VISUAL DISPLAY
The EliteSuite™ LED keypad features an easy to use 8 zone
display, which in conjuction with the status LED’s allows you
to monitor your system at a glance.
When not using the menu system for programming options
or modifying user accounts, your keypad will display the
status of each programmed zone by lighting the
corresponding number on the display. The 3 status options
shown are:
FLASHING CONTINUALLY: The zone is operating
incorrectly. Contact your building manager or security
company for assistance.
ON: The zone is open.
OFF: The zone is closed.
AUDIBLE TONE
When you press a key on the EliteSuite™ LCD keypad a
short audible tone is generated. Other tones are generated
when certain functions are used, you should be familiar with
the following audible tones.
Confirmation Tone
When an operation (arming/disarming) is successfully
entered on the keypad or when the system switches to a
new status/mode, the keypad generates a series of four
audible tones.
Rejection Tone
When the system times out or when an operation is
incorrectly entered on the keypad, it will generate a
continuous audible tone for three seconds.
