Installation Guide

INSTALLATION WALKTHROUGH:
For more information log onto www.curtmfg.com, & for helpful towing tips log onto www.hitchinfo.com
5. Support the exhaust and lower by removing the (2) rubber
isolators by each muffler, 1 hanger on the in front of the
passenger side muffler and (1-2) center isolators. Allow
exhaust to be lowered 6-10".
6. Remove the (2) tie down / exhaust hanger brackets from the
frame using a 14mm socket. Return brackets to vehicle owner
but keep hardware and rubber isolators for step 9.
7. Remove heat shield(s) using a 10mm socket for access to
frame rails.
8. Locate the large hole in the frame rail on each side. Using a die
grinder enlarge to allow the carriage bolt and spacer to pass
through.
9. Reverse fishwire the bolt and spacer into the enlarged hole on
each side using the fishwires provided.
