TIB Hardware Reference Connectors
CTI Products, Inc.
68-10911-100
11
TIB J1 Function Direction
26 unused No Connect
1 Ground
27 unused No Connect
2 unused No Connect
28 Tx Select 8 Out Input/Output
3 Tx Select 7 Out Input/Output
29 Tx Select 8 In Input
4 Tx Select 7 In Input
30 unused No Connect
5 unused No Connect
31 unused No Connect
6 unused No Connect
32 unused No Connect
7 unused No Connect
33 unused No Connect
8 unused No Connect
34 Tx Select 6 Out Input/Output
9 Tx Select 5 Out Input/Output
35 Tx Select 6 In Input
10 Tx Select 5 In Input
36 unused No Connect
11 unused No Connect
37 unused No Connect
12 unused No Connect
38 unused No Connect
13 unused No Connect
39 unused No Connect
14 unused No Connect
40 Tx Select 4 Out Input/Output
15 Tx Select 3 Out Input/Output
41 Tx Select 4 In Input
16 Tx Select 3 In Input
42 unused No Connect
17 unused No Connect
43 unused No Connect
18 unused No Connect
44 unused No Connect
19 Force Select Output
45 unused No Connect
20 unused No Connect
46 Tx Select 2 Out Input/Output
21 Tx Select 1 Out Input/Output
47 Tx Select 2 In Input
22 Tx Select 1 In Input
48 unused No Connect
23 unused No Connect
49 unused No Connect
24 unused No Connect
50 unused No Connect
25 unused No Connect
Table 6 - TIB Connector J1 Pinout
