Installation Guide

INSTALLATION WALKTHROUGH:
For more information log onto www.curtmfg.com, & for helpful towing tips log onto www.hitchinfo.com
14. Re-install the underbody cover.
11. Torque all 10mm fasteners to 56 lb-ft and all 7/16" fasteners to
70 lb-ft.
12. Raise exhaust back into location and re-install rubber isolators.
13. ON SINGLE EXHAUST MODEL ONLY: Trim the underbody
panel as shown in the diagrams below for the hitch to pass
through.
10. Raise hitch into position. Using the fasteners from the
brackets, attach hitch to the vertical flange and the frame rail
with fasteners removed in step 6.
NOTE: To reinstall heat shield, trim to allow bolts to pass through
and clamp between hitch and frame.
