120 NetVision Plus/Elite and Micro DVR v2.3 SP2 User's Guide 21-0400E v2.3.3
27
Using the
ATM Interface Option
27.1
Introducing the ATM
Interface Option
An ATM interface option is available that
allows:
• Interfacing with automated teller machines
(ATMs) on a banking network;
• Recording the scene when each person
uses the ATM machine (with or without a
short video of just before each person used
the machine--i.e., pre-alarm recording);
• Showing the ATM transaction information as
a subtitle while each ATM camera is being
recorded;
• Tracking activity at an ATM vestibule;
• Playing captured videos associated with
each ATM transaction. (Remotely, you can
play the recordings, and/or download them
to you local hard drive);
• Taking snapshot image(s) from the ATM
videos and either saving them as a file, or
printing them as a single-page 'report'.
Note: For remote access, the ATM Interface option
can be used by remote users with access to the
"Playback" server.
Subtitles, and Alarm Overlays (v2.3 SP2): Regular
subtitles and alarm overlays should NOT be used
with the ATM interface option as they may interfere
with ATM overlays.
27.2
Topics Covered Elsewhere:
• "ComTools" Software Installation and Set Up;
• ATM Interface Option Installation and Set Up:
These topics are documented separately
(provided with the ATM Interface Option)
27.3
Viewing ATM Cameras
ATM cameras are viewed in the same manner
as other cameras. For details, refer to the
related topics.
Related Topics:
8.1 Viewing Cameras from a Remote Station
8.2 Viewing Cameras at a Video Server
22 Using the Small Remote Module
27.4
Recording ATM Camera
Images
ATM cameras are typically set to record in
response to each ATM transaction. This is
described in the documentation provided with
the ATM option (ATM Interface Option
Installation and Set Up).
All other recording methods and scheduling
can also be used if desired (i.e., the same as
for all other cameras).
Attention: ATM transactions are treated as alarms.
As such, alarm monitoring schedules associated with
ATM cameras will affect transaction-triggered
recordings. Be sure this is what you want before setting
up this type of scheduling.
Related Topics:
6.4 Alarm / Recording Status Indications at a Video
Server (Camera Number Colours)
9 Recording Camera-Views
18 Scheduled and/or Alarm-Triggered Recording
