Cybex Total Access 14010 Overhead Press Owner’s Manual
Service
Page 6-4
1 2 08171 SHIM, TAPERED RUBBER
2 1 08229 P/PIN,DETENT
3 1 11040-440 KNOB
4 1 11040-568 CLAMP BLOCK INSERT
5 1 11050-374 PIVOT PIN
6 1 11050-375 PIVOT PIN
7 2 11070-332 C/ COUNTERWEIGHT
8 1 11090-210 W/CLAMP
9 4 11090-374 END CAP
10 4 11090-376 RING, HANDLE GRIP
11 1 12000-467 PULLEY COVER
12 2 12000-387 EXTRUSION, INC WT CHANNEL
13 1 12000-392 CHANNEL, INCREMENT WEIGHT
14 1 12000-393 CHANNEL, INCREMENT WEIGHT
15 1 12000-395 TOP CAP
16 2 12000-396 END CAP
17 4 12000-398 SPACER
18 1 12000-417 PANEL INSERT
19 1 12030-353 BLOCK, STOP
20 2 12090-322 FOOT PAD
21 2 12102-330 INSERT, INCREMENT WEIGHT
22 2 12210-347 GUIDE ROD CAP
23 2 12210-348 GUIDE ROD CAP
24 2 12210-350 WT ROD .625 DIA X 49.53
25 1 13000-103 GAS SPRING ASSEMBLY
26 4 13000-353 FOOT PAD
27 1 13000-365 INSERT PLASTIC, 7.94 (MODIFIED)
28 1 13000-400 HOLDER, WATER BOTTLE
29 1 13000-402 MOUNT, WATER BOTTLE HOLDER
30 1 13010-316 SHAFT, PIVOT
31 1 14000-204 W/SEAT PIVOT
32 1 14000-206 P/CUSHION POST
33 1 14000-207 W/ BRACKET, SEAT PIVOT
34 1 14000-400 DECAL, WEIGHT PLATE
35 1 14010-200 W MAIN FRAME
36 1 14010-201 W INPUT ARM
37 1 14061-006 TOP WEIGHT ASSY 10
38 1 4816-205 W/ PIVOT ARM
39 1 4816-327 FOOT PAD
40 1 4816-332 P/DETENT PIN
41 1 4816-336 KNOB, PLASTIC T-SHAPE
42 1 51198 WARRANTY BOOK (NOT SHOWN)
43 2 BS070201 COM SPRING .56 x .66 1.50 LG
44 2 BS070208 COMPRESSION SPRING
45 1 CM000202 DECAL, SERIAL NO.
46 2 FB030232 BEARING, RADIAL 17 mm
EXTENDED RACE
47 4 FB050211 BRG FLG .38 X .50 .25 LG
ITEM QTY PART NO. DESCRIPTION
48 2 FC030006 TOLERANCE RING 1.575 ID
49 4 FB130207 BRG FLG 17mm X 19mm X 25mm
50 A/R GB000202 BELT .95 WIDE
51 6 GP000209 PULLEY ASSEMBLY-3.50
52 1 HC622808 SHCS .250-20 X .250
53 6 HC700415 BHSCS .375-16 X .75
54 2 HC700417 BHSCS .375-16 X 1.00
55 6 HC700428 BHSCS .375-16 X 2.25
56 2 HC700430 BHSCS .375-16 X 2.50
57 4 HF449063 INSERT 3/4 X 1/4-20
58 12 HF579000 PANEL FASTNER, 10-24 U TYPE
59 1 HN664900 NUT, HEX SELF-LOCKING .312-18 ZINC
60 6 HN704901 LOCKNUT, .375-16 NYLON
61 1 HP286819 SPIRAL PIN .188 X 1.12
62 8 HS347600 WASHER, SAE .375
63 10 HT512517 TAP SC 10-24 X 1.00 TYPE WB PN
HD PHIL BLACK
64 1 HT552515 TAP SC NO. 8-16 X .75 PLASTITE PN
HD PHIL BLACK
65 4 HT570410 SCREW, PNH TORX 10-24 X .375, BLACK
66 12 HX570412 BHSCS, 10-24 X .50, SS
67 3 HY740000 SET SCREW
68 2 JC620415 BHSCS .250-20 X .75
69 4 JC620422 BHSCS .250-20 x 1.50
70 2 JC620914 FHSCS .250-20 X .625
71 6 JC700412 BHSCS .375-16 X .50
72 1 JD343320 S BOLT .375 X 1.25 .312-18
73 4 JS347400 LOCKWASHER, INT TOOTH .375
74 1 PN660200 INSERT, PLASTIC 1.00 DIA-11 GA
75 2 PP080226 INSERT, DOMED PLASTIC 2.00, RIB
76 2 PP130003 INSERT, DOMED PLASTIC
77 2 PR060005 BUMPER, WEIGHT
78A 2 4605-514 GRIP 1.38 OD X .96 ID 4.5” LG
78B 2 4605-523 GRIP 1.38 OD X .96 ID 13.25” LG
79 1 4800-180 BACK PAD W/ WEAR COVER
80 1 4800-183 WEAR COVER
81 1 5207S0430 SEAT PAD
82 1 14010-999-4 OWNER’S MANUAL
83 1 14010-598-4 PLACARD
84 1 4605-381-4 DECAL, WARNING
85 1 8500-025-4 DECAL, CAUTION
86 3 4000Y316 DECAL, CAUTION
87 1 4520-362 DECAL, CAUTION
88 2 11040-409 BUMPER
89 1 11040-216 BELT CLAMP
90 1 11040-301 INSERT
91 1 14000-407-4 INCREMENT WEIGHT DECAL
92 1 11040-790 DECAL, MADE IN U.S.A.
ITEM QTY PART NO. DESCRIPTION
