D-Link DIR-655 User Manual Configuration ............................................................. 12 Web-based Configuration Utility ............................ 12 Setup Wizard ................................................... 13 Manual Configuration....................................... 17 Dynamic (Cable)........................................... 17 PPPoE (DSL) ............................................... 18 PPTP............................................................ 19 L2TP................
D-Link DIR-655 User Manual Connect to a Wireless Network ................................ 70 Using Windows® XP............................................... 70 Configure WEP ...................................................... 71 Wireless Security....................................................... 61 What is WEP?........................................................ 61 What is WPA? ........................................................ 62 Wireless Security Setup Wizard ..........................
Product PackageOverview Contents D-Link DIR-655 User Manual • Ethernet-based Cable or DSL Modem • Computers with Windows®, Macintosh®, or Linux-based operating systems with an installed Ethernet adapter • Internet Explorer Version 6.0, Mozilla 1.7.12 (5.0), or Firefox 1.
Introduction D-Link DIR-655 User Manual 5 * Maximum wireless signal rate derived from IEEE Standard 802.11g and Draft 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely affect wireless signal range.
Features D-Link DIR-655 User Manual 6 * Maximum wireless signal rate derived from IEEE Standard 802.11g and Draft 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely affect wireless signal range.
D-Link DIR-655 User Manual Power Receptor Receptor for the supplied power adapter. Reset Pressing the Reset button restores the router to its original factory default settings. Internet Port The auto MDI/MDIX Internet port is the connection for the Ethernet cable to the cable or DSL modem. USB Connect a USB 1.1 or 2.0 flash drive to configure the wireless settings using WCN. Connections Hardware Overview LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and hubs.
D-Link DIR-655 User Manual Power LED A solid light indicates a proper connection to the power supply. Status LED A blinking light indicates that the DIR-655 is ready. WLAN LED A solid light indicates that the wireless segment is ready. This LED blinks during wireless data transmission. Local Network LEDs A solid light indicates a connection to an Ethernet-enabled computer on ports 1-4. This LED blinks during data transmission. WCN LED Insert a USB flash drive with WCN information.
Installation D-Link DIR-655 User Manual 9 If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoet, Broadjump, or Enternet 300 from your computer or you will not be able to connect to the Internet. Please configure the router with the computer that was last connected directly to your modem. Also, you can only use the Ethernet port on your modem.
Wireless Installation Considerations D-Link DIR-655 User Manual 5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use. 4.
Getting Started D-Link DIR-655 User Manual 11 Note: It is reccomended to write down the SSID and Security Key, followed by the login password on the provided CD holder. Click Install Router When the autorun screen appears, click Install Router. If the CD Autorun function does not automatically start on your computer, go to Start > Run. In the run box type “D:\DIR655.exe” (where D: represents the drive letter of your CD-ROM drive). Insert the Quick Router Setup Wizard CD in the CD-ROM drive.
Configuration D-Link DIR-655 User Manual If you get a Page Cannot be Displayed error, please refer to the Troubleshooting section for assistance. Select Admin from the drop-down menu and then enter your password. Leave the password blank by default. To access the configuration utility, open a web-browser such as Internet Explorer and enter the IP address of the router (192.168.0.1).
Setup Wizard D-Link DIR-655 User Manual If you want to configure your wireless settings, click Launch Wireless Security Setup Wizard and skip to page 62. Click Launch Internet Connection Setup Wizard to begin. If you want to enter your settings without running the wizard, click Manual Configuration and skip to page 19. You may click Setup Wizard to quickly configure your router.
D-Link DIR-655 User Manual Select the type of Internet connection you use and then click Next to continue. Select your time zone from the drop-down menu and then click Next to continue. Create a new password and then click Next to continue. Click Next to continue.
D-Link DIR-655 User Manual If you selected PPTP, enter your PPTP username and password. Click Next to continue. Note: Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router. Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. If you selected PPPoE, enter your PPPoE username and password. Click Next to continue. The Host Name is optional but may be required by some ISPs.
D-Link DIR-655 User Manual Close your browser window and reopen it to test your Internet connection. It may take a few tries to initially connect to the Internet. Click Connect to save your settings. Once the router is finished rebooting, click Continue. Please allow 1-2 minutes to connect. If you selected Static, enter your network settings supplied by your Internet provider. Click Next to continue. If you selected L2TP, enter your L2TP username and password. Click Next to continue.
Dynamic (Cable) Manual Configuration D-Link DIR-655 User Manual MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.
PPPoE (DSL) Internet Setup D-Link DIR-655 User Manual 18 MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.
PPTP Internet Setup D-Link DIR-655 User Manual DNS Servers: The DNS server information will be supplied by your ISP (Internet Service Provider.) Maximum Idle Enter a maximum idle time during which the Internet Time: connection is maintained during inactivity. To disable this feature, enable Auto-reconnect. Reconnect Mode: Select either Always-on, On-Demand, or Manual. Password: Enter your PPTP password and then retype the password in the next box. Username: Enter your PPTP username.
D-Link DIR-655 User Manual 20 MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP.
L2TP Internet Setup D-Link DIR-655 User Manual DNS Servers: Enter the Primary and Secondary DNS Server Addresses (Static L2TP only). Maximum Idle Time: Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable Auto-reconnect. Reconnect Mode: Select either Always-on, On-Demand, or Manual. Password: Enter your L2TP password and then retype the password in the next box. Username: Enter your L2TP username.
D-Link DIR-655 User Manual 22 Clone MAC The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not Address: recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP.
Static (assigned by ISP) Internet Setup D-Link DIR-655 User Manual MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.
D-Link DIR-655 User Manual MAC Address: The default MAC Address is set to the Internet’s physical interface MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP. 1500 is the default MTU.
Wireless Settings D-Link DIR-655 User Manual Transmission Rate: Select the transmit rate. It is strongly suggested to select Best (Auto) for best performance. Channel Width: Select the Channel Width: Auto 20/40 - This is the default setting. Select if you are using both 802.11n and non-802.11n wireless devices. 20MHz - Select if you are not using any 802.11n wireless clients. 802.11 Mode: Select one of the following: 802.11g Only - Select if all of your wireless clients are 802.11g. Mixed 802.
D-Link DIR-655 User Manual Wireless Security: Refer to page 60 for more information regarding wireless security. 26 Visibility Status: Select Invisible if you do not want the SSID of your wireless network to be broadcasted by the DIR-655. If Invisible is selected, the SSID of the DIR-655 will not be seen by Site Survey utilities so your wireless clients will have to know the SSID of your DIR-655 in order to connect to it.
Network Settings D-Link DIR-655 User Manual Enable DNS Relay: Uncheck the box to transfer the DNS server information from your ISP to your computers. If checked, your computers will use the router for a DNS server. Local Domain: Enter the Domain name (Optional). Subnet Mask: Enter the Subnet Mask. The default subnet mask is 255.255.255.0. If you change the IP address, once you click Apply, you will need to enter the new IP address in your browser to get back into the configuration utility.
DHCP Server Settings D-Link DIR-655 User Manual Add DHCP Refer to the next page for the DHCP Reservation Reservation: function. Lease Time: The length of time for the IP address lease. Enter the Lease time in minutes. Note: If you statically (manually) assign IP addresses to your computers or devices, make sure the IP addresses are outside of this range or you may have an IP conflict. DHCP IP Address Enter the starting and ending IP addresses for Range: the DHCP server’s IP assignment.
DHCP Reservation D-Link DIR-655 User Manual Save: Click Save to save your entry. You must click Save Settings at the top to activate your reservations. Copy Your PC’s If you want to assign an IP address to the MAC Address: computer you are currently on, click this button to populate the fields. MAC Address: Enter the MAC address of the computer or device. IP Address: Enter the IP address you want to assign to the computer or device. This IP Address must be within the DHCP IP Address Range.
Virtual Server D-Link DIR-655 User Manual For a list of ports for common applications, please visit http://support.dlink.com/faq/view.asp?prod_id=1191. 30 Each virtual service that is created will be listed at the bottom of the screen in the Virtual Servers List. There are pre-defined virtual services already in the table. You may use them by enabling them and assigning the server IP to use that particular virtual service.
D-Link DIR-655 User Manual Schedule: The schedule of time when the Virtual Server Rule will be enabled. The schedule may be set to Always, which will allow the particular service to always be enabled. You can create your own times in the Tools > Schedules section. Inbound Filter: Select Allow All (most common) or a created Inbound filter. You may create your own inbound filters in the Advanced > Inbound Filter page. Protocol Type: Select TCP, UDP, or Both from the drop-down menu.
Port Forwarding D-Link DIR-655 User Manual Schedule: The schedule of time when the Virtual Server Rule will be enabled. The schedule may be set to Always, which will allow the particular service to always be enabled. You can create your own times in the Tools > Schedules section. Inbound Filter: Select Allow All (most common) or a created Inbound filter. You may create your own inbound filters in the Advanced > Inbound Filter page.
Application Rules D-Link DIR-655 User Manual Schedule: The schedule of time when the Application Rule will be enabled. The schedule may be set to Always, which will allow the particular service to always be enabled. You can create your own times in the Tools > Schedules section. Traffic Type: Select the protocol of the firewall port (TCP, UDP, or Both). Firewall: This is the port number on the Internet side that will be used to access the application. You may define a single port or a range of ports.
QoS Engine D-Link DIR-655 User Manual Detected xDSL: When Connection Type is set to automatic, the automatically detected connection type is displayed here. 34 Connection Type: By default, the router automatically determines whether the underlying connection is an xDSL/Frame-relay network or some other connection type (such as cable modem or Ethernet), and it displays the result as Detected xDSL or Frame Relay Network.
Network Filters D-Link DIR-655 User Manual DHCP Client: Select a DHCP client from the drop-down menu and click << to copy that MAC Address. MAC Address: Enter the MAC address you would like to filter. To find the MAC address on a computer, please refer to the Networking Basics section in this manual. Configure MAC Select Turn MAC Filtering Off, allow MAC Filtering: addresses listed below, or deny MAC addresses listed below from the drop-down menu.
Access Control D-Link DIR-655 User Manual Click Next to continue with the wizard. Access Control Wizard Add Policy: Click the Add Policy button to start the Access Control Wizard. 36 The Access Control section allows you to control access in and out of your network. Use this feature as Parental Controls to only grant access to approved sites, limit web access based on time or dates, and/or block access from applications like P2P utilities or games.
Access Control Wizard (continued) D-Link DIR-655 User Manual • Address Type - Select IP address, MAC address, or Other Machines. • IP Address - Enter the IP address of the computer you want to apply the rule to. Enter the following information and then click Next to continue. Select a schedule (I.E. Always) from the drop-down menu and then click Next to continue. Enter a name for the policy and then click Next to continue.
Access Control Wizard (continued) D-Link DIR-655 User Manual Click Save to save the access control rule. To enable web logging, click Enable. Enter the rule: Enable - Check to enable the rule. Name - Enter a name for your rule. Dest IP Start - Enter the starting IP address. Dest IP End - Enter the ending IP address. Protocol - Select the protocol. Dest Port Start - Enter the starting port number. Dest Port End - Enter the ending port number. Select the filtering method and then click Next to continue.
Website Filters D-Link DIR-655 User Manual Website URL/ Enter the keywords or URLs that you want to Domain: block (or allow). Any URL with the keyword in it will be blocked. 39 Website Filters are used to deny LAN computers from accessing specific web sites by the URL or domain. A URL is a specially formatted text string that defines a location on the Internet. If any part of the URL contains the blocked word, the site will not be accessible and the web page will not display.
Inbound Filters D-Link DIR-655 User Manual Inbound Filter This section will list any rules that are created. Rules List: You may click the Edit icon to change the settings or enable/disable the rule, or click the Delete icon to remove the rule. Save: Click the Save button to apply your settings. You must click Save Settings at the top to save the settings. Source IP End: E n t e r t h e e n d i n g I P a d d r e s s. E n t e r 255.255.255.255 if you do not want to specify and IP range.
Firewall Settings D-Link DIR-655 User Manual IP Address: Specify the IP address of the computer on the LAN that you want to have unrestricted Internet communication. If this computer obtains it’s IP address automatically using DHCP, be sure to make a static reservation on the Basic > DHCP page so that the IP address of the DMZ machine does not change. Note: Placing a computer in the DMZ may expose that computer to a variety of security risks. Use of this option is only recommended as a last resort.
Application Level Gateway (ALG) Configuration D-Link DIR-655 User Manual MMS: Allows Windows Media Player, using MMS protocol, to receive streaming media from the Internet. Wake-On-LAN: Allows Ethernet network adapters with Wake-On-LAN (WOL) to function. 42 SIP: Allows devices and applications using VoIP (Voice over IP) to communicate across NAT. Some VoIP applications and devices have the ability to discover NAT devices and work around them. This ALG may interfere with the operation of such devices.
D-Link DIR-655 User Manual 43 Short GI: Check this box to reduce the guard interval time therefore increasing the data capacity. However, it’s less reliable and may create higher data loss. WMM Function: WMM is QoS for your wireless network. This will improve the quality of video and voice applications for your wireless clients. 802.11d: This enables 802.11d opration. 802.11d is a wireless specification developed to allow implementation of wireless networks in countries that cannot use the 802.
WISH Settings D-Link DIR-655 User Manual 44 WISH supports overlaps between rules. If more than one rule matches for a specific message flow, the rule with the highest priority will be used. WISH Rules: A WISH Rule identifies a specific message flow and assigns a priority to that flow. For most applications, the priority classifiers ensure the right priorities and specific WISH Rules are not required.
D-Link DIR-655 User Manual Host Port Range: The rule applies to a flow of messages for which host’s port number is within the range set here. Host IP Range: The rule applies to a flow of messages for which one computer’s IP address falls within the range set here. Protocol: The protocol used by the messages. BK: Background (least urgent) BE: Best Effort. VI: Video VO: Voice (most urgent) Priority: The priority of the message flow is entered here.
D-Link DIR-655 User Manual Multicast Check the box to allow multicast traffic to pass streams: through the router from the Internet. Internet Port You may set the port speed of the Internet port Speed: to 10Mbps, 100Mbps, or auto. Some older cable or DSL modems may require you to set the port speed to 10Mbps. Internet Ping: Unchecking the box will not allow the DIR-655 to respond to pings. Blocking the Ping may provide some extra security from hackers.
Administrator Settings D-Link DIR-655 User Manual Inbound Filter: This section will list any rules that are created. You may click the Edit icon to change the settings or enable/disable the rule, or click the Delete icon to remove the rule. Remote Admin The port number used to access the DIR-655. Port: Example: http://x.x.x.x:8080 whereas x.x.x.x is the Internet IP address of the DIR-655 and 8080 is the port used for the Web Management interface.
Time Settings D-Link DIR-655 User Manual Manual: To manually input the time, enter the values in these fields for the Year, Month, Day, Hour, Minute, and Second and then click Set Time. You can also click Copy Your Computer’s Time Settings. NTP Server Used: Enter the NTP server or select one from the drop-down menu. Enable NTP NTP is short for Network Time Protocol. NTP Server: synchronizes computer clock times in a network of computers. Check this box to use a NTP server.
SysLog D-Link DIR-655 User Manual SysLog Server IP The address of the SysLog server that will be Address: used to send the logs. You may also select your computer from the drop-down menu (only if receiving an IP address from the router via DHCP). Enable Logging to Check this box to send the router logs to a SysLog Server: SysLog Server. 49 The Broadband Router keeps a running log of events and activities occurring on the Router. You may send these logs to a SysLog server on your network.
Email Settings D-Link DIR-655 User Manual 50 Schedule: This option is enabled when On Schedule is selected. You can select a schedule from the list of defined schedules. To create a schedule, go to Tools > Schedules. On Schedule: Selecting this option will send the logs via email according to schedule. On Log Full: When this option is selected, logs will be sent via email when the log is full. Password: Enter the password associated with the account. Re-type the password associated with the account.
System Settings D-Link DIR-655 User Manual Reboot Device: Click to reboot the router. Restore to Factory This option will restore all configuration settings Default Settings: back to the settings that were in effect at the time the router was shipped from the factory. Any settings that have not been saved will be lost, including any rules that you have created. If you want to save the current router configuration settings, use the Save button above.
Update Firmware D-Link DIR-655 User Manual Check Email Notification of Newer Firmware Version to have the router send an email when there is a new firmware available. Notifications Check Automatically Check Online for Latest Options: Firmware Version to have the router check automatically to see if there is a new firmware upgrade. Browse: After you have downloaded the new firmware, click Browse to locate the firmware update on your hard drive. Click Upload to complete the firmware upgrade.
DDNS D-Link DIR-655 User Manual Timeout: Enter a time (in hours). Password or Key: Enter the Password for your DDNS account. Username or Key: Enter the Username for your DDNS account. Host Name: Enter the Host Name that you registered with your DDNS service provider. Server Address: Choose your DDNS provider from the drop down menu. DDNS: Dynamic Domain Name System is a method of keeping a domain name linked to a changing IP Address. Check the box to enable DDNS.
System Check D-Link DIR-655 User Manual Ping Results: The results of your ping attempts will be displayed here. Ping Test: The Ping Test is used to send Ping packets to test if a computer is on the Internet. Enter the IP Address that you wish to Ping, and click Ping.
Schedules D-Link DIR-655 User Manual Schedule Rules The list of schedules will be listed here. Click the List: Edit icon to make changes or click the Delete icon to remove the schedule. Save: Click Save to save your schedule. You must click Save Settings at the top for your schedules to go into effect. Time: Check All Day - 24hrs or enter a start and end time for your schedule. Days: Select a day, a range of days, or All Week to include every day. Name: Enter a name for your new schedule.
Device Information D-Link DIR-655 User Manual IGMP Multicast Displays the Multicast Group IP Address. Memberships: LAN Computers: Displays computers and devices that are connected to the router via Ethernet and that are receiving an IP address assigned by the router (DHCP). Wireless LAN: Displays the wireless MAC address and your wireless settings such as SSID and Channel. LAN: Displays the MAC address and the private (local) IP settings for the router.
Log D-Link DIR-655 User Manual Save Log: This option will save the router to a log file on your computer. Email Now: This option will send a copy of the router log to the email address configured in the Tools > Email screen. Clear: Clears all of the log contents. Refresh: Updates the log details on the screen so it displays any recent activity. Apply Log Will filter the log results so that only the selected Settings: options appear.
Stats D-Link DIR-655 User Manual Active Sessions 58 The screen below displays the Traffic Statistics. Here you can view the amount of packets that pass through the DIR-655 on both the Internet and the LAN ports. The traffic counter will reset if the device is rebooted.
Wireless D-Link DIR-655 User Manual The WISH details page displays full details of wireless clients that are connected when WISH is enabled. WISH 59 The wireless client table displays a list of current connected wireless clients. This table also displays the connection time and MAC address of the connected wireless clients.
D-Link DIR-655 User Manual Section 3 - Configuration Support 60
Wireless Security What is WEP? • WPA2-PSK (Pre-Shared Key) • WPA-PSK (Pre-Shared Key) D-Link DIR-655 User Manual 61 To gain access to a WEP network, you must know the key. The key is a string of characters that you create. When using WEP, you must determine the level of encryption. The type of encryption determines the key length. 128-bit encryption requires a longer key than 64-bit encryption.
What is WPA? D-Link DIR-655 User Manual 62 WPA/WPA2 incorporates user authentication through the Extensible Authentication Protocol (EAP). EAP is built on a more secure public key encryption system to ensure that only authorized network users can access the network. WPA-PSK/WPA2-PSK uses a passphrase or key to authenticate your wireless connection. The key is an alpha-numeric password between 8 and 63 characters long. The password can include symbols (!?*&_) and spaces.
Wireless Security Setup Wizard D-Link DIR-655 User Manual Click Next to continue. To run the security wizard, click on Setup at the top and then click Launch Wireless Security Setup Wizard.
D-Link DIR-655 User Manual Click Next to continue. If you selected Good, enter 13 characters or 26 Hex digits. If you selected Best or Better, enter a password between 8-63 characters. Click Next to continue. • Best - WPA2 Authentication • Better - WPA Authentication • Good - WEP Encryption • None - No security Select the level of security for your wireless network: Enter the SSID (Service Set Identifier). The SSID is the name of your wireless network. Create a name using up to 32 characters.
D-Link DIR-655 User Manual 65 If you selected WPA-Enterprise, the RADIUS information will be displayed. Click Save to finish the Security Wizard. Click Save to finish the Security Wizard. If you selected Best, the following screen will show you your Pre-Shared Key to enter on your wireless clients. Click Save to finish the Security Wizard. If you selected Better, the following screen will show you your Pre-Shared Key to enter on your wireless clients. Click Save to finish the Security Wizard.
Configure WEP D-Link DIR-655 User Manual 6. Click Save Settings to save your settings. If you are configuring the router with a wireless adapter, you will lose connectivity until you enable WEP on your adapter and enter the same WEP key as you did on the router. 5. Next to Authentication, select Shared Key. 4. Next to WEP Key 1, enter a WEP key that you create. Make sure you enter this key exactly on all your wireless devices. You may enter up to 4 different keys. 3.
Configure WPA-Personal (PSK) D-Link DIR-655 User Manual 67 6. Click Save Settings to save your settings. If you are configuring the router with a wireless adapter, you will lose connectivity until you enable WPA-PSK on your adapter and enter the same passphrase as you did on the router. 5. Next to Pre-Shared Key, enter a key (passphrase). The key is entered as a pass-phrase in ASCII format at both ends of the wireless connection. The pass-phrase must be between 8-63 characters. 4.
Configure WPA-Enterprise (RADIUS) D-Link DIR-655 User Manual 8. Next to RADIUS Server Shared Secret, enter the security key. 7. Next to RADIUS Server Port, enter the port you are using with your RADIUS server. 1812 is the default port. 6. Next to RADIUS Server IP Address enter the IP Address of your RADIUS server. 5. Next to Authentication Timeout, enter the amount of time before a client is required to re-authenticate (60 minutes is default). 4.
D-Link DIR-655 User Manual 11. Click Apply Settings to save your settings. 10. Click Advanced to enter settings for a secondary RADIUS Server. 9. If the MAC Address Authentication box is selected then the user will need to connect from the same computer whenever logging into the wireless network.
D-Link DIR-655 User Manual If you get a good signal but cannot access the Internet, check you TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. The utility will display any available wireless networks in your area. Click on a network (displayed using the SSID) and click the Connect button. Right-click on the wireless computer icon in your system tray (lower-right corner next to the time). Select View Available Wireless Networks.
Configure WEP D-Link DIR-655 User Manual 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. 1. Open the Windows® XP Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower-right corner of screen). Select View Available Wireless Networks. 71 It is recommended to enable WEP on your wireless router or access point before configuring your wireless adapter.
D-Link DIR-655 User Manual It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WEP settings are correct. The WEP key must be exactly the same as on the wireless router. 3. The Wireless Network Connection box will appear. Enter the same WEP key that is on your router and click Connect.
Configure WPA-PSK D-Link DIR-655 User Manual 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. 1. Open the Windows® XP Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower-right corner of screen). Select View Available Wireless Networks. 73 It is recommended to enable WEP on your wireless router or access point before configuring your wireless adapter.
D-Link DIR-655 User Manual It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WPA-PSK settings are correct. The WPA-PSK passphrase must be exactly the same as on the wireless router. 3. The Wireless Network Connection box will appear. Enter the WPA-PSK passphrase and click Connect.
Troubleshooting D-Link DIR-655 User Manual 75 • Disable any internet security software running on the computer. Software firewalls such as Zone Alarm, Black Ice, Sygate, Norton Personal Firewall, and Windows® XP firewall may block access to the configuration pages. Check the help files included with your firewall software for more information on disabling or configuring it. • Verify physical connectivity by checking for solid link lights on the device.
D-Link DIR-655 User Manual 76 To reset the router, locate the reset button (hole) on the rear panel of the unit. With the router powered on, use a paperclip to hold the button down for 10 seconds. Release the button and the router will go through its reboot process. Wait about 30 seconds to access the router. The default IP address is 192.168.0.1. When logging in, the username is admin and leave the password box empty. If you forgot your password, you must reset your router.
D-Link DIR-655 User Manual Example: ping yahoo.com -f -l 1472 ping [url] [-f] [-l] [MTU value] • Once the window opens, you’ll need to do a special ping. Use the following syntax: • Windows® 95, 98, and Me users type in command (Windows® NT, 2000, and XP users type in cmd) and press Enter (or click OK). • Click on Start and then click Run. 77 To find the proper MTU Size, you’ll have to do a special ping of the destination you’re trying to go to. A destination could be another computer, or a URL.
D-Link DIR-655 User Manual • Test your email. If changing the MTU does not resolve the problem, continue changing the MTU in increments of ten. • To change the MTU enter the number in the MTU field and click Save Settings to save your settings. • Click on Setup and then click Manual Configure. • Enter your username (admin) and password (blank by default). Click OK to enter the web configuration page for the device. • Open your browser, enter the IP address of your router (192.168.0.1) and click OK.
Wireless Basics D-Link DIR-655 User Manual 79 Under many circumstances, it may be desirable for mobile network devices to link to a conventional Ethernet LAN in order to use servers, printers or an Internet connection supplied through the wired LAN. A Wireless Router is a device used to provide this link. Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards.
D-Link DIR-655 User Manual 80 In a wireless local area network, a device called an Access Point (AP) connects computers to the network. The access point has a small antenna attached to it, which allows it to transmit data back and forth over radio signals. With an indoor access point as seen in the picture, the signal can travel up to 300 feet.
D-Link DIR-655 User Manual Small Office and Home Office • Stay on top of everything at home as you would at office • Remotely access your office network from home • Share Internet connection and printer with multiple computers • No need to dedicate office space Home • Gives everyone at home broadband access • Surf the web, check email, instant message, and etc • Gets rid of the cables around the house • Simple and easy to use 81 Wireless technology as become so popular in recent years that almost everyone is
D-Link DIR-655 User Manual 82 Place home appliances such as cordless telephones, microwaves, and televisions as far away as possible from the router/access point. This would significantly reduce any interference that the appliances might cause since they operate on same frequency. Eliminate Interference Make sure you place the router/access point in a centralized location within your network for the best performance.
D-Link DIR-655 User Manual 83 An Ad-Hoc network contains only clients, such as laptops with wireless cardbus adapters. All the adapters must be in Ad-Hoc mode to communicate. An Infrastructure network contains an Access Point or wireless router. All the wireless devices, or clients, will connect to the wireless router or access point.
Networking Basics D-Link DIR-655 User Manual 84 If you are connecting to a wireless network at a hotspot (e.g. hotel, coffee shop, airport), please contact an employee or administrator to verify their wireless network settings. If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your router. Some firewall software programs may block a DHCP request on newly installed adapters.
D-Link DIR-655 User Manual Step 5 Click OK twice to save your settings. Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP. Example: If the router´s LAN IP address is 192.168.0.1, make your IP address 192.168.0.X where X is a number between 2 and 99. Make sure that the number you choose is not in use on the network. Set Default Gateway the same as the LAN IP address of your router (192.168.0.1).
• 117Mbps (243) • 78Mbps (162) • 58.5Mbps (121.5) • 39Mbps (81) • 19.5Mbps (40.5) • 6.5Mbps (13.5) • Power • WLAN • Internet • LAN (10/100) Warranty 1 Year Dimensions • L = 7.6 inches • W = 4.6 inches • H = 1.2inches Safety & Emissions • FCC • CE Humidity 95% maximum (non-condensing) Operating Temperature 32°F to 131°F ( 0°C to 55°C) LEDs • Status • USB External Antenna Type Three (3) detachable reverse SMA Antennas Transmitter Output Power 19dBm Frequency Range 2.4GHz to 2.
Phone Support: (800) 361-5265 Monday to Friday 7:30am to 9:00pm EST Internet Support: http://support.dlink.ca Phone Support: (877) 453-5465 24 hours a day, seven days a week. Internet Support: http://support.dlink.com D-Link DIR-655 User Manual For customers within Canada: For customers within the United States: 87 You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues. • Model number of the product (e.g.
Warranty D-Link DIR-655 User Manual 88 The customer’s sole and exclusive remedy and the entire liability of D-Link and its suppliers under this Limited Warranty will be, at D-Link’s option, to repair or replace the defective Hardware during the Warranty Period at no charge to the original owner or to refund the actual purchase price paid. Any repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office.
D-Link DIR-655 User Manual • The customer must obtain a Case ID Number from D-Link Technical Support at 1-877-453-5465, who will attempt to assist the customer in resolving any suspected defects with the product. If the product is considered defective, the customer must obtain a Return Material Authorization (“RMA”) number by completing the RMA form and entering the assigned Case ID Number at https://rma.dlink.com/.
D-Link DIR-655 User Manual 90 EXCEPT FOR THE LIMITED WARRANTY SPECIFIED HEREIN, THE PRODUCT IS PROVIDED “AS-IS” WITHOUT ANY WARRANTY OF ANY KIND WHATSOEVER INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. Disclaimer of Other Warranties: While necessary maintenance or repairs on your Product can be performed by any company, we recommend that you use only an Authorized D-Link Service Office.
D-Link DIR-655 User Manual Copyright ©2006 by D-Link Corporation/D-Link Systems, Inc. All rights reserved. 91 No part of this publication or documentation accompanying this product may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the United States Copyright Act of 1976 and any amendments thereto.
These Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. - - - factory to match the intended destination. The firmware setting is not accessible by the end user.
services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and EN 301 489-17 V1.2.1 (2002-08) services; Part 1: Common technical requirements Electromagnetic compatibility and Radio Spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and EN 301 489-1 V1.6.
Ar šo [name of manufacturer / izgatavotƗja nosaukums] deklarƝ, ka [type of equipment / iekƗrtas tips] atbilst Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Svenska [Swedish] Suomi [Finnish] Slovensky [Slovak] Slovensko [Slovenian] Português [Portuguese] Polski [Polish] Magyar [Hungarian] Malti [Maltese] Nederlands [Dutch] Lietuviǐ [Lithuanian] DirektƯvas 1999/5/EK bnjtiskajƗm prasƯbƗm un citiem ar to saistƯtajiem noteikumiem. Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Registration D-Link DIR-655 User Manual Version 1.1 October 19, 2006 94 Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights.
