5. Specifications
Relay Circuits 8, DPDT (Dual Form C), Sealed
Relay Type MIL-R-39016/6
Contact Type Gold Plated over Hardened Silver;
Stationary contacts are bifurcated
Contact rating and life
expectancy
0.5 A @ 28VDC Resistive 500,000 Operations
1.0 A @ 28VDC Resistive 250,000 Operations
2.0 A @ 28VDC Resistive 100,000 Operations
3.0 A @ 28VDC Resistive 50,000 Operations
.16 A @ 28VDC Lamp 10,000 Operations
30 uA @ 50 mVDC Low Level 1,000,000 Operations
Relays which are used for intermediate and high-level (above .5A
and/or 28 volts), inductive, or lamp service will not be suitable for
low-level operation.
Supply Voltage 12 VDC Nominal (10-15 VDC)
Input (Control) Signals: Active low
88 mA max. @12VDC
110 mA max. @15VDC
Supply Current
(all 8 relays activated)
704 mA max. @12VDC
880 mA max. @15VDC
Operate & Release Time 4.0 ms max.
with 12 VDC supply and contact load of 10 mA @ 6VDC
Board Size H x W x D 7.5” x 3.75” x 2.5” (mounted with connectors seated)
Relay Control (Input)
Connector
50-pin Female Micro-ribbon AMP connector
(TELCO 25-pair style)
Relay Output (Contact)
Connector)
50-pin Female Micro-ribbon AMP connector
(TELCO 25-pair style) with Velcro cable clamp
Optional telephone line
terminations:
620 Ohm 1/4 W 5%
Power Connector: 4-pin screw terminal strip, accepts #24 to #14 AWG wire.
Fuse AGC 1A
PCB Flammability Rating: 94V-0
Temperature Rating -25 to +65 Degrees C
