Quick Start-en.book Seite 1 Dienstag, 5. Dezember 2006 10:48 10 Introduction Introduction This Quick start guide is intended as a quick introduction into working with the printer and also to enable inexperienced users to operate the device properly. It describes the most important functions of the printer and contains the essential information for your everyday work with the printer.
Quick Start-en.book Seite 2 Dienstag, 5. Dezember 2006 10:48 10 Introduction ` Using the Online CD-ROM Quick start guide First install the Adobe Acrobat Reader on your hard disk, unless the program has already been installed. To install it, follow the steps described in the README file in the READER directory. To start the online documentation, call the Windows Explorer and double click on the START.PDF file. Then follow the instructions and menus on the screen.
Quick Start-en.book Seite 3 Dienstag, 5.
Quick Start-en.book Seite 4 Dienstag, 5.
Quick Start-en.book Seite 5 Dienstag, 5. Dezember 2006 10:48 10 Quick start guide Installation Installation Place your packaged printer on a solid base. ENGLISH ` Unpacking the printer Make sure that the “Up” symbols point in the correct direction. Open the packaging, lift the printer out of the cardboard box and remove the remaining packaging material. Check the printer for any visible transport damage and missing items.
Quick Start-en.book Seite 6 Dienstag, 5. Dezember 2006 10:48 10 Installation Quick start guide ` Placing the printer Place the printer on a solid, flat, surface, ensuring that the printer is positioned in such a way that it can not topple, and that there is easy access to the control panel and paper input devices.
Quick Start-en.book Seite 7 Dienstag, 5. Dezember 2006 10:48 10 Installation ` Checking the printer voltage Make sure that the device has been set to the correct voltage (e.g. 230 V in Europe, 120 V in the USA). To do this, check the type plate at the back of the printer. Contact your dealer if the setting is incorrect. STOP Never switch on the printer if the voltage setting is incorrect, since this may result in severe damage.
Quick Start-en.book Seite 8 Dienstag, 5. Dezember 2006 10:48 10 Installation Quick start guide ` Switching on the printer Press the power which is located at the front bottom right of the printer switch for switching on the printer. The printer initializes. ONLINE NO PAPER PAPER SETUP 8 USER1 STOP USER2 /EJECT When the initialization is completed, the Ready indicator lights up. The message ONLINE NO PAPER appears on the LCD.
Quick Start-en.book Seite 9 Dienstag, 5. Dezember 2006 10:48 10 Control panel Control panel The control panel consists of three keys for controlling the printer functions, four LEDs displaying the status of the printer and a LCD display with 2 x 16 digits. 1 LCD display: Displays the internal printer status, operating instructions and error messages. 2 Paper LED: Displays if paper is inserted or not; on = paper is inserted, off = no paper inserted.
Quick Start-en.book Seite 10 Dienstag, 5. Dezember 2006 10:48 10 Operating the printer Quick start guide Operating the printer ` Inserting a document Before inserting a document make sure that the printer is switched on and the the message ONLINE NO PAPER is displayed in the LCD. Insert the document in such a way that the right paper edge is positioned inside the area between the left side of the symbol and the right edge of the document support, so that the document alignment can grasp it securely.
Quick Start-en.book Seite 11 Dienstag, 5. Dezember 2006 10:48 10 ` Inserting a passbook Operating the printer Before processing a new vertical-fold or horizontal-fold passbook, you should eliminate the stiffness of the fold by proceeding as follows. Open the passbook on the page that you want to print. Bend the fold backwards extremely hard. Stroke along the fold of the passbook with both thumbs and index fingers and slightly bend the passbook outwards.
Quick Start-en.book Seite 12 Dienstag, 5. Dezember 2006 10:48 10 Operating the printer Quick start guide The bulge of the opened passbook should be as flat as possible to ensure trouble-free transportation into the printer. Place the passbook on the right-hand side of the document support with the page to be printed facing up. The passbook must be entered into the opening of the chute. Once in the chute the printer mechanism will take the book.
Quick Start-en.book Seite 13 Dienstag, 5. Dezember 2006 10:48 10 Quick start guide PAPER SETUP USER1 STOP USER2 /EJECT When the passbook is inserted, the message ONLINE PAPER is displayed on the LCD. STOP Do not use passbooks that do not correspond to the specifications listed in the section “Paper specifications”. Otherwise the passbooks and the print head may be damaged. When the passbook is printed, it is automatically transported out of the printer and released for removal.
Quick Start-en.book Seite 14 Dienstag, 5. Dezember 2006 10:48 10 Service and Maintenance Quick start guide Service and Maintenance ` Replacing the ribbon cassette Make sure that the printer is switched off before replacing the ribbon cassette. STOP The print head may be hot if the printer has been printing for a long time. Wait until it cools down and you are no longer in danger of being burnt.
Quick Start-en.book Seite 15 Dienstag, 5. Dezember 2006 10:48 10 Service and Maintenance Remove the colored ribbon guide from the print head by pulling it downwards. ENGLISH Quick start guide Raise the front end of the ribbon cassette on both sides. Take the ribbon cassette out of the printer.
Quick Start-en.book Seite 16 Dienstag, 5. Dezember 2006 10:48 10 Service and Maintenance Quick start guide Take the new ribbon cassette from the packaging and lift the ribbon guide from the cassette. Remove the transportation lock which fixes the ribbon guide to the cassette. Insert the new ribbon cassette by hooking it into the rear slots of its mountings first. Push the front of the cassette into its mounting so that it clicks into position.
Quick Start-en.book Seite 17 Dienstag, 5. Dezember 2006 10:48 10 Service and Maintenance Pull the ribbon guide under the print head. Tighten the ribbon by turning the tension gear in the direction of the arrow. ENGLISH Quick start guide Press the ribbon guide onto the print head from underneath until you hear it click into place. Check if the ribbon is transported correctly by turning the tension gear in the direction of the arrow.
Quick Start-en.book Seite 18 Dienstag, 5. Dezember 2006 10:48 10 Service and Maintenance Quick start guide Close the main frame by pressing the colored section in the middle of the frame as shown and ensure both left and right hand sides of the frames are fully latched. Close the cover. The printer is now ready to operate and to be switched on again.
T3010-Quick Start-en.fm Seite 19 Dienstag, 5. Dezember 2006 10:54 10 Quick start guide Service and Maintenance ` Printing the Status Page ENGLISH The printer has a function that allows you to printout the current parameter settings. Power the printer off. Press and hold the USER2 key while switching on the printer. PAPER SETUP USER1 STOP USER2 /EJECT Print StatusPage Load Paper PAPER SETUP Print StatusPage Printing...
Quick Start-en.book Seite 20 Dienstag, 5. Dezember 2006 10:48 10 Technical data Quick start guide Technical data ` Printer specifications Printing method 24-pin Dot matrix impact printer Character pitch 10, 12, 15, 16.6, 17.
Quick Start-en.book Seite 21 Dienstag, 5. Dezember 2006 10:48 10 Quick start guide Only use paper that corresponds to the paper specifications and test new sorts of paper before use.
Quick Start-en.book Seite 22 Dienstag, 5. Dezember 2006 10:48 10 Technical data ` Consumables and accessories Quick start guide Only use ribbon cassettes from the manufacturer as products from other manufacturers may damage the print head or the ribbon drive. Consumables Fabric ribbon in recyclable cassettes, color: black Order no. 043393 Only use print heads that are approved to prevent damage to your printer. Accessories 22 Order no.
