Installation Guide

INSTALLATION WALKTHROUGH:
For more information log onto www.curtmfg.com, & for helpful towing tips log onto www.hitchinfo.com
7) Temperarily remove rear fascia by releasing
press in tabs all along top portion of facia.
NOTE: For other models unclip (4) rear
sensor plugs prior to removing rear fascia.
8) Remove (8) M10 nuts on inner panel to
remove the bumper, (4) per side. Remove
bumper. Set aside bumper and hardware
for reassembly.
9) Align hitch on bumper through the weld
on bolts.
10) Place bumper/hitch on rear of vehicle
through original bumper mounting holes.
Loosely fasten with the M10 nuts to
check fit.
