PV720A User’s Manual U s e r ’ s M a n u a l PV720A 1
PV720A User’s Manual Table of Contents 1. Important Safety Instructions 3 2. Introduction 8 3. Recommended Use of the Monitor 14 4. Controls and Adjustments 16 5. Energy Declaration 24 6. Trouble Shooting 25 7. Technical Information 27 8. Product Overview 29 9.
PV720A User’s Manual Important Safety Instructions FCC Statement This equipment has been tested to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
PV720A User’s Manual TCO'99 TCO99 compliant monitors must be compliant with TCO99 which is more stringent than MPRII. The purchase of TCO99 compliant monitors contributes to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method-for encouraging the adaptation of goods and services to the environment.
PV720A User’s Manual The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for the user. Labelled products must meet strict environmental demands, for example, in respect of the reduction of electric and magnetic fields, physical and visual ergonomics and good usability.
PV720A User’s Manual Cadmium** Cadmium is present in rechargeable batteries and in the colour-generating layers of certain computer displays. Cadmium damages the nervous system and is toxic in high doses. The relevant TCO'99 requirement states that batteries, the colour-generating layers of display screens and the electrical or electronics components must not contain any cadmium. Mercury** Mercury is sometimes found in batteries, relays and switches. It damages the nervous system and is toxic in high doses.
PV720A User’s Manual 2. Do not place your LCD Monitor near a window. Exposing the Monitor to rain, water, moisture or sunlight can severely damage it. 3. Do not place anything on top of the Monitor/PC signal cord. Make sure the cord is placed in an area where it will not be stepped on. 4. Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the display. 5. Do not remove the cover or attempt to service this unit by yourself. You may void the warranty.
PV720A User’s Manual Introduction Product Description Congratulations on purchasing this new generation monitor. Your LCD monitor incorporates high quality display into a small lightweight module. It has power- saving capabilities and emits no X-ray radiation. The features are: • 17" TFT Liquid Crystal Display • Compatible with IBM VGA, VESA • Direct RGB input • SXGA 1280x1024 resolution • Lightweight compact design, weighing less than 7.
PV720A User’s Manual User's Guide / Driver CD Power Cord Power Adapter D-Sub 15 VGA Signal Cable 3.5 mm Audio Cable Speaker Box CAUTION Keep the shipping carton in case the need arises to store or transport the unit. Let the LCD lie on its face when you put it into the carton.
PV720A User’s Manual Installation & Remove 1-1. Installing the Portrait 1-2.
PV720A User’s Manual 2-1. Rotating to the mode "Portrait" (vertical orientation) 3-1. Installing VESA-compliant Connecting Device* This product provides square screw holes that conform to 100mm*100mm VESA-compliant connection interface.
PV720A User’s Manual 3-2. Remove VESA-compliant Connecting Device* *User should prepare the connection device for VESA themselves. 4-1. Speaker Box Install Cabling for Your Display 1. Turn off the power of your computer and other devices. 2. Connect (1) the video signal cable of the monitor to the 15-pin connector of the video port in your computer. 3. With the monitor switched off, attach (2) the power cord to the monitor and then to a grounded power outlet.
PV720A User’s Manual 4. Connect your audio cable one end to the external speaker, through the connector of audio input on the rear part; the other end to audio device (such like connector of the sound card in the PC). 5. Connect to the earphone plug-in if you need this device. 6. Turn on the monitor and computer. 7. If necessary, adjust the front panel controls according to your personal preference.
PV720A User’s Manual Recommended Use of the Monitor Power Use the type of power indicated on the marking label. Plugs Do not remove any of the prongs of the monitor's three-pronged power plug. Disconnect the power plug from the AC outlet if you are not going to use it for an indefinite period of time. Power cords Use the proper power cord with correct attachment plug type. If the power source is 120 V AC, use a power cord that has UL and CSA approvals.
PV720A User’s Manual Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord. Environment Place the monitor on a flat level surface. Place the monitor in a well-ventilated place. Keep the monitor away from: rain or water overly hot, cold or humid places sunlight dusty surroundings equipment that generates strong magnetic fields.
PV720A User’s Manual Controls and Adjustments Once you have installed this monitor with your system, please read the instructions in this section, they give you some guidelines on how to use the monitor more efficiently. And lead you through the various functions of the user controls and explain how to adjust the monitor to your personal preference.
PV720A User’s Manual (1) Enter " " button To display the OSD manual and select functions. (2) Down " " button To adjust the selected OSD function or the brightness directly. (3) Up " " button To adjust the selected OSD function or the contrast directly. (4) "ESC" button To close the OSD manual and to escape function. (5) Power LED Indicator As long as the monitor is powered, this indicator is lit. In normal operation, it lights green. While in power saving mode, the indicator will turn to amber.
PV720A User’s Manual On Screen Display (OSD) Main menu 1. Press " " to open the OSD main menu. 2. Use the " " and " " arrows to move through the displayed functions. 3. Press " " to confirm your selected function. Brightness Press the " " button to enter the brightness, and press the " " or " " button to increase or decrease the brightness level, then press " ESC" button to exit.
PV720A User’s Manual 1. Volume Tuning Normal Mode Press " " to enter "Volume", and press " " or " " to adjust the volume. Power Saving Mode (when power indication lights amber) a. Mute Hot Key (when playing music) Press "ESC" to enter Mute Mode, and press "ESC" again will return to sound playing mode. b. Control the volume In Power Saving Mode, press " " or " " to enter the volume tuning window, and press " " or " " key to adjust the volume.
PV720A User’s Manual 2. Auto Tune Press " " button, the system will automatically adjust the clock, phase, H-position and V-position values for optimal settings. ADVANCE AUTO TUNE PATTERN PROGRAM USING GUIDE • As some VGA Card doesn't match the VESA standard. It can't out-put 0.7 V p-p VESA standard. Therefore, we need "ADVANCE AUTO TUNE PATTERN PROGRAM" to modify the parameters of monitor to match different output level of VGA card. • Win_pat.
PV720A User’s Manual 3. Color You can choose either the 6500°K, 9300°K colour temperature mode or User mode to store your user defined color settings. User Mode • Press " • Press the " " or " " button to select the R/G/B gain, then press " • Finally, press "ESC" button to leave this function. " button to enter User mode. " button to roceed. 4. Quality Here are some items can be adjusted as below, please press " " enter the item menu.
PV720A User’s Manual 5. Position To adjust the Image or OSD position. Image Position or OSD Position H - Position: Press the " " or " " button to reposition of the picture or the OSD window to the right or left. V - Position: Press the" " button to moves the picture or the OSD window upwards and " " to move them downwards. Center: The Image or OSD window will be adjusted automatically on center of the screen. 6.
PV720A User’s Manual 7. Recall Press the " " or " " button to select "Yes" or "No". Choosing Recall to callback all the settings for the current Input Signal mode to factory preset.
PV720A User’s Manual Energy Declaration This monitor is equipped with a function for saving energy, which supports the VESA Display Power Management Signaling (DPMS) standard. This means that the monitor must be connected to a computer, which also supports the VESA DPMS standard to fulfill the requirements of the NUTEK specification 803299/94/96. The time settings for switching to a power saving mode are adjusted from the system unit by software.
PV720A User’s Manual Trouble Shooting If you are experiencing trouble with the LCD display refer to the following. If the problem persists please contact your local dealer or our service center. The monitor does not Check if the monitor is turned on. respond after you turn on the system. Turn off the power and check the monitor power cord and signal cable are properly connected. The characters on the Refer to the Controls and Adjustments screen are dim.
PV720A User’s Manual Image has vertical line Use "Clock" to make an adjustment. bars Check and reconfigure the display mode of the vertical refresh rate of your graphic card to make it compatible with the LCD display. Image has horizontal flickering lines Signal out of Range Use "Phase" to make an adjustment. When the input signal is outside the normal specifications the screen will display an "Signal out of Range" message.
PV720A User’s Manual Technical Information Compatibility This LCD monitor supports multiple operating platforms such as IBM compatible computers. This section provides you with detailed information on pin assignment of the D-Sub connector and the preset timing chart of the prevailing video standards.
PV720A User’s Manual Video Modes Resolution VCLK(MHz) Horizontal Refresh Frequency Rate (KHz) (Hz) Standard 640*350 25.175 31.470 70.000 IBM VGA 720*400 28.322 31.469 70.000 IBM VGA 640*480 25.175 31.470 59.940 IBM VGA 640*480 30.240 37.861 72.000 VESA 640*480 31.500 37.500 75.000 VESA 800*600 40.000 37.879 60.000 VESA 800*600 50.000 48.077 72.000 VESA 800*600 49.500 46.880 75.000 VESA 1024*768 65.000 48.363 60.000 VESA 1024*768 75.000 56.476 70.
PV720A User’s Manual Product Overview Pivot Function You can turn the LCD panel right 90 degree for particular viewing.
PV720A User’s Manual Side View (unit: mm) For viewing clarity, you can tilt the LCD panel forward (up to 5 degrees) or backward (up to 20 degrees) Rear View (unit: mm) 30
PV720A User’s Manual Specifications LCD Panel 17" TFT LCD module with wide-viewing angle, 0.264(H)x0.264 (V)mm pixel [ Monitor ] Effective display size 17" (43.2 cm diagonal) Resolution (max.) SXGA 1280x1024 Displayable colours 16.7M True color Brightness 250 Cd/m2 (typical) Contrast ratio 350:1 (typical) Scan Frequency Horizontal: 30 to 82 kHz automatically Vertical: 50 to 75 Hz automatically Response time 45 ms Audio Input 1V(RMS), Max.
PV720A User’s Manual [ Dimension & Weight ] Size (WxDxH) 438 x 166 x 447 mm Weight (net) 7.
