™ All-in-one, all year round heating, cooling and domestic hot water supply solution HEAT PUMP INVERTER R-410A
Heat pump solution to fit both new build homes and the harder to heat older properties High Quality, Innovative Products Innovation and quality are constantly at the forefront of Daikin’s philosophy. Daikin’s systems provide highly efficient solutions, which minimize the impact on the ™ environment and running costs.
™ 3 IN 1 SYSTEM 1. Daikin ™ Page 4 ™ Page 6 ™ Page 10 ™ Page 18 ™ Page 19 ™ Page 24 ™ Page 30 the 3 in 1 guarantee for absolute comfort FOR NEW CONSTRUCTION & RENOVATION >> 2. Daikin MORE COMFORT the basics >> LOW ENERGY CONSUMPTION >> FEWER CO2 EMISSIONS 3. Daikin TECHNICALLY 4. Daikin ECONOMICALLY 5. Daikin Applications 6. Daikin Technical specifications Domestic HOT WATER PRODUCTION 7.
™ 1.THE 3 in 1 Guarantee for absolute comfort Daikin AlthermaTM is an innovative system that heats, produces domestic hot water and can even cool spaces. Daikin Altherma offers your customer maximum comfort the whole year through.
Daikin offers the Complete renewable solution for home heating and hot water Daikin AlthermaTM Benefits for New Construction and Retrofit Installations How Heat Pumps Work A ‘‘Heat Pump’’ is a mover of heat, utilizing the available renewable heat from the outside air.
2.THE BASICS ™ Daikin offers you the choice between a Daikin Altherma™ system with an outdoor unit and indoor unit, or a Daikin Altherma™ Monobloc System, in which the hydrobox components are located within the outdoor unit. The Daikin Altherma™ is a low temperature heating system optimized to work with radiant floor heating.
the basics Daikin AlthermaTM monobloc Application Heating and (optional) cooling (+ domestic hot water) monobloc outdoor unit Heat pump type Outdoor unit only (compressor and hydronic parts combined) R-410A refrigerant piping Inside outdoor unit H2O piping Between outdoor unit and heating terminal units Installer’s advantages Only H2O piping needed to install the system The monobloc system can be combined with: - Under floor heating - Fan coil units - Low temperature radiators, to provide your c
Air-to-water HEAT PUMP THE BASICS ™ The system consists of 5 components which work together to provide the ideal comfort and water temperature. 1A / Outdoor Unit : an efficient use of energy from the air 1B / hydrobox : the heart of the Daikin AlthermaTM system Daikin Altherma uses a natural source of energy. The outdoor unit extracts heat from the outside air and transfers it inside through refrigerant piping to supply heating.
3 / Monobloc outdoor unit: all in one In addition to Daikin Altherma Split type systems, Daikin has a monobloc version in which the hydrobox components are located within the outdoor unit. In this new system, the water pipes, rather than refrigerant lines, run indoors from the outdoor unit, making installation much quicker and easier for the installer.
3.TECHNICALLY ™ 1 - daikin AlthermaTM Split type Air-to-water HEAT PUMP THE OUTDOOR UNIT >> Compact, weather-resistant and easy to install >> Contains an inverter controlled compressor for energy efficiency and precise temperature regulation >> Heat pump operation range: heating and domestic hot water to -4°F (-20°C) outside temperature HEAT EXCHANGER ANTI-CORROSION TREATMENT As standard, the heat exchanger in the outdoor unit is provided with an anti-corrosion treatment.
TECHNICALLY hydrobox >> Available in two versions: EKHBH for heating only, EKHBX for heating and cooling >> Built-in electric back-up heater for additional heating during extremely cold outdoor temperatures or as back-up in case of problems with the outdoor unit >> 2 shut-off valves to assemble the water outlet and inlet >> Compact and easy to install: all components are pre-assembled, all parts are easy to reach for maintenance. Wall-mounting is comparable to a traditional gas heater. 1.
THE user interface With the easy to reach digital user interface in the indoor unit, controlling the Daikin Altherma system is also simple for your customer.
TECHNICALLY 2 - Daikin AlthermaTM MONOBLOC air-to-water heat pump >> All hydronic parts are located within the outdoor unit >> H2O piping between outdoor unit and indoor heating apparatus 3 4 2 1. High efficiency compressor 2. Expansion tank 3. Tank with back up heating 4. Pressure gauge (water circuit) 5.
3 - THE domestic HOT WATER TANK >> Available in 2 capacities: 50 and 80 gallons for floor mounted installation. >> Stainless steel design. >> 1 37/64” cfc-free insulation material (polyurethane). >> Contains 2 heating elements: a heat exchanger at the bottom where the hot water from the hydrobox circulates and an extra 3 kW electric heater at the top. >> A thermistor in the hot water tank controls a 3-way valve and/or booster heater via the hydrobox. 1. Field supply 2.
TECHNICALLY MULTIFUNCTIONAL HOT WATER TANK … >> Stainless steel Daikin offers a tank made of stainless steel equipped with a sacrificial rod to protect the tank against corrosion. >> Regulating switch-on and shut-off temperatures You personally set the minimum and maximum temperature when the water in the tank must be heated by the heat pump for the customer. >> Anti-bacteria function To prevent the development of bacteria, the hot water tank is equipped with an anti-bacteria function.
4 - SOLAR CONNECTION SOLAR Thermal BOILER Averaged over an entire year, the sun delivers half of the energy we need to bring our domestic water up to the desired temperature for free. Your customer can use this solar energy by connecting a solar boiler to the Daikin Altherma system. A solar boiler is a thermal solarenergy system, whereby solar rays are transformed into heat. The heat is then stored in a water supply tank.
TECHNICALLY 5 - Hydronic Fan Coil Unit The Hydronic Fan Coil Unit has been engineered to provide an effective solution in combination with the “Low Temperature” Daikin Altherma system. High efficiency and comfort are delivered and allow your application to blend into the environment using the traditional ductwork for Heating and Cooling air distribution.
4.ECONOMICALLY ™ How We Use Energy in Our Homes Heating and cooling account for the largest portion of a typical utility bill. Source: 2007 Buildings Energy Data Book, Table 4.2.1., 2005 energy cost data. 1.0% % 4.3% 3% 4.3% 4.1% 4.5% 6.5% � � � � � � 35.2% 6.6% 9.7% 10.8% Space Heating - 35.2% Water Heating - 13.1% Space Cooling - 10.8% Lighting - 9.7% Refrigeration- 6.6% Electronics- 6.5% Cooking - 4.5% Wet Clean - 4.3% Computers - 1.0% Others - 4.3% Adjust to SEDS - 4.1% 13.
5.Applications ™ Design STEP 1 Define the leaving water temperature range of the necessary heat emitters and the heat load. design STEP 2 Calculation of heat losses (Transmission and ventilation losses) Selection of the Daikin Altherma™ system based on heat loss calculation. Tip: Use the available Daikin Altherma™ selection and software tools.
™ Daikin AlthermaTM split type APPLICATIONS 1. Application “heating only” with a room thermostat connected to the indoor unit 1. 2. 3. 4. 5. 6. 7. Outdoor unit Hydrobox Heat exchanger Pump Valve Manifold (field supply) Valve FHL1…3 T (Under) floor heating loop (field supply) Room thermostat 2. Application “heating” and “production of domestic hot water” The temperature in each room is regulated by a valve on every water circuit.
3. Application “heating/cooling” via room thermostat and “production of domestic hot water” Heating using under floor heating loops and fan coil units. Cooling using only the fan coil units. Hot water for domestic use is delivered by the domestic hot water tank connected to the indoor unit. Outdoor unit Hydrobox 3. Heat exchanger 4. Pump 5. Valve 6. Manifold (field supply) 7. Valve 8. Motorized 3-way valve 10. Booster heater 11. Heat exchanger spiral 12. Tank for domestic hot water 13.
™ Daikin AlthermaTM monobloc APPLICATIONS 1. Application “heating only” with a room thermostat connected to the indoor unit 1. 2. 3. 4. 5. Unit Heat exchanger Pump Shut-off valve Collector (field supply) FHL1…3 T I Floor heating loop (field supply) Room thermostat (field supply) User interface 2. Application “heating” and “production of domestic hot water” The temperature in each room is regulated by a valve on every water circuit.
3. Application “heating/cooling” via room thermostat and “production of domestic hot water” Heating using under floor heating loops and fan coil units. Cooling using only the fan coil units. Hot water for domestic use is delivered by the domestic hot water tank connected to the unit. Unit 2. Heat exchanger 3. Pump 4. Shut-off valve 5. Collector (field supply) 6. Motorized 3-way valve 8. Booster heater 9. Heat exchanger coil 10. Domestic hot water tank 11. Motorized 2-way valve (field supply) 1.
outdoor SPLIT TYPE 6.
TECHNICAL Specifications hydrobox (for use with ERLQ018/024/030BAVJU) hydrobox EKHBH030BA3VJU Function Heating Cooling Leaving water temperature range Drain valve Material Color Dimensions (Net) HxWxD Net Gross Weight Capacity kW Capacity Steps Max Overcurrent Protection (MOP) Minimum Circuit Amps (MCA) Power supply Factory mounted heater When connected to all outdoor units Volume Main com- Expansion Max.
hydrobox (for use with ERLQ036/048/054BAVJU) hydrobox EKHBH054BA3VJU Function Leaving water temperature range Drain valve Material Color Dimensions (Net) Weight Factory mounted heater Water circuit Refrigerant circuit Main components Water side Heat exchanger Water side Heat exchanger Pump When connected to ERLQ054 Main Water side Heat exchanger components Water flow rate Nom. Heating Cooling Heating Cooling Water volume Water flow rate Min./Max Water flow rate Nom.
TECHNICAL Specifications domestic hot water tank Water volume gal. Max.water temperature EKHWS050BA3VJU EKHWS080BA3VJU 52.8 79.2 185 (85) °F (°C) Max.water pressure PSI 145 Insulation (Polyurethane foam) Min. thickness in. 1 5/8 Height in. Diameter in. Booster heater 45 3/8 63 22 7/8 kW 3 Water inlet H/E Diameter in. ø 3/4 FBSP Piping Water outlet H/E Diameter in. ø 3/4 FBSP connections Cold water in Diameter in. ø 3/4 FBSP Hot water out Diameter in.
Fan Coil Unit Capacity 018 024 030 036 048 054 EFWT024AEVLU EFWT024AEVJU EFWT036AEVLU** EFWT036AEVJU** EFWT036AEVLU EFWT036AEVJU EFWT048AEVLU EFWT048AEVJU EFWT060AEVLU EFWT060AEVJU Cooling Performance (chilled water cooling): Nominal Capacity Btu/hr 19,100 22,600 28,600 32,000 42,700 52,400 Nominal Sensible Capacity Btu/hr 17,700 22,400 25,800 34,700 42,400 EWT Range Nominal Flow Rate °F GPM 4.5 5.0 6.0 6.0 8.0 10.0 Nominal Pressure drop Ft Hd 5.5 7.7 4.8 5.5 5.4 7.
UNIQUE BENEFITS ™ Control customized to your customer The water temperature changes in function with the outside temperature so that your customer can enjoy a stable level of heating at any time. As the installer, you set up the system according to the desires of your customer. You input four temperatures to determine the “heating curve” and in doing so, you perfectly tune the Daikin Altherma system to the type of home.
7.THE SOFTWARE ™ Daikin Altherma’s “simulator” software program allows quick and easy indication of the benefits of a Daikin Altherma system. By specifying a number of parameters such as the location, the surface area to be heated, the required heating and cooling capacity, the entry and exit water temperatures of the distribution network and the local energy prices, the program displays the following simulation details. 1. Material list with technical specification 2.
other Residential solutions available Single Split Systems SEER 18 Heat Pump FTXS/RXS Cool Only FTKS/RKS 15+ Heat Pump FTXS/RXS single zone 14 13 Capacity R-410A INVERTER TAX CREDIT QUALIFIED Heat Pump Only 15MBH Only Heat Pump FTXN/RXN Cool Only FTKN/RKN Concealed FDXS/RXS 9kBtu/h 450 sq. ft. 12kBtu/h sq. ft. Recommended 625 Maximum Room size For reference use only. Equipment selection should always be based on detailed load calculations. 15kBtu/h 813 sq. ft. 18kBtu/h 1,050 sq. ft.
WARNINGS • Always use a licensed installer or contractor to install this product. Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. • Use only those parts and accessories supplied or specified by Daikin. Ask a licensed contractor to install those parts and accessories. Use of unauthorized parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
