32” LED Television MODEL: RLED3218A
Caution Contents Caution Safety Information 2 3 Unit and Accessories 4 Introduction 1. Front View 2. Rear View 3. Instruction for Wall Mount 4. Remote Control 5-9 5 6 7 8-9 Basic Operation 10 OSD Menu 1. Picture menu 2. Audio menu 3. Time menu 4. Setup menu 5. Lock menu 6.
Caution Caution is intended to alert the user to the presence of un-insulated "dangerous to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Safety Information Safety Information Electrical safety Physical safety 3
Unit and Accessories Unit and Accessories INPUT 1 2 3 4 5 6 7 8 9 0 -/-- PICTURE SOUND SLEEP DISPLAY CH+ VOL+ MUTE CH- VOLEXIT MENU OK CC MTS EPG FAV Remote control Batteries: 2xAAA TV set Instructions for fixing stand Instructions for fixing stand User's manual 4
Introduction Introduction 1. Front View INPUT MENU CH+ CHVOL+ VOLPOWER Led Indicator Remote Control window (Keep clear) 1). (IR) Infrared Receiver: Receives IR signals from the remote control. (Power on/Standby)LED Indicator: Press POWER to turn on and off.
Introduction HDMI1 HDMI2 HDMI3 RF COAX RIN Y Pb Pr Service VIDEO LIN VGA Y Pb Pr Video L-IN R-IN RF COAX PC Headphone out Audio PC Headphone out audio in 2. Rear View Service HDMI1 HDMI2 HDMI3 VGA AC POWER IN AC POWER IN: Connect to an earth 100-240V~ 50/60Hz outlet with the Power Cable. Service : For service use only. HDMI1/2/3 : Connect it to the HDMI of DVD or other equipment. Headphone out : Connect it to your headphone or other audio equipments. COAX : Digital coaxial output.
Introduction 3. Instruction for Wall Mount The wall mount kit (not included) with your purchase allows you to mount your RCA TV on the wall. For detailed information on installing the wall mount, refer to the instructions provided by the wall mount manufacturer. It is strongly recommended to contact a technician for professional assistance for wall mount installation. RCA is not responsible for any damage to the product or injury to yourself or others resulting from the wall-mounting.
Introduction 4. Remote Control The remote control is using Infra-Red(IR). Point it towards the front of the LED TV. The remote control may not work correctly if it is operated out of range or out of angle. POWER(red button): Turn the TV on/standby. INPUT: Press to display the input source menu. INPUT 1 2 3 4 5 6 7 8 9 0 -/-- PICTURE SOUND SLEEP DISPLAY CH+ VOL+ MUTE CH- VOLEXIT MENU OK CC Number Buttons: Choose channel directly.
Introduction Installing Batteries 1. Open the battery compartment cover on the back of the remote control. 2. Insert two 1.5V AAA size batteries observing the polarity markings inside the battery compartment. Don’t mix different types or used batteries with new ones. 3. Close the cover. - The remote control should be operated within 30 feet(7m) and 300 to the left and right of the IR receive at the front of the LED TV. - Used batteries should be disposed properly.
Basic Operation Power on/off 1. -To turn on the Switch Press POWER button on the TV or remote control. -To turn off the TV Press POWER button on the TV or remote control. Input Source select TV AV Component Press INPUT button on the TV set or remote control to display input source menu, and use CH+/- button on the TV set or ġ Ģ button on remote control to select the input source, press OK button on the remote control to enter.
OSD Menu OSD Menu 1. Picture menu Description Picture mode: Select between Standard, Dynamic, Mild, SportsˈUser and Power Saving. You may select the picture mode directly by pressing the PICTURE button on the remote control. Note: when select the "Power Saving", the machine is in energy-saving status. Contrast: Control the difference between the bright and dark regions of the screen picture. Brightness: Adjust brightness of the picture. Color: Adjust color of the picture.
OSD Menu 2. Audio menu 12 6 Picture Audio Sound Mode Time Setup Lock Channel Flat Bass 50 Treble 50 Balance 50 Surround SPDIF Type Audio Language Select Off PCM English Move MENU Exit Description Sound Mode: Select your desired picture mode as follow: Flat, Music, Movie, Sports and User You may select the sound mode directly by pressing the SOUND button on the remote control. Bass: Low frequency intensity. Treble: High frequency intensity.
OSD Menu 3. Time menu Description Sleep timer: You may set the automatic shutdown timer choosing from 5 to 240 minutes, or deactivate this function. Time zone: Select between Pacific, Alaska, Hawaii, Eastern, Central and Mountain. Daylight Saving Time: Select between On and Off. Clock: User can not change time manually during DTV mode, for time is from signal source directly.
OSD Menu 4. Setup menu Description Menu Language: Select OSD menu language. Transparency: Turn on or off the transparency menu function. Zoom Mode: Select the zoom mode between 16:9, 16:9 zoom, 4:3, 4:3 zoom. Noise reduction: Select the noise reduction mode between Strong, Off, Weak and Middle. PC SETUP: If the video input signal comes from your PC, you may adjust the V-Position, H-Position, Clock, Phase or even perform an Auto adjustment.
OSD Menu 5. Lock menu You must enter the password to gain access to the Lock menu. The default password is 0000. You may modify the following options: Description Ģ Change password: Change the password, you must enter the new password twice to confirm it. Note: Do not forget the password. System Lock: Allow you to turn on or off the system lock. If deactivated, the functions described below don’t work. This option menu allows you to lock any TV channel or adjust the Movie rating filter.
OSD Menu 6. Channel menu Description Air/Cable: Allow you to select antenna between Air and Cable. If you selet “Cable”, the following items(Favorite, Show/Hide, Channel NO, Channel Label and DTV Signal) are unable to use. Auto Scan: Enter the Auto Scan menu to start auto scan. Ģ ƾ If you select “Cable” as input signal in Antenna item, allows you to select Cable System among: Auto, STD, IRC and HRC. Use Ģ button to highlight the “Start to Scan”, then press button to search the channels automatically.
OSD Menu Show/Hide: Allow you to show or hide the channels. Ģ Use / Ģ button to highlight the desired item, then press OK button to show or hide the highlighted channel. Ģ Channel Label: Allow you to setup a label for the channel. Press / Ģ button to select the position of the table, and press words. Ģ DTV Signal: Show the quality of digital signal: good, Normal, Bad. 17 / Ģ Channel No.: Show and select the channel.
Simple Troubleshooting Simple Troubleshooting If the display fails or performance dramatically deteriorates check the Display in accordance with the following instructions.Remember to check the peripherals topinpiont the source of the failure. If the display still fails to perform as expected,connect your helpline for assistance. No power - Check all connections to the TV. - Press either the power button or the Standby button on the Remote control.
Technical Specifications LED Panel RGB ATV 32 inch (diagonal) 400 cd/m2 3000:1 1366x768 H: 30-75KHz V: 56-75Hz 0.7Vp-p@75ohm Max 1920X1080@60Hz impedance NTSC M, J, 4.43. BTSC/A2 Panel Size Brightness Contrast Resolution Sync Signal MODE Input Video System Sound System DTV 6MHz Impedance Bandwidth Modulation Video System ATSC:8VSB QAM:64QAM, 256QAM MPEG 2 MP@ML Sound System Color system Video MPEG 1/ layer 1/AC-3 Audio 500mV rms Video Audio Y:1Vp-p@75ohm,PbPr:0.7Vp-p@75ohm Format Max.
PRESET MODE FOR VGAǃHDMI VGA FORMAT MODE Resolution 1366X768 1024X768 800X600 640X480 720X400 Refresh Rate 60HZ 55.5KHZ 60HZ 59.9KHZ 60HZ 48.4KHZ 70HZ 56.5KHZ 75HZ 60.0KHZ 60HZ 37.9KHZ 70HZ 47.2KHZ 75HZ 46.9KHZ 60HZ 31.5KHZ 70HZ 37.9KHZ 75HZ 37.5KHZ 70HZ 31.5KHZ HDMI FORMAT MODE Format Resolution Hor.Freq(KHz) Vert.Freq(HZ) 480i 480 15.734 60 480p 480 31.465 59.94 31.500 60 576i 576 576p 576 31.250 50 720p 720 44.955 60 1080i 1080 28.125 50 33.
LIMITED PRODUCT WARRANTY RCA CANADA TV EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND AS DESCRIBED BELOW CURTIS INTERNATIONAL LTD EXPRESSLY DISCLAIMS, ALL ACTUAL AND IMPLIED WARRANTIES AND CONDITIONS WITH RESPECT TO ANY PRODUCT USED FOR INSTITUTIONAL OR OTHER COMMERCIAL PURPOSES (INCLUDING BUT NOT LIMITED TO RENTAL PURPOSES). What your warranty covers: • Defects in materials or workmanship to the original purchaser.
