User Manual - MPK8099BUK
What’s in the box? Operating Unit User Manual USB Cable Earphone CD Driver
Content Buttons location and usages Basic Operation Intro ……………………………………………………….3 - 7 Operation of Music Mode …………………..…………8 - 12 Operation of Video Mode ……………………..…………..13 Operation of Pictures Mode……………………………….14 Operation of FM radio………………………………..15 - 16 Operation of Camera………………………………………17 Operation of Video Recorder……………………………..18 Operation of Others…………………………………..
Buttons location and usages (1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) On/Off Button Display Screen M Button Next Button Play/ Pause Button Power Button Previous Button USB Port Microphone Earphone Jack Camera Lens
Software Utilities Installation Insert the CD into the CD ROM Drive of your PC. Click Setup.exe to start driver installation. Follow the on-screen-menu to complete the installation. Click Close once you reach the Installation Complete Screen.
Connect & Charge Your player will be charged while being connected to PC through the USB cable. ! You will see the charging animation in the bottom right hand corner of the display. The player is fully charged when the charging animation stops. (Switch on the player when charging) Transfer Step 1: Set the Online Device of the player as USB Disk (Refer to Page 6), then connect it to your PC by USB cable. Once the connection is successfully made, the above screen display would be shown.
Step 2: The above screen would appear. (Apply only to Window XP) Choose Take no action and click OK to close the window. Double click My Computer on your desktop and the above window would appear. Look for the Removable Disk Icon. Double click the Removable Disk icon. Note: Do not disconnect the USB cable once you click into the removable disk window. Such action may cause data loss or problems to the player. Drag and drop your media files into the removable disk.
Software Operation Video Converter You can convert your fovourite video file in any other format into the .AVI format with the help of the AVI converter. The converting progress is shown. Media Manager You can enjoy songs from both PC and your player thru the Media manager.
Basic Operation Power on/off and Lock Switch on the Power button on the top and hold ON/OFF button to switch on the device. Main interface Once your switch the player on you’ll reach to the main interface as below..
Operation of Music Mode Press Previous/ Next button to select “Music” and press Play/ Pause button to enter the page. Once you’ve entered the music mode, the following screen would show up. Now Playing Press Previous/ Next button to select Now Playing and press Play/ Pause button to resume playing the current song. All Music Press Previous/ Next button to choose All Music and press Play/ Pause button to show your library of music.
Genre Press Previous/ Next button to select Genre to browse all genre of your songs. Press Play/Pause button to enter the genre that you’ve chosen and press Play/ Pause button to start playing the selected song. My Music List Press Previous/ Next to select My Music List to browse all songs that you’ve added to be your playlist. Press Previous/ Next button to select desire song list and press Play/ Pause button to start playing the selected song.
Previous / Next Press Next to jump to the next song, and press Previous to jump back to the previous song. Hold Previous/ Next button to go fast forward or backward Play Option Hold M button to enter the Play Option Menu. You can set your preference in AB Repeat/ Repeat/ Select EQ/ Set Sound/ Replay times/ Repeat intervals/ Variable speed/ Lyric display/ Add to my list/ Delete the file AB Repeat While playing music, hold M to enter the sub-menu.
Select EQ Press Previous/ Next to choose Select EQ and press Play/ Pause button enter the sub-menu and choose different EQ from Normal / Rock / Pop / Classic / Soft/ Jazz / DBB. Once you’ve selected your choice, press Play/ Pause to confirm and press M to return to sub-menu. Set Sound Press Previous/ Next to select Set Sound, press Play/ Pause to enter User EQ. Hold M to jump to different bar and press Previous/ Next button to adjust your own EQ Setting.
Lyric Display Press Previous/ Next to select Lyric display and press Play/ Pause to enter the page. Choose enable / off and press Play/ Pause to display lyrics. *The player only supports .LRC lyric. Add to MyList Press Previous/ Next to select add to my list and press Play/ Pause to choose from My Playlist 1 to My Playlist 5. Once you’ve selected your choice, press Play/ Pause to confirm and and press M to return to sub-menu.
Operation of Video Mode Press Previous/ Next button to select “Movie” and press Play/ Pause button to enter video mode. Once you’ve entered the video mode, the following screen would show up. Press Previous/ Next button to select your desire movie and press Play/ Pause button to start playing. For video recording file, it will be saved inside the CAMERA folder. Basic Video Control Press Previous button to choose previous movie, hold Previous to rewind.
Operation of Pictures Mode Press Previous/ Next button to select “Pictures” on the main menu and press Play/ Pause to enter the photo mode. Once you’ve entered the photo mode. Photo Browsing Press Previous/ Next to select Dir List and browse all photos. Press Previous/ Next to select a particular photo, and press Play/ Pause to open it. Menu Style Press Previous/ Next to choose “play mode” and press Play/ Pause to choose List mode and Thumbnail.
Operation of Radio Mode Press Previous/ Next to select “Radio” on the main menu and press Play/ Pause to enter the radio menu Radio Sub-menu Hold M to enter the sub-menu and press Previous/ Next to choose from FM record/ Record quality/ Record Gain/ Save Channel/ Auto search/ Station List/ FM Band. FM record: Press Previous/ Next to choose FM record and press Play/ Pause to confirm. Once you selected the option, the player will start recording the radio.
Station List: Press Previous/ Next to choose station list and press Play/ Pause to confirm.Press Play/ Pause button to browse all preset channel. FM Band: Press Previous/ Next to choose FM band and press Play/ Pause to enter sub-menu. Choose from USA/Japan and press Play/ Pause to confirm and return to sub-menu.
Operation of Camera Mode Press Previous/ Next to select “Camera” and press Play/ Pause button to enter the camera mode. Basic Camera Control Photo Shooting: Press Play/ Pause button to take photo. Zoom in/ out: Press Previous to zoom out and press Next to zoom in.
Operation of Video Recorder Mode Press Previous/ Next to select “Video Recorder” and press Play/ Pause button to enter the recording mode. Basic Video recorder Control Press Play/ Pause button to record video and press Play/ Pause again to pause the video recording. Press M during the recording to save the file.
Operation of Others Press Previous/ Next button to choose “Other” on the main menu to enter the page. Operation of Record Mode Press Previous/ Next button to select “Recordings” and press Play/ Pause to enter the record mode. Once you’ve entered the record mode, the following screen would show up. Basic record control Press Play/ Pause to start recording and press Play/ Pause again to pause recording, Press M to save or cancel the recorded file.
Basic e-book control Press Play/ Pause to enter the Dir List, and press Previous/ Next to select .TXT file. When opened an e-book file, press Previous to go back to previous page, and press Next to skip to the next page. Hold M to enter the E-book sub-menu. Tag List: Press Previous/ Next to Select “Tag List” and press Play/ Pause to browse the list. E-book Sub-menu Skip to: Press Previous/ Next to adjust the percentage jumping between pages.
Operation of Calculator Press Previous/ Next to select the digit and function, press Play/ Pause to confirm the selection. Press M to return to previous menu. Operation of Setting Mode Press Previous/ Next to select Set up and press Play/ Pause to enter the Set up menu. Date and Time Adjust Date: Press Play/ Pause button to enter adjust date, hold M to jump to day, month and year and press Previous/ Next to set the date. Once you’ve set the date, press Play/ Pause to confirm and return to previous menu.
Power Saving Idle Time: Press Previous/ Next to choose from Off/ 10 Sec/ 30 Sec/ 1 Minute/ 3 Minutes/ 5 Minutes/ 10 Minutes and press Play/ Pause to confirm setting. Sleep Time: Press Previous/ Next to choose from Off/ 10 Minutes/ 30 Minutes/ 1 Hour/ 2 Hours/ 3 Hours/ 4 Hours/ 5 Hours and press Play/ Pause to confirm setting. Language Press Previous/ Next to choose your desired language and press Play/ Pause to confirm.
Technical Specification Flash Memory MP3 compressed rate supported Video format supported 128MB – 16GB MP3(8 – 320 kbps) WMA(5-384kbps) OGG/ ACC/APE/WAV FLV/ AVI Photo format supported JPEG/BMP/GIF Digital camera 0.3 mega pixel Battery 3.7V Lithium rechargeable battery Interface USB2.
Trouble Shooting What should I do if there’s no sound when playing? You should check the volume first. If the volume has been turned up, maybe the memory format of the device is incorrect.. We trust you are completely satisfied with this product from Argos Ltd, however please feel free to contact us if you experience any difficulties, or if you would like to express your views regarding our products.
