S/M No. : WDF1011001 Service Manual Washing Machine Model: DWD-F1011/1012/1013/1014 DWD-F1211/1212/1213/1214 NFL-1065/1265 DWD-F1021/1022/1023 DWD-F1221/1222/1223 ✔ Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center DAEWOO ELECTRONICS CORP. Mar.
AUTO WASHER WASHER AUTO WASHER AUTO WASHER WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO AUTO WASHER AUTO AUTO WASHER Contents WASHING MACHINE WASHER AUTO WASHER AUTO AUTO WASHER AUTO WASHER AUTO WASHER AUTO AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
1. SPECIFICATIONS ■ DWD-F1X1X SERIES HOT (OPTION) COLD INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER DWD-F1011(S) / 1012(S) / 1013(S) / 1014(S) DWD-F1211(S) / 1212(S) / 1213(S) / 1214(S) NFL-1065 / NFL-1265 MODEL POWER SOURCE 220-240V, 50Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 64kg WATER CONSUMPTION 47~59l POWER CONSUMPTION 2200W MAXIMUM MASS WASH 6 / 6.5 / 7 kg OF TEXTILE SPIN 6 / 6.
■ DWD-F1X2X SERIES HOT (OPTION) COLD INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER DWD-F1021(S) / F1021(S) / F1023(S) DWD-F1221(S) / F1221(S) / F1223(S) MODEL POWER SOURCE 220-240V, 50Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 64kg WATER CONSUMPTION 47~59l POWER CONSUMPTION 2200W MAXIMUM MASS WASH 6 / 6.5 / 7 kg OF TEXTILE SPIN 6 / 6.5 / 7 kg WASHER TYPE DRUM TYPE (FRONT LOADING WASHING MACHINE) OPERATING WATER PRESSURE 0.
2. INSTALLATION ■ Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. ■ Removing transit bolts 1. To prevent internal damage during trnasport, the special 3 bolts are locked. Before operating the washer, remove the bolts along with the rubber bungs. • If they are not removed, it may cause heavy vibration, noise and malfunction. 3. Close the holes with the caps supplied. 4 INSTALLATION 2.
■ Installation place requirement Level floor : Allowable slope under entire washer is 1° Power outlet : Must be with 1,5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required. (10cm : rear / 2cm : right & left side) Do not place or store laundry products on top of washer at any times. They can damage the finish or controls. ■ BS Plug Safety Details (For U.K.
■ Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar of the inlet hose to separate it from the water tap adapter. 2 Loosen the four screws properly in order to fit into water tap.
■ Installation of drain hose • When installing the drain hose in sink, secure it tightly with a string. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • The drain hose should not be placed higher than 100cm above the floor. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • When the drain hose is too long, do not force back in to the washer. This will cause abnormal noise.
■ Level adjustment 1. The level adjustment of the washing machine prevents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: the wooden floor may cause excessive vibration. leg 2. If the floor is uneven, adjust the adjustable leg as the following. (Do not insert pieces of wood etc. under legs.) • Please check whether there is any gap between four adjustable legs and the floor.
3. MAINTENANCE ❈ Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. ■ Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive houshold detergent. Immediately wipe off any spills. Wipe with damp cloth. Try not to hit surface with sharp objects. • Do not use methylated spirits, diluents or similar products. 2.
■ Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • If your water is very hard or contains traces of lime deposit, the water inlet filter may become clogged. • It is therefore a good idea to clean it from time to time. 1. Turn off the water tap. 1. Turn off the water tap. 2. Unscrew the water inlet hose. 2. Unscrew the water inlet hose. 3. Clean the filter using a had bristle brush. 4. Tighten up the inlet hose.
■ Cleaning the detergent case ❈ After a while detergents and fabric softeners leave a deposit in the detergent case. max MAX MAX • It should be cleaned from time to time with a jet of running water. • If necessary it can be removed completely from the machine by pressing the catch downwards and by pulling it out. • To facilitate cleanling, the upper part of the fabric softener compartment can be removed.
4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gaske clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove four screws on the back cover, and remove the back cover. 12 DIRECTION FOR DISASSABLY 2) Remove connectors and the earth terminal.
3) Remove the nut by using a box wrench, and remove the earth terminal. 4) Loosen the nut by using a box wrench, and pull out the heater. UNIVERSAL MOTOR 1) remove the belt from the pulley. 2) Lay the right side of the washer on the floor, and remove the connector. 3) Remove two bolts and two nuts mounting the motor by using a box wrench. 4) Remove the motor from the tub.
DRAIN PUMP 1) Lay the right side of the washer on the floor, and remove the lower panel by pressing six sanp fits. 2) Remove connectors. 3) Remove the screw, and remove the drain pump from the lower frame. 4) Remove the drain hose. 5) Remove the inner drain hose, and remove the drain pump.
5. EXPLODE VIEW AND PARTS LIST ■ BOX INLET AS (DWD-F1X1X SERIES) No.
■ BOX INLET AS (DWD-F1X2X SERIES) No.
■ PANEL FRONT AS (DWD-F1X1X SERIES) No.
■ PANEL FRONT AS (DWD-F1X2X SERIES) No.
■ CABINET FRONT AS No.
■ TUB ASS’Y 20 EXPLODE VIEW AND PARTS LIST
No.
■ CABINET AS 22 EXPLODE VIEW AND PARTS LIST
No. E01 E02 E03 E04 E05 E06 E07 E08 E09 E10 E11 E12 PART NAME CABINET SPECIAL SCREW FRAME UPPER SCREW TAPPING FRAME TOP-L FRAME TOP-R STOPPER SPRING COVER BACK AS SENSOR PRESSURE FRAME LOWER BASE U-L BASE U-R CAP WATER REMAIN PART CODE 3610811100 3616029100 3612205800 3616029950 3612205600 3612205700 3615202200 3611425510 3614825300 3612205500 3610392200 3610392300 36189L4F10 36189L4E10 3610916800 SPECIFICATION Q'TY SGCC, T0.8, PAINTING 1 M4x12.5, MACHINE 2 SGCC T1.
■ PLATE T AS + PANEL LOWER AS (DWD-F1X1X SERIES) No.
■ PLATE T AS + PANEL LOWER AS (DWD-F1X2X SERIES) No.
6. FUNCTIONS OF THE CONTROL PANEL ■ DWD-F1X1X SERIES ■ DWD-F1X2X SERIES Power Switch Press this buton to turn the power ON or OFF. Start/Hold This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed. Spin Speed Button By pressing this button, the spin speed can be chosen.
Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00" is displayed. The maximum delayed time is 12:00 hours and the minimum time is 2:00 hours. Each pressing of the button advances on time delay by one hour.
7. FUNCTIONS OF THE CONTROLLER ■ SEQUENCE CHART Division Sensing P R Water Supply E Pre Wash W Drain A S B-Spin H Middle Spin Sensing Water Supply M A I N Wash 1 (Heating) W A S H Wash 2 R I N S E Cotton Progress Time Drain B-Spin Middle Spin Water Supply Rinse 1 Drain B-Spin Middle Spin Water Supply Rinse 2 20sec. 2min. 10min. 8min. 1min. 1min. 3min. 20sec. 2min. 70min. 60min. 35min. 30min. 20min. 15min. 10min. 83min. 63min. 23min. 1min. 1min. 4min. 2min. 3min. 1min. 1min. 4min. 2min. 3min.
Division Soak P R E W A S H Water Supply Wash 1 (Heating) Wash 2 Drain B-Spin Middle Spin Water Supply Rinse 1 Drain B-Spin R I Middle Spin N S Water Supply E Rinse 2 Drain B-Spin Middle Spin Water Supply S P I N Rinse 3 Drain B-Spin Progress Time 30min. 2min. 1min. 15min. 10min. 5min. 20min. 10min. 5min. 1min. 1min. 4min. 2min. 1min. 3min. 1min. 1min. 4min. 2min. 1min. 3min. 1min. 1min. 4min. 2min. 1min. 3min. 1min. 1min.
8. FUNCTION OF THE CONVENIENT SERVICE ■ The test mode of the load movement You can check the PCB ASS'Y and the condition of each load movement simply. • The method to enter 1 Press the Power switch button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Each load makes a movement as follows, whenever the Time Delay button is pressed a time.
9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. CAUSE SOLUTION Rattling and clanking noise Foreign objects such as coins or safety pins maybe in the drum or pump Stop washer and check drum and filter. Thumping sound Heavy wash loads may produce a thumping sound. This is usually normal.
SYMPTOM Washer does not start. Washer will not spin. SOLUTION Electronical power cord may not be plugged in or connection may be loose. Make sure plug fits tightly in wall outlet. House fuse blown, circuit breker tripped, or a power outage has occurred. Reset circuit breaker or replace fuse. Do not increase fuse capacity. If problem is a circuit overload, have it corrected by a qualified electrician. Water supply tap is not turned on. Turn on water supply tap. Check that the door is firmly shut.
MESSAGE IE OE ERROR WATER INLET ERROR DRAIN ERROR UE UNBALANCE ERROR LE DOOR OPEN ERROR E2 OVERFLOW ERROR CAUSE The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. The water level sensor (sensor pressure) is an inferior product Change the water level sensor or broke down. (sensor pressure). The drain motor works during water supply.
MESSAGE ERROR H5 WATER TEMP. ERROR H6 H8 lb PFE 34 CAUSE The water temp. is over 45°C in delicate & wool course. (The thermistor wash is an inferior product or broke down.) HEATER WASH The heater wash dose not work. ERROR (The water temp. doesn't rise over 2°C during 15min.) HEATER WASH OVERHEATING The heater worked without the water in the tub. ERROR IGBT ERROR PUMP FILTER ERROR SOLUTION Change the thermistor wash. Change the heater wash. Check the water level and the heater wash.
10.
DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M No. : WDF1011001 PRINTED DATE: Mar.
