56 NetVision Plus/Elite and Micro DVR v2.3 SP2 User's Guide 21-0400E v2.3.3
Drive
(List of drive letters): Select all drives to be
affected by the specific housekeeping
task/plan.
File Type
(List of types of recording files): Select all
types of recording files to be affected by the
specific housekeeping task/plan.
(Bottom of the screen)
Files To: Enter a target backup folder here, or
click […] to browse to (and select) a desired
folder.
Generate Log Files: This causes the self-
housekeeping feature to record the scheduled
file management ‘plans’ that were executed on
each specific day.
Location and Filename: Self-Housekeeping logs can
be found under: d:\dsr-video\Log\HK\yyyymmdd.txt
--------------------------------------------------
When finished, click [OK], and then click
[X] to close the list (upper-right corner).
Attention: All new or changed self-housekeeping tasks
(plans) take effect beginning the next day after
the self-
housekeeping settings are saved and the NetVision
software is re-started.
10.7.1
Viewing the Self-Housekeeping
Logs
The execution of self-housekeeping tasks
(plans) can be set to be recorded in a log file.
This record is stored in a text file (one file per
day).
To view these files in your default text editor
(e.g., notepad), locate and open (double-click)
the indicated file.
File Locator:
d:\DSR-Video\Log\HK\yyyymmdd.txt
("d" represents the drive letter of the recording hard
drive.)
