CR49 Traveler www.crosleyradio.
IMPORTANT SAFETY INSTRUCTION PLEASE READ CAREFULLY ALL THE FOLLOWING IMPORTANT SAFEGUARDS THAT ARE APPLICABLE TO YOUR EQUIPMENT 1. 2. 3. 4. 5. Read Instructions - All the safety and operating instructions should be read before the product is operated. Retain instructions - The safety and operating instructions should be retained for future reference. Heed Warnings - All warnings on the product and in the operating Instructions should be adhered to.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. CAUTION: Use of controls or adjustments or performance of procedures other than those specified may result in hazardous radiation exposure. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER - SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Welcome Thank you for purchasing the Crosley Traveler (CR49). Before operating this unit, please read this manual thoroughly and retain it for future reference. Table of Contents Getting Started Unpacking................................. 4 Power Source........................... 4 About This Manual Instructions in this manual describe the control functions of the CR49. Control Locators....................... 5 Base Operation Turntable Operation.................. 6 Accessory: Adapter for 45 rpm .........
Getting Started Unpacking 1 Remove packing materials from unit. Note: Save all packing materials. 2 Remove plastic bag covering radio. 3 Remove plastic safety cover from A/C plug. 4 Open lid and remove styrofoam shipping material from turntable. 5 Remove black tie-wrap from under the tone arm. 6 Remove white protective needle cover by gently pulling towards the front of the unit. Set Up 1 Plug A/C adapter into appropriate outlet.
Control Locators Unit Controls 1 LOCATION OF PARTS 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12.
Turntable Operation Accessory: ADAPTER FOR 45 RPM Turntable Operation Turn the unit on by rotating the ON/OFF-VOLUME ROTARY KNOB (9) located on the front panel to the ON position. 1 Set the SPEED CONTROL SWITCH (4) to desire speed (33 1/3,45 or 78 rpm). Place the record on the turntable. 2 Use the CUE LEVER (2) to raise the tone arm off its rest. Pull the TONE ARM (3) slightly to the right side until hear the “click” sound to activate the turnatable.
General Troubleshooting The unit does not operate. 1 The AC power cord is not connected to a power outlet. 2 The unit is not turned on : rotate the VOLUME knob from the OFF position TURNTABLE No sound is coming from unit. 1 The white protective needle cover was not removed. 2 The volume is not turned up. Tone arm will not move. 1 Black tie-wrap was not removed from underneath tone arm 2 Tone arm hold down clip was not released.
LIMITED MANUFACTURERS WARRANTY Crosley Radio, Inc. warrants the product to be free from defects in material and workmanship under normal use for a period of one year from the original date of purchase. This warranty is not transferable. If the product is determined to be defective during the warranty period, the unit will be repaired or replaced at Crosley Radio’s sole discretion.
