Welcome
Common
Admin Config Install Tech-Ref
31
Server Name / IP Address: Enter (or select)
the IP address or PC name of the NetVision
server PC (computer that contains the video
files).
User Name: Enter your (valid) remote
username as set up at this specific NetVision
server PC.
Password: Enter your (valid) remote user
password as set up at this specific server PC.
Connection Bandwidth: Indicate your
connection speed (Low for dial-up; Medium for
cable/DSL; High for a network (LAN)
connection).
Tip: This sets the streaming playback image quality
and frame rate as suitable for your type of connection.
Notice
: Due to speed and reliability considerations,
dial-up connections are NOT recommended.
Use a faster connection if you have a choice.
------------------------------
When ready, click [OK].
7.9.4
The (Quad) Search Screen
Locator: [Playback], Ö[Quad Playback].
Remote Software: Click the coloured 'Play' button,
and then select [Quad Playback].
Then, click the 'search' button
(folder/binoculars) at the bottom of the quad
playback screen
Top of the Screen
- Local and Remote: Local pertains to files on
your PC (or mapped to as a drive letter).
Remote pertains to files on another PC, as
accessed through an IP connection (you will be
prompted to enter server / connection criteria).
- [Stop Search] and [Apply]: The search runs
automatically when you select a camera.
[Stop Search] stops the present search, and
[Apply] restarts it.
Note: Clicking [Apply] when a search is running
will return you to the (quad) playback screen.
- [X] and [Cancel] (top-right corner): Clicking
either of these buttons will close this
screen.
- Server: Select your desired server. (The
search will 'look' in the folder for files from that
server.) The screen will remain blank until you
select a camera.
