Specifications

2 1/2"
(63mm)
6"
(150mm)
2 3/8"
(60mm)
20"
(508mm)
26"
(660mm)
3/8"Max
(10mm)
11/16"
(18mm)
3 1/16"
(77mm)
6 3/4"
(172mm)
4 5/8"
(116mm)
ø7 3/16"
(ø182mm)
65"-78"
(1651mm-1981mm)
1 3/8"~2 1/2"
(35mm~64mm)
ø5/8"
(ø16mm)
1 5/8"~1 3/4"
(41mm~45mm)
1/2"-14NPT
1/2"-14NPT
PLASTIC GUARD
1:4
SD500045/08-10.01
Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com
Contractor: Contact #:
Job Name: Location:
Submittal Information:
D500045 D500045
SPECIFICATIONS
Warranty
Danze products are covered by a manufacturer’s
limited "lifetime" warranty for manufacturing defects.
Description
• 6" three function traditional style showerhead
• All brass 6" shower arm
• Combination 1/2" copper sweat/IPS 4-port
hook up
• Diverter on valve (Tub & Shower Only)
• Chrome
• Other:Refer to Price List
for additional finish
With Diverter & Stops:
500045 (Tub/Shower)
With Stops:
500545 (Shower only)
Finishes Available
Model
D500045
Standards
• UPC/cUPC
• Energy policy act of 1992
• CSA B125
• ADA Accessibility Guidelines for
Buildings and Facilities -
4.27.4 Controls and Mechanisms
• ASME A112.18.1
• ASSE 1016
SOUTH SEA
™
SINGLE HANDLE PRESSURE BALANCE TUB & SHOWER FAUCET
SOUTH SEA
™
SINGLE HANDLE PRESSURE BALANCE TUB & SHOWER FAUCET
Trim Kits:
(for use w/pressure balance valves)
D500045T (Tub/Shower trim)
D500545T (Shower only trim)
D500445T (Valve only escutcheon trim w/diverter)
D510445T (Valve only escutcheon trim w/o diverter)
Special Packaging
• This product also available with valve
packaged separate from trim.
• Tub & Shower and Valve Only Escutcheon
w/Diverter Trim Kit - use w/valve:
D113000BT (w/diverter & stops)
• Shower Only & Valve Only Es
cutcheon w/o Diverter Trim Kit - use w/valve:
D112000BT (w/stops) or D115000BT (w/o stops)
• Pressure Balance Valves are combination 1/2"
copper sweat, 1/2" NPT threaded connectors for
all ports.
ASSE
1016
Flow Rate
20 40 60 80
3
5
7
9
1
GPM
PSI
