Foreword General This user’s manual (hereinafter referred to as "the Manual") introduces the characteristics, basic configurations, daily operation and maintenance of the thermal camera (hereinafter referred to be "the Device"). Thermal hybrid camera contains all the binocular and trinocular cameras.
No. Version Revision Content 4 V1.0.3 Function of safety management modified. Parameters of camera modified. Screenshots of interfaces updated. GDPR requirements added. Release Time July 15, 2018 Privacy Protection Notice As the device user or data controller, you might collect personal data of others such as face, fingerprints, car plate number, Email address, phone number, GPS and so on.
Table of Contents Cybersecurity Recommendations ........................................................................................................... I Regulatory Information ........................................................................................................................... III Foreword .................................................................................................................................................. IV 1 Product Introduction .....................
4.2.6 Configuring UPnP ............................................................................................................. 78 4.2.7 Configuring SNMP ............................................................................................................ 78 4.2.8 Configuring Bonjour .......................................................................................................... 81 4.2.9 Configuring Multicast .............................................................................
5.5 Version Information ................................................................................................................... 155 5.6 System Log ............................................................................................................................... 156 5.6.1 Searching System Logs.................................................................................................. 156 5.6.2 Remote View..........................................................................
1 Product Introduction 1.1 Overview Thermal Hybrid Camera is based on requirements such as temperature measurement, fire prevention, safety protection and night vision. This product can help you view videos, videotape an object, test temperature, warn the potential fire, track a cold/hot spot and analyze a special behavior.
Figure 1-1 Application scenarios 1.3 Functions Live Table 1-1 Function description Function Description Real-time preview You can view both the visible images and thermal images. You can use thermal images to identify an object, and then use visible images to view more details of the object. PTZ operation For those cameras with PTZ, you can use the PTZ to operate the cameras to enlarge the surveillance range and identify details of an object.
Function Description Real-time spot temperature measurement For cameras with temperature measuring, you can check the real-time temperature data of any spot in your monitoring area. Laser ranging For cameras with laser ranging, you can measure the distance between the camera and the object in the middle of the image. Additional functions Switch video bit stream or streaming protocol.
Management of Add, modify or delete an account group. user group Manage user permissions based on user groups. User Add, modify or delete a user account. Management Set the user permissions. Change password Change users’ admin password. External Device Management You can manage your camera’s external devices such as heater, fill light and wiper.
Function Description You can implement operation of motion detection and video masking detection. Video detection When there is an alarm, you can implement following operations at the same time such as linkage video recording, alarm output, email delivery, PTZ operation and screenshots. Supports detection of input exception and mutation of acoustic intensity.
Function Additional functions Description Supports enabling or closing temperature testing rules. Supports enabling or closing isotherm. Supports enabling or closing color code articles.
2 Basic Settings 2.1 Device Initialization When using the Device for the first time or after the Device is restored to factory settings, you need to initialize the Device. To initialize the Device, you can log in the web client or use the ConfigTool. Web client is taken as an example for detailed description. The Device cannot be used if not initialized. To secure your admin account, please keep the password properly and change it regularly.
Management > User Management > User to implement the settings. See "2.4 Resetting Password" for more details. Step 2 Click Save to complete initialization. After you have initialized the Device, if the Online Upgrading is displayed, please operate according to the interface prompts. 2.2 Modifying IP Address Default IP address of all devices is 192.168.1.108. When you use the Device for the first time or there is change of the network, modify IP address of your device according to network planning.
2.2.2 Modifying Several IP Addresses When there are several devices or the login passwords of devices are the same, you can modify several IP address at the same time through the ConfigTool. Preparation You have obtained the installation package of ConfigTool. To obtain the installation package, you can consult technical support staffs. You have achieved network communication between PC (which is with ConfigTool) and the Device. Procedure Step 1 Click . The Modify IP interface is displayed.
Select the check box of The Same IP and set the IP addresses of the Devices you have picked up as the same one. Step 6 Click OK to finish configuration. 2.3 Logging in Web Interface After you have modified the IP addresses, you can log in the WEB interface of the Device through a browser to operate, configure and maintain the Device. Background Information To log in the Device in a smooth way, you need to make sure that the PC connected to the Device satisfies the following requirements. See Table 2-1.
Functions of different devices might vary, and the actual product shall prevail. Figure 2-5 Live Interface Click Log out on the upper right corner to exit the interface. 2.4 Resetting Password If you forget the password, you can use the reserved E-mail address to achieve password resetting. Step 1 Open IE browser and type the camera’s IP address. Then press Enter. The Thermal Camera interface is displayed. See Figure 2-6.
Figure 2-7 Reset the password(1/2) Step 3 Reset the password. Scan the QR code, and the security code will be sent to the email address you have already fulfilled. Type the security code then. Reset the password in time when you receive the security code, because the security code will be invalid within 24 hours. If you get security codes twice but do not use them, when you get the security code for the third time, the system will prompt failure.
3 Daily Operation 3.1 Live On the Live interface, you can do operations to the real-time surveillance images such as viewing, taking snapshots and recording videos. Functions of different devices might vary, and the actual product shall prevail. Image channel with a box around it is the one that has been chosen. All your operation is valid only to this channel. Double-click an image channel and the image channel is displayed in a full video display area.
No. Name Description 2 Encode bar Select bit stream type and streaming protocol when previewing a video. Main Stream: It has large bit stream value and image with high resolution, but also requires large bandwidth. This option is normally used for storage and surveillance. Sub Stream: It has small bit stream value and smooth image, and requires little bandwidth. This option is normally used to replace main stream when bandwidth is not enough.
No. 5 Name Description Zoom in You can zoom in video image with two operations: Click the icon to enlarge part of visible light or thermal images. Right-click to resume. Click the icon to zoom a video image by scrolling the mouse. Click the icon to capture a live image and save it under the path you have set. 6 Snapshot To check or modify the storage path, see "4.7.2.1 Configuring Storage Path.
3.1.3.1 Image Adjustment Adjust brightness, contrast, hue and saturation of video images on your web. For detailed operations, see "4.1.1 Configuring Lens." Click , and the Image Adjustment interface is displayed at the right side of live interface. See Figure 3-5. Figure 3-5 Image adjustment interface Table 3-3 Image adjustment configuration Icon Function Description Brightness Adjusts the overall image brightness, change the value when the image is too bright or too dark.
Adjust focal length of your lens to zoom in or out surveillance images; adjust optical afterfocus of your lens to improve clarity level of video images. Click , and the zooming and focusing interface is displayed at the right side of live interface. Select the visible channel and you can zoom, focus and change the aperture. Select the thermal channel and you can zoom and focus. Table 3-4 Zoom and focus description Parameters Description Variable focal length Click Auto focus Auto focus.
Figure 3-6 Temperature recording area 3.1.4 More Functions 3.1.4.1 Real-time Spot Temperature Measuring Only devices with temperature-measuring function support this function, and the actual product shall prevail. Move the pointer to any position of the video image and click. Then the real-time temperature of this spot is displayed. See Figure 3-7. Figure 3-7 Real-time spot temperature measuring 3.1.4.
Mind the distance during laser ranging. Less than 50 m will result in a damaged laser. Click Start Ranging, and the camera starts to measure the distance from itself to the object in the middle of the image (as indicated with the red cross sign). 3.2 PTZ 3.2.1 Bullet Camera PTZ setting of bullet camera is used for controlling external PTZ device. Connect the Device to external PTZ through RS-485 port before using this function. 3.2.1.
Step 3 Click Save to finish configuration. 3.2.1.2 Configuring PTZ Functions The protocol setting has been completed. For detailed operations about protocol setting, see "3.2.1.1 Configuring Protocol". For images representing the effect of external PTZ, you need to preview on the preview images of the external PTZ, not on the preview image of the bullet camera. The following functions are available only when your bullet camera is connected to the external PTZ. 3.2.1.2.
Step 2 Through the direction button, move the camera to the surveillance direction that you need. Step 3 In the preset box, type the preset number. Range of the preset number is limited by the PTZ protocol. Step 4 Click Add to add a preset. Step 5 Enter a preset number and click Go to. The camera turns to the corresponding position. 3.2.1.2.
3.2.1.2.5 Turing on Wiper Step 1 Click the PTZ tab and select Wiper in the PTZ Function setting list. See Figure 3-11. Figure 3-11 Wiper Step 2 Click Enable to enable the wiper; click Disable to disable it. 3.2.1.3 Operating PTZ The corresponding protocol setting and function setting have been completed. See "3.2.1.1 Configuring Protocol" and "3.2.1.2 Configuring PTZ Functions" for more details.
2 Speed 3 Zoom, focus and iris 4 PTZ function Controls the movement speed. The bigger the value is, the faster the movement will be. With this function, you can also change the speed of adjusting the PTZ direction, zooming, changing the focal length and adjusting the aperture. Click bigger; click smaller. and the zoom, focus and iris’ value becomes and the zoom, focus and iris’ value becomes For detailed operations of PTZ, see "3.2.1.2 Configuring PTZ Functions." 3.2.1.
Figure 3-14 Network PTZ setting Step 2 Select the protocol that is matched with the camera. Step 3 Click Save to finish configuration. 3.2.2.2 Configuring PTZ Functions Select Setting > PTZ > Function and the Function interface is displayed. It’s set by default that the thermal image is displayed. In the thermal image, you can click to switch the image to visible image. And, in the visible image, you can click to switch the image to thermal image. 3.2.2.2.
2) 3) Operate the PTZ control panel to move the camera lens to a specific direction you need. Double-click the preset’s Number to modify it. Some presets are already endowed with fixed and special functions by this camera producer. See Table 3-7. If you want to use those functions, you can set these presets’ No. to be the Number. Table 3-7 Function description of the very presets Preset No. Description 21 Enable this preset.
Figure 3-16 The tour interface Step 2 Configure tour. 1) Click Add to add a tour. 2) Click Add to add a preset. Click repeatedly to add several presets. 3) Double-click to select a preset. And double-click to configure the lasting time. 4) Double-click the touring name that you have added to modify it. Click Save to finish configuration. Click to delete a tour or a preset. Step 3 Select a tour and click Start to start camera tour. Click Stop to stop the tour. 3.2.2.2.
Figure 3-17 The scan interface Step 2 Configure scan. 1) Select a Scan No. and set its Speed. 2) Click Setup. Buttons of Set Left Limit and Set Right Limit are displayed. 3) Operate the PTZ control panel and move the camera to a left border you want and click Set Left Limit; move the camera to a right border you want and click Set Right Limit. Step 3 Select a Scan No. and click Start to start scan. Click Stop to stop the scan. 3.2.2.2.
Figure 3-18 The pattern interface Step 2 Configure pattern. 1) Select a Pattern No. 2) Click Setup. Buttons of Start Rec and Stop Rec are displayed. 3) Click Start Rec. 4) Operate the PTZ control panel and adjust you camera’s direction, zoom and focus. 5) Click Stop Rec to finish configuration. Step 3 Select a Pattern No. and click Start to start pattern. Click Stop to stop the pattern. 3.2.2.2.
3.2.2.2.6 Configuring PTZ Speed PTZ speed is determined by two factors—firstly and basically, the speed level (low, middle and high, marked by ① in Figure 3-20); secondly, the control panel’s speed value (1, 2, 3…8 marked by ② in Figure 3-20). If you select Low as the PTZ Speed ①, then according to the maximum Low value, the Speed② will be divided into 8 parts, and it’s the same for you to select Middle or High as the PTZ Speed ①. Step 1 Select Setting > PTZ > Function > PTZ Speed.
Figure 3-21 The idle motion interface Step 2 Configure idle motion. 1) Select the Enable check box to enable this function. 2) Select an idle motion and set idle time. 3) After you have set a value of idle time, when the time when you do not operate the PTZ is longer than that value, the idle motion will be implemented immediately. Click Save to finish configuration. 3.2.2.2.8 Configuring Power Up If you want the PTZ to implement certain actions after the camera is powered, configure this function.
Figure 3-22 Power up Step 2 Select the Enable check box. Step 3 Select the Power Up actions. Select Auto and the PTZ will continue to implement the action before the power is off. Step 4 Click Save to finish configuration. 3.2.2.2.9 Configuring Time Task You can configure a time task and let camera implement certain actions within the period you have set. Preparation You have configured preset, tour, scan and pattern before configuring time task.
Figure 3-23 The time task interface Step 2 Configure time task. 1) Select the Enable check box to enable this function. 2) Select a Time Task Num. 3) Select a Time Task Action from Preset, Tour, Scan and Pattern. 4) When you set Preset as Time Task Action, the Action Number selection box is displayed. You can select the action number based on your needs. In the Auto Home selection box, set the time for the camera to return to its previous condition.
Figure 3-24 The PTZ restart interface Step 2 Click PTZ Restart. PTZ restarts. 3.2.2.2.11 Restoring PTZ to the Default Settings The operations below will delete all the PTZ settings you have configured. Please be cautious. Step 1 Select Setting > PTZ > Function > Default. The Default interface is displayed. See Figure 3-25.
Figure 3-25 The default interface Step 2 Click Default. All your PTZ settings are restored to the default ones. 3.2.2.3 Operating PTZ The corresponding protocol settings and function settings have been completed.
Figure 3-26 PTZ control panel Table 3-8 Parameter description No. Function Description 1 Direction button Eight directions are contained: up, down, left, right, upper left, upper right, lower left, and lower right. 2 Speed Controls the movement speed. The bigger the value is, the faster the movement will be. With this function, you can also change the speed of adjusting the PTZ direction, zooming, changing the focal length and adjusting the aperture.
If you want to export or import presets, you have to obey the following steps. Step 1 Select Setting > PTZ > Preset Backup. The Preset Backup interface is displayed. Figure 3-27 Preset backup Step 2 Export or import presets. Click Export to export presets for backup. Click Import to import presets you have already backed up 3.3 Playback Playback of both videos and pictures is supported. Functions of different devices might vary, and the actual product shall prevail.
Figure 3-29 Video playback Table 3-9 Function bar description No. Functions Description 1 Playback control bar For detailed information about control buttons, see "3.3.1.2 Operate Control Bar." Controls playback volume. 2 3 4 Volume adjustment muted. muted, and the volume can be adjusted. Record type Record type includes All, General, Event, Alarm, and Manual. You can select according to your actual needs. Time bar Displays the record type and the time period.
Table 3-10 Playback control bar Icons Functions Description Play Click this icon to play video. Stop Click this icon to stop playback. Play by Frame Click this icon to play the next frame. You need to pause the playback before using play by frame. Slow playback Click this icon to slow down the playback. Fast playback Click this icon to speed up the playback. 3.3.1.3 Playing Back Videos There are differences in operation of video playback according to the differences of data sources.
Each color on the time bar represents a certain record type. See the matching relationship in Figure 3-30. Step 4 Play video. Click in the playback control bar. The system plays the recorded video of the selected date (in time order). Click any point in the colored area of the time bar. See Figure 3-32. The playback starts from that point. Figure 3-32 Time bar Click , and the video files of the selected date will be listed. Double-click a file in the list. See Figure 3-33.
Operation Description between the entered start time and end time. Select dav or mp4 in the Download Format. Then click Download . The file will be downloaded to the set storage path. For detailed operations of setting the storage path, see "4.1.2.5 Configuring Storage Path." Downloading and playing video at the same time is not supported. Back Click to go back to the calendar interface. 3.3.1.3.2 Playing Back Local Videos Step 1 In the Data Src box, select video type. See Figure 3-30.
Step 1 In Video Format, select dav or mp4. Step 2 Click on the time bar to select the start time, and then click to start. Step 3 Click again on the time bar to select the end time, and then click Step 4 Click to finish. . The system prompts that you cannot play back and download a recorded video at the same time. Step 5 Click Save. The system stops playback and save the edited file under the storage path you have set. For detailed operations of setting the storage path, see "4.1.2.
No. Function Description 2 Snapshot type selection There are three types including General, Event and Alarm, and you can select one of them according to actual needs. 3 Playback file list You can select file type and snapshot data. 3.3.2.2 Picture Playback You can check and play a snapshot image based on your own needs. Step 1 Select a snapshot type in the selection bar of snapshot type. See Figure 3-37. Figure 3-37 Snapshot type selection Step 2 Select jpg in File Type. See Figure 3-38.
Figure 3-39 List of playback files Table 3-13 Picture Playback file more operations Operation Description Enter starting time and ending time, and click Search . Finds out all the picture files between the entered starting time and ending time. Click , and the file is downloaded to local host. Download The download operation might vary with different browsers, and the actual interface shall prevail. Back Click to go back to the calendar interface. 3.
Step 1 Click the Report tab. The Report interface is displayed. See Figure 3-40. Figure 3-40 Report Step 2 Set the conditions for searching and click Search. Temperature data you have searched is displayed. See Figure 3-41. Figure 3-41 Result of report searching 3.5 Alarm You can select alarm type as needed, when the selected alarms are triggered, the system would record detailed alarm information at the right side of the interface.
Alarm Type Description Condition Disk error The alarm is triggered when there is SD card error or abnormality. You have enabled detection to SD card storage space. For detailed operations, see "4.5.5.1 Configuring SD Card Abnormality Parameters." External alarm The alarm is triggered when there is alarm from external device. There is an alarm input port and the external alarm is enabled. For detailed operations, see "4.5.4 Configuring Alarm.
Figure 3-42 Alarm Step 2 Select an alarm type. Step 3 Select Prompt, and the system prompts and records alarm information as needed. If you are not in the Alarm interface when alarm events you have subscribed are triggered, there will be a displayed on the Alarm tab and the alarm information will be recorded. Click the Alarm tab, and the sign disappears.
4 Setting Click Default, and the Device is restored to default configuration. Click Refresh to view the latest configuration. 4.1 Configuring Camera Configure camera’s components such as lens, video and audio to ensure proper surveillance. Functions of different devices might vary, and the actual product shall prevail. 4.1.1 Configuring Lens 4.1.1.1 Configuring Visible Image 4.1.1.1.
Parameter Description Style Select display style of the video image, including Soft, Standard and Vivid. Brightness Changes the value to adjust the picture brightness. The bigger the value is, the brighter the picture will be. Contrast Changes the contrast of the picture. The bigger the value is, the more the contrast will be between bright and dark areas. Saturation Makes the color deeper or lighter. The bigger the value is, the deeper the color will be.
Parameters and its description in Table 4-2 are based on the condition that you have selected Standard as Profile. Table 4-2 Description of exposure parameters Parameter Description Mode Anti-flicker Auto: Adjusts the image brightness according to the actual condition automatically. Shutter priority: When the exposure range is normal, the system prefers the configured shutter range when auto adjusting according to the ambient lighting condition.
4.1.1.1.3 Configuring Backlight Backlight mode is divided into BLC, HLC and WDR. You can select one from the three options above at one time. When in BLC mode, the camera gets clearer image of the dark areas on the target when shooting against light. When in WDR mode, the camera constrains over bright areas and compensates dark areas to improve the image clarity. When in HLS mode, the camera dims strong light, and it is applicable to the exit of toll station or parking lot.
4.1.1.1.4 Configuring White Balance With the white balance technology, you can make a white object displaying itself clearly on the video image under all kinds of environment. Step 1 Click the WB tab. The WB interface is displayed. See Figure 4-4. Figure 4-4 The WB interface Step 2 Configure white balance parameters. See Table 4-4. Table 4-4 WB mode description WB Mode Description Auto The system compensates WB according to light condition to ensure color precision.
Figure 4-5 The day & night interface Step 2 Configure day & night parameters. See Table 4-5. Table 4-5 Day & night mode description Parameter Description Type Select Type from Electrical and ICR. You can select device display mode from Color, Auto and B/W. Mode Sensitivity Day & night configuration is independent from profile management configuration. Color: The system displays color image. Auto: The system switches between color and black-and-white display according to the actual condition.
Figure 4-6 The focus & zoom interface Step 2 Configure the focus & zoom parameters. See Table 4-6 for details. Table 4-6 Description of focus & zoom parameters Parameter Description Digital Zoom Select the On check box to enable it. You can use the digital zoom to continue the zooming operation even if the optical zoom is at the maximum value. Zoom Speed The larger the value, the faster the zooming operation. Mode The camera’s focusing mode.
4.1.1.1.7 Configuring Defog The image quality will be compromised in foggy or hazy environment, and defog can be used then to improve image clarity. Step 1 Click the Defog tab. The Defog interface is displayed. See Figure 4-7. Figure 4-7 The defog interface Step 2 Configure the defogging settings. See Table 4-7. Table 4-7 Defogging settings description Defogging Settings Description Auto The system adjusts image clarity according to the actual condition. Manual Adjust image clarity manually.
Figure 4-8 Restoring lens to the default settings 4.1.1.2 Configuring Thermal Image To find and configure thermal image, you need to select Setting> Camera > Conditions > Conditions first, and in the Channel box, select 2. See the following steps for details. Configure a specific scenario where you use the camera, including indoor scenario, outdoor scenario, and adaptive scenario. You can choose a scenario you need, and configure and check the scenario.
Figure 4-9 The thermal image interface Step 3 Configure lens parameters. For detailed description, see Table 4-8. Table 4-8 Parameter description of lens Classification Parameter Description Profile Common model, day and night can be selected. You can set the relevant parameter of thermal image after you configure files. Scene (marked by ① in Figure 4-9) Select the duplicate frame and set the frequently used video parameter as the user-defined scene.
Classification Basic Settings Parameter Description Colorization Add color to the thermal imagery image and use color to indicate the temperature. "White glow" is the default color. White glow: Lighter when the temperature is higher in gray image. Black glow: Lighter when the temperature is lower in gray image. Fusion: Color is concentrated on the range of purplered-yellow. More purple when the temperature is lower and more yellow when the temperature is higher.
Classification Gain settings Parameter Description Brightness Change the overall image brightness through linear mode. The bigger the value is, the brighter the image will be, and the smaller the darker. Sharpness Change the sharpness of image edges. The larger the value, the more obvious the image edge. Do not make the value too large to prevent image noise. EZoom Enlarge the thermal image according to the zoom time you have set. ROI Type Select the district of strengthening video quality.
4.1.1.3 Configuring Profile Management When configuring the profile management, you can select from Normal, Full Time and Schedule based on your own needs. Step 1 Select Setting > Camera > Conditions > Conditions > Profile Management. The Profile Management interface is displayed. Step 2 Profile management configuration: When Profile Management is set as Normal, the surveillance system works under normal configuration.
Step 1 Select Setting > Camera > Video > Video. The Video interface is displayed. See Figure 4-13. The default bit stream value of different devices might vary, and the actual product shall prevail. Figure 4-13 Video Step 2 Configure video streaming. For detailed description, see Table 4-9. Table 4-9 Parameter description Parameter Description Enable Select the option box to enable sub stream (enabled by default). Enabling sub stream 1 and sub stream 2 at the same time are supported.
Parameter Description Reference bit rate value According to resolution and frame rate you have set, we have offered you a reference bit rate value, which is also the best value you can adopt. Bit rate This parameter can be configured only when the bit rate type is set as Fixed. If you select the bit rate value according to “reference bit rate value”, the streaming changes little and keeps close to the bit rate value you have selected. Select Customized and you can configure bit rate value manually.
Step 2 Configure snapshot streaming. See Table 4-10. Table 4-10 Parameter description Parameter Description Snapshot type You can select General or Event. General means the system takes snapshot as scheduled Event means snapshot functions when video\audio detection, event or alarm is triggered. Image Size The same resolution with main stream. Quality Snapshot quality. The bigger the value, the better the snapshot quality. Snapshot interval Snapshot frequency.
Step 3 Select Enable, and then drag the block to the area that you need to cover. You can draw four area boxes at most. Click Remove All to delete all the area boxes; you can also just select one box, and click Delete or right-click to delete it. Step 4 Click Save to finish configuration. 4.1.2.3.2 Configuring Channel Title You can enable this function if you need to display Channel title in the video image. Step 1 Select Setting > Camera > video > Overlay. The Overlay interface is displayed.
Figure 4-17 Time title Step 3 Select the Enable check box, and the time displays in the video image. Step 4 Click Week Display, and then the week information displays in the video image. You can drag the "Time Title" box in the video image with your mouse to adjust the box’s location. Step 5 Click Save to finish configuration. 4.1.2.3.4 Configuring OSD Info Enable this function if you want to display words on the video image. Text Overlay and Picture Overlay can’t work at the same time.
Figure 4-18 OSD Info Step 3 Select the Enable check box of Text Overlay, and enter text based on your own needs. Then, select the text align method, and the OSD Info box is displayed on the video image. You can drag the OSD Info box on the video image with your mouse to adjust the box’s location. Step 4 Click Save to finish configuration. 4.1.2.3.5 Configuring Font You can adjust size and color of the font in the video images based on your own needs. Step 1 Select Setting > Camera > video > Overlay.
Step 4 Click Save to finish configuration. 4.1.2.3.6 Configuring Picture Overlay You can enable this function if you need to display picture information in the video image. Geography location and Picture overlay can’t work at the same time. Step 1 Select Setting > Camera > video > Overlay. The Overlay interface is displayed. Step 2 Click the Picture Overlay tab. The Picture Overlay interface is displayed. See Figure 4-20. Figure 4-20 Picture overlay interface Step 3 Select the Enable check box.
Figure 4-21 ROI interface Step 2 Select the Enable check box. Step 3 Hold the left mouse button to draw a ROI area on video images. You can also configure the ROI’s display quality. You can draw at most four ROI areas. Click Remove All to delete all the area boxes; you can also just select one box, and click Delete or right-click to delete it. Step 4 Click Save to finish configuration. 4.1.2.
Table 4-11 Storage path description Path Description Live Snapshot Live snapshot refers to the snapshot of live interface. C:\Users\admin\WebDownload\LiveSnapshot is the default path. Live Record Live record refers to the recorded video of live interface. C:\Users\admin\WebDownload\LiveSnapshot is the default path. Playback Snapshot Playback snapshot refers to the snapshot of playback interface. C:\Users\admin\WebDownload\LiveSnapshot is the default path.
Figure 4-23 Audio Step 2 Configure Audio parameters. For detailed description, see Table 4-12. Table 4-12 Parameters Parameters Description Enable Audio can be enabled only when video is enabled. Enable Main Stream or Sub Stream, and the network stream is composed of both audio and video streams. If you do not select Main Stream or Sub Stream, then only video images are transmitted. Encode Mode You can select audio encode mode. G.711A, G.711Mu, and AAC are included.
Parameters Description Adjusts speaker volume. Speaker Volume This function is not available for all devices. Step 3 Click Save to finish configuration. 4.2 Configuring Network 4.2.1 Configuring TCP/IP You need to configure the camera’s IP address and DNS server to connect the camera with other devices in the network. Preparation You have connected the camera to network. Procedure Step 1 Select Setting > Network > TCP/IP. The TCP/IP interface is displayed. See Figure 4-24.
Parameter Description Mode Static: You need to manually configure IP Address, Subnet Mask and Default Gateway. DHCP: Obtains IP address automatically. With DHCP enabled, IP Address, Subnet Mask and Default Gateway cannot be configured. You can check the current IP address whether the DHCP takes effect or not. MAC Address Host’s MAC address, cannot be modified. IP Version Select IPv4 or IPv6. IP Address You can type IP address and subnet mask according to your own needs.
Parameter Description Select the check box, get the device MAC address, and then you can modify and configure the device IP address with ARP/ping command. This is enabled by default. During reboot, you will have no more than two minutes to configure the device IP address with a ping packet which has certain length. The server will be turned off in 2 minutes, or it will be turned off immediately after IP address configuration. If this is not enabled, the IP address cannot be configured with ping packet.
Figure 4-25 Port Step 2 Configure parameters. See Table 4-14 for details. Configuration of Max Connection takes effect immediately and others after reboot. 0–1024, 37780, 37880, 1900, 3800, 5000, 5050, 9999, 37776, 39999 and 42323 are occupied for specific uses. It is not recommended to use the default value of other port during port configuration.
Parameters Description 554 is the default port number. If you play live view through Apple’s QuickTime or VLC, the following format is available. This function is also available for Blackberry. When the URL format requiring RTSP, you need to specify channel number and bit stream type in the URL, and also user name and password if needed. When playing live view with Blackberry smart phone, you need to turn off the audio, and then set the code mode to H.264B and resolution to CIF.
Figure 4-26 ONVIF Step 2 Select the On check box in Authentication bar Step 3 Click Save to finish configuration. 4.2.3 Configuring PPPoE Point-to-Point Protocol over Ethernet, it is one of the protocols that device uses to connect to the internet. Get the PPPoE user name and password from the Internet Service Provider, and then, set up network connection through PPPoE, the device will acquire a WAN dynamic IP address. Disable UPnP while using PPPoE to avoid possible influence.
If Quick DDNS is not the DDNS’ type, you need to log in the domain name of website registration provided by DDNS service provider. Register and log in the DDNS website, and then you can view the information of all the connected devices in your account. Procedure Step 1 Select Setting > Network > DDNS. The DDNS interface is displayed. See Figure 4-28. Figure 4-28 DDNS setting interface Step 2 Select Type and configure as needed.
Figure 4-29 SMTP (Email) Step 2 Configure your SMTP server. Step 3 For SMTP (Email)’s other parameters to be configured, see Table 4-16. Table 4-16 SMTP (Email) parameter description Parameters Anonymity Description Enable Anonymity, and senders’ identities will not be displayed in Emails transmitted to others. Sender Sender’s email address Encryption type Select Authentication type from None, SSL and TLS. TLS is set by default. Attachment Select the check box to support attachment in the email.
4.2.6 Configuring UPnP Configure UPnP protocols to establish the reflection relation between intranet and external network. A user can access IP address of external network to visit devices in the intranet. Preparation Ensure UPnP network service has been installed to your PC. Log in the router, and configure WAN IP address to set up internet connection. Enable UPnP in the router. Connect your device to the LAN port of the router.
Step 1 Select Setting > Network > SNMP. The SNMP interface is displayed. See Figure 4-31 and Figure 4-32. Figure 4-31 SNMP (1) Figure 4-32 SNMP (2) Step 2 Select the Version check box to enable SNMP. Step 3 Configure SNMP parameters. See Table 4-17 for details. In the Trap Address bar, enter the IP address of the PC that has MIB Builder and MG-SOFT MIB Browser installed, other parameters leave to the default.
Parameter Description Select a version and its information will be displayed in the SNMP interface. SNMP Version Select v1, and only v1’s information is displayed. Select v2, and only v2’s information is displayed. Select v3, and you can configure user name, password and authentication type. It requires corresponding user name, password and authentication type from the server to visit your device. V1 and v2 version are now unavailable.
5) Unfold all the tree lists displayed in the MG-SOFT MIB Browser, and then you can view the configuration information, video channel amount, audio channel amount and software version. Use PC with Windows OS and disable SNMP Trap service. The MG-SOFT MIB Browser will display prompt when alarm is triggered. 4.2.8 Configuring Bonjour Bonjour is also called zero-configuration networking. With Bonjour built into devices such as your phone, this thermal camera can be searched and accessed.
Figure 4-34 Multicast Step 2 Select Enable and then enter IP address and port number. For detailed description, see Table 4-18. Table 4-18 Multicast Parameter Description Port Meaning The Multicast IP address of Main Stream/Sub Stream is 224.1.2.4 by default, and the range is 224.0.0.0–239.255.255.255. See the multicast port of corresponding stream: Main Stream: 40000; Sub Stream1: 40016; Sub Stream2: 40032, all the range is 1025–65500. Step 3 Click Save, and the login interface is displayed.
The 802.1x interface is displayed. See Figure 4-36. Figure 4-36 802.1x Step 2 Select the Enable check box. Step 3 Set up 802.1x parameters. See Table 4-20. Table 4-20 Parameters of 802.1x Parameter Description Authentication PEAP (protected EAP protocol). Username The user name that was authenticated on the server. Password Password of your username. Step 4 Click Save to finish configuration. 4.2.12 Configuring QoS QoS can solve problems including network delay and congestion.
4.3 Peripheral Manage the Camera’s components. 4.3.1 Configuring IR Light Step 1 Select Setting > Peripheral > IR Light. The IR Light interface is displayed. See Figure 4-38. Figure 4-38 IR light Step 2 Configure IR light’s running mode. Zoom Prio: When the camera zooms in or out the visible surveillance image, the IR light’s brightness will be adjusted automatically. Manual: Adjust the IR light’s brightness manually to realize the best image display effect under night vision condition.
Timing: You can configure the Interval Time and Period. 1. Interval Time: Interval from the point when the wiper starts to the point when the wiper stops. 2. Period: Time when the wiper works. 3. Click Save to finish configuration. Manual: Turn on and off the wiper manually. 1. Interval Time: Interval from the point when the wiper starts to the point when the wiper stops. 2.
Auto: Select Start Tem and Stop Tem as the temperature range for heater to start, and click Save. When the sensor temperature is in the range, heater works automatically. Manual: When you think it’s cold enough and you want to let the camera work in a warm condition, you can select Manual as the Mode. Select the On check box, and click Save to finish configuration. 4.4 Smart Thermal Configure the Device’s common behavior analysis, fire alarm and hot trace.
The pixel of the target should be no less than 10×10; the pixel of abandoned object should be no less than 15×15(CIF image); the width and height of the target should be no more than 1/3 that of the image; it is recommended that the height of the target should be set to 10% of the image height. The brightness difference of the target and the background should be no less than 10 gray levels.
Figure 4-43 Tripwire 2) Click Draw Rule to draw a rule on surveillance image. Right-click to end drawing. 3) Click Clear to delete all the tripwires. Select Maximum Size or Minimum Size and click Draw Target. Then you can drag the filter box’s corner to make the box larger or smaller. An alarm is triggered only when size of the target that is crossing tripwire lies between the two filter boxes.
Parameters Description Direction Configure the target moving direction for tripwire alarm, you can select A->B, B->A and A<->B. Enable this function and alarm recording will be triggered when there is an alarm. To check and reset recorded videos’ storage path, see "4.1.2.5 Configuring Storage Path". Two more conditions must be satisfied before alarm recording function works: You have enabled motion detection recording. See "4.7.1.1 Configuring Video Recording" for detailed operations.
You have set up preset spots or tunnels’ smart plan. See "4.4.1 Configuring Smart Plan" for detailed operations. Procedure Step 1 Select Setting > Smart Thermal > IVS > IVS. The IVS interface is displayed. Step 2 Select a preset in Preset bar. The camera turns to the position. This step is required only when preset dot function is carried on this interface. Step 3 Set up area invasion rules. 1) Click and then double-click the rule you have just added to set up its name. Select Area Invasion as the type.
3) Click Clear to delete monitoring area you have set up. Select Maximum Size or Minimum Size and click Draw Target. Then you can drag the filter box’s corner to make the box larger or smaller. An alarm is triggered only when size of target that is crossing your monitoring area lies between the two filter boxes. When drawing a rule, you can select Maximum Size or Minimum Size and click Clear to delete a relevant filter box. 4) Set up intrusion parameters. See Table 4-23 for details.
Parameters Description Report Interval Set this parameter when you select Inside or Cross/Inside as your Rule Type. Set the shortest time between a target appears and an alarm is triggered. Enable this function and alarm recording will be triggered when there is an alarm. To view and set storage path of recorded videos, see "4.1.2.5 Configuring Storage Path". The following two conditions must be satisfied before alarm recording function works: You have enabled motion detection recording. See "4.7.1.
Preparation You have enabled detection to general behaviors. For detailed operations, see "4.4.1 Configuring Smart Plan." Procedure Step 1 Select Setting > Smart Thermal > IVS > IVS. The IVS interface is displayed. Step 2 Select a preset in Preset bar. The camera turns to the position. This step is required only when preset is supported by the Device. Step 3 Configure rules. 1) Click and then double-click the rule you have just added to set up its name. In the Rule Type list, select Abandoned Object.
An alarm is triggered only when size of abandoned objects lies between the two filter boxes. When drawing a rule, you can select Max Size or Min Size and click Clear to delete a relevant filter box. 4) Configure abandoned object parameters. See Table 4-24 for details. Table 4-24 Abandoned object parameters Parameter Description Period Define a period during which the alarm settings are active. 1. Click Setting, and the period setting interface is displayed. 2. Configure period.
Parameter Description Select the check box of PTZ and select an item from None, Preset, Tour, and Pattern in the Activation bar. Once an alarm is triggered, your PTZ will execute the item you have selected in the Activation bar. PTZ Set up PTZ first before enabling this function. See "3.2 PTZ" for detailed operations. Select the Snapshot check box to take a snapshot when there is an alarm. Snapshot To view and set storage path of snapshots, see "4.1.2.5 Configuring Storage Path".
Figure 4-46 Missing object 2) 3) Click Draw Rule to draw a monitoring area on surveillance image. Right-click to end drawing. Click Clear to delete monitoring area you have set. Select Max Size or Min Size, then click Draw Target, and then drag the filter box’s corner to adjust the box’s size to your requirement. An alarm is triggered only when size of the missing object lies between the two filter boxes.
Parameter Description Duration The shortest time from placing an object in the detection area to an alarm is triggered. Enable this function and alarm recording will be triggered when there is an alarm. To view and set storage path of recorded videos, see "4.1.2.5 Configuring Storage Path". The following two conditions must be satisfied before alarm recording function works: You have enabled motion detection recording. See "4.7.1.1 Configuring Video Recording" for detailed operations.
You have set smart plans of presets or channels. See "4.4.1 Configuring Smart Plan" for detailed operations. Procedure Step 1 Select Setting > Smart Thermal > IVS > Global Setup. The Global Setup interface is displayed. See Figure 4-47. Figure 4-47 Global setup Step 2 Select a preset in Preset bar. The camera turns to the position. You need this step only when presets are supported in this Device. Step 3 Add detected area and excluded area.
Parameter Description Shadow Screen Enable Select the On check box to enable this function. This function is aimed at eliminating an object's shadow and representing only the object itself in the object box; several objects with their shadows partly overlaid can be told separately. So this function can give user a precise clue of where the object really locates. However, if an object’s part looks like the object’s shadow, it’s likely that this part will be identified as a shadow and eliminated.
Step 4 Set rules of fire warning. 1) Select fire warning mode on your own needs. High response mode is your only option when you want your camera to detect any a hidden fire danger. Anti-jamming: Your camera will only detect those objects that are newly with high temperature and send off alarms. That means under Anti-jamming mode, a constantly high-temperature object (a boiler, for example) is excluded. High Response: Your camera will detect any a hidden fire danger and send off alarms.
Parameter Description Record Delay Set a length of time for the Device to delay turning off recording after an alarm is ended. Relay-out You can connect this relay-out port to such alarm devices as light and siren. When an alarm is triggered, those alarm devices will work. Select the check box to enable this function. Alarm Delay Set a length of time for the Device to delay turning off alarm after an event is actually ended.
Figure 4-49 Hot trace Step 2 Select the On check box. Step 3 Configure parameters of cold/hot spot tracking. See Table 4-28 for details. Table 4-28 Parameters of hot trace Parameters Description Color Mode Select a color for cold and hot spots. Auto: Select colors for the highest/lowest temperature automatically according to surveillance images. Manual: Define colors for the highest/lowest temperature. Alarm Condition Conditions under which an alarm is triggered.
Parameters Description Anti-Dither Only one motion detection event is recorded within the time you have set. Enable this function and alarm recording will be triggered when there is an alarm. To view and set storage path of recorded videos, see "4.1.2.5 Configuring Storage Path". The following two conditions must be satisfied before alarm recording function works: You have enabled motion detection recording. See "4.7.1.1 Configuring Video Recording" for detailed operations.
Figure 4-50 Effect of hot trace 4.4.5 Configuring Pic in Pic Put the thermal image that has shrunk on the visible image. Step 1 Select Setting > Smart Thermal > Pic in Pic. The Pic in Pic interface is displayed. See Figure 4-51. Figure 4-51 Pic in pic Step 2 Select the Enable check box. Step 3 Drag the blue box’s angle to enlarge the box. Click in the box and drag your mouse to adjust the box’s location. Step 4 Click Save to finish configuration. 4.4.
Figure 4-52 Link schedule Step 2 Configure periods for each weekday. In Figure 4-52, you can hold your mouse’s left button to directly drag a period bar for each weekday. 1) In Figure 4-52, click Setting next to the green bar and the dialogue box of Setting is displayed. See Figure 4-53. Figure 4-53 Setting 2) Select a weekday and a period. Then you can define the period. When you select the check box of All, you’re doing period settings towards all weekdays. 3) Click Save.
Figure 4-54 Motion detection setting Step 2 Select the Enable check box. Step 3 Configure a motion detection area. 1) Next to Area, click Setting. The Area interface is displayed. See Figure 4-55.
2) Set area name and select motion detection areas as needed. You can configure the sensitivity and mutation threshold. The threshold defines the allowed moving area for certain objects. The motion detection will not be triggered as long as those objects stay within the area.
Parameter Description Alarm Delay Set a length of time for the Device to delay turning off alarm after an event is actually ended. Select the Send Email check box and an e-mail will be delivered to the device user once an alarm is triggered. Send Email Set your e-mail first before enabling the Send Email function. See "4.2.5 Configuring SMTP" for detailed operations. Select the check box of PTZ and select an item from None, Preset, Tour, and Pattern in the Activation bar.
Figure 4-56 Video temper Step 2 Select the Enable check box. Step 3 Configure video temper parameters. See Table 4-29 for details. Table 4-30 Parameters description Parameter Description Period Define a period during which the alarm settings are active. 1. Click Setting, and the period setting interface is displayed. 2. Configure period. Method 1: Hold down and drag the left mouse button to select working period you need.
Parameter Description Enable this function and alarm recording will be triggered when there is an alarm. To view and set storage path of recorded videos, see "4.1.2.5 Configuring Storage Path". The following two conditions must be satisfied before alarm recording function works: You have enabled motion detection recording. See "4.7.1.1 Configuring Video Recording" for detailed operations. You have enabled auto recording. See "4.7.3 Configuring Record Control Parameters" for detailed operations.
Figure 4-57 Audio detection settings Step 2 Configure parameters of audio detection. See Table 4-31 for details. Table 4-31 Parameters of audio detection Parameters Description Input Abnormal Enable this function and an alarm will be triggered when there is abnormal audio input. Intensity Change Enable this function and an alarm will be triggered when the change of sound intensity exceeds the threshold you have set.
Parameters Description Period Define a period during which the alarm settings are active. 1. Click Setting, and the period setting interface is displayed. 2. Configure period. Method 1: Hold down and drag the left mouse button to select working period you need. Method 2: Select Setting > Event > Video Detection and click Setting on the right side of Period. An interface is displayed. In this interface, there are seven Settings altogether each of which corresponds to a day in a week.
Parameters Description Select the Snapshot check box to take a snapshot when there is an alarm. Snapshot To view and set storage path of snapshots, see "4.1.2.5 Configuring Storage Path". To make the snapshot function take effect, you need to firstly enable motion-detection snapshots. See "4.7.1.2 Configuring Snapshot" for detailed operations. Step 3 Click OK to finish configuration. 4.5.3 Configuring Temperature Alarm You can set an alarm condition.
Table 4-32 Temperature alarm parameters Parameter Description Period Define a period during which the alarm settings are active. 1. Click Setting, and the period setting interface is displayed. 2. Configure period. Method 1: Hold down and drag the left mouse button to select working period you need. Method 2: Select Setting > Event > Video Detection and click Setting on the right side of Period. An interface is displayed.
Parameter Description Select the Snapshot check box to take a snapshot when there is an alarm. Snapshot To view and set storage path of snapshots, see "4.1.2.5 Configuring Storage Path". To make the snapshot function take effect, you need to firstly enable motion-detection snapshots. See "4.7.1.2 Configuring Snapshot" for detailed operations. Step 4 Click Save to finish configuration. 4.5.
Parameters Description Anti-dither Only one temperature alarm event is recorded within the time you have set. Sensor type You can select from normally open (NO) and normally closed (NC). Enable this function and alarm recording will be triggered when there is an alarm. To view and set storage path of recorded videos, see "4.1.2.5 Configuring Storage Path.
The "No SD Card", "SD Card Error" and "Capacity Warning" events are available only on models that support SD card. 4.5.5.1 Configuring SD Card Abnormality Parameters When any abnormality happens to the SD card, an alarm will be triggered and linked activities will be executed. SD card abnormality includes "No SD card", "SD Card Error" and "Capacity Warning." Step 1 Select Setting > Event > Abnormality > SD Card. The SD Card interface is displayed. See Figure 4-60.
4.5.5.2 Configuring Network Abnormality Parameters When any abnormality happens to network, an alarm will be triggered and linked activities will be executed. Network abnormality includes "Disconnection" and "IP conflict." Step 1 Select Setting > Event > Abnormality > Network. The Network interface is displayed. See Figure 4-61. Figure 4-61 Network Step 2 Select an event type. Step 3 Select the Enable check box. Step 4 Configure network abnormality parameters. See Table 4-35 for details.
4.5.5.3 Configuring Illegal Access Parameters If the password is continuously wrongly typed and the mistakes have reached the maximum you have set, an alarm will be triggered and linked activities will be executed. Step 1 Select Setting > Event > Abnormality > Illegal Access. The Illegal Access interface is displayed. See Figure 4-62. Figure 4-62 Illegal access Step 2 Select the Enable check box. Step 3 Configure illegal access parameters. See Table 4-36 for details.
This function is supported on select models and the actual interface shall prevail. Step 1 Select Setting > Event > Abnormality > Burning Warning. The Burning Warning interface is displayed. See Figure 4-63. Figure 4-63 Burning warning Step 2 Select the Enable check box. Step 3 Configure Sensitivity and Energy Threshold: Sensitivity: Sensitivity for the camera to recognize whether the lenses are watching towards the sun. The larger the value is, the easier the camera will be to recognize the sun.
Figure 4-64 Parameter Step 2 Configure temperature measuring rules and then parameters. 1) Click to add a rule. See Figure 4-65. Figure 4-65 Rule adding 2) Double-click the rule you have just added to select measurement items and modify the measurement name. Draw your rules. Select Measurement Items as Spot, and you can click a position on the surveillance image and a spot is formed.
Parameters Description Target Radiation Coefficient Radiation coefficient of targets that are shot by this Device. Ranges from 0.5 – 1. Target Distance Distance from the camera to targets that are shot. Ranges from 0m – 10000m. Target Reflection Temperature Temperature of targets that are shot by this Device. Ranges from -50 °C to 327.7 °C. 5) Enable the Relay-out check box and configure its parameters. See Table 4-38 for details.
You have set at least two temperature testing rules. See "4.6.1.1Configuring Temperature Measuring Rules" for detailed operations. Procedure Step 1 Select Setting > Temperature > Rule > Temp Contrast. The Temp Contrast interface is displayed. See Figure 4-66. Figure 4-66 Temperature contrast Step 2 Set temperature contrast rules 1) Click to add a temperature contrast rule. See Figure 4-67. Figure 4-67 Temperature contrast rules adding 2) 3) Double-click to add a temperature contrast rule.
Parameters Description Alarm Condition Contains "lower", "matched" and "higher." Alarm Threshold Temperature Temperature of triggering an alarm. Ranges from 0 – 550 °C. Step 3 Click Save to finish configuration. On the left-side live image, you can view temperature contrast results of the object you have selected. 4.6.2 Configuring Global Setup You can enable Temperature Switch, Isotherm and Color Code. Temperature Switch: A switch with which you can enable or disable temperature testing rules.
Parameter Description Atmospheric Temperature Temperature of our environment. Ranges from -50 °C to 327.7 °C. Target Radiation Coefficient Set Radiation coefficient of targets that are shot by this Device. Ranges from 0.5 – 1. Target Distance Distance from the camera to targets that are shot. Ranges from 0m – 10000m. Target Reflection Temperature Temperature of targets that are shot by this Device. Ranges from -50 °C to 327.7 °C. Isotherm Select the On check box.
Figure 4-69 Temperature switch Figure 4-70 Isotherm Setting 126
Figure 4-71 Color code 4.6.3 Exporting Heat Map By exporting heat map, you can grasp temperature of every pixel on thermal images. Step 1 Select Setting > Temperature > Heat Map. The Heat Map interface is displayed. See Figure 4-72. Figure 4-72 Heat map setting Step 2 Click Export Heat Map. Heat map files will be saved under the path you have set. For detailed operation of resetting the storage path, see "4.1.2.5 Configuring Storage Path." 4.7 Storage Management 4.7.
Step 1 Select Setting > Storage > Schedule > Record. The Record interface is displayed. See Figure 4-73. Figure 4-73 Record Step 2 Select recording type and configure time period. Select recording type, and then you can also press and hold the left mouse button to select the time period as needed in the chart. 1) Click the Setting for the day that you want to configure time period. The Setting interface is displayed. See Figure 4-74. Figure 4-74 Setting 2) Select a day in a week and configure its period.
Step 3 Click Save to finish configuration. 4.7.1.2 Configuring Snapshot Set video snapshot schedule, covering General, Motion and Alarm. Step 1 Select Setting > Storage > Schedule > Snapshot. The Snapshot interface is displayed. See Figure 4-75. Figure 4-75 Snapshot Step 2 Select snapshot type and configure time period. Select snapshot type, and then you can also hold down the left mouse button to select the time period in the chart as needed.
The system returns to the Snapshot interface. Each color matches with a certain Snapshot type. Green means General Snapshot, yellow means motion detection Snapshot and red means alarm Snapshot schedule. Step 3 Click Save to finish configuration. 4.7.1.3 Configuring Holiday Schedule Select a day as your "holiday" and video recording/snapshots will be enabled at your "holiday." To use holiday recording function, you need to configure holiday recording schedule. For detailed operation, see "4.7.1.
Figure 4-78 Path Step 2 Select different storage paths for the recorded videos and snapshots which belong to different event types. Table 4-41 Path parameters Parameter Description Event type Select from Scheduled, Motion Detection and Alarm. Local Save in the internal SD card. FTP Save in the FTP server. NAS Save in the NAS (network attached storage). Step 3 Click Save to finish configuration. 4.7.2.2 Configuring Local Storage The system will display the internal SD card information.
Figure 4-80 FTP settings Step 2 Select the Enable check box, and then select the service type. SFTP service is recommended. Step 3 Configure FTP parameters. See Table 4-42. Table 4-42 FTP parameter description Parameters Description Server Address The IP address of the SFTP or FTP server. Port The port of the SFTP or FTP server. User name The user name to log in the server. Password The password to log in the server. Remote Directory The destination path in the server.
Step 2 Select the Enable check box. Step 3 Configure NAS parameters. See Table 4-43 for details. Table 4-43 NAS parameters Parameter Description Server Address The IP address of the NAS server. Remote Directory The destination path in the NAS server. Step 4 Click Save to finish configuration. 4.7.3 Configuring Record Control Parameters This chapter introduces configurations including pack duration, pre-event record, disk full, record mode and record stream.
4.8 System Management 4.8.1 General Settings 4.8.1.1 Configuring General Information Configure device name, language and video standard. Step 1 Select Setting > System > General > General. The General interface is displayed. See Figure 4-83. Figure 4-83 General Step 2 Configure general parameters. See Table 4-45. Table 4-45 General parameter description Parameter Description The name of the device. Device name Each device has different name. Language Select system language.
Figure 4-84 Date & Time Step 2 Configure Date & Time parameters. See Table 4-46 for details. Table 4-46 Date & Time parameters Parameter Description Date Format Date format. Time Format Configure the Time format, you can select from 24-Hour or 12-Hour. Time zone Configure the Time zone that the device is at. Current Time Configure system time. Click "Sync PC", and the system time changes to the time on PC. DST Enable DST as needed. Select the check box to enable daylight saving time.
The GPS interface is displayed. See Figure 4-85. Figure 4-85 GPS Step 2 Fill in your camera’s LON, LAT and Altitude information. Step 3 Click Save to finish configuration. 4.8.2 User Management Managing users and groups are only available for administrator users. The max length of the user or group name is 15 characters which can only be consisted of letters, numbers and underlines.
Figure 4-86 User group Step 2 Click Add Group. The Add Group interface is displayed. See Figure 4-87. Figure 4-87 Add Group Step 3 Enter Group name and memo. Then select Group authorities. Step 4 Click Save to finish configuration. The newly added group displays in the group name list. See Figure 4-88. After adding group, click to modify group memo or authorities; click to delete the added group, admin group and user group cannot be deleted.
Step 1 Select Setting > System > Account > Account. The Account interface is displayed. See Figure 4-89. Figure 4-89 User settings Step 2 Click Add User. The Add User interface is displayed. See Figure 4-90. Figure 4-90 Add user Step 3 Configure parameters. See Table 4-47. Table 4-47 User parameter description Parameter Description Username User’s unique identification You cannot use existing user name. Password Confirm Password Enter password and confirm it. The two items must be the same.
The newly added users are displayed in the user list. After adding user, click click to modify password, group, memo or authorities; to delete the added user, admin user cannot be deleted. Click in the admin row to modify user name and email address. 4.8.2.3 Modifying User Password For data security, it’s strongly recommended that you change the default password of the Device and modify it regularly. Also, it’s recommended that you adopt a complicated and strong password.
Figure 4-93 Modify user (2) Step 4 Type old password. Type new password and confirm it. The password must have 8 to 32 digits and at the same time have at least two of the four types: capital letter, lowercase letter, number and special characters. Step 5 Click Save to finish password modification. 4.8.3 Adding ONVIF User Step 1 Select Setting > System > Account > ONVIF User. The ONVIF User interface is displayed. See Figure 4-94. Figure 4-94 ONVIF user Step 2 Click Add User.
Figure 4-95 Add user Step 3 Enter username, password and confirm the password. Then, select group name. Step 4 Click Save to finish configuration. 4.8.4 Safety Management Set RTSP authentication, IP filter, system service and HTTPS to secure data transmission and prevent data leakage. 4.8.4.1 Configuring RTSP Authentication RTSP (Real Time Streaming Protocol) is to secure transmission of streaming media. Step 1 Select Setting > System > Security > RTSP Authentication.
When accessing through WAN, you can only use MAC of your router to limit MAC verification. You cannot enable white list and black list at the same time. You cannot add your device IP/MAC to the white list. Step 1 Select Setting > System > Safety > IP Filter. The IP Filter interface is displayed. See Figure 4-97. Figure 4-97 IP filter Step 2 Select the check box of Enable. Add an IP/Mac address to the white list. 1) Click the Trusted Sites tab. The Trusted Sites interface is displayed.
Step 1 Select Setting > System > Safety > System Service. The System Service interface is displayed. See Figure 4-98. Figure 4-98 System service Step 2 Enable functions on the System Service interface. See Table 4-50. Table 4-50 System service parameters description Parameter Description Disabled by default. SSH SSH (Secure Shell) can encode your data for its transmission. By this way, data leakage can be prevented when you manage your device remotely. Enabled by default.
Parameter Mobile Push Description Enabled by default. Snapshots under alarm condition can be delivered to your phone. Step 3 Click Save. 4.8.4.4 Configuring HTTPS With HTTPS, you can install customized certificates or signed certificates. You can also obtain and install a root certificate. After installing customized certificates or signed certificates to your device, you need to install a root certificate to your PC.
Figure 4-100 Certificate creating 2) Configure HTTPS parameters. See Table 4-51. Table 4-51 Parameters description Parameter Description Country Abbreviation of a country. Limited to 2 capital letters. IP or Domain Name IP address or domain name of your device Validity period Validity period of the certificate. Province Province where you use this certificate. Location Location where you use this certificate. Organization Organization that uses this certificate.
Figure 4-101 Certificate 2) Click Install Certificate. The Certificate Import Wizard interface is displayed. See Figure 4-102. Figure 4-102 Certificate import wizard 3) Click Next. The certificate store selection interface is displayed.
Figure 4-103 Certificate store 4) 5) 6) Select "Place all certificates in the following store." Click Browse and set the "Trusted Root Certification Authorities" as certificate store. Click Next. The certificate import completing wizard is displayed. See Figure 4-104. Figure 4-104 Certificate import wizard completing Click Finish. The security warning interface is displayed. See Figure 4-105.
Figure 4-105 Security warning 7) Click Yes. The system pops up a messaged that indicates the import was successful. See Click OK to finish certificate importing. Figure 4-106 Successful import prompt 8) Click OK to finish installation of root certificate. Step 6 Enable HTTPS and a prompt that the Device needs to be rebooted is displayed. After your device reboots, type IP address of the Device in your browser and access the Device through HTTPS protocol. 4.8.4.4.
Figure 4-107 HTTPS Step 2 Install a certificate that has been signed. 1) Click Browse on the right side of Certificate Path bar to select a certificate you are to upload. 2) Click Browse on the right side of Certificate Key Path bar to select the certificate password you are to upload. Step 3 Click Upload. Installation begins. After that, certificate property will be displayed in the Certificate Installed bar of the HTTPS interface.
Figure 4-108 Certificate 2) Click Install Certificate. The Certificate Import Wizard interface is displayed. See Figure 4-109. Figure 4-109 Certificate import wizard 3) Click Next. The certificate store selection interface is displayed. See Figure 4-110.
Figure 4-110 Certificate store 4) 5) 6) Select "Place all certificates in the following store." Click Browse and set the trusted root certificate authority as certificate store. Click Next. The certificate import completing wizard is displayed. See Figure 4-111. Figure 4-111 Certificate import wizard completing Click Finish. The security warning interface is displayed. See Figure 4-112.
Figure 4-112 Security warning 7) Click Yes. The system pops up a messaged that indicates the import was successful. See Figure 4-113. Click OK to finish certificate importing. Figure 4-113 Successful import prompt 8) Click OK to finish installation of root certificate. Step 6 Enable HTTPS and a prompt that the Device needs to be rebooted is displayed. After your device reboots, type IP address of the Device in your browser and access the Device through HTTPS protocol.
5 System Maintenance 5.1 Maintenance Requirements For the system’s good and safe running, it’s recommended to manage and maintain the system, backup files with the following methods. Check surveillance images regularly. Clear regularly user and user group information that are not frequently used. Modify your password every 3 months. Check your system logbook regularly. Handle problems as soon as possible. Backup your configuration of system regularly.
Figure 5-2 Auto maintain Step 2 Enable Auto Delete Old Files and select on your own the time gap of deleting the old files. Ranges from 1 to 31 day(s). Step 3 Click OK to finish configuration. 5.3 Backing Up and Restoring 5.3.1 Importing and Exporting Files that are exported do not contain presets. To import and export presets, see "3.2.1.4 Configuring Preset Backup" and "3.2.2.4 Configuring Preset Backup." Step 1 Select Setting > System > Import/Export. The Import/Export interface is displayed.
Step 2 Restore the Device to default setting. Click Default, and all the configurations except IP Address and Account are reset. Click Factory Default, and all the configurations are reset. 5.4 Upgrading Firmware If a wrong upgrade file has been used, please reboot the device, otherwise some functions might not work properly. When upgrading, do not cut off power/network, reboot or turn off the Device. Step 1 Select Setting > System > Upgrade. The Upgrade interface is displayed. See Figure 5-5.
Select Setting > Information > Version, and the Version interface is displayed. See Figure 5-6. Figure 5-6 Version 5.6 System Log 5.6.1 Searching System Logs The log type includes "all, system, setting, data, event, record, account and safety." Step 1 Select Setting > Information > Log. The Log interface is displayed. See Figure 5-7. Figure 5-7 Log Step 2 Set start time and end time, and then select log type.
Parameters Description Type The log type includes "all, system, setting, data, event, record, account and safety." All: All log information. System: Includes program launch, force exit, exit, program reboot, device turn off/reboot, system reboot and system upgrade. Setting: Includes save configuration and delete configuration file. Data: Includes configure disk type, erase data, hot swap, FTP state, NAS state, record mode, SD card error and hard disk error.
Step 3 Set IP Address, Port and Device Number. Then click Save. You need to type remote computer’s IP address here. 5.7 Online User View all the current Web users. Select Setting > Information > Online User, and the Online User interface is displayed. See Figure 5-10.
6 Additional Accessing Methods 6.1 Accessing through NVR Connect this camera to NVR (Network Video Recorder) through Wi-Fi or Ethernet. Then you can set and manage this camera through the NVR’s web client. Preparation Your PC, NVR and your thermal camera are all connected to network. You have enabled platform accessing function. You have logged in the NVR’s web client. Procedure Step 1 Select Setting > Camera > Registration. The Remote Log interface is displayed. See Figure 6-1.
6.2 Accessing through SmartPSS You can set up and manage this thermal camera through SmartPSS client. Preparation You PC (with SmartPSS installed) and your thermal camera have been both connected to network. You have installed and opened SmartPSS. Procedure Step 1 Click Devices in the homepage. The Devices interface is displayed. See Figure 6-2. Figure 6-2 Device list Step 2 Type the network segment the Device is in, and then click Search.
