MPK8065BUK
Portable Media Player Your Pocket Guide Install Software Get Connected Transfer Media Plug Your Ears & Enjoy
What’s in the blister? Know Your Player Well System Requirement Software Installation Connect & Charge Transfer Software Operation Language Selection Music Playback Edit Lyrics Repeat Mode EQ Mode Video Playback Photo Browse E-Book Records Game Technical Data Trouble Shooting 2 3 4 5 6 7-8 9 - 12 13 14 15 16 17 18 19 20 21 22 23 24 1
What’s in the blister? What’s in the blister? Earphone USB Cable Portable Media Player Your Pocket Guide Install Software Get Connected Transfer Media Portable Media Player Plug Your Ears & Enjoy Your Pocket Guide 2 CD-ROM containing: Media player driver for Windows® 98/98SE Software for converting .act files into .wav files. Software for formatting internal memory.
System Requirement You’ll need a computer with: Windows® 98/98SE/ME/2000/XP/Vista Pentium Class or faster Processor CD-ROM Drive 64MB RAM 30MB free hard disk space USB Port 4
Software Installation Software Utilities Installation Insert the CD into the CD ROM drive of your PC. Click Setup.exe to start driver installation. Follow the on-screen-menu to complete the installation. Click Close once you reach the Installation Complete screen. For Windows® 98/98SE users, please install the driver in the CD-ROM before downloading any files to your player.
Connect & Charge Connect Z Z Z Z Z Z Z Z Your player will be charged while being connected to PC through the USB cable. ! You will see the charging animation in the bottom right hand corner of the display. The player is fully charged when the charging animation stops.
Transfer Get Your Player Connected Z Z Z Z Z Z Z Z Step 1: Set the Online Device of the player as USB Disk (Refer to Page 6), then connect it to your PC by USB cable. Once the connection is successfully made, the above screen display (1) would be shown. Try re-connecting the player if the above screen doesn't appear. Step 2: The above screen (2a) would appear. (Apply only to Windows® XP) Choose Take no action and click OK to close the window.
Step 3: Double click the Removable Disk icon. Note: Do not disconnect the USB cable once you click into the removable disk window. Such action may cause data loss or problems to the player. 3 Drag and drop your media files into the removable disk. You can create any folder or directory in the removable disk. Close the removable disk window and disconnect the player from your PC after the data transfer.
Software Operation Software Operation You can convert your favorite video file in any other format into the .AMV format with the help of the AMV converter (Programs\MP3 Player Utilities 4.13\AMV Converter ). The converting progress is shown as below.
Software Operation Enjoy Your AMV Movie To enjoy the converted movie on your PC, you can play it thru the AMV player ( Programs\MP3 Player Utilities 4.13\AMV Player).
Software Operation Software Operation Your can enjoy songs from both PC and your player thru the Media Manager (Programs\MP3 Player Utilities 4.13\ Media Manager). You can also convert your recorded .ACT voice into .WAV format thru the Media Manager.
Software Operation 12 You are also allowed to format the memory of your player, or divide it into two partitions in Programs\ MP3 Player Utilities 4.13\MP3 Player Disk Manager. If the updated version is available, please use MP3 Player Firmware Upgrade Tool to upgrade it.
System on the main menu, Record type Record type 13
Music Playback Music Playback 26 Select Music on the main menu and press to enter the music mode, then you can select different songs by pressing / , and you can easily play the song you’ve chosen by a simple press of . 001 - 003 00:05:10 ROOT my heart will go 128 K 0:02:00 ROCK MP3 While enjoying music, you can press to pause or continue the music; press / to move back to the previous song or jump to the next song; Hold / long to move your song forward or rewind it.
Edit Lyrics Edit Lyrics You can copy the synchronous lyrics from internet, and create a new Text Document on your PC, paste them, and then select to save this document in the extension of .LRC shown as below. 2 Then put both .LRC and .MP3 (or .WMA) files of the same song into the same folder in the removable disk. Your lyrics would be shown when you play that song.
Repeat Mode Repeat Mode 26 001 - 003 00:05:10 ROOT my heart will go 128 K 0:02:00 MP3 ROCK SRS WOW mode Replay mode List mode Procedure: In PLAYING mode (1), press while playing music to enter the selection menu screen (2). Choose Repeat and press to enter the Repeat menu screen (3). 8 Repeat Modes are available: Normal, Repeat One, Folder, Repeat Folder, Repeat All, Random, Intro, A-B Repeat.
EQ mode Listen to your music at its best 26 001 - 003 00:05:10 ROOT my heart will go 128 K 0:02:00 ROCK MP3 Procedure: In PLAYING mode (1), press while playing music to enter the selection menu screen (2). Press to select Equalizer and press to enter the Equalizer menu screen (3). 7 EQ Modes are available: Natural, Rock, Pop, Classic, Soft, Jazz, DBB.
Photo Browse Photo Browse SlideShow If you want to create a SlideShow for all photos, you can press when you select a photo on the ROOT folder list, then press to select Play set , press then to select Auto play. Press to get access to the Screen of Auto Play Gap Setting. You can adjust the auto play gap by press / . Then press to confirm your setting. Select Photo on the main menu and press to enter the ROOT folder with listed photos under it.
Ebook Ebook Ebook Local Folder Auto Play Play Set Delete Delete all Exit Auto Play Setting Press / to select Ebook on the main menu, and press to enter it. Press to select desire text file , and press to enter it. Press again to return to previous page. While reading an article, press to bookmark the text. 20 After entering Ebook, press to select Play Set. Press to choose Manual Play or Auto Play.
Game Game / to select Game and press Press to confirm and press it again to start the game. RusBlock / After entering the sub-menu, press to select to confirm. RusBlock and press / Press to move the block and press to rotate it. Press to play/ pause the game and hold to return to main menu. Puzzle After entering the sub-menu, press to select / / to confirm. Press to move to Puzzle and press to left and right. Press to move downward and press to go upward.
Voice Recording General Information Power Supply 180mA, 3.7V Lithium battery Supported File Types Dimensions 41mm x 85mm x 9mm Video Playback Weight 20g Supported File Type Display 1.8 inch Colour Display Photo Browse Capacity 128MB/256MB/512MB/1GB/2GB/4GB internal flash memory Supported File Type .JPG, .BMP and .GIF for photo files Operating System Windows?98/98SE/Me/2000/XP/Vista MAC OS 9.0, 10.0 Viewing Mode Manual Browse, Slideshow Interface USB 2.
Trouble Shooting What should I do if … Q: I cannot enter the MUSIC mode after using the player for a period of time. A: You should format the memory of the player under connection to PC. (Be sure you remember to backup the data in your player before performing the above action.) Q: I cannot convert my video file into the .AMV format. A: Please make sure that the media player software for video files has been installed on your PC. Then try to convert again.
More Disposal of your old product Electrical and electronic equipment (EEE) contains materials, parts and substances which can be dangerous to the environment and harmful to human health if wastes of electrical and electronic equipment (WEEE) are not disposed correctly. Equipments which are marked with the WEEE logo (as shown on the right), should not be thrown away with your household waste.
Contact Details We trust you are completely satisfied with this product from Argos Ltd, however please feel free to contact us if you experience any difficulties, or if you would like to express your views regarding our products. Please write to: Customer Services Argos Ltd 489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes MK9 2NW Telephone: 0870 600 3030 Through the process of continuous improvement, Argos Ltd. reserves the right to change of alert specifications without prior notice.
