2Megapixel HD-SDI Speed Dome Camera User manual Version D0704 DMC-20SEC www.d-max.co.
Mega HD-SDI Speed Dome Camera User manual Content 1. Caution.................................................................................................................................................................................................. 3 2. Product Introduction ........................................................................................................................................................................ 5 3. 2.1. Description and features ...................
2Mega HD-SDI Speed Dome Camera User manual 1. Caution Thank you for purchasing our product. Please operate the product after being fully aware of the manual. Pease contact us if you have any query. Precaution Note the following matters before the installation of the product. Avoid the following places for the installation. A high/low temperature: Using indoor-cameras in the places of +50°C~ -10°C can cause troubles and lower its capacity.
2Mega HD-SDI Speed Dome Camera User manual Caution in Use Do not disassemble the unit and put alien substances in the unit. Disassembling the unit or putting alien substances such as a metal can make the camera defective. - Make sure of power switch-off before the installation. : Ensure power switch-off and check the voltage the camera before the installation. - Do not give the unit a shock and an operation. : Giving a strong shock or an excessive power on the button, terminal can cause problem.
2Mega HD-SDI Speed Dome Camera User manual 2. Product Introduction 2.1. Description and features This camera, 2 Megapixel Full HD-SDI speed dome camera, has been designed elegantly for buildings, department stores that need to be in harmony with the interior as a high speed dome camera, including various observation functions. - Feature - Support full 2.2 Megapixel Full HD-SDI (1080p) Optical x20 zoom rates, Digital x8 zoom rates Enhance Electronic sensitivity lowest illumination 0.
2Mega HD-SDI Speed Dome Camera User manual 2.2. Product package The following items are included in the product package. MEGA Speed Dome Camera 1 pcs Wall Mount Bracket 1 pcs Power Supply (Power Cable & Linear AC24V/2.
2Mega HD-SDI Speed Dome Camera User manual 2.3.Name and function of each part - Exterior - No ① Name Function Wall Mount Bracket Attached wall bracket on the wall ② Camera Housing Outdoor PTZ housing. - when the product is released, outdoor housing and indoor housing are united, when the user installs the camera in indoor and in-ceiling, only use indoor housing taking apart from outdoor housing.
2Mega HD-SDI Speed Dome Camera User manual - Interior System base ① ② No Name Function ① 26-Pin D-SUB Port (Male) Terminal board connect port ② DIP Switch (1~8) DIP Switch (1~4) : Address Setting switch : Set-up Setting switch 8
2Mega HD-SDI Speed Dome Camera User manual Connect Cover Inside ① ⑥ ② ⑤ ③ No ④ Name Function ① Power Port AC 24V / 2.
2Mega HD-SDI Speed Dome Camera User manual 2.4.Installation 1. Installing wall mount bracket Cause Please use Grip when housing and camera dome drive’s Dsub port are connected or disconnected from housing - Not using Grip is caused by disorder when connect or disconnect camera dome drive in the camera housing.
2Mega HD-SDI Speed Dome Camera User manual ③ When the camera is installed retaining wall or Concrete building, put the cables in the bracket as picture and close hole by TAB/P1/11" flexible connector(28") ⑥ Connect D-sub part and camera dome drive with triangle mark of housing as picture. ④ Connect Cover housing to wall bracket as above.
2Mega HD-SDI Speed Dome Camera User manual 2.
2Mega HD-SDI Speed Dome Camera User manual ⑥ Connect to Data, Video and Power ⑧ Connect to the clear bubble ⑦ Recombine housing and dome drive. Housing, Connect D-sub part and camera dome drive with triangle mark of housing as picture.
2Mega HD-SDI Speed Dome Camera User manual 3.
2Mega HD-SDI Speed Dome Camera User manual For connecting cables in the junction box, Please refer to wall mount bracket installation part The PTZ junction box inside part is as below. AC 24V Power Supply AC 24V Input Port AC 24V Output Port Power LED LAN (output) LAN (Input) Output port Input port AC IN AC OUT ※ Please refer to the speed dome junction box user manual.
2Mega HD-SDI Speed Dome Camera User manual 3. DIP switch setting 3.1. DIP Switch setting -Termination Resistor (DIP S2/SW1) (.*** The first default is ADDRESS.**) -Set the communication speed (baud rates) and -Turn the last camera on the data line as a Protocol (Demand for the technical inquiry) up in switch to turn on/off the terminal resistor on. the state of the INITAIL.
2Mega HD-SDI Speed Dome Camera User manual 3.2. Protocol setting Set up the switch The switch for select protocol The switch for select baud rates Change S2 to INIT if user wants to change protocol ① Please the power off ② Switch protocol that user wants to change on in the above the table ③ The power on, then the set protocol and baud rates are displayed. ④ The power off, if every setting is right. Then the change of protocol is finished. ⑤ Change No.
2Mega HD-SDI Speed Dome Camera User manual 3.3. Address DIP Switch Setting ADDRESS is set No 1 ~ 255 by DIP switch 1~8.
2Mega HD-SDI Speed Dome Camera User manual 3.4. OSD Menu setting 3.4.1. OSD Menu control ■ OSD (ON SCREEN DISPLAY) menu control It is the function to call up the Menu of the camera. ◈ User can not only set Preset, Group, Tour, Swing, Trace functions of the camera up by the menu, but also set them up by shortening keys. ■ OSD MENU Enter ① ② The menu is displayed on the screen with the key tone when user presses No.1 and menu key. << DOME CAMERA SETUP >> - DOME DRIVER SET. - CAMERA SET. - SPECIAL SET.
2Mega HD-SDI Speed Dome Camera User manual 3.4.2.
2Mega HD-SDI Speed Dome Camera User manual - DOME DRIVER SET. : Set Pan, Tilt or various surveillance functions. - CAMERA SET. : Set Video, screen display functions. - SPECIAL SET. : Set motion detection, alarm, multi-language, Password, Factory default - EXIT. : Out of OSD menu ■ DOME DRIVER SET 1. SET PTZ FUNCTION Set up or execute Preset, Swing, Group, Tour, Trace. - DOME DRIVE SET. 1. SET PTZ FUNCTION. 2. RUN PTZ FUNCTION:UNDEF 3. SET PRIVACY. 4. MANUAL P/T SPEED:MIDDLE 5.
2Mega HD-SDI Speed Dome Camera User manual PRESET CH:001[PRESET:001] User can select ID letter or icon by using joystick Up/Down/Right/Left. Shift letter digit by "ZOOM !"$%&'()*+,- . /0123456789 :;<=>?@ABCDEFGHIJKLMNOPQRS TUVWXYZ[\]^_,abcdefghijklm nopqrstuvwxyz{ㅣ}~ ZOOM(IN/OUT), ID SHIFT. F/F SAVE, F/N NOT SAVE.
2Mega HD-SDI Speed Dome Camera User manual - SET PRESET & RUN. 1. SELECT PRESET CH:001 2. PRESET ID SET 3. PRESET PTZ SET 4. SWING SET 5. GROUP SET CH:01~12 6. TOUR SET 7. TRACE SET 8. PREVIOUS MENU PAGE. - SWING SET. 1. PAN/TILT SWING 2. START PRESET 3. END PRESET 4. SWING TIME 5. SWING SPEED : UNDEF : 000 : 000 : 000 : 000 F/F SAVE, F/N NOT SAVE. JOYSTICK U/D/L/R TO SELECT. : Moves menu : Changes Setting 1. PAN/TILT SWING TILT – Move Up and Down. PAN – Move Left and Right. 2.
2Mega HD-SDI Speed Dome Camera User manual [P] PESET : Enter PRESET No [S] SPEED : Set movement speed (1~64) 1<64 [T] TIME : Set duration time (1~127 sec) Move next menu (Save PRESET No) Move previous menu Change setting 6). TOUR SET Tour is included 12 groups. - SET PRESET & RUN. 1. SELECT PRESET CH:001 2. PRESET ID SET 3. PRESET PTZ SET 4. SWING SET 5. GROUP SET 6. TOUR SET 7. TRACE SET 8. PREVIOUS MENU PAGE. - TOUR SET.
2Mega HD-SDI Speed Dome Camera User manual ■ TRACE Set ① ② "7. TOUR SET" Press F/N button to select “SET” mode → move camera by using joystick toward position you want up to for 180/sec ③ After finishing all work, move cursor to save mode → press F/N button to save joystick movement • [SET] : Start TRACE set up • [SAVE] : Save and previous OSD screen • [DELETE] : Delete PRESET • [RETURN] : Go to previous OSD screen (Cancellation) 8).
2Mega HD-SDI Speed Dome Camera User manual - DOME DRIVE SET. - PRIVACY ZONE SET. 1. SET PTZ FUNCTION. 2. RUN PTZ FUNCTION:UNDEF 3. SET PRIVACY. 4. MANUAL P/T SPEED:MIDDLE 5. AUTO TILT MOVE:OFF 6. SMART PAN/TILT:ON 7. RETURN TO MAIN PAGE. CH 01: CH 03: CH 05: CH 07: SET BLANK BLANK BLANK CH 02: CH 04: CH 06: CH 08: BLANK BLANK BLANK BLANK PREVIOUS MENU PAGE. SELECT (F/F), CHANGE (L/R) JOYSTICK U/D/L/R TO SELECT.
2Mega HD-SDI Speed Dome Camera User manual 4. MANUAL P/T SPEED User can control the maximum speed in controlling of up and down; The mode is Low, Medium, Max 5. AUTO TILT MOVE The PAN is turned in a 180° degree arc automatically when the angle of the camera moves down to the maximum degree, therefore, it is possible to track objects continuously - DOME DRIVE SET. 1. SET PTZ FUNCTION. 2. RUN PTZ FUNCTION:UNDEF 3. SET PRIVACY. 4. MANUAL P/T SPEED:MIDDLE 5. AUTO TILT MOVE:OFF 6. SMART PAN/TILT:ON 7.
2Mega HD-SDI Speed Dome Camera User manual 2. H-V REVERSE Set up H-V reverse mode. . ● Normal ● H-REV : Flip the picture horizontally on the screen. ● V-REV : Flip the picture vertically on the screen. ● HV-REV : Flip the picture horizontally and vertically on the screen. 3. AGC CONTROL AGC(Automatic Gain Control)- It adjusts the amount of video amplification to maintain a full 1-volt peak-to-peak video signal output automatically. ▶ OFF, LOW, MIDDLE, MAX - CAMERA SET. 1. ID SET(PRESS F/F KEY).
2Mega HD-SDI Speed Dome Camera User manual 7. DNR LEVEL Reduce noise of minimum illumination and also file size becomes smaller while DVR is being recorded by the effective reduction of noise. ▶ OFF, LOW, MIDDLE, MAX ◈ cf. Not available under AGC off 8. NEXT MENU PAGE. ▶ Go to next menu page. - CAMERA SET. 1. ID SET(PRESS F/F KEY). : NORMAL 2. H-V REVERSE : MAX 3. AGC CONTROL : AUTO 4. SHUTTER SPEED : 12 5. SHARPNESS LEVEL 6. BRIGHTNESS LEVEL : 50 : MIDDLE 7. DNR LEVEL 8. NEXT MENU PAGE. 9.
2Mega HD-SDI Speed Dome Camera User manual 14. BACK LIGHT MODE It provides clear images of object and back ground against a severe back light. - CAMERA SET. 10. STABILIZER : OFF 11. FOCUS MODE : ONE SHOT 12. MAX ZOOM LIMIT : x20 13. DSS CONTROL : 10FIELDS 14. BACK LIGHT MODE : OFF/WDR/HLC/BLC 15. WHITE BALANCE : AUTO 16. DAY&NIGHT : AUTO SLOW 17. PREVIOUS PAGE PRESS F/F SET BACKLIGHT ▶ OFF : Disables the BACKLIGHT ▶ WDR : Activates back light.
2Mega HD-SDI Speed Dome Camera User manual - BLC AREA SET. F/F SAVE, F/N NOT SAVE. Move BLC area Reduce BLC Enlarge BLC area area ② It is enables to move BLC area, reduce BLC area and enlarge BLC area by Joystick ZOOM IN/OUT 15. WHITE BALANCE The white balance menus adjusts the balance of the screen colors under differnet lighting condition. ▶ AUTO, INDOOR, OUTDOOR 16. DAY&NIGHT The Day & Night function allows the camera to switch between color and B/W mode.
2Mega HD-SDI Speed Dome Camera User manual ■ SPECIAL SET 1. OSD DISPLAY - SPECIAL SET. << DOME CAMERA SETUP >> 1. OSD DISPLAY : ID+STATUS : SENSOR 2. SELECT ALARM 3. MOTION DETECTION : OFF 4. ALARM CHANNEL ON/OFF. 5. ALARM PRESET SET 6. AUTO REFRESH TIME : 3 Day 7. NEXT MENU PAGE. 8. RETURN TO MAIN PAGE. JOYSTICK U/D/L/R TO SELECT. - DOME DRIVER SET. - CAMERA SET. - SPECIAL SET. - EXIT. JOYSTICK U/D/L/R TO SELECT.
2Mega HD-SDI Speed Dome Camera User manual - SPECIAL SET. 1. OSD DISPLAY : ID+STATUS 2. SELECT ALARM : MOTION 3. MOTION DETECTION : ON 4. ALARM CHANNEL ON/OFF. 5. ALARM PRESET SET 6. AUTO REFRESH TIME : 3 Day 7. NEXT MENU PAGE. 8. RETURN TO MAIN PAGE. PRESS F/F, AREA OR LINE SET. - MOTION DETECTION AREA SET. F/F SAVE, F/N NOT SAVE. ■ Set up motion detection ① "2. SELECT ALARM". Select “motion”. ② "3.
2Mega HD-SDI Speed Dome Camera User manual - ALARM CH On/Off : Alarm Input – Each channel can be ON/OFF. - According to signal connection, user can select ACTIVE OPEN(N/C) or ACTIVE CLOSE(N/O). - If the user selects ACTIVE OPEN, it is activated when Alarm input is open, if the user selects ACTIVE Close, it is activated when Alarm input is Close - Resume Time Set : It can select the delay time that the camera move to the place alarming to observe where wrong signal is sensed.
2Mega HD-SDI Speed Dome Camera User manual ■ Home Position Time It sets the dwell time in Home Position Preset. It automatically moves to where observes ordinarily in the regular time that Master user set in observation of other area, if set Home Position Preset. (You can set 1~180sec. Set control Home Position Preset and Home Position Time together for using this function.) - It is enable to set Alarm by D-max keyboard.
2Mega HD-SDI Speed Dome Camera User manual ■ Short cut key menu Function Group 1 Group 2~11 Group 12 Run Tour Run Pan Swing Run Tilt Swing Operation 51 + Preset 52 ~61 + Preset 62 + Preset 63 + Preset 64 + Preset 65 + Preset Function Run Trace Run Spiral B/W Mode Color Mode OSD Menu ON/OFF Operation 66 + Preset 67 + Preset 68 + Preset 69 + Preset 95 + Preset Caution) it is able to perform the functions in all protocol type 10.
2Mega HD-SDI Speed Dome Camera User manual 13. CHANGE PASSWORD - "13. CHANGE PASSWORD" the user can select password by Joystick Left / Right. - SPECIAL SET. 9. USE SHORTCUT KEY : ON 10. RUN DEHUMIDIFICATION. : ENGLISH 11. LANGUAGE 12. USE PASSWORD : OFF 13. CHANGE PASSWORD. 14. FACTORY RESET ! WARNING! 15. PREVIOUS PAGE. - CHANGE PASSWORD. OLD PASSWORD : 0000 NEW PASSWORD: 0000 JOYSTICK U/D/L/R TO SELECT. F/F SAVE, F/N NOT SAVE. JOYSTICK U/D/L/R TO SELECT.
2Mega HD-SDI Speed Dome Camera User manual Ex) Delete No 5 Preset (Holding 3 seconds) ④ All Preset Movement Press button for 3 sec then beep sound, it follows the steps as below (holding 3 seconds) 2. Swing Setting ① Swing set Set up duration time (1~127 sec) after movement Set up movement speed (1~64sec) ② Swing execute (Pan execute) ③ Swing stop (Tilt execute) 3. Group setting ① Start Group setting mode To set more preset, enter preset No and set same process.
2Mega HD-SDI Speed Dome Camera User manual ② Group execute ③ Group stop 4.
2Mega HD-SDI Speed Dome Camera User manual 5. Spiral Function It is a function to observe objects automatically in the spiral direction. ② Spiral Off Spiral On * 26. “67+PRESET key” is also available in Shortcut key ‘On’ mode 6. PTZ Trace It memorizes P/T/Z motions for 200sec then operates them at the same Trace. ① ▪ Trace execute/Stop ② Trace setting ▪ Cancellation: ③ Trace Cancellation * 26.
2Mega HD-SDI Speed Dome Camera User manual 3.4.4. OSD Message Description 1. PRESET Message CAM-001 CAM-001 CAM-001 SAVE PRESET:001 PRESET:001 CLEAR PRESET:001 User can check that Preset No.1 is saved as an appeared message in Preset set. It appears when moving to the preset No.1. It appears when user deletes PRESET No.1. The message ‘All clear PRESET’ is displayed when user delete PRESER data all at once. 2. SWING Message CAM-001 Display SWING execute in the screen. [SWING] PRESET:001 3.
2Mega HD-SDI Speed Dome Camera User manual 4. TOUR Message CAM-001 Set Tour GP:01 As the message in the time of operation of Tour set, “GP:01” means GROUP No.1 and it shows that GROUP No.1 was saved. CAM-001 [TOUR&GP:01] PRESET:001 As the message in the time of operation of Tour RUN, it will show that moving to PRESET No.1 in GRIOUP No.1. CAM-001 CLEAR TOUR&GROUP. It shows the data in GROUP and TOUR saved was deleted. 5.
2Mega HD-SDI Speed Dome Camera User manual 4. TROUBLE SHOOTING CAUTION IN USE • Make sure that turn the power switch off before installation. • Avoid the places where is the high/low temperature and humid. • Power supply must be min AC24V/1A for indoor (DMS-200) and min AC24V/1.5A for oudoor (DMS-200Se) • Please be careful of that you connect respective wires without mismatching in installation.
2Mega HD-SDI Speed Dome Camera User manual 5.
2Mega HD-SDI Speed Dome Camera User manual 6.
2Mega HD-SDI Speed Dome Camera User manual ■ HD-SDI Repeater • Using 1pcs repeater • Using 2pcs repeater • Using 4pcs repeater 46
2Mega HD-SDI Speed Dome Camera User manual 7. Specification Model Image sensor DMC-20SEC 1/4” 2Mega Panasonic CMOS Scan mode Progressive Scan Number of active pixels 1944(H) × 1092 (V) = 2,122,848 (pixels) Total number of pixels 2010(H) × 1108 (V) = 2,227,080 (pixels) Minimum illumination Color:1.5Lux@F1.6(50IRE), 0.02Lux (Sens-up 60X) B/W: 0.1Lux@F1.6(50IRE), 0.0001Lux (Sens-up 60x) Lens Angle of View 4.45~89mm (20x), Digital Zoom (8x) H:56.56°(Wide)~3.10°(Tele), V:43.32°(Wide)~2.
