LCD TELEVISION INSTRUCTION MANUAL DLT-26C2 DLT-26C3 DLT-32C1 DLT-32C2 DLT-32C3 DLT-37C3
Caution CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk electric shock.
Important Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. Read, Retain and Follow All Instructions Read all safety and operating instructions before operating the TV. Retain them safely for future reference. Follow all operations and instructions accordingly. 2. Heed Warnings Adhere to all warnings on the appliance and in the operating instructions. 3.
Important Safeguards 13. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. 14. Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 15.
Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user’s own safety, and the proper operation of the product. WARNING Ignoring or disregarding the contents of this section and improper operation of the product may result in the person’s death or serious injury. In case of an accident, please unplug the unit from the outlet immediately.
Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user’s own safety, and the proper operation of the product. CAUTION Ignoring or disregarding the contents of this section and improper operation of the product may result in the person’s death or serious injury. Please keep the user’s manual in a safe place for future reference.
Table of Contents Installation and Maintenance Antenna Connection . . . . . . . . . . . . . . Video Connection . . . . . . . . . . . . . . . . Camcorder & Video Game Connection. . . DVD player/STB(Set Top Box) Connection . PC Connection . . . . . . . . . . . . . . . . . . Cable TV Broadcasting Connection . . . . . Connect with the Dolby Digital AMP . . . . Name of Each Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplied Accessories Make sure that the following accessories are provided with the product. POWER MUTE DVB/Analog AV ABC 1 2 GHI JKL MULTIMEDIA DEF 3 MNO 4 5 6 PQRS TUV WXYZ 7 8 9 PICTURE 0 VOL PR AC CORD MENU VOL PR OK/SELECT GUIDE SUB TITLE CANCEL/EXIT STILL RECALL ASPECT EDIT SLEEP S.
Supplied Accessories The method of wire arrangement (32C1, 26/32/37C3) 1. Assemble the cable holder enclosed on the back of TV (picture 1). (ASSEMBLY METHOD: After you push the ”A” (prominence part of cable holder) in the hole, rotate the cable holder clockwise as an angle of 90°. You can separate in reverse order of assembly.) 2. Open the cable holder (picture 2), you can open the cable holder that press and push “B” part. 3. After arrange lines with the cable holder, lock the ”B” again (picture 3).
Antenna Connection Indoor Antenna Connection 1. Connect the feeder cable of the antenna to the combining adapter. WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong antenna connection. Be sure to check its direction and place when installing. 2. Connect the combining adapter to the antenna input at the left side of the TV set. WHEN USING THE COMBINING ADAPTER : You may obtain the combining adapter at your closest Service Center.
Antenna Connection CTV Antenna Connection Such community TV Antenna installation may be found in most of co-op apartments. When a coaxial cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to the right. Antenna socket on the wall Antenna socket at the left side of the TV set ANT/CABLE When a feeder cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to the right.
Antenna Connection Outdoor Antenna Connection Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses. Single Antenna Connection Antenna socket at the left side of the TV set VHF Antenna Back of the tv set UHF Antenna ANT/CABLE Separate Antenna Connection.
Video Connection Connecting with an External Source You may connect an S-Video input to enjoy clearer and brighter picture images. You can make the connection with the AV3 input. Note : If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is recommended for better picture quality. Connecting with SCART VIDEO 1. Prepare the scart lead for picture / sound. 2.
Camcorder & Video Game Connection Watching the Camcorder Recording or Video Game on TV 1. Prepare the S-video and RCA connector. 2. These connectors connect to S-video or AV 3 as shown in the picture below. 3. Turn on the TV set and camcorder/video game. 4. Select AV3 or S-video mode, using the ” AV” button of the Remote controller or “ ” button of the TV set.
DVD player / STB (Set Top Box) connection When connecting with a component cable and Euro SCART cable Back of the tv set DVD Note : • When you connect with the component video, please check the colour of the cable between the DVD and TV set. When connecting with a S-VHS cable and RCA cable Back of the tv set DVD Note : If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is recommended for better picture quality.
DVD player / STB (Set Top Box) connection When connecting with a HDMI cable Back of the tv set Set Top Box When connecting with a component cable Back of the tv set Set Top Box Note : • When you connect with the component video, please check the colour of the cable between the Set Top Box and TV set.
PC Connection When connecting with PC(D-Sub) cable. 1. Adjust PC resolution to available resolution in LCD TV. 2. Connect between PC and TV set using the D-Sub and Audio cable like below the picture. 3. Turn on the PC and TV set. 4. Select PC mode by pressing ‘Multimedia’ button on the remote control or ” ” button of the TV set. Back of the tv set PC When connecting with a HDMI cable. 1. Adjust PC resolution to available resolution in LCD TV. 2.
PC Connection PC CONNECTION NOTES: 1) The resolution of the TV set is the best at 1360 x 768 (WXGA). 2) If there is a [Vertical Frequency] setting menu in the [Screen] Menu of the PC, adjust the frequency to 60Hz. 3) If the PC resolution is too high, it may be hard to read letters. Select a suitable resolution. 4) HDMI input port receives only Digital Signal. 5) Depending on the graphic card when plug & unplug the HDMI connection, the screen may not display correctly. Restart the computer if this happens.
Cable TV Broadcasting Connection External Input Connection Source Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver. You may make the connection to any of the Component input and SCART input AV1, AV2. Input Cable TV Broadcasting Station CATV Receiver Antenna Input Connection Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver.
Connect with the Dolby Digital AMP. If you connect the optical output to a Dolby digital AMP, you can listen to better sound.
Name of Each Part Front Panel (DLT-26C2/DLT-32C2) Buttons on the TV set have the same functions as those of the remote controller. Control Key Buttons. ① Buttons : Each time you press this button, the TV will cycle through: TV / AV1 / AV2 / AV3 / S-Video / Component / PC /HDMI / DVB-T ② MENU Button : Use this button to enter and exit the MENU. ③ Buttons : Use these buttons to change your TV’s volume or to move the cursor in the menu.
Name of Each Part Front Panel (DLT-26C3/DLT-32C1/DLT-32C3/DLT-37C3) Buttons on the TV set have the same functions as those of the remote controller. Control Key Buttons. ① Button : Each time you press this button, the TV will cycle through: TV / AV1 / AV2 / AV3 / S-Video / Component / PC /HDMI / DVB-T ② MENU Button : Use this button to enter and exit the MENU. ③ Buttons : Use this buttons to change your TV’s volume or to move the cursor in the menu.
Name of Each Part Side and Rear Panel Left Side of the TV set Rear Panel 23
Parts of the Remote Controller 1. (MUTE) : Press this button, and the sound goes off. Press again, and the sound returns. 2. (POWER) : TV on/off button in Stand-By mode. 3.
Parts of the Remote Controller 18. STILL : Press this button to freeze the picture Note : It works only AV 1, AV 2, AV 3, S-VIDEO, Analog TV, DVB-T 19. ASPECT : Select screen aspect ratio : Auto => 4:3 => 14:9 => Zoom 14:9 => Zoom 16:9 => 16:9 => Auto Note : When current mode is multimedia ( PC, HDMI, Component), the aspect only work as the 16:9 mode. POWER 20. EDIT : You can enter the channel edit mode. It works only in Analog TV mode. AV MULTIMEDIA ABC DEF 21. SLEEP : Sleep Timer setting.
Method To Use Basic Menu Basic Menu - The basic menu appears on the screen if you press the menu button of the remote control. - There are 5 items Picture, Sound, Screen, Utilities, and Setup in the basic menu. - Each item has sub-items under it. If the desired item is selected, the relevant sub-items are displayed upward. 1. Press the “MENU” button. • The main menu appears if you press the “MENU” button. Picture MENU Picture Mode Brightness Contrast Colour Sharpness Tint N.
To Watch TV On/Off, Number, Mute, RECALL[ ], PR , VOL Buttons with same name in the main body performs the same function. Press the “ON/OFF” button of the front or right side of the set or the “POWER” button of Remote controller. • You can also turn on the TV using “ PR ” or digit key in the STBY mode. Note : • The buttons of the remote control and the main body operate only when AC power turn on.
To Watch TV 1. Press the “ (ON/OFF)” button of the front or right side of the set or the “POWER” button of Remote controller. • The Stand-by LED lamp turns on in red colour. • Press “ PR ” buttons of the main body or “POWER” button of the remote control. • The Stand-by LED lamp on the front panel turns red to green colour and the TV turns on. POWER PR 2. Press the “ PR ” buttons. • Select the desired program by pressing the “ PR ” buttons or the number button.
Setting Up TV Stations Auto Tuning - All stations that can be received are stored by this method. It is recommended that you use Auto tuning during installation of this set. 1. Press the “Menu” button to select the Setup menu. • Move the selection bar to the Setup menu with “ UP/DOWN ” buttons. Picture MENU Picture Mode Brightness Contrast Colour Sharpness Tint N.R Move Favourite 42 48 40 32 0 Off Access Exit Setup 2. Select the “Auto Setup”.
Setting Up TV Stations Manual tuning The Manual tuning menu shows you information as follows: - System information: GB, France, E/Euro, W/Euro. - Program number, Station name and Real channel number, frequency. 1. Locate the selection bar on the Manual tuning at the Setup menu. • Press the menu button to select the Setup menu. • Move the selection bar to the Setup menu with “ UP/DOWN ” buttons. • Place the selection bar on Manual Tuning and press the “RIGHT ” button.
Setting Up TV Stations Manual tuning 4. Searching for channel. • Move the selection bar to the Program with “ UP/DOWN ” buttons. • Select a programme number you want to tune finely with the “ LEFT/RIGHT ” buttons. • Move the selection bar to the System and select a system which you want. 5. Enter a station name. • Move the selection bar to the Name with “ UP/DOWN ” buttons. • You can enter a station name with the “ UP/DOWN ”, “ LEFT/ RIGHT ” buttons.
Setting Up TV Stations Edit The Edit menu shows you information as follows: - Program position assignment: Program number, Real channel number, Station name and Skip. VOL PR 1. Skipping the Programs. • Move to EDIT in the Setup menu and press the “RIGHT ” button. • Move the selection bar to program number to skip with the “ UP/ DOWN ”,“ LEFT/RIGHT ” buttons. • Press the “Skip(Red)” button, then the Skip will be changed to Yes from No.
Selection of AV and Multimedia Input Signal When watching video, Camcorder, DVD, Cable TV with AV - See page 12 for connection method of TV and “Video”. - When pressing ” ” button on the TV set, screen changes as follows: Analog => AV1 => AV2 => AV3 => S-Video => Component => PC => HDMI => DVB-T => Analog 1. Press the “AV” button on the remote controller.
Selection of AV and Multimedia Input Signal When connecting PC, STB, DVD with Multimedia 1. Press the “MULTIMEDIA” button on the remote controller. • Screen changes as follows whenever pressing the “MULTIMEDIA” button. Component => PC => HDMI => Component POWER MUTE DVB/Analog AV ABC COMPONENT PR 19 PC PR 19 MULTIMEDIA DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ HDMI PR 19 HDMI & PC mode 1. For optimum picture quality, use 1360x768 computer at a 60Hz refresh rate.
Screen Adjustment When setting up various screen modes - The user may select various screens designed for a good picture without adjusting the brightness, contrast or colour individually. 1. Pressing the “PICTURE” button. • Screen changes as follows whenever pressing the “PICTURE” button. Normal => Cinema => Dynamic => Favourite => Normal • The screen adjustment status changes as the following screens are displayed sequentially whenever pressing the “Picture” button.
Screen Adjustment When adjusting the screen to taste - You can enjoy various screens by adjusting Brightness, Contrast, Colour, Sharpness, etc to the user’s taste. 1. Select Picture by pressing the “Menu” button. • The menu screen appears as follows. Picture MENU Picture Mode Brightness Contrast Colour Sharpness Tint N.R Move 2. Select and adjust each item. • Move to the PICTURE menu.
Screen Adjustment Adjustment of Screen Size in TV and AV mode - Randomly change the size of the screen. - The AUTO screen operates when power is turned on firstly. OK/SELECT 1. Pressing the “ASPECT” button on the remote controller. • The screen changes as below whenever pressing the “Aspect” button. Auto => 4:3 => 14:9 => Zoom 14:9 => Zoom 16:9 => 16:9 => Auto GUIDE SUB TITLE CANCEL/EXIT STILL RECALL ASPECT EDIT SLEEP S.
Screen Adjustment Adjustment of Screen in PC mode 1. Select the PC from the Screen menu. • Press the “RIGHT ” button and the PC mode appears. • Press the ” UP/DOWN ” buttons to adjust the horizontal position of displayed image. 2. Adjustment of the H Position. • Move to H Position in the PC menu. • Press the “ LEFT/RIGHT ” buttons to adjust the horizontal position of displayed image. PC MENU H Position V Position Phase Clock Auto Adjust Move 3. Adjustment of the V Position.
Screen Adjustment 5. Auto Adjust. • Move to Auto Adjust in the PC menu. • Press the “ LEFT/RIGHT ” buttons to detect optimal resolution automatically. Note : • You can adjust the PC menu only in the PC mode. • During the Auto Adjust, you must not alter a screen on the monitor. • During the moving picture, Auto Adjust is able to incorrectly work. So you must execute Auto Adjust in still image. • Auto Adjust incorrectly work at a part graphic card or picture.
Sound Adjustment When selecting various sound modes 1. Sound mode selects what you want. • Press the “S. EFFECT” button, then the sound status changes as followed : Flat => 3D Panorama => Super Bass => Speech => Flat STILL RECALL ASPECT EDIT SLEEP S.EFFECT MGDI Flat 3D Panorama Speech Super Bass Note : • Flat : Suitable for watching any motion picture or allows the user to adjust as desired.
Sound Adjustment When adjusting sound to taste - The user can enjoy various the sounds by adjusting Sound Effect, AVC, Balance and Equalizer. 1. Select Auto Volume Control. • Move to AVC in the Sound menu. • Select either AVC ON or OFF using the “ LEFT/RIGHT ” buttons. Sound MENU Sound Effect AVC Balance Equalizer Move Flat On 0 Access Select Exit Sound 2. Adjust the Balance level. • Move to Balance in the Sound menu. • Adjust the balance level by using the “ LEFT/RIGHT ” buttons.
Sound Adjustment Multi-Sound and Stereo GHI 1. Mono Sound Selection. • In Stereo reception if the stereo is weak, you can switch to MONO by pressing the “ (MTS)” button. Then the colour of “MONO” character will be change to Black. In Mono reception the depth of sound is improved. • To switch back to stereo, press the “ (MTS)” button again.
Utilities Setup of Child Lock 1. Setup of Child Lock. • Move to Child Lock in the Utilities menu. • Select Child Lock to “On/Off” using the “ LEFT/RIGHT ” button. Note : • This prevents the use of the TV set without the remote control. • If TV set is set up Child Lock, LED will cycle through red/green for the ST-BY mode. • If the Child Lock is “On”, the set can only be switched back on using the remote control.
Utilities Adjustment of Time 1. Setting the Clock. • Move to Timer in the Utilities menu. • To go to the Time, press the “RIGHT ” button. • Place the cursor to Hour / Minute with “ LEFT/RIGHT ” buttons. • Set the Hour / Minute with the “ UP/DOWN ” buttons. • Press the Menu button to initialize Time.
Teletext Teletext SWITCHING TELETEXT ON/OFF Press the TELETEXT button ( ). The index page or the page viewed last will appear. Repeatedly press the TELETEXT button the mode in the following order: TV => TELETEXT => Double Window => TV Note : Teletext works only in TV/AV mode. COLOUR BUTTONS IN TOP/FLOF TELETEXT A red, green, yellow and blue field is shown at the bottom of the screen.
Channel Banner (Digital) Channel Banner (Digital) - The channel banner displays information about a channel number, name, broadcasting time, audio service and more. You can see this banner by pressing “OK/SELECT” button or “ UP/DOWN ” buttons on the Remote Control. 1① BBC ONE ② THIS IS BBC ⑤ NOW : 08:00 – 08:50 ⑦ NO SERVICE ③ 08:49 ④ ⑥ Subtitle OFF ⑧ PROFILE ⑨ 1. General Information. ① Channel number: Displays the current channel number. ② Channel name: Displays the current channel name.
Channel Banner (Digital) 2. View the Channel Information. • You can view information of all channels currently listed services. • Press “ UP/DOWN ” buttons to preview the program information of the listed channels. • Press “ LEFT/RIGHT ” buttons to display the now/next program information of the watching channel. • Press “RECALL [ ]” button to display extended information on the current program. If channel has no information, RECALL [ ] button does not work.) 3. View the User Profile List.
Setting up DVB-T System Automatic Tuning of DVB 1. Press the “MENU” button to select the DVB-T Setup. • Move the selection bar to the DVB-T Setup menu with “ UP/ DOWN ” buttons and press the “RIGHT ” button. DVB-T Setup MENU Auto Setup System Move 2. Select the “Auto Setup”. • Place the selection bar on Auto Setup and press the “RIGHT ” button. Access Exit DVB-T Setup MENU Auto Setup System Move 3. Please wait until the Tuning screen disappears. • All available channels are searched automatically.
Setting up DVB-T System DVB-T Setup The System menu shows you information as follows: - Banner Display time, Subtitle Language, Audio Language. - Common Interface, Signal Strength, Software Update. 1. Setting Banner Display Time. • Move to System in the DVB-T Setup. • To go to the Banner Display Time, press the “RIGHT ” button. • Position a selection bar to Banner Display Time.
Setting up DVB-T System 4. Common Interface. • Place the selection bar on Common Interface and press the “RIGHT ” button. • The Common Interface menu provides the Information of CI card inserted into the CI slot, at the left side of the TV. See page 54. Note : • If no CI card is inserted the Message “No CI Module” will be displayed. If you have inserted a CI card, check that it is fully inserted. Common Interface Top Up TV Move Select Back Exit 5. Signal Strength.
Setting up DVB-T System Note : • The whole downloading process may take about 10~15 minutes according to signal status. Software Update Downloading .... Please wait! 0 100% Back Software Update • If you want to start the installation press the “OK/SELECT” button to start. Downloading is completed! Do you want to start the installation? Back WARNING : • During the installation process don’t power off TV. Start Software Update WARNING ! Writing To Flash, Don’t Power Off TV It takes about 2 minutes.
Electronic Program Guide (EPG) VOL PR - The DTV Electronic Program Guide(EPG) displays program information about each channel, up to seven days ahead. - You can edit your own profiles, and record programs. - By pressing the “GUIDE” button to access EPG directly, you can see all channels broadcasting now. OK/SELECT GUIDE SUB TITLE CANCEL/EXIT STILL RECALL ASPECT EDIT SLEEP S.EFFECT Note : • The Program Guide is only available when watching DVB channels. Program Guide 1.
Electronic Program Guide (EPG) 3. Category / Theme Select. • Press the “BLUE” multi function button to display the Category list. • Press the “YELLOW” multi function button to change the Category/Theme list. • Press “ LEFT/RIGHT ” buttons to select the Category/Theme. • Press “OK/SELECT” button to sort the channel • For information of the each program, press the “RED” multi function button and select the program with the “ UP/DOWN ” buttons, press “GREEN” multi function button to display the information.
Common Interface Module Menu - The Common Interface menu allows you to access a pay-per-view (PPV) service on your TV set. This feature operates once you have obtained a CI module and a viewing card. If you want to know the pay-per-view (PPV) service in your region, please contact your nearest PPV provider for detail. Note : • Switch off the TV using the power button before inserting or removing a module.
Common Interface Module Menu 3. Module Information. • You can see information of CI Module. - Serial number, SAP number, Manufacturer, SW version, FW version. CI - Module Information Serial Number: 11410520101045 SAP Number: 904244R10 Manufacturer: SCM Systems SW version: Top Up TV 1.03.002 FW version: 1.04.03 Move 4. Smart Card Information. • This Feature displays the serial number and a term of validity of the module. Select Back Exit CI - Smart Card Information Top Up TV Move 5.
Digital Teletext (MHEG5) - Many broadcasters provide a Digital Teletext service in form of a dedicated Teletext channel. When you switch to a Digital Teletext service, the image you see can contain graphics and text, laid out and controlled in a manner decided by the broadcaster. - In all cases, it is possible to navigate the pages using buttons on the remote control, but because the commands available must apply to all manufacturers of DVB-T equipment.
User Profile - This feature allows you to edit your own profiles on your TV set. You can edit your favorite channels on the Program Guide. - You can add up 3 user profiles. Before starting the user profile menu, you must operate Program Guide. 1. Press “GUIDE” button to move the user profile menu. • Before starting the user profile menu, you must operate Program Guide. • The messages ‘User Profile’ and ‘Please add a profile before continuing.’ will be displayed if no user profile added.
Troubleshooting Symptoms and Solutions Please check the following items before asking for repair service. Symptom Check items Neither picture nor sound - Check the contact of sockets is all right. - Check the TV main power is on. Picture is OK but no sound - Check the Volume control is set to minimum or mute. Sound is OK, but no colour. - Check the colour control and adjust it properly. - Check the program is in colour and not in black & white. The picture has image.
Troubleshooting In DVB-T mode Some Problems will only occur when viewing DVB channels. Due to the different techniques involved in digital reception, DVB signal quality can be poor even if you appear to have a strong signal when viewing analogue programmes. The DVB system requires a good quality signal to provide the best picture. When viewing analogue pictures, interference such as signal reflection from nearby buildings or mountains causes ‘ghosting’, but still provides a viewable picture.
Troubleshooting In PC mode Symptom Check items “OUT OF RANGE” appears on the screen - Check the resolution and frequency of your PC. Then, adjust them to optimum condition for LCD TV. - Refer to the table of PC mode input format (If registered resolution and frequency on the table no listed then no picture will be displayed.) “NO SIGNAL” appears on the screen. - Ensure that the signal cable is firmly connected to PC and TV. Image is not clear. - Adjust the PHASE control. Image is not centered.
Standard of Product Model Features DLT-26C2 DLT-32C2 LCD Panel Screen Size 26” 32” Aspect Ratio 16:9 16:9 TV System Resolution 1366 x 768(WXGA) 1366 x 768 (WXGA) Pixel Pitch 0.4215 mm 0.51075 mm Contrast Ratio 1000 : 1 800 : 1 Receiving System PAL-I, B/G, D/K, SECAM-B/G, D/K, DVB-T Stereo System Power Consumption 2-Carrer/NICAM Max. 130W 150W Power Source 100-240V, 50-60Hz 100-240V, 50-60Hz Dimension (W x H x D) Set Dimension 812 x 502.7(456.
