Select All / Delete Original...
(Bottom-Left Corner)
• Select All Files
: Selects (or deselects) all
files in the list;
• Delete original file(s) after backup
: If
selected (9), the files are effectively moved
to the new location. If not selected, the files
are copied to the new location.
To view a file first (i.e., before backup or
deletion), select the file (click the camera
name), and click [PlayBack] (in the row of
buttons at the bottom).
Before backing up file(s), select the desired
target drive letter near the top-right corner of
the screen.
Mapped (Video Server PC Only): This includes
'mapped' drives from other PCs in the list.
Note: Moved files will be placed under d:\dsr-
video\Image\Server(orIP)\Camera\Date
To backup or delete your selected file(s), click
[Start] at the bottom of the screen. When
prompted to confirm, respond as desired (OK
or Cancel).
Minimize: You can use the [Minimize] button to
hide the housekeeping window for lengthy file
management operations (such as when moving a
large number of files through a slow network
connection). To restore the housekeeping screen,
click [House keeping] on the windows taskbar, and
then click the yellow broom symbol in the top-left
corner of the screen.
--------------------------------------------------
When finished, click [Cancel] to close the
'housekeeping' screen.
10.7
Automatic Video File
Management (Self
Housekeeping)
You can set the NetVision Video Server and
remote stations to perform file management
tasks automatically on a recurring schedule.
Each scheduled task is saved as a ‘Plan’,
allowing different file management tasks to be
performed for different servers on different
days or times, etc.
Also See: 10.3 Introduction to Video File
Management (Filekeeping and Housekeeping)
10.5 Filekeeping (v2.3 SP2); 10.6 Housekeeping
Locator: At the Video Server PC (will
prompt for "Supervisor" login),
Select: (Windows task bar) Start, Settings,
Control Panel, DSR Configuration.
Desktop Link: There should also be a link to this on
your desktop called "NetVision Configuration".
Tips: If you cannot access the Windows task bar,
press Ctrl-Esc (or your 'Windows' key). To view the
names for items on the task bar, click a blank area on
the bar, and then 'hover' your mouse pointer over each
item.
Logon as a "Supervisor" when prompted.
Then, double-click Self-Housekeeping Setup
in the list. When the screen appears, make
your desired selection(s).
Remote Station: (Logged in at a remote
station), Select: The "Utility" button
(tools symbol), Ö Self-Housekeeping
Setup, Ö[Start Setup].
