74 NetVision Plus/Elite and Micro DVR v2.3 SP2 User's Guide 21-0400E v2.3.3
15.3
Auto Alarm Display
(v2.3 SP2)
This feature causes cameras to be displayed
automatically on the Video Server desktop
whenever an external alarm is triggered, or
motion is detected at selected cameras.
Note: This feature works only in conjunction with
alarm-based recording (motion-detection and/or via
an external input for each camera).
Related Topic:
18 Scheduled and/or Alarm-Triggered Recording
Locator: At the Video Server PC (will
prompt for "Supervisor" login),
Select: Windows Control Panel,
ÖDSR Configuration, ÖAuto Alarm
Display.
- Enable Auto Alarm Display: This turns this
feature on [9] and off [ ].
Display for Alarm Type
- External Alarm: Select this if you want an
external alarm at the selected cameras to trigger
this feature.
Also See: 25.3 Wiring Reference
- Motion: Select this if you want motion-detection
at the selected cameras to trigger this feature.
Also See:
11.3 Viewing a List of Motion-Detection Alarms
18.5 Setting up Video Motion-Detection
Display for Camera
- (check-box for each camera): Select each of
the cameras that you want to be monitored for
this feature.
- Suspend Sequencing When Alarm: This
stops on-screen sequencing while alarm-
triggered cameras are being displayed to ensure
they remain on-screen until the alarm recording
ends.
Tip: If multiple cameras are triggered, they will
appear on-screen in the order they were triggered.
------------------------
- [OK]: Click this to save your settings.
- [Cancel]: Click this to abort your entries,
leaving this screen in its previous state.
Attention: To recognize any changes made in DSR
Configuration while the NetVision Video Server
software is running, you may need to restart the
software.
