70 NetVision Plus/Elite and Micro DVR v2.3 SP2 User's Guide 21-0400E v2.3.3
External Inputs/Sensors: For details on setting up
external sensors, refer to:
18.3 External Sensors and Recording Duration.
15.1
Enable/Disable
Alarm Alerts or E-Mail
The alarm alert feature lets a remote
surveillance station know any time an alarm
occurs (external sensor tripped, video motion
sense, and/or video signal lost).
A recording of the scene will also be available
at the Video Server PC.
This feature operates through an IP
connection, and can also alert persons via
email (with or without a 'snapshot' of the first
frame of the alarm-triggered recording).
TechTip: This feature must also be set up through
the Alarm Alert Caller module on the taskbar, and
the Video Server must be able to communicate with
the remote station (via IP). As well, the Alarm Alert
feature can be customized as desired at the remote
stations (see "Related Topics").
Note: This feature works only in conjunction with
alarm-based recording (motion-detection and/or via
an external input for each camera).
Related Topic:
18 Scheduled and/or Alarm-Triggered Recording
Locator: At the Video Server PC (will
prompt for "Supervisor" login),
Select: (Windows task bar) Start, Settings,
Control Panel, DSR Configuration.
Desktop Link: There should also be a link to this on
your desktop called "NetVision Configuration".
Tips: If you cannot access the Windows task bar,
press Ctrl-Esc (or your 'Windows' key). To view the
names for items on the task bar, click a blank area on
the bar, and then 'hover' your mouse pointer over each
item.
Logon as a "Supervisor" when prompted.
Then, double-click Optional Features Setup
in the list. When the screen appears, select
Alarm Alert , and then make your desired
selection(s).
Alarm Alert
Enable Alarm Alert: Select this to activate
the alarm alert (and/or Alarm Email) feature.
Enable Alarm Email: This turns the alarm-
email feature on (or off).
Sender Information
Name: This shows the name (or IP address)
of the Netvision Video Server PC;
From: This is the outgoing email address;
Server Information
SMTP Server: This is the name of your
outgoing SMTP email server. (Get this from
your network administrator or email service
provider.)
My server requires authentication: Select
this, and enter an account name (outgoing
email address) and password if required for
your outgoing email;
15
Alarm / Reporting Settings
