Antenna
Connection
CTV Antenna Connection
Such community TV Antenna installation may be found in most of co-op apartments.
When a coaxial cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to the right.
Antenna socket at the left side of the TV set
Antenna socket on the wall
ANT/CABLE
When a feeder cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to the right.
Antenna socket on the wall
Antenna socket at the left side of the TV set
ANT/CABLE
Feeder cable connection with the combining adapter
