPS-6L, providing for easy network integration and seamless communications with Crestron control systems.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Internal Block Diagram The following diagram represents the basic operation of the TPS-6L. TPS-6L Internal Block Diagram Specifications Specifications for the TPS-6L are listed in the following table. TPS-6L Specifications SPECIFICATION DETAILS Touchscreen Display Display Type TFT Active matrix color LCD Size 5.7 inch (14.
Isys® 5.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L TPS-6L Specifications (Continued) SPECIFICATION DETAILS Enclosure Construction Injection molded plastic, flush mountable using (4) clips provided (additional mounting kits available) Faceplate Injection molded plastic, button and no-button faceplates included, optional solid or backlit engraving sold separately Dimensions Height 5.60 in (14.23 cm) Width 7.40 in (18.80 cm) Depth 2.28 in (5.78 cm) 3.58 in (9.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L 3. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product Catalog for a complete list of 2-Series control systems. NOTE: Crestron software and any files on the website are for Authorized Crestron dealers and Crestron Authorized Independent Programmers (CAIP) only. New users may be required to register to obtain access to certain areas of the site (including the FTP site).
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L TPS-6L Dimensions – Front and Side View with Cutaway Showing Internal Controls TPS-6L Dimensions and Connections – Rear View 8 • Isys® 5.7” Wall Mount Touchpanel: TPS-6L Operations & Installation Guide - DOC.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Connectors, Controls & Indicators # CONNECTORS1, CONTROLS & INDICATORS 1 BUTTONS 2 MICROPHONE (1) Built-in microphone behind the bezel supports programmable intercom functionality. 3 LIGHT SENSOR Programmable photosensor for automatic backlight dimming. Refer to “Auto Brightness Control” on page 25 for additional information.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Connectors, Controls & Indicators (Continued) # CONNECTORS1, CONTROLS & INDICATORS 9 NTSC/PAL INPUT 10 SPEAKER OPTION DESCRIPTION (1) 5-pin 3.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Industry Compliance As of the date of manufacture, the TPS-6L has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Setup Network Wiring When wiring the Cresnet® or Ethernet network, consider the following: • Use Crestron Certified Wire. • Use Crestron power supplies for Crestron equipment. • Provide sufficient power to the system. CAUTION: Insufficient power can lead to unpredictable results or damage to the equipment. Please use the Crestron Power Calculator to help calculate how much power is needed for the system (www.crestron.com/calculators).
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Configuring the Touchpanel NOTE: The only connection required to configure the touchpanel is power. Refer to “Hardware Hookup” which starts on page 34 for details. To configure the unit, it may be necessary to access a series of setup screens prior to viewing run-time screens that are loaded into the touchpanel for normal operation.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L MAIN MENU Calibration Menu Before beginning other setup procedures, it is advisable to perform screen calibration. Press Touch Screen Calibration to display the CALIBRATION MENU, as shown in the following illustration. CALIBRATION MENU Touch Perform Calibration. The message “Touch Upper Left” appears centered on the panel with a cross hair in the upper left corner. Touch the center of the cross hair in the corner of the screen to initiate calibration.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L hair in the corner of the screen. A final message, “Touch Lower Right”, appears with a cross hair in the correct corner. Touch the center of the cross hair in the corner of the screen to conclude calibration and return to the MAIN MENU. NOTE: When touching the screen during calibration, be as accurate as possible. Use the tip of a capped pen or the eraser end of a pencil.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L parameters, select the Interface button located on the SETUP MENU and display the INTERFACE MENU, shown below. The Cresnet network identity number (Cresnet ID also known as the Net ID) is displayed on the INTERFACE MENU. Net ID is a two-digit hexadecimal number that can range from 03 to FE and must correspond to the Net ID set in the SIMPL Windows program of the Cresnet system.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L The menu shows the current IP address. The LINK STATUS button shows if the Ethernet link is active (green) or inactive (gray). With DHCP enabled (default), the bottom buttons let you renew or release DHCP functions. When you press each button, the button legend changes to Working until the selected function is completed. NOTE: If DHCP is unable to locate an IP address, a notice appears on the screen.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L STATIC IP SETTINGS Menu • Press the appropriate EDIT buttons to display submenus that let you change the IP address, the subnet mask, and the default router address. Each EDIT button selection displays a submenu similar to the following: EDIT IP ADDRESS Submenu • Press Return to go back to the ETHERNET MENU. 18 • Isys® 5.7” Wall Mount Touchpanel: TPS-6L Operations & Installation Guide - DOC.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L STATIC DNS SETTINGS Menu • Press the EDIT buttons to display submenus that let you edit the primary and secondary DNS addresses, and the primary and secondary WINS addresses. Each EDIT submenu is similar to the following: EDIT PRIMARY DNS Submenu • Press Return to go back to the ETHERNET MENU. Operations & Installation Guide – DOC. 6630A Isys® 5.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Audio Menu To set the audio communication parameters, select the Audio button located on the SETUP MENU and display the following AUDIO SETUP menu. AUDIO SETUP Menu – Audio Main • With the Audio Main button pressed (default), you can verify the function of the internal speaker, restore default audio settings and adjust the relative level (0% to 100%) or mute the key click volume and the WAV file volume.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L • With the LINE-IN button set to ON (default), you can adjust the volume as well as the bass and treble levels. Pressing the LINE IN button turns it to OFF. • Press Return to return to the SETUP MENU. Video Menu To set the video parameters, select the Video button located on the SETUP MENU and display the VIDEO SETUP menu, shown below. VIDEO SETUP Menu • Adjust the controls as desired for best viewing under local conditions.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Full Screen Video Display • Press Return to return to the SETUP MENU screen. Screen Settings From the SETUP MENU screen, press Screen Settings to display the SCREEN SETTINGS menu as shown below. SCREEN SETTINGS Menu • With Auto Brightness Control set to OFF (default), the screen brightness is at the level set by the screen brightness controls. 22 • Isys® 5.7” Wall Mount Touchpanel: TPS-6L Operations & Installation Guide - DOC.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L • Use the controls to adjust the relative level (0% to 100%) of current brightness, and the high and low preset brightness levels. Press the HIGH and LOW buttons to check each level. • With Auto Brightness Control set to ON, the Current LCD Brightness Level display changes to show the LCD Threshold value and the Light Sensor Level, as shown in the following figure.
Isys® 5.7” Wall Mount Touchpanel • Crestron TPS-6L Press the White, Almond, or Black Bezel button to set the Auto Key Backlight Control threshold for the color of your bezel. The Current Light Sensor Level value is provided as a reference. The internal light sensor adjusts the brightness level to accommodate for the current room ambience. For white or almond bezels, if the current sensor level is above or equal to the threshold, the brightness is set to the low level.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Auto Brightness Control Select Auto Brightness Control to display the AUTO BRIGHTNESS CONTROL SETUP menu as shown below. AUTO BRIGHTNESS CONTROL SETUP Menu • Press the ON and OFF (default) Auto LCD Brightness Control buttons to turn that feature on and off. • With auto LCD brightness set to ON, the internal light sensor adjusts the brightness level to accommodate for the current room ambience.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L For black bezels: When the sensor is below the threshold the key backlight brightness is set to the low level. When the sensor is above the threshold the key backlight brightness is set to the high level. • With Manual (OFF) selected, the key backlight brightness is controlled manually (sensor is ignored). • With No Key Backlight selected, the key backlight is turned off, regardless of the sensor reading or other settings.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L KEY BACKLIGHT Menu • Use the Current Key Backlight Level controls to adjust the current screen brightness level as desired. • Press the HIGH, MEDIUM, and LOW buttons to check the preset levels. Use the High-, Medium-, and Low Backlight Level controls to adjust the preset levels as desired. Graphics Options Select Graphics Options to display the GRAPHICS MENU as follows. Operations & Installation Guide – DOC. 6630A Isys® 5.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L GRAPHICS MENU The dynamic graphics loading icon is displayed whenever a dynamic graphic image is queued to load, is actively loading or is being decompressed. It will appear as a grey spinning circle if the image has been queued to load, a blue spinning circle if it is actively loading and a solid blue circle while the image is being decompressed.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L DIAGNOSTICS MENU Mounting Options The TPS-6L touchpanel installs simply and cleanly into existing or newly constructed walls, with an assortment of pre- and post-construction mounting options. The TPS-6L is supplied with four screws and clips for post-construction installation. All available mounting options are listed in the following table. The options listed are provided separately from the actual touchpanel.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L NOTE: Pre-construction refers to framed walls prior to hanging drywall. Post-construction refers to framed walls with drywall hung. NOTE: There is also a rack mount kit (RMK-6L) available for the TPS-6L. Refer to the latest version of the RMK-6L Installation Guide (Doc. 6599).
Isys® 5.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L 3. Using masking tape (or equivalent), fasten the template to the wall; verify that the template is level, and trace the opening shape on the wall. 4. Remove the template, and then cut out and remove the traced shape to produce the required opening. NOTE: Before inserting the TPS-6L in the mounting hole, ensure that all required cables have been installed in the wall. 5.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Insert the TPS-6L Into the Mounting Surface 7. Tighten the mounting screws evenly and only enough to compress the mounting clips and secure the TPS-6L squarely in the mounting surface. Do not over-tighten the screws. NOTE: If it becomes necessary to remove the touchpanel from the mounting surface, the original mounting clips cannot be reused to remount the touchpanel.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Touchpanel Removal If it is necessary to remove the touchpanel after it has been installed into a mounting surface, complete the following steps in the order provided to remove the touchpanel. The only tool required is a #2 Phillips tip screwdriver. 1. Lift one edge of the bezel to free it from the touchpanel, and lift it off. Do not apply excessive pressure to the touchscreen. 2.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Hardware Connections for the TPS-6L CAUTION: Do not apply excessive pressure to the touchscreen display during handling. Doing so can crack the screen and damage the touchpanel. NOTE: The TPS-6L can only be powered via the 4-position terminal block connector labeled NET. Power cannot be supplied from network devices that are connected to the mini-terminal block connectors.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Programming Software Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at http://support.crestron.com. First-time users will need to establish a user account.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Configuration Manager Configuration Manager is the view where programmers “build” a Crestron control system by selecting hardware from the Device Library. • To incorporate the TPS-6L into the system, drag the TPS-6L from the Touchpanels | Touchpanels (Cresnet) folder (or the Touchpanels (Ethernet) folder) of the Device Library and drop it in the System Views.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L • Additional TPS-6L devices are assigned different Net ID (for Cresnet devices) or IP ID (for Ethernet devices) numbers as they are added. • If necessary, double click a device to open the “Device Settings” window and change the Net ID or IP ID, as shown in the following figures.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Programming with VisionTools Pro-e Touchpanel screens should be created in VisionTools Pro-e to allow switching of source signals to desired outputs as well as selection of the system mode. There are no special programming requirements to use the functions of the TPS-6L in a roomcontrol system.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L eye is more sensitive to the color green) 6-bits to represent 64 levels of green. These can therefore be combined to provide 65,536 mixed colors (32 x 32 x 64 = 65,536). In a 24-bit graphics display, the video memory allocates 24 bits for each pixel on the screen enabling each pixel to take on any one of a possible 16.7 million colors. Each 24-bit value is composed of 8-bits for red, 8-bits for green and 8-bits for blue.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L VT Pro-e “Page Properties” Window – Bit Depth Selection VT Pro-e “Image Properties” Window – Bit Depth Selection Pushbutton Programming The twelve pushbuttons that flank the display can be programmed to access any frequently used command. Each button has a permanently fixed digital join number. The sequence of digital join numbers is (top to bottom, left to right) 1 through 6 and 7 through 12. Refer to the following illustration.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L For example, Chinese fonts contain several thousand characters. Other multibyte languages include Japanese and Korean. There are two separate applications with multibyte characters – static text on buttons and indirect text on buttons. No Isys touchpanel firmware changes are required in either case. Indirect text on a button is entered in VisionTools Pro-e and the actual string to be displayed is entered in SIMPL Windows.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Uploading and Upgrading Crestron recommends using the latest programming software and that each device contains the latest firmware to take advantage of the most recently released features. However, before attempting to upload or upgrade it is necessary to establish communication. Once communication has been established, files (for example, programs, projects or firmware) can be transferred to the control system (and/or device).
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L • Use the Address Book in the Crestron Toolbox to create an entry for the TPS-6L with the TPS-6L’s TCP/IP communication parameters. • Display the “System Info” window (click the TPS-6L entry. icon) and select the Programs, Projects and Firmware Program, project or firmware files may be distributed from programmers to installers or from Crestron to dealers.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-6L Troubleshooting TROUBLE TPS-6L not functioning. POSSIBLE CAUSE(S) CORRECTIVE ACTION Net ID is not correct. Verify the Net ID In Crestron Toolbox. Net ID is not set to match the Net ID specified in SIMPL Windows.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Check Network Wiring Use the Right Wire In order to ensure optimum performance over the full range of your installation topology, Crestron Certified Wire and only Crestron Certified Wire may be used. Failure to do so may incur additional charges if support is required to identify performance deficiencies because of using improper wire. Calculate Power CAUTION: Use only Crestron power supplies for Crestron equipment.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Reference Documents The latest version of all documents mentioned within the guide can be obtained from the Crestron website (www.crestron.com/manuals). This link will provide a list of product manuals arranged in alphabetical order by model number.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Software License Agreement This License Agreement (“Agreement”) is a legal contract between you (either an individual or a single business entity) and Crestron Electronics, Inc. (“Crestron”) for software referenced in this guide, which includes computer software and as applicable, associated media, printed materials and “online” or electronic documentation (the “Software”).
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L If You are a business or organization, You agree that upon request from Crestron or its authorized agent, You will within thirty (30) days fully document and certify that use of any and all Software at the time of the request is in conformity with Your valid licenses from Crestron of its authorized agent.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L Return and Warranty Policies Merchandise Returns / Repair Service 1. No merchandise may be returned for credit, exchange or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact an authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory and request an RMA (Return Merchandise Authorization) number.
Isys® 5.7” Wall Mount Touchpanel Crestron TPS-6L This page is intentionally left blank. Operations & Installation Guide – DOC. 6630A Isys® 5.
