Setting 101
Parameter
Description
Record Delay
Set a length of time for the Device to delay turning off recording after an
alarm is ended.
Relay-out
You can connect this relay-out port to such alarm devices as light and
siren. When an alarm is triggered, those alarm devices will work. Select
the check box to enable this function.
Alarm Delay
Set a length of time for the Device to delay turning off alarm after an
event is actually ended.
Send Email
Select the Send Email check box and an e-mail will be delivered to the
device user once an alarm is triggered.
Set your e-mail first before enabling the Send Email function. See "4.2.5
Configuring SMTP" for detailed operations.
PTZ
Select the check box of PTZ and select an item from None, Preset,
Tour, and Pattern in the Activation bar. Once an alarm is triggered, your
PTZ will execute the item you have selected in the Activation bar.
Set up PTZ first before enabling this function. See "3.2 PTZ" for detailed
operations.
Snapshot
Select the Snapshot check box to take a snapshot when there is an
alarm.
To view and set storage path of snapshots, see "4.1.2.5 Configuring
Storage Path."
To make the snapshot function take effect, you need to firstly enable
motion-detection snapshots. See "4.7.1.2 Configuring Snapshot" for
detailed operations.
Click Save to finish configuration. Step 5
4.4.4 Configuring Hot Trace
You can enable Hot Trace to track spot with the highest temperature and spot with the lowest
temperature.
Select Setting > Smart Thermal > Hot Trace. Step 1
The Hot Trace interface is displayed. See Figure 4-49.
