Daily Operation 20
Click Save to finish configuration. Step 3
3.2.1.2 Configuring PTZ Functions
The protocol setting has been completed. For detailed operations about protocol setting,
see "3.2.1.1 Configuring Protocol".
For images representing the effect of external PTZ, you need to preview on the preview
images of the external PTZ, not on the preview image of the bullet camera.
The following functions are available only when your bullet camera is connected to the
external PTZ.
3.2.1.2.1 Configuring Scan
The camera scans on the horizontal direction between the left and right borders.
Click the PTZ tab and select Scan in the PTZ function setting list. Step 1
Linear sweep Figure 3-9
Type the scan number and set the left and right border. Step 2
1) Through the direction button, move the camera to the left border that you want and
click Set Left.
2) Through the direction button, move the camera to the right border that you want
and click Set Right.
Click Start to start scan; click Stop to end it. Step 3
3.2.1.2.2 Configuring Presets
By configuring presets, the camera can store parameters such as PTZ’s horizontal angle,
inclination angle, and the lens focal length under the current situation to the Device. If you need
those parameters later, you can quickly adopt them and adjust the PTZ and camera to those
locations.
Click the PTZ tab and select Preset in the PTZ Function setting list. Step 1
Preset Figure 3-10
