Installation Instructions Preference Renaissance Cooktop ® Models: RGC304, RGC365 Part No. 103778 Rev.
Table of Contents Important Safety Instructions........................................... 1 Important Information About Safety Instructions............... 1 General Safety Precautions.............................................. 2 Electrical Requirements.................................................... 3 Gas Supply Requirements................................................ 3 Installation Specifications................................................. 4 Cabinet Layout..................................
Important Safety Instructions Important Information About Safety Instructions IMPORTANT: If you smell gas: • • Do not use or light any appliance. • Do not touch any electrical switch or use any electrical devices, including the telephone, in your building. • From a neighbor’s phone, immediately call the gas supplier. Follow the gas supplier’s instructions. • If you cannot contact the gas supplier, call the fire department.
Important Safety Instructions General Safety Precautions To reduce the risk of fire, electric shock, serious injury or death when using your appliance, follow basic safety precautions, including the following: WARNING • Read the accompanying use and care manual completely before operating this appliance. • Keep packaging materials away from children. Plastic sheets and bags can cause suffocation. • If you receive a damaged product, immediately contact your dealer or builder.
Installation Specifications warning Observe all governing codes and ordinances during planning and installation. Contact your local building department for further information. Electrical Requirements warning To prevent an electric shock hazard, the power supply must meet the specifications stated below. It is the owner’s responsibility to make sure that the electrical service meets electrical requirements and that the electrical outlet has been properly installed.
Installation Specifications Cabinet and Countertop Layout • warning • To reduce the risk of personal injury caused by reaching over a hot appliance, avoid locating cabinet storage space directly above the cooktop. • To reduce the risk of fire hazard, observe all specified clearances. • The back edge of the cooktop must be located a minimum of 2 ½” (64 mm) from any combustible backsplash material. Special cabinet and countertop dimensions may be required.
Installation Specifications Product and Cutout Dimensions All tolerances +1/16” -0 (+1.6 mm, 0) unless otherwise noted. 21" (533 mm) 30" (762 mm) Rear wall 4" (102 mm) Chassis height 1/4" (6 mm) Min. to combustibles below chassis Vertical combustible surface 3 1/8" (79 mm) 27 1/2" (699 mm) 7 1/2" (191 mm) Min. to combustible side wall above the cooktop (both sides) 19 7/8" (505 mm) 25" (635 mm) Min. 2" (51 mm) Min.
Installation Instructions Verify Package Contents • Literature • Hold down brackets (2) • Cleaning kit (stainless steel models only) • Grates • Burner sets (4 for model RGC304, 5 for model RGC365) • Gas pressure regulator Connecting the Gas Line warning • Verify that the gas supply meets specifications before connection. See page 3. • Do not install or use the cooktop without the included gas regulator installed.
Installation Instructions Installing the Burner Components warning • Never attempt to operate the cooktop with any of the burner parts removed. • Do not attempt to adjust the burner air mixture settings. All adjustments are preset at the factory. 1. Remove the burner heads, burner rings, burner caps and grates from their shipping packages. 2. Install the burners as shown. When installing the burner components, twist each piece back and forth until it drops completely into place.
Installation Instructions Verifying Proper Operation warning • Make sure that power to the electrical outlet is turned off at the circuit breaker or fuse box and that the gas is turned off at the gas supply valve before proceeding. • The cooktop must be properly grounded at all times when electrical power is applied. Prior to operating the cooktop, read the accompanying use and care manual carefully. 1. Make sure all the cooktop burner controls are in the OFF position. 2.
Installation Instructions Installation Checklist warning To ensure a safe and proper installation, the following checklist should be completed by the installer to ensure that no part of the installation has been overlooked. Proper installation is the responsibility of the homeowner. The importance of proper installation of your Dacor cooktop cannot be overemphasized.
Wiring Diagrams 10
Wiring Diagrams WIRING DIAGRAM RGC365 120V, 60Hz, 0.235A POWER SUPPLY CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION.
Notes 12
Dacor ● 1440 Bridge Gate Drive, Diamond Bar, CA 91765 ● Tel: (800) 793-0093 ● FAX: (626) 403-3130 ● www.Dacor.
