Cybex Total Access 14010 Overhead Press Owner’s Manual 1 - Safety Safety Read the Owner’s Manual carefully before assembling, servicing or using the equipment. It is the responsibility of the facility owner and/or owner of the equipment to instruct users on proper operation of the equipment and review all labels. WARNING: Serious injury could occur if these safety precautions are not observed: User Safety Precautions • Obtain a medical exam prior to beginning an exercise program.
Cybex Total Access 14010 Overhead Press Owner’s Manual • Make sure that each machine is set up and operated on a solid level surface. Do not install equipment on an uneven surface. • Make sure that all users are properly trained on how to use the equipment. • Make sure there is enough room for safe access and operation of the equipment. • Perform regular maintenance checks on the equipment.
Cybex Total Access 14010 Overhead Press Owner’s Manual 3. Anchoring holes are provided on the feet of the frame. All anchoring locations must be used when anchoring the equipment to the floor. 4. Due to the wide variation of flooring on which machines may be anchored or installed, verify anchoring method and anchoring fasteners with a qualified and licensed contractor. 5. A minimum pull out force of 220 lbs/100 kgs is required for each anchor position.. 6. Do not use machine until it is properly anchored.
Cybex Total Access 14010 Overhead Press Owner’s Manual A CAUTION Personal injury may occur. Keep away from moving parts to avoid injury. B 4000Y316-4 C CAUTION Seat may fall if improperly engaged. Verify seat is secure before exercising to avoid injury.
Cybex Total Access 14010 Overhead Press Owner’s Manual Total Access Overhead Press - 14010 B B (both sides) A C D Description Part No. A. Warning Label....................4605-381-4 B. Caution Decal.....................4000Y316-4 C. Caution Decal.....................4520-362-4 D. Caution Decal.....................
Cybex Total Access 14010 Overhead Press Owner’s Manual Regular Maintenance Activities Preventative maintenance activities must be performed to maintain normal operation of your equipment. Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative maintenance activities. The preventative maintenance actions are described in detail in Chapter 5. Briefly, they include: Daily 1. Clean upholstery. Weekly 1. Inspect all nuts and bolts for looseness.
Cybex Total Access Owner’s Manual 2 - Exercise MUSCLES USED Intended Use The intended use of this equipment is to aid or improve general physical fitness and exercise. For commercial use. Instruction Read and understand all instructions and warnings prior to using this machine. See Chapter 1, Safety, in the Owner’s Manual or consult with floor staff.
Cybex Total Access Owner’s Manual Set Up - Consult floor staff if assistance is required. 1. Adjust seat so hands are slightly above shoulder. Wheelchair users: Lift detent pin and lock to the “out” position. Rotate seat outward to allow access. 2. Choose a suitable hand grip position that allows hands to start slightly above the shoulders. Movement 1. Push handles directly upward until arms are fully straightened.
Cybex Total Access Owner’s Manual 3 - Customer Service Contacting Service Hours of phone service are Monday through Friday from 8:30 a.m. to 6:00 p.m. Eastern Standard Time. For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239. For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300 or fax 508-533-5183. Find information on the web at www.eCybex.com or by e-mail at techhelp@cybexintl.com. Ordering Parts Fax your order to 508-533-5183.
Cybex Total Access Owner’s Manual Return Material Authorization (RMA) The Return Material Authorization (RMA) system outlines the procedures to follow when returning material for placement, repair or credit. The system assures that returned materials are properly handled and analyzed. Follow the following procedures carefully. Contact your authorized Cybex dealer on all warranty-related matters. Your local Cybex dealer will request a RMA from Cybex, if applicable.
Cybex Total Access Owner’s Manual Damaged Parts Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier (UPS, Federal Express, trucking companies, etc.) Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must be noted on the freight bill and signed by the carrier’s agent. Failure to do so will result in the carriers refusal to honor your damage claim.
Cybex Total Access Owner’s Manual This page intentionally left blank Customer Service Page 3-4
Cybex Total Access Owner’s Manual 4 - Assembly TOOLS REQUIRED • • • • • 7/32” Allen wrench 1/8” Allen wrench Medium weight automotive engine oil Torque wrench 3/4” Wrench NOTE: Two people will be required for this procedure. NOTE: It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate clearance around each machine to allow for safe use and passage. NOTE: Refer to chapter 6 for reference diagrams. 1.
Cybex Total Access Owner’s Manual E. Slide spring loaded top guide rod cap down guide rod until guide rod cap is clear of frame. NOTE: Top guide rod cap is spring loaded. F. Slowly release grasp of guide rod cap. NOTE: Guide rod cap contains a compression spring that will fly if grasp is not released slowly. G. Remove guide rod cap and spring and set aside. H. Repeat steps 5F-5H for other rod guide. I. Carefully lean guide rods slightly outward, away from machine to clear pulley.
Cybex Total Access Owner’s Manual 6. Belt Routing. Correct belt routing A. Verify belt is routed through top of pulley bracket and then route end of belt down to the top weight. Wrong belt routing Insert Insert Belt Belt B. Carefully lift top weight and verify that the position of the belt clamp (on the top weight) is aligned properly with the top pulley bracket. Stem Stem C. Slide belt through slot in belt clamp. Figure 2A D. Verify belt and insert are installed properly, as shown in Figure 2A.
Cybex Total Access Owner’s Manual NOTE: It is important that you perform regular inspection and maintenance activities on your equipment. See the CYBEX Owner’s Manual for inspection and maintenance activities. If you do not have a CYBEX Owner’s Manual or if you have any questions or concerns, call CYBEX Customer Relations at 888-462-9239. 9. Verify proper operation 10. Securely anchor machine to the floor. A. Securely anchor machine to the floor using the anchor holes provided in each machine.
Cybex Total Access Owner’s Manual Chapter 5 - Maintenance All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment. NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines. Instruct all personnel in equipment inspection and maintenance actions and also in accident reporting/recording.
Cybex Total Access Owner’s Manual More Difficult Stains • Dampen a soft white cloth with a solution of 10% household bleach (sodium hypochlorite), 90% water. Rub gently. Rinse with a water dampened cloth to remove bleach concentration. • The same procedure can be used with full strength household bleach, if necessary. • Allow bleach to puddle on the affected area or apply with a soaked cloth for approximately 30 minutes. Rinse with a water dampened cloth to remove any remaining bleach concentration.
Cybex Total Access Owner’s Manual 4. Guidelines for cleaning front panel: • Use clean soft cloths or sponges for application of cleaners and again for washing and rinsing. • Follow up the application with warm water rinse. • Don’t use abrasives or high alkaline cleaners. • Don’t leave cleaners on for long periods, wash immediately. • Don’t apply cleaners in direct sunlight or at elevated temperatures. • Don’t use scrapers, squeegees or razors. • Don’t clean with gasoline. 5.
Cybex Total Access Owner’s Manual Weekly Procedures 1. Check all nuts and bolts for looseness. Tighten as required. 2. Inspect all belts (entire length) for any non-uniformity and wear.
Cybex Total Access Owner’s Manual 3. Some machines use cables in addition to belts. Inspect all cables for wear or damage and proper tension. When inspecting cables, run your fingers on the cable, paying particular attention to bends in the cable and attachment points. Replace all worn cables immediately. The following conditions may indicate a worn cable: • A tear or crack in the cable sheath that exposes the cable. See Figure 1 Figure 1 • A kink in the cable. See Figure 2.
Cybex Total Access Owner’s Manual 4. Inspect bars and handles for wear, paying particular attention to tab area connecting points. Replace all worn handles immediately. 5. Inspect snap links for proper latching (indicates wear). Replace all worn snap links immediately. 6. Inspect for loose or worn grips. Replace all loose or worn grips immediately. 7. Inspect all labeling for readability. This includes instructional placards, warning and caution decals. Replace all worn labeling immediately. 8.
Cybex Total Access Owner’s Manual Environment Static Electricity - Depending upon where you live, you may experience dry air, causing a common experience of static electricity. This may be especially true in the winter time. You may notice a static build-up just by walking across a carpet and then touching a metal object. The same can hold true while working out on your unit. You may experience a shock due to the build-up of static electricity on your body and the discharge path of the unit.
Cybex Total Access Owner’s Manual This page intentionally left blank Maintenance Page 5-8
Cybex Total Access Owner’s Manual 6 - Service Please refer to the next several pages for parts lists, exploded-view diagrams and cable and belt routing diagrams. NOTE: All inspections and repairs must be performed by trained service personnel only. Cybex will void warranty if non-Cybex replacement parts are used.
Cybex Total Access Owner’s Manual This page intentionally left blank Service Page 6-2
Cybex Total Access 14010 Overhead Press Owner’s Manual OVERHEAD PRESS PRODUCT NO. 14010 A B F B (both sides) H,I G D O K,L N J C E NOTE: See exploded-view diagram for location of M (serial number decal). DESCRIPTION A. B. C. D. E. F. G. DESCRIPTION PART NO. Placard Decal .................... 14010-598 Caution Decal .................... 4000Y316 Caution Decal .................... 4520-362 Warning Label ................... 4605-381 Caution Decal ....................
QTY 2 1 1 1 1 1 2 1 4 4 1 2 1 1 1 2 4 1 1 2 2 2 2 2 1 4 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 2 4 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 Service Page 6-4 47 FB050211 08171 08229 11040-440 11040-568 11050-374 11050-375 11070-332 11090-210 11090-374 11090-376 12000-467 12000-387 12000-392 12000-393 12000-395 12000-396 12000-398 12000-417 12030-353 12090-322 12102-330 12210-347 12210-348 12210-350 13000-103 130
64 63 28 63 29 17 3 39 70 70 27 25 65 17 63 54 63 65 73 32 87 63 63 81 17 63 63 43 52 6 49 31 65 65 2 1 49 54 73 11 1 45 80 47 62 62 59 71 79 71 76 67 47 62 85 41 38 4 47 62 49 49 61 5 8 71 40 47 62 71 43 72 86 73 73 75 62 62 78B 10 56 56 69 71 9 53 62 53 57 9 57 9 69 57 69 78A 78A 10 14010 VR3 TA MAIN ASSEMBLY 78B 57 9 69 68 10 19 45 10 7 46 75 68 30 48 Serial Number Decal 36 48 46 53 53 7 Cyb
Cybex Total Access 14010 Overhead Press Owner’s Manual OVERHEAD PRESS PANEL ASSEMBLY DETAIL 16 15 14 12 16 17 66 66 58 83 63 11 58 13 12 66 63 63 58 17 65 65 66 65 58 58 66 66 91 66 84 17 58 66 63 58 66 63 58 17 63 66 58 Service Page 6-6 92 63
Cybex Total Access 14010 Overhead Press Owner’s Manual Top Weight Assembly (Light Stack and Heavy Stack Configurations) ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 QTY 1 1 2 2 1 1 1 1 1 1 1 4 2 1 1 2 PART NO.
Cybex Total Access 14010 Overhead Press Owner’s Manual Belt Routing Assembly Detail 50 44 60 22 24 44 60 24 51 51 60 50 90 55 51 55 60 55 Torque Set Screws 300-350 in/lbs 89 59 55 47 67 8 Torque Set Screws 300-350 in/lbs 4 67 72 47 37 51 55 55 88 77 51 21 23 88 21 Service Page 6-8 60
