28.2
Step 1: Open the Video Player
At a remote station, click the blue 'Play'
button in the bottom-left corner. At a Video
Server, click [Playback] in the panel near the
bottom-right.
Remote Module Software: Click the dark green
'Play' button.
Tip: To close the playback window when finished,
click the [X] in the top right corner.
Then, select [Playback] when prompted (as
opposed to [ATM Playback] ).
Related Topic: 27.5 Playing ATM Video Recordings
New Style Player: Click the 'search'
button (folder/binoculars) at the
bottom of the playback screen.
Older 'Quad' Player: Click the
'quad mode' button (4 squares) at the
bottom of the playback screen.
Then, click the 'search' button
(folder/binoculars) at the bottom of
the 'quad' playback screen.
Instructions Bubble: If an instructions
bubble is present, you'll need to click once
to close the bubble, and then again to open
the file-search screen.
28.3
Step 2: Local / Remote, and
Connection Screen
A remote connection screen will appear
automatically if your last session was not local.
Tip: Close the screen and select 'local' if desired.
------------------------------
Local: Select this for video files on your
present PC;
Remote: Select this to access video files on
some other PC (Video Server).
New Style Player: Click [Select].
ServerName/IP Address: Enter (or select)
the IP address or PC name of the server PC
(computer that contains the video files).
User Name: Enter your (valid) remote
username as set up at this specific server PC.
Password: Enter your (valid) remote user
password as set up at this specific server PC.
Connection Bandwidth: Indicate your
connection speed (Low for dial-up; Medium for
cable/DSL; High for a network connection).
Tip: This sets the streaming playback image quality
and frame rate as suitable for your type of connection.
Notice
: Due to speed and reliability considerations,
dial-up connections are NOT recommended.
Use a faster connection if you have a choice.
Streaming Mode (new-style player only):
• Time Based
: File playback duration
maintained (regardless of your connection
speed). Individual frames may be dropped.
• Frame Based
: Every frame will be shown no
matter how long it takes.
------------------------------
When ready, click [OK].
