Top of the Screen
This area shows a list of defined ‘plans’
(scheduled housekeeping tasks), and allows
you to [Add] new ones, [Remove] existing
ones, [Save] your changes, etc.
[Buttons] on the right: To set up a new
‘plan’, click [Add], type a suitable name, and
click [OK]. To view settings for an existing
one, select the ‘plan’ name in the list, and then
observe setting on the rest of the screen.
[Edit] allows changing settings for a selected
‘plan’, while [Remove] will delete a selected
one from the list.
Attention: Always use the [Save] button to retain your
added ‘plans’ and related settings, since clicking [OK]
only closes the screen without saving anything.
Details
Action: The file management task to occur on
the scheduled days/times.
Suspend: This blocks this ‘plan’ from executing
without having to delete it. For temporary use.
Retain: Retains only the specified number of days of
files in the "DSR-video" folder, and deletes all older
files.
Attention
: This selection should be used only in
conjunction with manual file-management (NOT
Self-Housekeeping). You must be sure to copy or
move any alarm/video files that you wish to keep.
Details: 10.3 Introduction to Video File
Management (Filekeeping and Housekeeping)
10.5 Filekeeping (v2.3 SP2); 10.6 Housekeeping
Backup: Copies older video files to the specified target
location, while leaving them in the original "DSR-video"
folder.
Move: Moves older video files to the specified target
location, while deleting them from the original "DSR-
video" folder.
Synchronize Backup: Copies older video files that do
not already exist in the specified target location
(compared by date), while leaving them in the original
"DSR-video" folder.
Synchronize Move: Moves older video files that do
not already exist in the specified target location
(compared by date), while deleting them from the
original "DSR-video" folder.
( ) days of files: This determines the 'age' of
files that will not be affected by the scheduled
housekeeping task/plan. (All older files in the
..\dsr-video\image folder will be copied
and/or deleted at the scheduled time.)
Action Start: Use the up/down arrows to
select how often the scheduled task is to occur
(every day, once per week on a specific
weekday, or once per month). Then, click
within the minutes, hours, or seconds, and use
the up/down arrows to set the time of day for
the process to start.
Note: Plans with the same start time will be executed in
alphabetical order.
Tip
: For dedicated access to the hard drive, select a
time of day when recordings are unlikely to occur.
Files From
Application: Use the up/down arrows to
select a source application here. (“DSR” for
files on your local NetVision video server PC,
“Remote” for files obtained from a remote
server, or “ATM” for files associated with the
optional ATM interface.)
Server Name: Use the up/down arrows to
select the originating server associated with
the files to be deleted or moved, etc.
