IQ3 Data Logger Dash Installation Manual
7
IQ3 Features
The IQ3 Logger Dash is a full programmable LCD digital display dash that is equipped with a 32
channel data logger, 3 axis G meter, 512MB microSD card and GPS board all contained inside
the dash housing. This design eliminates the necessity of an external data logger, G meters or
external GPS module.
The IQ3 is a multi-purpose product designed for use in road racing, circle track, driving schools,
pulling, boating, off road, hill climb or any other type of motorsports that can benefit from the
use of GPS data to obtain speed, timing and mapping functions, without the necessity of wheel
speed sensors, beacon receivers or transmitters.
Display Dash
28 programmable items on 4 pages
Programmable sequential shift lights
4 programmable warning lights with on-screen text warning
5 character programmable alpha/numeric text per display channel
Rear mounted Power/Ground/Engine RPM/Programming Button input
Rear mounted GPS antenna connector
Rear mounted Vnet sensor connector
Shielded, anti-glare coated display for sunlight viewing
Metric and English capable
Blue backlight
Gear indicator
Data Logger
512MB microSD memory card
32 Vnet (canbus) sensor inputs
3 axis G meter – Inline / Lateral / Vertical
4 HZ GPS Board
Base IQ3 Downloaded Data
Battery Voltage / Accel G / Lateral G / Vertical G / Engine RPM
Track Mapping / Speed / Lap Time / Lap Number
Full data analysis capabilities
