Installation Guide

INSTALLATION INSTRUCTIONS

CUSTOM WIRING

CONNECTOR

WIRING LOCATION GUIDEAPPLICATIONS

NOTICE

WARNING

TOOLS NEEDED

Check vehicle owner's manual or contact

the vehicle manufacturer for more information.

None

Exceeding the product rating can cause loss of warranty,

overheating and potential fire. Do not exceed product rating

or tow vehicle lamp load rating, whichever is lower.

Make Model

Ford F-150 Light Duty with factory 4-ﬂat

Ford F-250 Light Duty with factory 4-ﬂat

Ford F-150 Heritage with factory 4-ﬂat

WARNING: DO NOT EXCEED PRODUCT RATING OR TOW VEHICLE LAMP LOAD RATING, WHICHEVER IS LOWER

PICKUP TRUCKS

(

)

Representative vehicle shown below

T1 - Behind driver side taillight housing

T2 - Behind passenger side taillight housing

T3 - Behind driver side rear bumper

T2T1

All steps must be followed to ensure the wiring connector will

function properly. Once installed, test for proper function by

using a test light or connecting a properly wired trailer.

PAGE 1 • 55242-INS-RA

PAGE 1
INSTALLATION INSTRUCTIONS WARNING: DO NOT EXCEED PRODUCT RATING OR TOW VEHICLE LAMP LOAD RATING, WHICHEVER IS LOWER APPLICATIONS WIRING LOCATION GUIDE PICKUP TRUCKS (T) Make Model Ford F-150 Light Duty with factory 4-flat Representative vehicle shown below Ford F-250 Light Duty with factory 4-flat T1 - Behind driver side taillight housing Ford F-150 Heritage with factory 4-flat T2 - Behind passenger side taillight housing T3 - Behind driver side rear bumper CUSTOM WIRING CONNECTOR T1 T2 T3
PAGE 2
INSTALLATION / SAFETY INSTRUCTIONS Step 1 Locate the vehicle wiring harness connectors under the rear of the vehicle, inside the driver side frame rail. The connector ends will be similar to those on the custom wiring connector. Separate the connectors taking care not to damage the locking tabs. Step 2 Insert the custom wiring connector between the separated connectors.
