WARNING WARNING To prevent fire or shock hazard, do not use this plug with an extension cord, receptacle other outlet unless the blades can be fully inserted to present blade exposure. To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
TABLE OF CONTENTS This instruction manual is important to you. Please read it. In a short time it shows exactly how to connect, operate and adjust this unit for best performance. It can save you money. It shows simple things to do and check before you call for help and save the cost of unnecessary service and call out charge. WARNINGS.....................................................................................................................................1 TABLE OF CONTENTS.......................
LOCATION OF CONTROLS 12 8 11 10 9 7 6 13 88 14 92 96 100 104 108 SCALE MHz LOG 530 600 650 800 1000 1400 1700 KHz 15 5 BBS.
REMOTE CONTROL 1 STANDBY/ON Button 2 PROGRAM Button 5 3 STOP Button SKIP 4 PLAY/PAUSE Button 7 5 SKIP FORWARD Button 8 DISC PROGRAM MUTE 6 SKIP BACKWARD Button 7 DISC Button 4 6 STANDBY/ON 3 2 1 VOLUME 9 10 8 MUTE Button 9 VOLUME - Button 10 VOLUME + Button Inserting batteries in the remote control The battery compartment cover is on the back of the remote control. Press the tab in the direction of the arrow and lift off the cover. Take the 2 1.
OPERATING INSTRUCTION PHONES (HEADPHONE) JACK A headphone jack is provided for private listening. To listen to the unit with headphones (not included), set the volume to minimum and insert the 3.5mm mini stereo plug from the headphones into the PHONES jack. The speakers will be disconnected when a plug is inserted in the jack. Adjust the VOLUME control and BASS BOOST button as desired. MUTE Press the MUTE button on the remote control to temporarily cut off the sound; the STANDBY/MUTE indicator will blink.
TO LISTEN TO THE RADIO Press the POWER button to turn the unit on. Slide the FUNCTION selector switch to the TUNER position. Slide the BAND switch to the AM, FM or FM STEREO position. AM- Select this to listen to AM broadcasts. FM- Select this to listen to FM broadcasts in mono. Noise present in stereo broadcasts can be reduced by listening in mono. FM STEREO- Select this to listen to FM STEREO broadcasts. The FM STEREO indicator will light when the radio is tuned to a stereo FM station.
being played. G)PLAY INDICATOR-------- Comes on when a disc is playing. H)PAUSE INDICATOR----- Comes on, together with the play indicator, when the disc is in the pause mode. Goes off when the pause mode is canceled. NORMAL CD PLAYBACK 1 Press POWER button to turn the system on. 2 Set the FUNCTION selector to the CD position. The CD display lights and the changer begins to search all three disc pockets for CDs. If no discs are found the display indicates NO DISC. 3 The CD pockets are numbered (1.2.3).
HIGH SPEED MUSIC SEARCH During CD playback you may search forward or back within the tracks of the disc to locate a specific musical passage if desired. To perform high speed music search press and hold either the SKIP FORWARD or SKIP BACK buttons. Release the buttons when you locate the desired passage and normal playback will resume at high speed music search. REPEAT PLAY MODES There are 3 repeat options for your convenience.
A If you press the skip buttons during programmed playback the player skips forward or back to the next programmed track, not to the next track on the disc being played. B After the last programmed track has been played the player stops but the program remains in memory. If you press the PLAY/PAUSE button again the program will be repeated. C To cancel programmed playback press the STOP button twice ,opening the CD drawer, or switching the Power button off. . .
