demo), and click [Connect]. (pressing the
Enter key will not work here).
Then, select your desired cameras, and other
items on-screen.
Tip: As of this writing (2005.09), cameras 1, 3, 5, and 7
are available under netvisiondemo.
28.4.1
Items Under the Camera
Image(s)
- Camera: Select the camera number here.
- Rec: Click this to start (or stop) recording video
from the associated camera.
Tip: Video recordings will be saved under: d:\DSR-
Video\Remote\Server(orIP)\Camera#\Date\xxxxxxx.AV
I
- PTZ: Select this to activate the PTZ controls for
‘aiming’ and/or ‘zooming’ a PTZ camera (if you
have permission to do this).
Tip: To 'aim' the camera, 'hover' your mouse around
the camera-view, and watch for the cursor to change
to an arrow or magnifying glass. Then, click-and-hold
the image with the cursor showing the desired action.
To zoom in, click the centre (magnifying glass). To
zoom out, right
-click the centre (magnifying glass).
28.4.2
Items on the Right-Hand Side of
the Screen
- Camera-View Symbols (if present): These
allow switching between 1 and 4 camera-views.
- Server: Enter the name or IP address of the
NetVision Video Server here.
Tip: Remember to include the “:Port#” after the
server name or IP address if the port is not 80.
- User Name: Enter the name of a valid user with
permission to access the WebCam server at the
specific NetVision Video Server PC (e.g., demo).
- Password: Enter the password associated with
the user name that you entered--if required (e.g.,
demo).
- [Connect]: Click this button to connect with the
server and view the selected cameras.
Note: Pressing the Enter key will not work here.
- Bandwidth (Low / Medium / High): This
adjusts the frame rate and other video quality
parameters as suitable for your connection
speed. Select the value that most accurately
represents your connection speed/bandwidth.
- NTSC or PAL: Select the type of cameras
here (or try both settings to see which one
provides better results.
- Resolution: This allows selecting larger or
smaller camera-image size.
