Welcome
Common
Admin Config Install Tech-Ref
11
5.2.3
Logging in At a Video Server
Video Servers support two types of local users:
Supervisors, and Operators.
At a Video Server, click [Logon] on the main
screen. Then, enter a username and
password that has been registered.
Tip: Press Tab in between, and Enter (or OK)
when finished. Note: After restarting the software,
[Logon] may not be available for a minute or so.
Default Video Server User Names and
Passwords
User name Password Permissions
Super -- Access to everything.
Operator -- Everything except
configuration tasks.
Note: These passwords do NOT pertain to remote
stations.
Related Topics: 11.1 Video Server Users and
Passwords
5.2.4
If you Need to Minimize the
Video Server Desktop
While logged in, you can minimize the Video
Server software by right
-clicking any fixed
portion of the desktop (i.e., outside of any
buttons or display areas), and selecting
"Minimize".
If this feature is not available: This feature can be
turned on and off.
See: 14.2 Miscellaneous Settings
5.2.5
PTZ Control after Start-Up
The PTZ server has a delayed start-up to allow
Windows services to stabilize. (The PTZ
feature will not be available until 1 minute
(approx.)
after the Video Server is re-started.)
Related Topics:
8.3 Changing a Camera's View (Pan/Tilt/Zoom)
16.3 Pan/Tilt/Zoom Activation and Set Up
5.3
Remote Station: Logging
Out, Changing Operators, or
Shutting Down
At a surveillance station, there is no need to
leave the software running with no one logged
in, so you'll be logged out automatically when
you shut down the software.
To shut down the software, click, the [X] in the
upper right corner of the screen.
If a new operator wishes to log in, they can
start the software and login as usual.
5.4
Video Server: Logging Out,
Changing Operators, or
Shutting Down
To logout at a Video Server, click [Logoff]. If
a new operator wishes to log in, they can click
[Logon] and enter their username and
password as usual.
To exit (shut down) a Video Server, click
[Exit]. Note: as this will stop all camera
monitoring and recording for this Video Server,
you will be prompted to confirm your intentions.
Note: The [Exit] button is available only when
you are logged in, and depending on the start-
up options, may be available only for
"Supervisors".
