4 Gang Programmers Advanced Transdata Corporation PGM2000 8-Gang Programmer for PIC12CXXX, PIC14C000, PIC16CXXX, PIC17CXXX and PIC18CXXX Features: 2001 Microchip Technology Inc. Program data and configuration fuse settings is initially downloaded into the EEPROM of the MCU read from a master chip or downloaded from a file on the PC host. Once the codes reside in the MCU, they are stored securely and protected from accidental modifications.
Advantech Equipment Corp. LabTool-848 Features: • Eight independent, fully isolated 48-pin ZIP sockets • FLASH, EPROM, EEPROM, PIC16CXXX support • Device insertion and continuity test • Support both 5V and 3V chips • High throughput, program eight pieces 8 Mb flash chips within 45 seconds • Semiconcurrent programming with auto-sensing/self-start automatically independent modules allow flexible configuration and minimum down time • Universal adapters support 48 TSOP, 44 PSOP, 40 TSOP flash chips.
4 Advin Systems Inc. Gang Programmers PILOT-1600 Features: • • • • • • 4 Gang Programmers Product Information PILOT-1600 is designed for the production centers that demand high throughput. It programs 16 Microchip Technology PICmicro microcontroller (MCU) devices simultaneously, typically in 15 seconds to 1 minute, depending on device size. Each device is verified with both high and low Vcc margins according to Microchip Technology’s production programmer requirements.
Data I/O Corporation ProMaster 2500 Features: • Supports PICmicro® microcontrollers (MCU), Serial EEPROMs, Parallel EEPROMS and EPROMs • Programs, tests, labels and sorts in a single-pass, tube-to-tube operation • Pick-and-place device transport protects SMT and other devices against physical damage • Changeovers from one package style to another can be done in two minutes or less — no tools or special skills are required • Fully grounded device-contact surfaces guard against ESD damage • Advanced pin elect
4 Data I/O Corporation Gang Programmers ProMaster 3000 Features: 4 Product Information: Providing universal support for devices in both DIP and surface-mount technology (SMT) packages up to 84 pins, the ProMaster 3000 can program, label and sort as many as 7001 devices per hour. Its state-of-the-art pick-andplace handling technology minimizes damage to delicate surface-mount devices, for safe high-volume, high-yield SMT production.
Data I/O Corporation PP 100 Features: • Supports: PIC12CXXX, PIC14C000, PIC16C5X, PIC16C6X, PIC16C62X, PIC16C7XX, PIC16F87X, PIC16C9XX and PIC17CXXX • Supports memory, microcontroller and logic devices • Programs DIP, PLCC, SOIC, QFP, TSOP, BGA, uBGA and other chip-scale packages • Modular system design allows configuration for a wide range of applications • Configurable with 4 to 16 concurrent programming sites • Flexible input/output media options for tray, tube and tape • Label or Laser (CO2 or Yag) mark
Hi-Lo Systems, Inc. 4 ALL-GANG-08 Universal Gang Programmer Gang Programmers Features: 44388 S. Grimmer Blvd. Fremont, CA 94538, USA TEL: (510) 623-8859 FAX: (510) 623-9925 email: sales@tribalmicro.com web: www.hilosystems.com Hi-Lo Systems Research Co., Ltd. 2001 Microchip Technology Inc. The ALL-GANG-08 connects to the serial port of any desktop or laptop PC and features a new Windows compatible interface that makes it easy to use for an operator of any skill level.
LEAP Electronic Co., Ltd.
4 Lloyd Research Ltd. Gang Programmers L9000 Modular Programmer Features: 4 Product Information: The L9000 is a modular programmer which supports virtually all EPROMs, FLASH and almost the entire PICmicro® Microcontroller (MCU) range in both DIL and SOIC packages. Devices can be programmed with serial numbers. Contact: Lloyd Research Ltd. 2001 Microchip Technology Inc.
MQP Electronics System 2000 With Programming Module MP1 or MP3 and Package Converters Features: • Supports PIC16C5X, PIC16C6X, PIC16C7X, PIC16C8X, PIC16C92X, PIC17C4X and PIC12C50X • High-speed stand-alone Gang programmer • Fast and reliable programming • Complete PC remote control capability included • Exchangeable programming modules allow system to cater for most production programming requirements Product Information: The System 2000 is a stand-alone programming system mainly intended for volume produ
MQP ELECTRONICS Features • • • • Programming of parts is prevented if the Master pattern does not have the correct checksum, avoiding expensive manufacturing errors. All programmers in the range comply with the more stringent manufacturing programming specification from Microchip Technology. This ensures excellent programming margins.
ProgRama Tools ChipBurner-Gang 8 Features: • Ideal for bringing costly outsourcing of volume programming in house at a very low cost • Supports up to eight devices at one-time - virtually any package any technology • Program hundreds of devices in under an hour • Fully self-contained stand-alone desktop workstation for full gang, set and set-ofsets programming-contains it's own PC • PC-driven model is also available to keep your entry costs at a minimum • Industry’s first Microsoft® Windows® user interface
ProgRama Tools 4 ChipBurner-Gang 16 Gang Programmers Features: 2001 Microchip Technology Inc. Multi-Matrix Gate Array Technology enables the ChipBurner-Gang 16 to achieve greater results than cluster or concurrent programmers which are simply not suited for gang, set, or set of sets programming. Their exorbitant cost, thousands of dollars more, is not cost justifiable.
ProgRama Tools ChipBurner TRACKCels Features: • Choose from the largest selection of TRACKCels to support virtually every technology on the market today regardless of packaged type • Low-cost solution to today's gang/set programming needs • Wholly versatile through readily achievable selective customization • Mix and match TRACKCels for technology and package support • Ultimate expandibility – as requirements change simply plug in a new TRACKCel • ElectroSense socket isolation circuitry • Power failure devi
ProgRama Tools Features: PROMSoft-XD allows you to manage, program, verify, and even edit your device data straight from your PC. PROMSoft has finally relieved every program operator of the many detailed and error prone tasks involved in programming. Flexibility and ease-of-use were primary goals in the development of PROMSoft-XD. Statistical data is readily available to the user. The devices can be numbered.
ProgRama Tools ChipBurner-Portable Features: • Handheld battery packed device programmer • Supports EPROMS, EEPROMS, FLASH, PICmicros® microcontroller (MCUs) • Supports DIP, PLCC, PSOP/SOIC, TSOP, and PCMCIA Memory Cards • Built-in Dip package support for 8, 24, 28, 32, 40, 42, 44, and 48 pins • Built-in PLCC package support for 28 and 32 pins • Unparalleled 8 Mbit RAM is standard (Expandable to 64 Mbit) • Revolutionary built-in PCMCIA card allows storage of all your master device library files for true fie
4 Gang Programmers RASTEME System Co., Ltd. PIM/10A The Gang Programmer for the PIC16C5X Microcontroller (MCU) Family Features: 4 Product information Reliability increases with the device more because it can be set up freely within the range of the minimum voltage of each device and the maximum voltage. The support devices: Contact PIC16C52, PIC16C54, PIC16LC54, PIC16C54A, PIC16LC54A, PIC16C56, PIC16LC56, PIC16C58A, PIC16LC58A, PIC16C55, PIC16LC55, PIC16C57 and PIC16LC57 RASTEME SYSTEMS Co.,Ltd.
RASTEME System Co., Ltd. PIM/10B The Gang Programmer for the PIC16C6X and PIC16C7X Microcontroller (MCU) Families Features: • Program, blank check, verify functions • The code protection can be chosen • Stand-alone control (download from master device) • PC Host Mode-IBM® and NEC 98 compatibility • Can write 10 devices at once • One touch programming • Serialization capability in PC Host Mode • 12V DC, 2.
4 Stag Programmers Ltd. Gang Programmers Stag P803 Features: Stag Programmers Ltd. Stag Programmers Inc. The Stag P803 is the fastest known gang/set programmer with up to 16 devices in gang. Its FLASH memory stores algorithms which can be easily upgraded via the I/O ports and the CPU is a powerful 32-bit embedded RISC Microcontroller running at 24 MIPS giving high performance programming never encountered before.
Sunrise Electronics, Inc.
T-2000 Programming System Features: Since 1977 Sunrise Electronics, Inc. has produced the most cost effective and reliable Gang, Gang/Set and In-Circuit Programming Systems. The T-2000 represents the latest technology in multiple purpose programming systems having the capacity to program devices of any type, or combination of devices, including microcontrollers, FPGA, EPROM, EEPROM, FLASH, PLD, EPLD, PEEL and PGA. Only the manufacturer’s approved algorithms are used.
Sunrise Electronics, Inc.
T-5000 Programming System Features: The T-5000 represents the latest technology in multiple purpose programming systems having the capacity to develop software at the device or circuit board level, and program devices of any type, or combination of devices, including microcontrollers, FPGA, EPROM, EEPROM, FLASH, PLD, EPLD, PEEL and PGA. Only the manufacturer’s approved algorithms are used.
Sunrise Electronics, Inc.
4 Gang Programmers System General Corporation Multi-APRO Asynchronous Programmer Features: System General Corp. 2001 Microchip Technology Inc. Multi-APRO is based on a 48 Universal Pin-Driver architecture and is the ideal tool for design or manufacturing when working with programmable devices. The system can be configured with a single socket for R&D and then expanded as the application turns to production. All package styles are supported including DIP, PLCC, SOIC, SSOP, TSOP, QFP, TQFP and PGA.
System General Corporation Turpro-848 Gang Programmer • Gang Programmers supporting EPROM/ EEPROM/FLASH/Microcontrollers • Two Embedded CPU and Turbo Mapping Technology • Socket adapter for DIP, PLCC, PSOP, TSOP, VSOP and other device packages • Adapter support for PIC12C508, PIC16C54, PIC16C, PIC16C55, PIC16C56, PIC16C57, PIC16C84 on DIP package • Adapter support for PIC16C6XX and PIC16C7X on DIP package • Supporting 5.0V, 3.3V, 3.0V, 2.7V, 1.
4 Gang Programmers Unitec Electronics Company Ltd. Pim/10A Features: 4 Product Information: This product is a programmer for Microchip Technology PIC16C54, PIC16C55, PIC16C56 and PIC16C57 EPROM microcontrollers. Capable of programming up to 10 devices at once, with or without code protection. 4 Gang Programmers Contact: Unitec Electronics Co., Ltd.
Unitec Electronics Company, Ltd. Pim/10B Features: • Can write 10 devices at once • Programs all ten PIC16C61, PIC16C62, PIC16C64, PIC16C65, PIC16C71, PIC16C73, PIC16C74 PIC16C620, PIC16C621 and PIC16C622 devices • One-touch programming • Ten 40-pin DIP socket (28- to 40-pin devices) • 20 x 2 Liquid Crystal Display • Code protect selection capability • 12V DC, 2.
