User Manual

3 4
Function LCD Display Options Default Description
Sensitivity Low
Medium
High
Escape to
Function
Menu
Medium If the connected equipment
can tolerate more power
events (Example: unstable
power often associated with
stormy weather), select Low
Sensitivity. The UPS will go to
Battery Mode less often. If the
connected equipment is more
sensitive to power events,
select High Sensitivity. The
UPS will go to Battery Mode
more often.
Low Battery Warning 5~8 mins
Escape to
Function
Menu
5 mins The audible alarm will sound
when the remaining runtime
is less than the value
selected.
Self Test
(Battery Test)
YES
Escape to
Function
Menu
No Action In Line Mode, select YES to
perform a Self Test on the
battery.
Audible Alarm b.on
b.off
Escape to
Function
Menu
b.on “b.on” is buzzer enable;
“b.oFF” is buzzer disable.
If b.oFF is selected, the unit
will mute all alarms except for
fault or overload condition.
You can also set the audible
alarm with the MUTE button
mentioned before.
Function LCD Display Options Default Description
LCD Auto Off L.on (Auto Off is on)
L.oFF (Auto Off is off)
Escape to
Function
Menu
L.on “L.on” (Auto Off is on): In Line
Mode, LCD screen will off
automatically after 1 min of
inactivity; in Battery Mode,
LCD screen is always on.
“L.oFF” (Auto Off is off): LCD
screen is always on.
Last Fault Reason There is no setting in this
page. This page will only
show the error code for last
fault reason.
E01 : Charger fault (Over
Charge).
E02 : Charger fault (No
Charge)
E11 : Battery Fault
E21 : Output short.
E22 : Over load.
Back to Default Settings YES
Escape to
Function
Menu
No Action Select Yes to restore the UPS
factory default settings.
Return to Status Display -- Press the ENTER Button to
leave setup mode and go
back to the Status Display.
