Gryphon™ I GBT4102 General Purpose Handheld Linear Imager Barcode Reader with Bluetooth® Wireless Technology Quick Reference Guide
Datalogic USA Inc. 959 Terry Street Eugene, OR 97402 U.S.A. Telephone: (541) 683-5700 Fax: (541) 345-7140 ©2009-2018 Datalogic S.p.A. and/or its affiliates An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described therein may be reproduced or transmitted in any form or by any means without prior written permission of Datalogic USA Inc. or its subsidiaries or affiliates (“Datalogic” or “Datalogic USA”).
Table of Contents END USER LICENSE AGREEMENT .............................................. iii Software Product Policy ............................................................. vii Customers Under Software Support ................................ vii Configuring the Base Station .......................................................1 Changing the Base Station Position ......................... 1 Connecting the Base Station .......................................................
Support Through the Website ...................................................44 Ergonomic Recommendations ..................................................45 Keypad ..........................................................................................
END USER LICENSE AGREEMENT NOTICE TO END USER: BY DOWNLOADING OR INSTALLING THE SOFTWARE, OR BY USING THE DATALOGIC PRODUCT THAT INCLUDES THIS SOFTWARE, THE END USER CONSENTS TO BE BOUND BY THIS AGREEMENT. IF THE END USER DOES NOT AGREE WITH ALL OF THE TERMS OF THIS AGREEMENT, THEN DATALOGIC IS NOT WILLING TO LICENSE THE SOFTWARE AND THE END USER IS NOT ALLOWED TO DOWNLOAD, INSTALL OR USE THE SOFTWARE OR THE DATALOGIC PRODUCT --This End User License Agreement ("EULA") is between Datalogic IP Tech S.r.l.
Agreement. In the event such audit discloses non-compliance with this Agreement, Datalogic shall be entitled to immediately terminate the Agreement, request End User to promptly pay all (additional) license fees due and any further damages, if any. 2. License Fee License fees shall be due by End User to Datalogic according to the terms provided for in the relevant contract for the purchase of the Datalogic Product. 3.
EXEMPLARY, OR OTHER SIMILAR DAMAGES, EVEN IF DATALOGIC OR ITS LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. END USER MUST BRING ANY ACTION UNDER THIS AGREEMENT WITHIN 12 (TWELVE) MONTHS AFTER THE CAUSE OF ACTION ARISES. 6.
ara di Reno (Bologna), Italy, or such other address as may be specified by Datalogic in writing. 11. General Provisions. 11.1. Entire Agreement; Amendment. This document contains the entire agreement between the parties relating to use of the Datalogic Products and the licensing of the Software and supersedes all prior or contemporaneous agreements, written or oral, between the parties concerning the use of the Datalogic Products and licensing of the Software.
Software Product Policy Arbitration Rules of the Singapore International Arbitration Centre ("SIAC Rules") for the time being in force, which rules are deemed to be incorporated by reference in this clause. The seat of the arbitration shall be Singapore. The number of arbitrators will be three, with each side to the dispute being entitled to appoint one arbitrator. The two arbitrators appointed by the parties will appoint a third arbitrator who will act as chairman of the proceedings.
Software Product Policy NOTES viii Gryphon™ I GBT4102
Setting Up the Reader Follow the steps below to connect and get your reader up and communicating with its host. 1. Configure the Base Station starting on this page. 2. Charge the Batteries (see page 8). 3. Link to the Base Station (see page 14). 4. Select the Interface Type (see page 16). 5. Configure the Reader starting on page 30 (optional, depends on settings needed).
Configuring the Base Station A tool such as a rigid pen or a flat screwdriver can be used to change the mounts. Do not allow it to touch the contacts. 1. Insert the appropriate parts for the desired base station position, as shown below. Standing, Horizontal or Vertical 2. Horizontal Only Using your thumbs, push open the plastic tabs on the bottom of the base to free the wing holders. Tab Tab To ensure best contact and performance, do not intermix the parts of the two different mount sets.
Configuring the Base Station 3. The stand can now be repositioned in either horizontal or standing position.
Connecting the Base Station Connecting the Base Station Figure 1 shows how to connect the Base Station to a terminal, PC or other host device. Turn off the host before connection and consult the manual for that equipment (if necessary) before proceeding. Connect the interface cable before applying power to the Base Station. Gryphon BT can also be Powered by the Terminal. When powered by the Terminal, the battery charger is automatically set as Slow charge.
Connecting the Base Station Securing the DC Power Cord (Optional) The DC power cord for the adapter can be secured to the bottom of the base in order to maximize the mechanical retention of the cable itself. The routing of the power cord can be changed to accommodate the base station positioning: horizontal, stand or wall mounting. The cables can be looped around to the front of the Base Station, or fed directly out the back of the Base Station, as shown in Figure 2 on page 5. Figure 2.
Connecting the Base Station Host Connection — Verify before connection that the reader’s cable type is compatible with your host equipment. The Gryphon I GBT4102 can be set up to require a PIN code when connecting to the host. If you are adding new equipment to a system that uses a custom security PIN, please see the PRG for information before proceeding. Most connections plug directly into the host device as shown in Figure 4.
Connecting the Base Station Using the BC4032™ Radio Base Radio Base LEDs LEDs on the Gryphon I Base provide information about the Bases well as battery charging status, as shown in Figure 6. Figure 6. Gryphon I Base LEDs YELLOW LED BUTTON RED LED — GREEN LED The following table describes the significance of each LED. Table 1. Radio Base LEDs LED STATUS Power on / Data Yellow On = Base is powered Yellow Blinking = Base receives data and commands from the Host or the Reader.
Charging the Batteries Charging the Batteries To charge the battery, simply insert the Gryphon into the base. When the scanner is fully seated in the cradle, it will sound a “chirp” to indicate that the cradle has detected the scanner connection. The LEDs on the base (shown in Table 1) will indicate the status of the battery. Before using the Battery, read “Battery Safety” in the following section. Datalogic recommends annual replacement of rechargeable battery packs to ensure maximum performance.
Charging the Batteries • Do not place the battery pack in fire or heat. • Do not connect the positive terminal and negative terminal of the battery pack to each other with any metal object (such as wire). • Do not carry or store the battery pack together with metal objects. • Do not pierce the battery pack with nails, strike it with a hammer, step on it or otherwise subject it to strong impacts or shocks. • Do not solder directly onto the battery pack.
Charging the Batteries CAUTION CAUTION Do not place the battery in or near fire, on stoves or other high temperature locations. Do not place the battery in direct sunlight, or use or store the battery inside cars in hot weather. Doing so may cause the battery to generate heat, explode or ignite. Using the battery in this manner may also result in a loss of performance and a shortened life expectancy. Do not place the battery in microwave ovens, high-pressure containers or on induction cookware.
Charging the Batteries CAUTION Only in case of long storage, to avoid deep discharge of the battery it is recommended to partially recharge the battery every three months to keep the charge status at a medium level. As a reference, run a fast recharge for 20 minutes every three months on unused products to avoid any performance deterioration of the cell. The useful life of LI batteries depends on usage and number of charges, etc.
Charging the Batteries Replacing the Batteries Before proceeding, read “Battery Safety” on the preceding pages. Datalogic recommends annual replacement of rechargeable battery packs to ensure maximum performance. Use the following procedure to change the reader’s battery: 1. With a screwdriver, unscrew the battery cover screw. 2. Unplug the three screws securing the battery holder, and unplug the white connector. Screw Connector Screw 3.
Charging the Batteries Pass-through hole Gold contacts circuit 4. Remove the old battery from its place (if present), and insert the new battery in the same position. 5. Replace the battery holder, plug in the connector and return the contacts circuit to its previous location. When inserting the new battery into the handle, take care to position the battery and the connector as shown. 6. Insert the cover in the handle and screw it back into place.
Linking the Reader Linking the Reader Link Datalogic RF Devices to Base For RF devices, before configuring the interface it is necessary to link the handheld with the base. To link the handheld and the base, press the trigger to wake it and place it on the base. If the reader was previously linked to another base, you must first scan the Unlink barcode before re-linking to the new base. Unlink Link Scanner to Bluetooth Adapter in Server Mode 1. Install any drivers provided with the Bluetooth adapter.
Linking the Reader Linking to Bluetooth Adapter in HID 1. Install any drivers provided with the Bluetooth adapter. 2. Scan the Link to a PC in HID bar code below to make the scanner visible to the host computer. 3. Use the host computer's Bluetooth manager to "Discover new devices" and select "Datalogic Scanner." If you receive an error message, it may be necessary to disable security on the device. 4. Select "connect" on the PC to link the reader to the PC.
Selecting the Interface Type System and Network Layout Typical Setup with Cradle and Host Figure 7. Reader Layout Selecting the Interface Type Upon completing the physical connection between the reader and its host, proceed directly to Interface Selection on page 16 for information and programming for the interface type the reader is connected to (for example: RS232, Keyboard Wedge, USB, etc.) and scan the appropriate barcode to select your system’s correct interface type.
Selecting the Interface Type Unlike some other programming features and options, interface selections require that you scan only one programming barcode label. DO NOT scan an ENTER/EXIT barcode prior to scanning an interface selection barcode. Some interfaces require the scanner to start in the disabled state when powered up. If additional scanner configuration is desired while in this state, pull the trigger and hold for 5 seconds. The scanner will change to a state that allows programming with barcodes.
Selecting the Interface Type IBM (with an accessory cable) IBM-46xx Port 5B reader interface Select IBM-P5B IBM-46xx Port 9B reader interface Select IBM-P9B USB-OEM USB-OEM (can be used for OPOS/UPOS/JavaPOS) Select USB-OEM a. Download the correct USB Com driver from www.datalogic.
Selecting the Interface Type Keyboard Interface Use the programming barcodes to select options for USB Keyboard and Wedge Interfaces.
Selecting the Interface Type KEYBOARD (continued) PC/XT w/Standard Key Encoding Select KBD-XT Keyboard Wedge for IBM Terminal 3153 Select KBD-IBM-3153 Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx make only keyboard Select KBD-IBM-M Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx make break keyboard Select KBD-IBM-MB Keyboard Wedge for DIGITAL Terminals VT2xx, VT3xx, VT4xx Select KBD-DIG-VT 20 Gryphon™ I GBT4102
Selecting the Interface Type KEYBOARD (continued) USB Keyboard with standard key encoding Select USB Keyboard USB Keyboard with alternate key encoding Select USB Alternate Keyboard USB Keyboard for Apple computers Select USB-KBD-APPLE WAND EMULATION Wand Emulation Select WAND Quick Reference Guide 21
Selecting the Interface Type Scancode Tables Reference the Gryphon™ I PRG for information about control character emulation which applies to keyboard interfaces. Country Mode This feature specifies the country/language supported by the keyboard. Only the following interfaces support ALL Country Modes.
Selecting the Interface Type COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Country Mode = U.S.
Selecting the Interface Type COUNTRY MODE (continued) Country Mode = Denmark* Country Mode = France Country Mode = French Canadian Country Mode = Germany Country Mode = Hungary* Country Mode = Italy *Supports only the interfaces listed in the Country Mode feature description 24 Gryphon™ I GBT4102
Selecting the Interface Type COUNTRY MODE (continued) Country Mode = Japanese 106-key* Country Mode = Lithuanian Country Mode = Norway* Country Mode = Poland* Country Mode = Portugal* *Supports only the interfaces listed in the Country Mode feature description Quick Reference Guide 25
Selecting the Interface Type COUNTRY MODE (continued) Country Mode = Romania* Country Mode = Slovakia* Country Mode = Spain Country Mode = Sweden Country Mode = Switzerland* *Supports only the interfaces listed in the Country Mode feature description 26 Gryphon™ I GBT4102
Selecting the Interface Type Caps Lock State This option specifies the format in which the reader sends character data. This applies to keyboard wedge interface and Bluetooth HID Profile. It does not apply when an alternate key encoding keyboard is selected.
Selecting the Interface Type Numlock This option specifies the setting of the Numbers Lock (Numlock) key while in keyboard wedge interface. This only applies to alternate key encoding interfaces. It does not apply to USB keyboard.
Selecting the Interface Type BT HID ALT Mode This feature Enables/Disables the ability to transmit correctly a label content to the host regardless the BT HID Country Mode selected, when BT HID profile is configured.
Programming Programming The reader is factory-configured with a set of standard default features. After scanning the interface barcode from the Interfaces section, you can select other options and customize your reader through use of the instructions and programming barcodes available in the Gryphon™ I Product Reference Guide (PRG). Check the corresponding features section for your interface, and also the Data Editing and Symbologies chapters of the PRG.
Stand Detection Stand Detection The following labels control how the scanner behaves when it is placed into a cradle or stand that has the hardware to support automatic stand detection. Switch to Stand Mode — Automatically switches the scanner to Stand Mode when the scanner is placed in the stand. Switch to Flashing — Automatically switches the scanner to Flash Mode when the scanner is placed in the stand.
Technical Specifications Technical Specifications The following table contains Physical and Performance Characteristics, User Environment and Regulatory information. Item Description Physical Characteristics Color White/Gray Black/Gray Dimensions Height 7.1”/181 mm Length 3.9”/100 mm Width 2.8”/71 mm Weight (without cable) Approximately 8.7 ounces/246 g 9.
Technical Specifications Item Description Minimum Element Width 3 mil Print Contrast Minimum 15% minimum reflectance Decode Capability UPC/EAN/JAN, P2 /P5 add-ons; Code 39; Italian Pharmacode 39; Code 128; C128 ISBT; Code 128 add-ons; I 2 of 5; Standard 2 of 5; Code 11;Codabar; EAN 128; Code 93; MSI; GS1 DataBar™ Omnidirectional, GS1 DataBar™ Limited, GS1 DataBar™ Expanded; Code4, Code5.
Technical Specifications Item Description Regulatory See the Regulatory Addendum for details. Radio Features Frequency Range 2400 to 2483.
LED and Beeper Indications LED and Beeper Indications The reader’s beeper sounds and its LED illuminates to indicate various functions or errors on the reader. An optional “Green Spot” also performs useful functions. The following tables list these indications. One exception to the behaviors listed in the tables is that the reader’s functions are programmable, and may or may not be turned on. For example, certain indications such as the power-up beep can be disabled using programming barcode labels.
LED and Beeper Indications INDICATION DESCRIPTION While in Stand Mode or Trigger Stand Mode the Green Spot is on green spot shall continuously be on while in stand watch state. Green Spota flashes momentarily Upon successful read of a label, the software shall turn the green spot on for the time specified by the configured value. LED BEEPER N/A N/A N/A N/A Programming Mode - The following indications ONLY occur when the reader is in Programming Mode.
Error Codes Error Codes Upon startup, if the reader sounds a long tone, this means the reader has not passed its automatic Selftest and has entered FRU (Field Replaceable Unit) isolation mode. If the reader is reset, the sequence will be repeated. The following table describes the LED flashes/beep codes associated with an error found.
Base Station Indications Base Station Indications INDICATION 38 LEDS Power-up Complete Yellow LED on Reader Disabled by the HOST or the communication with HOST is not established Yellow LED blinking ~1Hz Data/labels are transmitted to the HOST Yellow LEDs turned off for 100mSec Programming Mode Yellow LED blinks quickly Configuration alignment with the HH is in progress Red LED blinks quickly Battery charger in progress Red LED on Battery charger complete Green LED on Battery charger error
Cleaning Procedure Cleaning Procedure Exterior surfaces and scan windows exposed to spills, smudges or debris accumulation require periodic cleaning to ensure best performance during scanning operations. Contacts on the scanner and base should also be cleaned as needed to ensure a good connection. Follow the procedures described in this instruction sheet to keep your Gryphon device in good operating condition. Be sure to turn off power and unplug the device from electrical outlet before cleaning.
Cleaning Procedure Cleaning enclosure and window surfaces 1. 2. 3. 4. Moisten a soft cloth with a recommended cleaning solution. Be sure to apply the solution to your cloth first. Wring excessive liquid from the cloth. Use the cloth to wipe down the surface of the unit. Use cotton swabs, lightly moistened, to reach in corners and crevices. Minimize the amount of disinfectant applied to the contacts. Use another clean dry cloth to remove any residue of the cleaning agent and ensure the unit is dry.
Datalogic Limited Factory Warranty Datalogic Limited Factory Warranty Warranty Coverage Datalogic warrants to Customer that Datalogic's products will be free from defects in materials and workmanship for a period of one year from product shipment. Datalogic hardware products are warranted against defects in material and workmanship under normal and proper use.
Datalogic Limited Factory Warranty for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations. Failure to follow the applicable RMA policy, may result in a processing fee. Customer shall be responsible for return shipment expenses for products which Datalogic, at its sole discretion, determines are not defective or eligible for warranty repair.
Datalogic Limited Factory Warranty DAMAGES REGARDLESS OF WHETHER DATALOGIC HAD ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES. Risk of Loss Customer shall bear risk of loss or damage for product in transit to Datalogic. Datalogic shall assume risk of loss or damage for product in Datalogic’s possession.
Support Through the Website Support Through the Website Datalogic provides several services as well as technical support through its website. Log on to www.datalogic.
Ergonomic Recommendations Ergonomic Recommendations In order to avoid or minimize the potential risk of ergonomic injury follow the recommendations below. Consult with your local Health & CAUTION Safety Manager to ensure that you are adhering to your company’s safety programs to prevent employee injury.
Keypad Keypad Use the barcodes that follow to enter numbers as you would select digits/characters from a keypad. If you make a mistake, scan the CANCEL barcode below to abort and not save the entry string. You can then start again. Cancel an incomplete HID Variable PIN Code Finish by scanning the Exit HID Variable PIN Code label.
Keypad 4 5 6 7 8 9 Quick Reference Guide 47
Keypad NOTES 48 Gryphon™ I GBT4102
