User`s manual

50
Smart innovation!
Specification
Display
LCD Type CCFL/LED
Windows Ratio 16:9
Resolution Full HD (1920*1080)
Frequency 60 / 120 Hz
Glass Glass Material AG (Anti Glare)
Touch
Touch Technology Optical
Touch Accuracy ±3 mm (for 70” screen)
Resolution 32767 X 32767
Response Time Less than 8 ms
Response Rate More than 125 responses per second
Operating Temperature 0 °C to 70 °C
IR Wavelength 850 nm
Current Consumption (w/o IR Bar) Typically 233 mA at 5V
IR Bar 200 mA per meter at 5 V at highest intensity
Touch Method Pointer including fingers
PC Interface USB 1.1 compatible (full speed)
using VID 0x2200 and PID 0x3100.
HID compliant, Plug & Play compatible, USB2.0
Operating Systems Windows XP, Windows Vista, Windows 7, Linux,
Mac OSX
Software No driver required for USB. Software provided for factory
setup and for user.
Touch Type Multi Touch
Gesture VOD consult
I/O Port
HDMI 2 Ports
D-SUB O
Component, Composite O
Speaker 2 x 10 W
USB JPEG, MP3
SPDIF O
Sensor USB O
RS232C (D-sub 9 pin) O
Audio Line Out O
Electrical Power Requirement 110 ~ 220 Vac, 50/60 Hz
Specifications may change without notice to improve performance.
