GRYPHON™ Dx30/Mx30 Reference Manual 90ACC1930
GRYPHON™ Dx30/Mx30 REFERENCE MANUAL
DATALOGIC S.p.A. Via Candini 2 40012 - Lippo di Calderara di Reno Bologna - Italy Gryphon™ Dx30/Mx30 Ed.: 08/2006 This manual refers to software version 3.1.0 and later ALL RIGHTS RESERVED Datalogic reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.
CONTENTS GENERAL VIEW ....................................................................................... viii 1 INTRODUCTION .......................................................................................... 1 2 2.1 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.8.1 2.8.2 2.8.3 INSTALLATION............................................................................................ 2 Gryphon™ Dx30 Interface Cable Connections .............................................
RS232 PARAMETERS ............................................................................... 31 Baud Rate ................................................................................................... 32 Parity........................................................................................................... 33 Data Bits ..................................................................................................... 33 Stop Bits..........................................................
DATA FORMAT .......................................................................................... 60 Code Identifier............................................................................................. 63 Custom Code Identifier ............................................................................... 64 Header ........................................................................................................ 65 Terminator...............................................................
Code 128 Family ....................................................................................... 100 Code 93 .................................................................................................... 101 Codabar Family......................................................................................... 102 MSI ........................................................................................................... 104 Plessey ...........................................................
5.5.1 5.5.2 5.5.3 5.5.4 5.5.5 5.6 5.6.1 5.6.2 5.6.3 5.7 5.7.1 5.7.2 5.7.3 5.7.4 5.8 5.9 5.9.1 5.9.2 5.9.3 5.10 5.11 Hardware Trigger Mode ............................................................................ 151 Trigger-Off Timeout................................................................................... 151 Reads per Cycle........................................................................................ 151 Safety Time..................................................................
GENERAL VIEW GRYPHON™ Dx30/Mx30 SERIES READERS Gryphon™ Dx30 Cable Connector Gryphon™ Mx30 Battery Cover Trigger LED Reading Window Figure A – Gryphon™ Dx30 and Mx30 Series Readers Battery Reconditioning Button LEDs Figure B – OM-GRYPHON™ and C-GRYPHON™ viii
INTRODUCTION 1 1 INTRODUCTION Datalogic has moved a step ahead in the concept of “instinctive reading. ”The new Gryphon™ reader series has been developed to provide optimised reading performance through excellent ergonomic design, a natural instinctive reading approach and innovative good reading feedback. The “INSTINCTIVE READING DISTANCE,” a concept introduced by Datalogic a few years ago based on in-depth ergonomic studies, represents the natural position of the user while reading a code.
GRYPHON™ Dx30/Mx30 2 2 INSTALLATION Connections should always be made with power OFF! CAUTION 2.1 GRYPHON™ DX30 INTERFACE CABLE CONNECTIONS The Gryphon™ Dx30 reader incorporates a multi-standard interface which can be connected to a Host by plugging the correct interface cable into the connector as shown below. To disconnect the cable, insert a paper clip or other similar object into the slot on the reader battery cover while unplugging the cable from the Gryphon™ Dx30 body.
INSTALLATION 2.2 2 OM-GRYPHON™ INTERFACE CABLE CONNECTIONS Interface Cable Power OM-GRYPHON™ Connectors The OM-GRYPHON™ incorporates a multi-standard interface which can be connected to a Host by simply plugging the correct interface cable into the Host connector, placed on the base of the cradle. In addition the cradle must be connected to an external power supply.
GRYPHON™ Dx30/Mx30 2 2.3 RS232 CONNECTION 2.
INSTALLATION 2.5 IBM USB POS 2.
2 6 GRYPHON™ Dx30/Mx30
INSTALLATION 2.
GRYPHON™ Dx30/Mx30 2 2.8 2.8.1 GRYPHON™ MX30 BATTERY MAINTENANCE Battery Type You can install NiMh, NiCd or Alkaline AA batteries in the Gryphon™ Mx30. 2.8.2 Battery Charging Once the system is connected and powered, you can place the Gryphon™ Mx30 into the cradle to charge the battery. When the scanner is correctly inserted in the cradle, the red LED on the cradle goes on to indicate that the battery is charging. The green LED on the cradle goes on when the battery is completely charged.
INSTALLATION 2.8.3 2 Replacing Gryphon™ M Batteries To change the batteries in your Gryphon™ Mx30 scanner, proceed as follows: 1. Unscrew the battery cover screw. 2. Open the battery cover. Battery Cover Screw Battery Cover 3. Replace the old batteries with new ones, then screw the battery cover back into place.
2 WARNING 10 GRYPHON™ Dx30/Mx30 Do not incinerate, disassemble, short terminals or expose to high temperature. Risk of fire, explosion. Use specified charger only. Risk of explosion if the battery is replaced by an incorrect type. Dispose of the batteries as required by the relevant laws in force.
GRYPHON™ MX30 SYSTEM AND NETWORK LAYOUTS 3 GRYPHON™ LAYOUTS MX30 SYSTEM 3 AND NETWORK There are two basic system layouts that can be employed: Stand Alone systems and Multidrop STAR-System™ Networks. 3.1 STAND ALONE LAYOUTS 3.1.1 Single Reader Layout 3.1.2 Multiple Reader Layout In stand alone systems, each cradle is connected to a single Host.
GRYPHON™ Dx30/Mx30 3 3.1.3 Multiple Stand Alone Layouts Many stand alone connections can operate in the same physical area without interference, provided all readers and cradles in the system have different addresses.
GRYPHON™ MX30 SYSTEM AND NETWORK LAYOUTS 3.2 3 MULTIDROP STAR-SYSTEM™ NETWORK LAYOUTS Even though many stand alone systems can operate in the same physical area without interfering with each other, it may be desirable to bridge data from multiple base stations in a network to a single Host. Gryphon™ Mx30 readers are compatible with STAR-System™ networks. These networks provide seamless active roaming for any RF reading device in the system. 3.2.1 A. B. C.
GRYPHON™ Dx30/Mx30 4 4 CONFIGURATION 4.1 4.1.1 CONFIGURATION METHODS Reading Configuration Barcodes This manual can be used for complete setup and configuration of your reader by following the setup procedures in this chapter (see par. 4.2 for an overview). If you wish to change the default settings, this manual provides complete configuration of your reader in an easy way.
CONFIGURATION 4.1.4 4 Sending Configuration Strings from Host An alternative configuration method is provided in Appendix A using the RS232 interface. This method is particularly useful when many devices need to be configured with the same settings. Batch files containing the desired parameter settings can be prepared to configure devices quickly and easily. 4.2 SETUP PROCEDURES For Gryphon™ Dx30 Series readers, follow the setup procedures in pars. 4.3, 4.6 and 4.7.
GRYPHON™ Dx30/Mx30 4 4.3 1. GRYPHON™ DX30 SETUP Read the restore default parameters code below. Restore Gryphon™ Dx30 Default Ì$+$*oÎ After reading the above code, go to par. 4.6 Interface Selection. 4.4 GRYPHON™ MX30/OM-GRYPHON™ STAND ALONE SETUP Read the restore default parameters code below. 1. Restore Gryphon™Mx30 Default 2. Read the codes below to set the radio address of the Gryphon™ Mx30 reader. Ì$+$*oÎ Enter configuration Ì$+;Î 3.
CONFIGURATION 5. 4 Read the Bind code to pair the Gryphon™ Mx30 to the OM-Gryphon™ cradle. The reader is dedicated to the cradle. Any previously bound reader will be excluded. To connect several readers to the same cradle see the following paragraph 4.4.1, ‘Using Multiple M Series Readers with Same Cradle'. Bind Ì$+RN0$-IÎ The green LED on the Gryphon™ Mx30 will blink; the reader is ready to be positioned onto the cradle. 6.
GRYPHON™ Dx30/Mx30 4 4.4.1 Using Multiple M-Series Readers With Same Cradle If you want to use several M-Series readers with the same OM-Gryphon™ cradle, you must first Bind the cradle with one of the readers (see previously described configuration procedure). Successive readers can be associated with the same cradle by following the configuration procedure substituting the Bind command with Join (step 5). Join 5.
CONFIGURATION 4.4.2 4 Gryphon™ M/STAR-Modem™ in Stand Alone Mode To configure a Gryphon™ Mx30 reader to communicate with STAR-Modem™ in Stand Alone Mode, follow the procedure in par. 4.4 substituting steps 4 and 5 with those below: STAR-Modem™ Address 4. ÌRSRÎ Read the code above and the four-digit address of the STAR-Modem™. 5. Exit and Save configuration Ì$-?Î END of procedure. YOUR READER IS NOW READY TO READ BARCODES. To change the defaults see par. 4.8.
GRYPHON™ Dx30/Mx30 4 4.5 GRYPHON™ M/STAR-SYSTEM™ SETUP The following procedure allows configuring a Gryphon™ Mx30 reader to communicate with various STAR-System™ devices such as STARGATE™ RF base stations. 1. Restore Gryphon™ Mx30 Default 2. Enter configuration 3. Ì$+$*oÎ Ì$+;Î Set the connection according to the length of the codes to be read: Code Length ≤240 Characters ÌRA1aÎ Code Length >240 Characters ÌRA2dÎ 4.
CONFIGURATION 4 First STAR-System™ Address 5. ÌRSRÎ Read the code above and the four-digit address of the First STAR-System™ device in the system. Set Last STAR-System™ Address 6. ÌRTTÎ Read the code above and the four-digit address of the Last STAR-System™ device in the system. Whenever the system is composed of a single base station, the first and last base station addresses (steps 5 and 6) must have the same value. NOTE Exit and Save Configuration 7. Ì$-?Î END of procedure.
GRYPHON™ Dx30/Mx30 4 4.6 INTERFACE SELECTION Read the interface selection code for your application. RS232 Standard Ì$+CP0$-$Î POS Terminals Nixdorf Mode A Ì$+CM2EC0$->Î Fujitsu Ì$+CM1$-ÈÎ ICL Mode Ì$+CM0$-ÃÎ For POS terminal default settings refer to par. 5.11.
CONFIGURATION 4 WEDGE IBM AT or PS/2 PCs Ì$+CP500$-aÎ IBM XT Ì$+CP503$-vÎ PC Notebook Ì$+CP505$-ÈÎ IBM SURE1 Ì$+CP506$-$Î IBM Terminal 3153 Ì$+CP504$-}Î 23
GRYPHON™ Dx30/Mx30 4 WEDGE (CONTINUED) IBM Terminals 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct KEY TRANSMISSION code. Select the KEYBOARD TYPE if necessary (default = advanced keyboard).
CONFIGURATION 4 WEDGE (CONTINUED) ALT MODE The ALT-mode selection allows barcodes sent to the PC to be interpreted correctly independently from the Keyboard Nationality used. You do not need to make a Keyboard Nationality selection. (default = Num Lock Unchanged). Make sure the Num Lock key on your keyboard is ON.
GRYPHON™ Dx30/Mx30 4 WEDGE (CONTINUED) DIGITAL TERMINALS VT2xx/VT3xx/VT4xx Ì$+CP512$-uÎ APPLE APPLE ADB Bus Ì$+CP513$-|Î 26
CONFIGURATION 4.7 4 USB READER CONFIGURATION The USB interface is compatible with: Windows 98 (and later) Mac OS 8.0 (and later) IBM POS for Windows 4690 Operating System USB Start-up As with all USB devices, upon connection, the Host performs several checks by communicating with the Gryphon™ Dx30. During this phase the green LED on the Gryphon™ Dx30 reader blinks and normal operations are suspended.
GRYPHON™ Dx30/Mx30 4 First Start-Up Connect Gryphon™ Dx30 to Host Green LED blinks Load drivers (if requested) Green LED off Disconnect reader at Host YES Connect external power supply to cable and power up BEEP OK Does a dialog box appear warning that Bus power is not sufficient? NO Green LED off - BEEP OK Select desired USB interface code (USB-KBD is default) Reconnect reader cable to Host and close dialog box Load drivers (if requested) Read test codes.
CONFIGURATION 4 USB USB-KBD Ì$+UA03$-:Î USB-KBD-ALT-MODE Ì$+UA04$-@Î USB-KBD-APPLE Ì$+UA05$-FÎ USB-COM* Ì$+UA02$-4Î USB-IBM-Table Top Ì$+UA00$-(Î USB-IBM-Hand Held Ì$+UA01$-.Î * When configuring USB-COM, the relevant files and drivers must be installed from the USB Device Installation software which can be downloaded from the web site http://www.datalogic.com.
GRYPHON™ Dx30/Mx30 4 4.8 CHANGING DEFAULT SETTINGS Once your reader is setup, you can change the default parameters to meet your application needs. Refer to the preceding paragraphs for initial configuration in order to set the default values and select the interface for your application. In this manual, the configuration parameters are divided into logical groups making it easy to find the desired function based on its reference group.
RS232 PARAMETERS All Gryphon™ Dx30 Series readers + Gryphon™ Mx30/OM-Gryphon™ configurations only BAUD RATE PARITY DATA BITS STOP BITS HANDSHAKING ACK/NACK PROTOCOL FIFO INTER-CHARACTER DELAY RX TIMEOUT SERIAL TRIGGER LOCK 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value 3. Read the Exit and Save Configuration code ONCE, available at the top of each page.
Enter Configuration Ì$+;Î Exit and Save Configuration RS232 Ì$-?Î BAUD RATE 150 baud ÌCDOKÎ 300 baud ÌCD1XÎ 600 baud ÌCD2[Î 1200 baud ÌCD3^Î 2400 baud ÌCD4aÎ 4800 baud ÌCD5dÎ 9600 baud ÌCD6gÎ 19200 baud ÌCD7jÎ 38400 baud ÌCD8mÎ 32
Enter Configuration Ì$+;Î Exit and Save Configuration RS232 Ì$-?Î PARITY none ÌCC0SÎ even parity ÌCC1VÎ odd parity ÌCC2YÎ DATA BITS 7 bits ÌCA0OÎ 8 bits ÌCA1RÎ 9 bits ÌCA2UÎ 33
Enter Configuration Ì$+;Î Exit and Save Configuration RS232 STOP BITS 1 stop bit ÌCB0QÎ 2 stop bits ÌCB1TÎ HANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration RS232 Ì$-?Î ACK/NACK PROTOCOL disable ÌER0sÎ enable ÌER1vÎ See par. 5.1.2 for details, particularly on implementing this parameter with Gryphon™ Mx30. FIFO disable ÌEC0UÎ enable ÌEC1XÎ See par. 5.1.3 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration RS232 INTER-CHARACTER DELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled RX TIMEOUT timeout control in reception from Host ÌCL5Î Read 2 numbers from the table where: 00 = TIMEOUT disabled 01-99 = TIMEOUT from .1 to 9.9 seconds rx timeout 5 seconds See par. 5.1.4 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration RS232 Ì$-?Î SERIAL TRIGGER LOCK disabled ÌCR0qÎ enable and select characters ÌCR1tÎ Read 2 characters from the Hex/Numeric table in the range 00-FE where: − − First Character enables device trigger Second Character inhibits device trigger until the first character is received again.
USB PARAMETERS USB-COM Handshaking, Ack/Nack protocol, FIFO, Inter-character delay, Rx timeout, Serial trigger lock USB-KBD Keyboard nationality, FIFO, Inter-character delay, Inter-code delay, Control character emulation, USB keyboard speed USB-IBM No parameter selection required. 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value 3.
Enter Configuration Ì$+;Î Exit and Save Configuration USB-COM Ì$-?Î HANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details. ACK/NACK PROTOCOL disable ÌER0sÎ enable ÌER1vÎ See par. 5.1.2 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration USB-COM FIFO disable ÌEC0UÎ enable ÌEC1XÎ See par. 5.1.3 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration USB-COM Ì$-?Î RX TIMEOUT timeout control in reception from Host ÌCL5Î Read 2 numbers from the table where: 00 = TIMEOUT disabled 01-99 = TIMEOUT from .1 to 9.9 seconds rx timeout 5 seconds See par. 5.1.4 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration USB-KBD Ì$-?Î KEYBOARD NATIONALITY Not Available for USB-KBD-ALT-MODE Interface This parameter default value is restored through the Interface Selection code and not Restore Default.
Enter Configuration Ì$+;Î Exit and Save Configuration USB-KBD Ì$-?Î FIFO disable ÌEC0UÎ enable ÌEC1XÎ See par. 5.1.3 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration USB-KBD INTER-CODE DELAY delay between codes transmitted to Host ÌFG.
Enter Configuration Ì$+;Î Exit and Save Configuration USB-KBD Ì$-?Î USB KEYBOARD SPEED Normal ÌUT10cÎ Fast ÌUT01dÎ 45
WEDGE PARAMETERS All Gryphon™ Dx30 Series readers + Gryphon™ Mx30/OM-Gryphon™ configurations only KEYBOARD NATIONALITY CAPS LOCK CAPS LOCK AUTO-RECOGNITION NUM LOCK INTER-CHARACTER DELAY INTER-CODE DELAY KEYBOARD SETTING CONTROL CHARACTER EMULATION 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value 3. .
Enter Configuration Ì$+;Î Exit and Save Configuration WEDGE Ì$-?Î KEYBOARD NATIONALITY Belgian ÌFJ7yÎ English ÌFJ4pÎ French ÌFJ2jÎ German ÌFJ3mÎ Italian ÌFJ1gÎ Spanish ÌFJ6vÎ Swedish ÌFJ5sÎ USA ÌFJ0dÎ The Japanese Keyboard Nationality selection is valid only for IBM AT compatible PCs.
Enter Configuration Ì$+;Î Exit and Save Configuration WEDGE Ì$-?Î CAPS LOCK caps lock OFF ÌFE0ZÎ caps lock ON ÌFE1]Î Select the appropriate code to match your keyboard caps lock status. Note: Caps lock manual configuration is ignored when Caps Lock Auto-Recognition is enabled. For PC Notebook interface selections, the caps lock status is automatically recognized, therefore this command is not necessary.
Enter Configuration Ì$+;Î Exit and Save Configuration WEDGE Ì$-?Î NUM LOCK toggle num lock ÌFL1kÎ num lock unchanged ÌFL0hÎ This selection is used together with the Alt Mode interface selection for AT or Notebook PCs.
Enter Configuration Ì$+;Î Exit and Save Configuration WEDGE INTER-CODE DELAY delay between codes transmitted to Host ÌFG.
Enter Configuration Exit and Save Configuration Ì$+;Î WEDGE Ì$-?Î KEYBOARD SETTING ALPHANUMERIC KEYBOARD SETTING The reader can be used with terminals or PCs with various keyboard types and nationalities through a simple keyboard setting procedure. The type of computer or terminal must be selected before activating the keyboard setting command. Keyboard setting consists of communicating to the reader how to send data corresponding to the keyboard used in the application.
01 : Shift 02 : Alt 03 : Ctrl 04 : Backspace 05 : SPACE 06 : ! 07 : " 08 : # 09 : $ 10 : % 11 : & 12 : ' 13 : ( 14 : ) 15 : * 16 : + 17 : , 18 : 19 : .
Enter Configuration Ì$+;Î Exit and Save Configuration WEDGE Ì$-?Î CONTROL CHARACTER EMULATION CTRL + Shift + Key ÌFO0nÎ CTRL + Key ÌFO1qÎ 53
PEN EMULATION All Gryphon™ Dx30 Series readers + Gryphon™ Mx30/OM-Gryphon™ configurations only OPERATING MODE MINIMUM OUTPUT PULSE CONVERSION TO CODE 39 OVERFLOW OUTPUT LEVEL IDLE LEVEL INTER-BLOCK DELAY 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Default value 3. 54 Read the Exit and Save Configuration code ONCE, available at the top of each page.
PEN EMULATION The operating mode parameters are complete commands and do not require reading the Enter and Exit configuration codes. OPERATING MODE interpret mode Ì$]8Î Interprets commands without sending them to the decoder. transparent mode Ì$[4Î Sends commands to the decoder without interpreting them.
Enter Configuration Ì$+;Î Exit and Save Configuration PEN EMULATION Ì$-?Î MINIMUM OUTPUT PULSE high resolution code emulation 200 µs ÌDG0\Î 400 µs ÌDG1_Î 600 µs ÌDG2bÎ 800 µs ÌDG3eÎ 1 ms ÌDG4hÎ 1.2 ms low resolution code emulation See par. 5.2.1 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration PEN EMULATION Ì$-?Î CONVERSION TO CODE 39 AND CODE 128 ► disable conversion to Code 39 ÌDA0PÎ Transmits codes in their original format. enable conversion to Code 39 ÌDA1SÎ Converts codes read into Code 39 format. enable conversion to Code 128 ÌDA2VÎ Converts codes read into Code 128 format. ► = default value for Gryphon™ Dx30 Series readers = default value fro Gryphon™ Mx30 Series readers See par. 5.2.2 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration PEN EMULATION OVERFLOW narrow ÌDH0^Î medium ÌDH1aÎ wide ÌDH2dÎ See par. 5.2.3 for details. OUTPUT LEVEL normal (white = logic level 0) ÌDD0VÎ inverted (white = logic level 1) ÌDD1YÎ See par. 5.2.4 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration PEN EMULATION Ì$-?Î IDLE LEVEL normal (black level) ÌDE0XÎ inverted (white level) ÌDE1[Î See par. 5.2.4 for details. INTER-BLOCK DELAY delay between character blocks transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from .1 to 9.9 seconds delay disabled See par. 5.2.5 for details.
DATA FORMAT NOT FOR PEN INTERFACES CODE IDENTIFIER CUSTOM CODE IDENTIFIER HEADER TERMINATOR SPECIAL KEYS FIELD ADJUSTMENT FIELD ADJ. CHARACTER CODE LENGTH TX CHARACTER REPLACEMENT ADDRESS STAMPING ADDRESS DELIMITER 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value 3. 60 Read the Exit and Save Configuration code ONCE, available at the top of each page.
DATA FORMAT CODE IDENTIFIER TABLE CODE 2/5 interleaved 2/5 industrial 2/5 normal 5 bars 2/5 matrix 3 bars EAN 8 EAN 13 UPC A UPC E EAN 8 with 2 ADD ON EAN 8 with 5 ADD ON EAN 13 with 2 ADD ON EAN 13 with 5 ADD ON UPC A with 2 ADD ON UPC A with 5 ADD ON UPC E with 2 ADD ON UPC E with 5 ADD ON Code 39 Code 39 Full ASCII CODABAR ABC CODABAR Code 128 EAN 128 ISBT 128 Code 93 CIP/39 CIP/HR Code 32 MSI Plessey Standard Plessey Anker Telepen Delta IBM Code 11 Code 16K Code 49 RSS Expanded Linear and Stacked RSS
DATA FORMAT • AIM standard identifiers are not defined for all codes: the X identifier is assigned to the code for which the standard is not defined. The y value depends on the selected options (check digit tested or not, check digit tx or not, etc.). • When customizing the Datalogic Standard code identifiers, 1 or 2 identifier characters can be defined for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).
Enter Configuration Ì$+;Î Exit and Save Configuration DATA FORMAT Ì$-?Î CODE IDENTIFIER disable ÌEB0SÎ Datalogic standard ÌEB1VÎ AIM standard ÌEB2YÎ custom ÌEB3\Î 63
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT CUSTOM CODE IDENTIFIER define custom code identifier(s) ÌEH/Î Read the above code. (Code Identifiers default to Datalogic standard, see table on previous page). Select the code type from the code table in Appendix B for the identifier you want to change. You can define 1 or 2 identifier characters for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).
Enter Configuration Ì$+;Î Exit and Save Configuration Ì$-?Î DATA FORMAT HEADER no header ÌEA00*Î one character header ÌEA01.Î two character header ÌEA022Î three character header ÌEA036Î four character header ÌEA04:Î five character header ÌEA05>Î six character header ÌEA06BÎ seven character header ÌEA07FÎ eight character header ÌEA08JÎ After selecting one of the desired Header codes, read the character(s) from the HEX table. Valid characters are in the range 00-FE.
Enter Configuration Ì$+;Î Exit and Save Configuration Ì$-?Î DATA FORMAT TERMINATOR no terminator ÌEA10-Î one character terminator ÌEA111Î two character terminator ÌEA125Î three character terminator ÌEA139Î four character terminator ÌEA14=Î five character terminator ÌEA15AÎ six character terminator ÌEA16EÎ seven character terminator ÌEA17IÎ eight character terminator ÌEA18MÎ After selecting one of the desired Header codes, read the character(s) from the HEX table.
Enter Configuration Ì$+;Î Exit and Save Configuration DATA FORMAT Ì$-?Î SPECIAL KEYS Available only for Wedge IBM AT-PS/2 and USB-KBD Interfaces It is necessary to define each Special Key by following the procedure given in par. 5.3.2. NOTE Select one or more of the following Special Keys according to your needs.
Enter Configuration Ì$+;Î Exit and Save Configuration Ì$-?Î DATA FORMAT FIELD ADJUSTMENT disable field adjustment ÌEF0[Î Field adjustment allows a number of characters n, to be added to or subtracted from the barcode read. The adjustment can be different for each enabled code type. To define the field adjustment: Read the enable field adjustment code: enable field adjustment ÌEF+Î Select the code type from the Code Identifier Table in Appendix B.
Enter Configuration Ì$+;Î Exit and Save Configuration DATA FORMAT Ì$-?Î FIELD ADJUSTMENT CHARACTER Read the field adjustment character code: field adjustment character ÌEG-Î Read the hexadecimal value corresponding to the character you want to use for field adjustment. Valid characters are in the range 00-FE. For Wedge and USB-KBD interfaces, it is also possible to read the Special Key(s) on page 67.
Enter Configuration Ì$+;Î Exit and Save Configuration DATA FORMAT Ì$-?Î CHARACTER REPLACEMENT disable character replacement ÌEO0mÎ This parameter allows up to three characters to be replaced from the barcode read. These substitutions are stored in memory.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT Example: The following strings define: 1. First Character Replacement: substitution in Code 39 barcodes of all occurrences of the 0 character with the 1 character. 2. Second Character Replacement: substitution in Code 39 barcodes of all occurrences of the A character with the B character.
Enter Configuration Exit and Save Configuration Ì$+;Î DATA FORMAT ADDRESS STAMPING (MX30 SERIES ONLY) disable reader address stamping ÌRU0ÊÎ enable reader address stamping ÌRU1"Î See par. 5.3.3 for details. ADDRESS DELIMITER (MX30 SERIES ONLY) disable reader address delimiter ÌRV0!Î enable reader address delimiter and select characters ÌRV1$Î Read 2 HEX characters in the range 00-FE. See par. 5.3.4 for details.
POWER SAVE SCAN RATE SLEEP STATE/USB SUSPEND ENTER SLEEP TIMEOUT STANDBY 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value 3. Read the Exit and Save Configuration code ONCE, available at the top of each page.
Enter Configuration Ì$+;Î Exit and Save Configuration POWER SAVE Ì$-?Î SCAN RATE 67 scans per sec. ÌBT0tÎ 135 scans per sec. ÌBT1wÎ 270 scans per sec. ÌBT2zÎ A lower scan rate reduces power consumption but can lengthen reading response time. SLEEP STATE/USB SUSPEND disable ÌBQ0nÎ enable ÌBQ1qÎ See par. 5.4.1 for details. For Mx30 series readers, sleep state is entered immediately after reading a code and is not configurable.
Enter Configuration Ì$+;Î Exit and Save Configuration POWER SAVE Ì$-?Î ENTER SLEEP TIMEOUT enter sleep timeout ÌBR@Î Read 2 numbers in the range 00-99: 00 = Enter Sleep state immediately 01-99 = corresponds to a max. 9.9 sec. delay before entering the Sleep state. enter sleep timeout = 0.6 sec. See par. 5.4.2 for details. STANDBY disable ÌBM1iÎ optimize for reading speed enable ÌBM0fÎ optimize for low power consumption See par. 5.4.3 for details.
READING PARAMETERS HAND-HELD OPERATION STAND OPERATION HARDWARE TRIGGER MODE TRIGGER-OFF TIMEOUT FLASH MODE READS PER CYCLE SAFETY TIME BEEPER INTENSITY BEEPER TONE BEEPER TYPE BEEPER LENGTH PDF DECODING RECOGNITION INTENSITY GOOD READ SPOT DURATION AUTOMATIC OPERATION AIMING LIGHT 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value 3.
Enter Configuration Ì$+;Î Exit and Save Configuration READING PARAMETERS Ì$-?Î HAND-HELD OPERATION hardware trigger ÌBK1eÎ software trigger ÌBK0bÎ * always on ÌBK3kÎ * not available for Mx30 series readers automatic ÌBK2hÎ hardware trigger ready ÌBK4nÎ STAND OPERATION hardware trigger ÌBU3ÃÎ software trigger ÌBU1yÎ * always on ÌBU2|Î * not available for Mx30 series readers automatic ÌBU0vÎ 77
Enter Configuration Ì$+;Î Exit and Save Configuration READING PARAMETERS Ì$-?Î HARDWARE TRIGGER MODE trigger active level ÌBA0NÎ trigger active pulse ÌBA1QÎ See par. 5.5.1 for details TRIGGER-OFF TIMEOUT trigger-off timeout ÌBD$Î Read 2 numbers in the range 00-99: 00 = disables the trigger-off timeout 01-99 = corresponds to a max. 99-sec. delay after the trigger press to allow the reader to turn off automatically. trigger-off timeout disabled See par. 5.5.2 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration READING PARAMETERS Ì$-?Î FLASH MODE "FLASH" ON duration ÌBB0PÎ "FLASH" OFF duration ÌBB1SÎ Read 2 numbers in the range 01-99: 01 to 99 = from .1 to 9.9 seconds. Flash-ON = 1 sec. Flash-OFF = 0.6 sec READS PER CYCLE one read per cycle ÌBC0RÎ multiple reads per cycle ÌBC1UÎ See par. 5.5.3 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration READING PARAMETERS Ì$-?Î SAFETY TIME safety time ÌBE&Î Limits same code consecutive reading. Read 2 numbers in the range 00-99: 00 = no same code consecutive reading until reader is removed (no decoding) for at least 400 ms. 01-99 = timeout from .1 to 9.9 seconds before a consecutive read on same code. safety time = 0.5 sec See par. 5.5.4 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration READING PARAMETERS Ì$-?Î BEEPER TONE tone 1 ÌBH0\Î tone 2 ÌBH1_Î tone 3 ÌBH2bÎ tone 4 ÌBH3eÎ BEEPER TYPE monotone ÌBJ0`Î bitonal ÌBJ1cÎ BEEPER LENGTH long ÌBI0^Î short ÌBI1aÎ 81
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS PDF DECODING RECOGNITION INTENSITY low ÌBW0zÎ high ÌBW1}Î GOOD READ SPOT DURATION disable ÌBV0xÎ short ÌBV1{Î medium ÌBV2~Î long ÌBV3ÅÎ 82
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS AUTOMATIC OPERATION AIMING LIGHT disable ÌBb0)Î enable ÌBb1,Î See par. 5.5.5 for details.
DECODING PARAMETERS INK SPREAD OVERFLOW CONTROL INTERDIGIT CONTROL DECODING SAFETY PUZZLE SOLVER™ Before changing these parameter values read the descriptions in par. 5.6. CAUTION 1. 2. 3. 84 Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.
Enter Configuration Ì$+;Î Exit and Save Configuration DECODING PARAMETERS Ì$-?Î INK SPREAD disable ÌAX0{Î enable ÌAX1~Î See par. 5.6.1 for details. OVERFLOW CONTROL disable ÌAW1|Î enable ÌAW0yÎ See par. 5.6.2 for details.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS INTERDIGIT CONTROL disable ÌAV0wÎ enable ÌAV1zÎ See par. 5.6.3 for details. DECODING SAFETY one read ÌED0WÎ (decoding safety disabled) two reads ÌED1ZÎ three reads ÌED2]Î four reads ÌED3`Î Required number of good reads before accepting code.
Enter Configuration Exit and Save Configuration Ì$+;Î DECODING PARAMETERS Ì$-?Î PUZZLE SOLVER™ disable ÌAU0uÎ enable ÌAU1xÎ In the case of damaged or poorly printed codes, this parameter allows reading multiple parts of the single code to reconstruct it. To read codes using this technology, simply move the illuminated bar over the code so that each line of the code is scanned. During this process a series of brief “ticks” indicates that reading is proceeding correctly.
CODE SELECTION EAN/UPC FAMILY 2/5 FAMILY CODE 39 FAMILY CODE 128 FAMILY CODABAR FAMILY CODE 93 MSI PLESSEY TELEPEN DELTA IBM CODE 11 CODE 16K CODE 49 PDF417 PDF READERS ONLY RSS CODES 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value 3. 88 Read the Exit and Save Configuration code ONCE, available at the top of each page.
Enter Configuration Exit and Save Configuration Ì$+;Î CODE SELECTION Ì$-?Î DISABLE ALL CODE FAMILIES ÌAZ0ÃÎ The reader allows up to 5 code selections. This does not limit the number of CODES enabled to 5, as it depends on the code family. NOTE SINGLE SELECTIONS = • ONE combination code from the EAN family • ONE code from the 2/5 family Example 5 code selections: 1. 2/5 Interleaved 2. 2/5 Industrial 3. Code 128 + EAN 128 4. Code 39 Full ASCII + Code 32 5.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î EAN/UPC FAMILY disable the family ÌAA0MÎ Read the desired family code Note: Since the EAN/UPC without ADD ON code selection is enabled by default, to correctly enable another selection, first disable the family.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION WITH ADD ON 2 AND 5 EAN 8/EAN 13/UPC A/UPC E ÌAA5\Î EAN 8/EAN 13 ÌAA6_Î UPC A/UPC E ÌAA7bÎ WITH ADD ON 2 ONLY EAN 8/EAN 13 ÌAAK7Î UPC A/UPC E ÌAAM=Î WITH ADD ON 5 ONLY EAN 8/EAN 13 ÌAAL:Î UPC A/UPC E ÌAAN@Î 91
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î WITH AND WITHOUT ADD ON EAN/UPC with and without ADD ON no Autodiscrimination ÌAA8Ad03Î EAN/UPC Autodiscrimination ADD ON by Prefix ÌAA8Ad19Î By setting the EAN/UPC Autodiscrimination ADD ON by Prefix, the desired prefixes must be selected by reading the corresponding codes given in the following section, since no prefix is configured by default.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION SELECT EAN/UPC PREFIXES NOTE When scanning the following codes, barcodes starting with the selected prefixes will be read and transmitted only if the ADD ON is present. If no ADD ON is found, the barcode will not be read. Barcodes starting with different characters are read regardless of ADD ON presence and transmitted always without ADD ON.
Enter Configuration Exit and Save Configuration Ì$+;Î CODE SELECTION Ì$-?Î Example: The following string allows reading and transmitting with ADD ON all EAN/UPC starting with the 434/439, 977 and 978 prefixes: 1. EAN/UPC Autodiscrimination ADD ON by Prefix. 2. 434/439: enables reading and transmission with ADD ON of all EAN/UPC barcodes starting with 434/439 prefixes. 3. 977: enables reading and transmission with ADD ON of all EAN/UPC barcodes starting with 977 prefix. 4.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION EAN/UPC CHECK DIGIT TX SELECTIONS For each code type in this family you can choose to transmit the check digit or not CHECK DIGIT TRANSMISSION NO CHECK DIGIT TRANSMISSION EAN 8 ÌAAG1oÎ EAN 8 ÌAAG0kÎ EAN 13 ÌAAH1rÎ EAN 13 ÌAAH0nÎ UPC A ÌAAI1uÎ UPC A ÌAAI0qÎ UPC E ÌAAJ1xÎ UPC E ÌAAJ0tÎ 95
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION CONVERSION OPTIONS UPC E to UPC A conversion ÌAAAÄÎ UPC E to EAN 13 conversion ÌAABÇÎ UPC A to EAN 13 conversion ÌAACÊÎ EAN 8 to EAN 13 conversion ÌAAD"Î Enable only ISBN conversion ÌAP1nÎ Enable only ISSN conversion ÌAP2qÎ Enable both ISBN and ISSN conversion ÌAP3tÎ Disable both ISBN and ISSN conversion ÌAP0kÎ 96 Ì$-?Î
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î 2/5 FAMILY disable the family ÌAC0QÎ Read the desired family code Read a check digit selection Interleaved 2/5 ÌAC1TÎ CHECK DIGIT TABLE no check digit control Ì12Î Normal 2/5 (5 Bars) ÌAC2WÎ check digit control and transmission Ì23Î Industrial 2/5 (IATA) ÌAC3ZÎ check digit control without transmission Ì34Î Matrix 2/5 (3 Bars) ÌAC4]Î − − The pharmaceutical code below is part of the 2/5 family but has no check digit or
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î CODE 39 FAMILY disables the family ÌAB0OÎ Read the desired family code Read a check digit selection CHECK DIGIT TABLE Standard Code 39 no check digit control ÌAB1RÎ Ì12Î Full ASCII Code 39 ÌAB2UÎ check digit control and transmission Ì23Î check digit control without transmission Ì34Î 98
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î The pharmaceutical codes below are part of the Code 39 family but have no check digit selections. Code CIP39 ÌAB3XÎ French pharmaceutical code Code 32 ÌAB4[Î Italian pharmaceutical code CODE LENGTH (optional) The code length selection is valid for the entire Code 39 family Read the code + 4 numbers for the code length where: First 2 digits = minimum code length. Second 2 digits = maximum code length.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î CODE 128 FAMILY disables the family ÌAI0]Î Read the desired family code Code 128 ÌAI11=Î control without transmission of check digit EAN 128 ÌAI21@Î control without transmission of check digit Transmit GS Before Code Code EAN 128 uses the ASCII character to separate a variable length code field from the next code field. This character can also be transmitted before the code.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î ISBT 128 ÌAI31CÎ Enabling ISBT 128 automatically disables Puzzle Solver™. CODE LENGTH (optional) The code length selection is valid for the entire Code 128 family. Read the code + 4 numbers for the code length where: set code length ÌAILJÎ First 2 digits = minimum code length Second 2 digits = maximum code length The maximum code length is 99 characters.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION CODABAR FAMILY disable the family ÌAD0SÎ Read the desired equality control code Read a start/stop transmission selection START/STOP CHARACTER TRANSMISSION Standard Codabar ÌAD113Î no start/stop character equality control no transmission Ì12Î Standard Codabar ÌAD127Î start/stop character equality control transmission Ì23Î The Codabar ABC code below uses a fixed start/stop character transmission selection.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION Codabar ABC Forced Concatenation enable Codabar ABC with forced concatenation ÌAD2321Î non start/stop character equality control but transmission CODE LENGTH (optional) The code length selection is valid for the entire Codabar family set code length Read the code + 4 numbers for the code length where: First 2 digits = minimum code length. Second 2 digits = maximum code length. ÌAD*AÎ The maximum code length is 99 characters.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î MSI disable the family ÌAE0UÎ Enable the code by selecting one of the check digit selections.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î PLESSEY disable the family ÌAF0WÎ Enable the code by selecting one of the check digit selections.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î TELEPEN disable the family ÌAL0cÎ Enable the code by selecting one of the check digit selections.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î DELTA IBM disable the family ÌAH0[Î Enable the code by selecting one of the check digit selections.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î CODE 11 disable the family ÌAG0YÎ Enable the code by selecting one of the check digit selections.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î CODE 16K disable the code ÌAJ0_Î Code 16K ÌAJ1bÎ To read stacked codes, simply move the reader over the code so that each line of the code is scanned. During this process a series of brief “ticks” indicates that reading is proceeding correctly. CODE 49 disable the code ÌAM0eÎ Code 49 ÌAM1hÎ To read stacked codes, simply move the reader over the code so that each line of the code is scanned.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î PDF417 Only PDF417 series readers disable the code ÌAR0oÎ PDF417 ÌAR1rÎ To read stacked codes, simply move the reader over the code so that each line of the code is scanned. During this process a series of brief “ticks” indicates that reading is proceeding correctly.
Enter Configuration Ì$+;Î Exit and Save Configuration CODE SELECTION Ì$-?Î RSS CODES disable the family ÌAQ0mÎ DISABLE CODE ENABLE CODE disable RSS Expanded Linear and Stacked ÌAQ10IÎ enable RSS Expanded Linear and Stacked ÌAQ11MÎ disable RSS Limited ÌAQ20LÎ enable RSS Limited ÌAQ21PÎ disable RSS 14 Linear and Stacked ÌAQ30OÎ enable RSS 14 Linear and Stacked ÌAQ31SÎ To read stacked codes, simply move the reader over the code so that each line of the code is scanned.
ADVANCED FORMATTING NOT FOR PEN INTERFACES CONCATENATION ADVANCED FORMATTING Please follow the setup procedure carefully for these parameters. NOTE The Advanced Formatting parameters may not be compatible with the IBM USB POS interface selection. NOTE 1. 2. Read the Enter Configuration code ONCE, available at the top of page . Read configuration codes precisely following the numbered procedure given. = Read the code and follow the procedure given = Default value 3.
Enter Configuration Ì$+;Î Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î CONCATENATION disable ÌEI0aÎ enable ÌEI1dÎ Permits the concatenation of two codes defined by code type and length. It is possible to set a timeout for the second code reading and to define code transmission if the timeout expires. The order of transmission is CODE 1-CODE 2. Define Concatenation 1 Code 1 code ID ÌEK0eÎ Read the code type from the Code Identifier Table beginning in Appendix B.
Exit and Save Configuration ADVANCED FORMATTING 2 Ì$-?Î Code 2 code ID ÌEK1hÎ Read the code type from the Code Identifier Table beginning in Appendix B. code length ÌEL1jÎ Read a number in the range 01-99 from the Hex/Numeric Table. 3 Concatenation Result Code ID use code 1 ID ÌEN0kÎ use code 2 ID ÌEN1nÎ Since you can concatenate codes from different families, you must select the Code ID character of the resulting code.
Exit and Save Configuration ADVANCED FORMATTING 5 Ì$-?Î Transmission after Timeout no code transmitted after timeout ÌEM0iÎ only code 1 transmitted (if read) after timeout ÌEM1lÎ only code 2 transmitted (if read) after timeout ÌEM2oÎ either code 1 or code 2 transmitted after timeout ÌEM3rÎ 115
ADVANCED FORMATTING ADVANCED FORMATTING Advanced formatting has been designed to offer you complete flexibility in changing the format of barcode data before transmitting it to the host system. This formatting will be performed when the barcode data meets certain criteria which you will define in the following procedure. Up to 4 advanced code management formats can be defined and saved in memory.
Enter Configuration Ì$+;Î 1 Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î Begin Format Definition begin Format 1 definition ÌHA0TÎ begin Format 2 definition ÌHA1WÎ begin Format 3 definition ÌHA2ZÎ begin Format 4 definition ÌHA3]Î 2 Match Code Type match code type ÌHB&Î Read the above code + the code type to match from the Code Identifier Table in Appendix B.
Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î Match with Predefined Characters 4 no match ÌHD0HE00ÄÎ OR match with 1 character ÌHD1]Î match with a 2-character string ÌHD2`Î match with a 3-character string ÌHD3cÎ match with a 4-character string ÌHD4fÎ After selecting the predefined match code, read the character(s) from the HEX table. Range of characters = 01-FE. Example: Match code with the 2-character predefined string = "@@".
Exit and Save Configuration ADVANCED FORMATTING 5 Ì$-?Î Divide Code into Fields divide code into fields ÌHF.Î Read one number in the range 1 to 5 to divide the code into fields. 6 Define Code Fields define code fields Each code field length can be set by either: a) defining a field separator character to be found in the code itself. In this case you can choose to discard the code separator character or include it as the last character of the field.
Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î DEFINE FIELD 1 BY: EITHER field separator ÌHG0`Î a) Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î OR match character ÌHG3iÎ b) Read the match character from the HEX table. Range of characters = 01-FE. OR field length ÌHG1cÎ c) Read two numbers in the range 01 to 99 to define the field length.
Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î DEFINE FIELD 2 BY: EITHER field separator ÌHG0`Î a) Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î OR match character ÌHG3iÎ b) Read the match character from the HEX table. Range of characters = 01-FE. OR field length ÌHG1cÎ c) Read two numbers in the range 01 to 99 to define the field length.
Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î DEFINE FIELD 3 BY: EITHER field separator ÌHG0`Î a) Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î OR match character ÌHG3iÎ b) Read the match character from the HEX table. Range of characters = 01-FE. OR field length ÌHG1cÎ c) Read two numbers in the range 01 to 99 to define the field length.
Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î DEFINE FIELD 4 BY: EITHER field separator ÌHG0`Î a) Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î OR match character ÌHG3iÎ b) Read the match character from the HEX table. Range of characters = 01-FE. OR field length ÌHG1cÎ c) Read two numbers in the range 01 to 99 to define the field length.
Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î DEFINE FIELD 5 BY: EITHER field separator ÌHG0`Î a) Read the field separator character from the HEX table. Range of characters = 01-FE. discard separator include separator Ì01Î Ì12Î OR match character ÌHG3iÎ b) Read the match character from the HEX table. Range of characters = 01-FE. OR field length ÌHG1cÎ c) Read two numbers in the range 01 to 99 to define the field length.
Exit and Save Configuration ADVANCED FORMATTING 7 Ì$-?Î First Additional Fixed Field no fixed field ÌHI0dÎ 1 character fixed field ÌHI1gÎ 2 character fixed field ÌHI2jÎ 3 character fixed field ÌHI3mÎ 4 character fixed field ÌHI4pÎ 5 character fixed field ÌHI5sÎ 6 character fixed field ÌHI6vÎ After selecting one of the Additional Fixed Field codes, read the corresponding character(s) from the HEX table. Range of characters = 01-FE.
Exit and Save Configuration ADVANCED FORMATTING 8 Ì$-?Î Second Additional Fixed Field no fixed field ÌHJ0fÎ 1 character fixed field ÌHJ1iÎ 2 character fixed field ÌHJ2lÎ 3 character fixed field ÌHJ3oÎ 4 character fixed field ÌHJ4rÎ 5 character fixed field ÌHJ5uÎ 6 character fixed field ÌHJ6xÎ After selecting one of the Additional Fixed Field codes, read the corresponding character(s) from the HEX table. Range of characters = 01-FE.
Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î Field Transmission 9 number of fields to transmit ÌHK8Î Read one number in the range 1 to 7 for the number of fields to transmit. Include only fields to be transmitted. Field Order Transmission Read the codes corresponding to the fields to transmit in the order in which they are to be transmitted. A field can be transmitted more than once. See example.
Exit and Save Configuration ADVANCED FORMATTING 10 Ì$-?Î Standard Formatting do not apply standard formatting ÌHL0jÎ apply standard formatting ÌHL1mÎ After performing Advanced Formatting on the barcode read, Standard Formatting (Headers, Code Length, Code ID, Terminators) can be applied to the message to be transmitted.
Enter Configuration Ì$+;Î Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î Enable Advanced Format no Advanced Formats enabled ÌHN0nÎ Advanced Format 1 enable ÌHN11NÎ disable ÌHN10JÎ Advanced Format 2 enable ÌHN21QÎ disable ÌHN20MÎ Advanced Format 3 enable ÌHN31TÎ disable ÌHN30PÎ Advanced Format 4 enable ÌHN41WÎ disable ÌHN40SÎ 129
Enter Configuration Ì$+;Î Exit and Save Configuration ADVANCED FORMATTING Ì$-?Î No Match Result clear data - no transmission ÌHO0pÎ transmit data using standard format ÌHO1sÎ This selection determines the action to be taken when codes read do not conform to the advanced format requisites (no match). • Codes not matching can be ignored, cleared from memory and not transmitted. • Codes not matching can be transmitted using the Standard formatting (Headers, Code Length, Code ID, Terminators).
RADIO PARAMETERS Gryphon™ Mx30 Series readers only RADIO PROTOCOL TIMEOUT POWER-OFF TIMEOUT BEEPER CONTROL FOR RADIO RESPONSE BATTERY TYPE SINGLE STORE 1. Read the Enter Configuration code ONCE, available at the top of each page. 2. Read configuration codes from the desired groups. = Read the code and follow the procedure given 3. Read the Exit and Save Configuration code ONCE, available at the top of each page.
Enter Configuration Exit and Save Configuration Ì$+;Î RADIO PARAMETERS Ì$-?Î RADIO PROTOCOL TIMEOUT radio protocol timeout ÌRH<Î Read a number from the table where: 02-19 = timeout from 2 to 19 seconds 2 seconds See par. 5.7.1 for details. POWER-OFF TIMEOUT power-off timeout ÌRPLÎ Read 2 numbers in the range 00-99: 00 = 01-99 = Power-off disabled; reader always ready corresponds to a max. 99 hour delay before power-off. power-off after 4 hours. See par. 5.7.2 for details.
Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS BEEPER CONTROL FOR RADIO RESPONSE normal ÌBF0XÎ only good decode ÌBF1[Î only good reception ÌBF2^Î off ÌBF3aÎ See par. 5.7.3 for details.
Enter Configuration Ì$+;Î Exit and Save Configuration RADIO PARAMETERS Ì$-?Î SINGLE STORE disable ÌRO0zÎ one attempt ÌRO1}Î two attempts ÌRO2ÄÎ three attempts ÌRO3ÇÎ four attempts ÌRO4ÊÎ five attempts ÌRO5"Î six attempts ÌRO6%Î seven attempts ÌRO7(Î eight attempts ÌRO8+Î nine attempts ÌRO9.Î See par. 5.7.
REFERENCES 5 5 REFERENCES 5.1 5.1.1 RS232 PARAMETERS Handshaking Hardware handshaking: (RTS/CTS) The RTS line is activated by the decoder before transmitting a character. Transmission is possible only if the CTS line (controlled by the Host) is active.
GRYPHON™ Dx30/Mx30 5 5.1.2 ACK/NACK Protocol GRYPHON™ Dx30 Readers This parameter sets a transmission protocol in which the Host responds to the reader after every code transmitted. The Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception. data Gryphon™ D cable Host ACK or NACK ACK/NACK enabled If the reader does not receive an ACK or NACK, transmission is ended after the RX Timeout (see par. 5.1.
REFERENCES 5 data data cable GRYPHON™ M good RX beep OM-GRYPHON™ NACK Host data ACK ACK/NACK enabled When ACK/NACK is enabled, the Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception. Only after the ACK character is received by the OM-Gryphon™ does the reader respond with the good reception tone. If the reader does not receive an ACK or NACK, transmission is ended after the RX Timeout (see par.
GRYPHON™ Dx30/Mx30 5 5.1.4 RX Timeout When the RS232 interface is selected, the Host can be used to configure the device by sending it command strings (see appendix A). This parameter can be used to automatically end data reception from the Host after the specified period of time. If no character is received from the Host, after the timeout expires, any incomplete string (any string not terminated by ) is flushed from the device buffer. 5.2 5.2.
REFERENCES 5.2.3 5 Overflow This parameter generates a white space before the first bar and after the last bar of the code. The selections are as follows: narrow medium wide = space 10 times the minimum output pulse. = space 20 times the minimum output pulse. = space 30 times the minimum output pulse. 5.2.
GRYPHON™ Dx30/Mx30 5 5.2.5 Inter-Block Delay For the PEN Emulation interface, data are sent to the Host in fixed size blocks of 20 characters each. The inter-block delay parameter allows setting a delay between each block sent to the Host. 5.
REFERENCES 5 For the WEDGE interface, the following extended keyboard values can also be configured: EXTENDED KEYBOARD TO HEX CONVERSION TABLE IBM AT IBM 3153 APPLE ADB IBM XT IBM 31xx, 32xx, 34xx, 37xx Wyse Digital HEX KEY KEY KEY KEY 83 84 85 86 87 88 89 8A 8B 8C 8D 8E 8F 90 91 92 93 94 95 96 97 98 99 9A 9B ENTER TAB F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 HOME END PG UP PG DOWN ↑ ↓ ← → ESC CTRL (Right) Euro ENTER TAB F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 ESC BACKSPACE HOME END PG UP PG DOWN ↑ ↓ ← →
Enter Configuration Ì$+;Î 5.3.2 Define Special Key Sequence The Special Key(s) for Wedge IBM AT-PS/2 and USB-KBD interface users can be associated with a sequence of keyboard keys that otherwise could not be selected, i.e. ALT + F6, SHIFT + F1. These Special Keys can be used for: Headers/Terminators Character Replacement Field Adjustment Custom Code ID Advanced Formatting – Define Field Advanced Formatting – Additional Fixed Field Follow the procedure to define the desired Special Key sequence: 1.
REFERENCES 2.
Exit and Save Configuration Ì$-?Î 3. Select the character to be associated with the Special Key sequence by reading the codes corresponding to the 3 character values from Appendix C. Then, read the Exit and Save Configuration code above to complete the Special Key sequence.
REFERENCES KEYB CHAR : ; < = > ? @ [ \ ] ^ _ ’ (accent) a b c d e f g h i j k l m n o p q r s t u v 5 ITA USA FR BE DE UK ES SW JP S 04C S 04C 041 S 055 049 S 04A S 01E S 054 05D 05B 036 S 04E S 00E 01C 032 021 023 024 02B 034 033 043 03B 042 04B 03A 031 044 04D 015 02D 01B 02C 03C 02A 049 041 061 055 061 S 03A S 045 A 02E A 03E A 04E A 046 A 03E 03D A 015 032 021 023 024 02B 034 033 043 03B 042 04B 04C 031 044 04D 01C 02D 01B 02C 03C 02A 049 041 061 04A 061 S 03A S 01E A 054 A 061 A 05B A 0
GRYPHON™ Dx30/Mx30 5 KEYB CHAR w x y z { | } ~ ITA USA FR BE 01D 022 035 01A S 00E - 01D 022 035 01A 054 S 05D S 05B S 00E S 01A 022 035 01D 025 A 036 A 055 A 01E A 01A 022 035 01D 046 A 016 A 045 A 04A A DE 01D 022 01A 035 052 04C 054 04E UK ES SW JP 01D 022 035 01A 054 S 061 S 05B S 05D S 01D 022 035 01A 052 A 016 A 05D A - 01D 022 035 01A 03D A 061 A 045 A 05B A 01D 022 035 01A 05B S 06A S 05D S 055 S To use upper case letters, it is necessary to read one of the SHIFT commands from st
REFERENCES KEYB CHAR 5 ITA Up arrow Down arrow Left arrow Right arrow Esc Ctrl right € SPACE USA FR BE DE UK ES SW JP 275 275 275 275 275 275 275 275 275 272 272 272 272 272 272 272 272 272 26B 26B 26B 26B 26B 26B 26B 26B 26B 274 076 274 076 274 076 274 076 274 076 274 076 274 076 274 076 274 076 214 A 02E 029 214 02E A 029 214 024 A 029 214 024 A 029 214 024 A 214 025 A 214 02E A 029 214 02E A 214 029 If Caps Lock Auto-Recognition is disabled, it is
GRYPHON™ Dx30/Mx30 5 2. the following example allows defining Special Key 2 as CTRL + S (upper case): enter configuration Read define Special Key 2 Ì$+;Î + ÌFQ9D2BÎ codes from Appendix C corresponding to the character value for s (lower case) + 3.
REFERENCES 2. 5 the following example allows setting Special Key 2 (defined in example 2 above) as header: enter configuration Read 3. Ì$+;Î one character header + ÌEA01.Î special key 2 + Ì9DÆÎ exit & save configuration + Ì$-?Î the following example allows setting Special Key 3 (defined in example 3 above) as header: enter configuration Read 4. Ì$+;Î one character header + ÌEA01.
GRYPHON™ Dx30/Mx30 5 5.4 5.4.1 POWER SAVE Sleep State/USB Suspend When using interfaces other than USB, this mode allows the µP in the reader to enter a “Sleep” state for minimum power consumption. For D-series readers, this command is only valid when hardware trigger type is selected. Before entering Sleep mode, the following are verified: • no commands coming from Host • no data being transmitted to Host • Enter Sleep Timeout ended (see par. 5.4.2) To exit Sleep mode press the trigger.
REFERENCES 5.5 5 READING PARAMETERS 5.5.1 Hardware Trigger Mode This mode determines how the reading phase is controlled when the hardware trigger operating mode is selected: • trigger active level: the reader goes ON when the trigger is pressed and goes OFF when it is released • trigger active pulse: the reader goes ON at the first trigger press and goes OFF only at a second press 5.5.
GRYPHON™ Dx30/Mx30 5 5.5.4 Safety Time Safety time prevents the device from immediately decoding the same code more than once. Same code consecutive reading can be disabled requiring the reader to be removed from the code (no decoding) for at least 400 ms, or a timeout can be set up to 9.9 seconds before the decoder will accept the same code. Reading is immediate if the code changes.
REFERENCES 5.7 5.7.1 5 RADIO PARAMETERS (MX30 SERIES ONLY) Radio Protocol Timeout This parameter sets the valid time to wait before transmission between the Mx30 series reader and OM-Gryphon™ cradle is considered failed. This parameter should be set taking into consideration the radio traffic (number of readers in the same area). If the RS232 interface is used with ACK/NACK enabled, this parameter should be at least equal to the RX Timeout parameter for low traffic environments.
GRYPHON™ Dx30/Mx30 5 5.7.4 Single Store When single store mode is enabled, if the Gryphon™ Mx30 fails to transmit a code to the cradle, it enters a special operating mode that prevents the user from reading barcodes. When such operating mode is entered, the trigger no longer enables barcode reading but is used to retry transmission itself for the number of attempts selected in configuration. Once the transmission is successful the reader returns to the standard mode.
REFERENCES 5.8 5 CONFIGURATION EDITING COMMANDS The following commands carry out their specific function and then exit the configuration environment. Command Description Ì$+$*oÎ Restore Gryphon™ reader default configuration (see the relative Quick Reference Manual for default settings) Ì$+$!KÎ Transmit the Gryphon™ Dx30 Gryphon™ Mx30 Software release Ì$+$&_Î Transmit Gryphon™ reader configuration in ASCII format.
GRYPHON™ Dx30/Mx30 5 5.9 CONFIGURATION COPYING COMMANDS 5.9.1 Copy Gryphon™ Dx30 Series Procedure: Connect the master (correctly configured reader) and the slave (reader to be configured) together through two RS232 serial interface cables and external power supply. Accessory cables and power supply are available from your Datalogic distributor to provide this connection.
REFERENCES 5.9.2 5 Copy Gryphon™ Mx30 Series Procedure: Using the slave reader and its OM-Gryphon™ cradle, follow the initialization procedure in chapter 4 of this manual or from the Quick Reference Manual. With the master Gryphon™ Mx30 (correctly configured reader), read the Copy Configuration barcode below. Then place it onto an OM-Gryphon™ cradle within 10 seconds. The reader will beep indicating the configuration has been copied.
GRYPHON™ Dx30/Mx30 5 5.9.3 Copy OM-Gryphon™ Procedure: Using the slave reader and its OM-Gryphon™ cradle, read the Restore Default barcode, set the radio address, and then read the RS232 interface barcode from chapter 4 of this manual or from the Quick Reference Manual. Connect the master OM-Gryphon™ and the slave OM-Gryphon™ (cradle to be configured) together through two RS232 serial interface cables and external power supply.
REFERENCES 5 5.10 C-GRYPHON™ CONFIGURATION Battery selection is required only when the Gryphon™ Mx30 reader has an Alkaline battery and you want to use C-Gryphon™ either for serial configuration, software upgrades or to hold Gryphon™ Mx30. Since this type of battery must not be charged it is necessary to disable the C-Gryphon™ charge function by following the procedure: 1.
GRYPHON™ Dx30/Mx30 5 5.11 DEFAULT PARAMETERS FOR POS TERMINALS The default values of the RS232 and Data Format parameters for POS terminals are listed in the following table: NIXDORF Mode A FUJITSU ICL Mode 9600 Odd 8 1 Hardware (RTS/CTS) Disabled DIsabled Disabled 9.9 sec Disabled 9600 None 8 1 None Disabled Enabled Disabled 2 sec Disabled 9600 Even 8 1 RTS always ON Disabled Enabled Disabled 9.
TECHNICAL FEATURES 6 6.1 6 TECHNICAL FEATURES GRYPHON DX30 Electrical Features Power Supply Consumption: Maximum Operating Sleep mode/USB Suspend Max. Scan Rate Reading Indicators Optical Features Sensor Illuminator Wavelength Max. LED Output Power LED Safety Class Reading Field Max.
GRYPHON™ Dx30/Mx30 6 6.2 GRYPHON™ MX30 Electrical Features Battery Type Time of recharge NiMh Operating autonomy (typ. continuous reading) Indicators Max scan rate Optical Features Sensor Illuminator Wavelength Max. LED Output Power LED safety class Reading field Max. Resolution PCS minimum Radio Features Working frequency Bit rate Range (in open air) System Configuration Max. number of devices per base stations Max.
TECHNICAL FEATURES 6.
GRYPHON™ Dx30/Mx30 6 6.4 SYSTEM AND RADIO FEATURES Radio Features Working Frequency 433.92 MHz Bit Rate 19200 Effective Radiated Power <10 mW Range (in open air) 30 m RF Modulation FSK System Configurations OM-GRYPHON™ STARGATE™ 16 255 Maximum number of devices per base stations Maximum number of devices in the same reading area Maximum number of base stations in network 6.5 2000 16 STATUS INDICATORS The reader has three indicators, LED, Beeper and Good Read Spot.
TECHNICAL FEATURES 6 GRYPHON™ Dx30/Mx30 READER DATA ENTRY Beeper¹ LED one beep² ON Good Read Spot Meaning ON Correct read of a code in normal mode H L long TX buffer full (when FIFO is enabled) or TX error between Gryphon™ Mx30 and OM-Gryphon™ H long ON ON Successful advanced format concatenation HHH Timeout expired – operation not completed H H long Error in advanced data formatting OFF OFF Ready to read a code GRYPHON™ Mx30 POWER Beeper LED 10 short H 10 short blinks Meaning Low Ba
GRYPHON™ Dx30/Mx30 6 OM-GRYPHON™/C-GRYPHON™ CHARGE STATUS Red LED Green LED Meaning ON ON Charging OFF ON End of charge OFF OFF No battery inserted Flashing OFF Discharging (see par. 2.8.2) Flashing Flashing Shorted or open battery OM-GRYPHON™/C-GRYPHON™ POWER/COMMUNICATION Yellow LED Meaning ON Power applied OFF Error in reading EEPROM parameters Blinking 6.
TECHNICAL FEATURES 6 GRYPHON™ D130/M130-LR Reading diagram at 25 °C and 300 lux ambient lighting Reading Zones (10° skew angle) 15 10 5 EAN13 M=1 0.33 mm (13 mils) CODE 39 0.13 mm (5 mils) CODE 39 0.50 mm (20 mils) 0 -5 -10 -15 0 5 10 15 20 25 30 35 40 45 50 55 (cm) GRYPHON™ D230/M230 Reading diagram at 25 °C and 300 lux ambient lighting Reading Zones (10° skew angle) 10 5 0.13 mm (5 mils) 0 EAN13 M=1 0.33 mm (13 mils) CODE39 0.
GRYPHON™ Dx30/Mx30 6 Reading diagram at 25 °C and 300 lux ambient lighting Reading Zones (10° skew angle) 8 PDF417 Aspect Ratio 3:1 6 4 2 0.17 mm (6.6mils) 0.38 mm (15mils) 0 -2 -4 -6 0.
HOST CONFIGURATION STRINGS A A HOST CONFIGURATION STRINGS In this section we provide a description of how to modify the device configuration using serial strings sent from the Host. This method requires the RS232 interface. The device configuration can be changed by receiving commands from the Host through the serial interface. When this method is used, the programming sequence format is the following: $+ Command $- CR Carriage return character (0D Hex.
GRYPHON™ Dx30/Mx30 A SERIAL CONFIGURATION STRINGS ENTER/EXIT CONFIGURATION COMMANDS DESCRIPTION Enter Configuration Exit and Save Configuration Restore Default Transmit Software Release (not for PEN emulation) Transmit Device Configuration in ASCII (not for PEN emulation) STRING $+ $$* $! $& These commands do not require $-.
HOST CONFIGURATION STRINGS A RS232 DESCRIPTION Baud rate 150 300 600 1200 2400 4800 9600 19200 38400 Parity none even odd Data bits 7 8 9 Stop bits 1 2 Handshaking disable RTS/CTS XON/XOFF RTS always On ACK/NACK Protocol disable enable FIFO disable enable Inter-character delay (ms) RX Timeout (100 ms) Serial Trigger Lock disable enable and select characters STRING CD0 CD1 CD2 CD3 CD4 CD5 CD6 CD7 CD8 CC0 CC1 CC2 CA0 CA1 CA2 CB0 CB1 CE0 CE1 CE2 CE3 ER0 ER1 EC0 EC1 CK00 - CK99 CL00 - CL99 CR0 CR1ab a = He
GRYPHON™ Dx30/Mx30 A USB DESCRIPTION USB-COM Handshaking ACK/NACK Protocol FIFO Inter-character delay (ms) RX Timeout (100 ms) Serial Trigger Lock USB-KBD Keyboard nationality (not for USB-KBD-ALT-MODE) FIFO Delays Control Character Emulation USB Keyboard Speed STRING disable RTS/CTS XON/XOFF RTS always ON disable enable disable enable disable enable CE0 CE1 CE2 CE3 ER0 ER1 EC0 EC1 CK00 - CK99 CL00 - CL99 CR0 CR1ab Belgian English French German Italian Spanish Swedish USA Japanese disable enable Inte
HOST CONFIGURATION STRINGS A WEDGE DESCRIPTION Keyboard nationality Caps Lock Caps Lock Auto-Recognition (IBM AT compatible only) Num Lock Delays Control Character Emulation Belgian English French German Italian Spanish Swedish USA Japanese (IBM AT compatible only) caps Lock ON caps Lock OFF disable enable Toggle Num Lock Num Lock Unchanged Inter-Character (ms) Inter-Code (s) CTRL + Shift + Key CTRL + Key STRING FJ7 FJ4 FJ2 FJ3 FJ1 FJ6 FJ5 FJ0 FJ8 FE1 FE0 FP0 FP1 FL1 FL0 CK00 - CK99 FG00 - FG99 FO0 FO1
GRYPHON™ Dx30/Mx30 A DATA FORMAT NOT FOR PEN EMULATION INTERFACES DESCRIPTION Code Identifier disable Datalogic standard AIM standard Custom Custom Code Identifier Headers Terminators Special Keys no header one character two characters three characters four characters five characters six characters seven characters eight characters no terminator one character two characters three characters four characters five characters six characters seven characters eight characters special key 1 special key 2 spe
HOST CONFIGURATION STRINGS A DATA FORMAT (continued) NOT FOR PEN EMULATION INTERFACES DESCRIPTION Code Length Tx Field Adjustment Field Adjustment Character Character Replacement Address Stamping Address Delimiter not transmitted transmitted in variable-digit format transmitted in fixed 4-digit format disable right addition left addition right deletion left deletion disable character replacement first character replacement second character replacement third character replacement disable reader address
GRYPHON™ Dx30/Mx30 A READING PARAMETERS DESCRIPTION Hand-Held Operation Stand Operation Hardware Trigger Mode Trigger-off Timeout (s) FLASH ON (100 ms) FLASH OFF (100 ms) Reads per Cycle Safety Time (100 ms) Beeper Intensity Beeper Tone Beeper Type Beeper Length PDF Decoding Recognition Intensity Good Read Spot - Duration Automatic Operation Aiming Light 176 software trigger hardware trigger automatic always on hardware trigger ready software trigger hardware trigger automatic always on trigger acti
HOST CONFIGURATION STRINGS A DECODING PARAMETERS DESCRIPTION Ink-spread Overflow control Interdigit control Puzzle Solver TM Decoding Safety disable enable disable enable disable enable disable enable one read two reads three reads four reads CODE SELECTION DESCRIPTION DISABLE ALL FAMILY CODES EAN/UPC disable EAN/UPC family EAN 8/EAN 13/UPC A/UPC E without ADD ON with ADD ON EAN 8/EAN 13 without ADD ON with ADD ON 2 ONLY with ADD ON 5 ONLY with ADD ON 2 AND 5 UPC A/UPC E without ADD ON with ADD ON 2 O
A GRYPHON™ Dx30/Mx30 CODE SELECTION (continued) DESCRIPTION EAN/UPC UPC E check digit transmission disable enable conversions UPC E to UPC A UPC E to EAN 13 UPC A to EAN 13 EAN 8 to EAN 13 ISBN Conversion codes enable ISBN enable ISSN enable ISBN and ISSN disable ISBN and ISSN Code 39 disable Code 39 family Standard no check digit control check digit control and transmission check digit control without transmission Full ASCII no check digit control check digit control and transmission check digit control
HOST CONFIGURATION STRINGS CODE SELECTION (continued) DESCRIPTION Codabar disable Codabar family Standard no start/stop character equality control nor transmission no start/stop character equality control but transmission start/stop character equality control but no transmission start/stop character equality control and transmission ABC Codabar no start/stop character equality control but transmission Codabar ABC forced concatenation code length start/stop character case in transmission lower case upper ca
GRYPHON™ Dx30/Mx30 A CODE SELECTION (continued) DESCRIPTION STRING Plessey disable the family Standard no check Standard check - with tx Standard check - no tx Anker no check Anker check - with tx Anker check - no tx AF0 AF11 AF12 AF13 AF21 AF22 AF23 Telepen disable the family Numeric no check Numeric check - with tx Numeric check - no tx Alpha no check Alpha check - with tx Alpha check - no tx disable the family no check Type 1 check Type 2 check disable the family no check Type C with tx Type C no
HOST CONFIGURATION STRINGS RADIO PARAMETERS DESCRIPTION Radio Protocol Timeout enable (seconds) Power-Off Timeout Beeper Control For Radio Response normal only good decode only good reception off Battery Type alkaline NiMh Single Store disable one attempt two attempts three attempts four attempts five attempts six attempts seven attempts eight attempts nine attempts A STRING RH02-RH19 RP00-RP99 BF0 BF1 BF2 BF3 RB0 RB1 RO0 RO1 RO2 RO3 RO4 RO5 RO6 RO7 RO8 RO9 181
GRYPHON™ Dx30/Mx30 B B CODE IDENTIFIER TABLE 2/5 Interleaved ÌNOÎ 2/5 Industrial ÌPQÎ 2/5 normal 5 bars ÌOPÎ 2/5 matrix 3 bars ÌQRÎ EAN 8 ÌABÎ EAN 13 ÌBCÎ UPC A ÌCDÎ UPC E ÌDEÎ EAN 8 with 2 ADD ON ÌJKÎ EAN 8 with 5 ADD ON ÌKLÎ EAN 13 with 2 ADD ON ÌLMÎ EAN 13 with 5 ADD ON ÌMNÎ UPC A with 2 ADD ON ÌFGÎ 182
CODE IDENTIFIER TABLE B UPC A with 5 ADD ON ÌGHÎ UPC E with 2 ADD ON ÌHIÎ UPC E with 5 ADD ON ÌIJÎ Code 39 ÌVWÎ Code 39 Full ASCII ÌWXÎ CODABAR ÌRSÎ ABC CODABAR ÌSTÎ Code 128 ÌTUÎ EAN 128 ÌklÎ Code 93 ÌUVÎ CIP/39 ÌYZÎ CIP/HR ÌefÎ Code 32 ÌXYÎ ISBT 128 ÌfgÎ 183
GRYPHON™ Dx30/Mx30 B MSI ÌZ[Î Plessey Anker ÌopÎ Plessey Standard ÌabÎ Delta IBM ÌcdÎ Telepen ÌdeÎ Code 16K ÌpqÎ Code 11 ÌbcÎ Code 49 ÌqrÎ RSS Expanded Linear and Stacked ÌtuÎ RSS Limited ÌvwÎ RSS 14 Linear and Stacked ÌuvÎ PDF417 ÌrsÎ 184
CODE IDENTIFIER TABLE B 185
GRYPHON™ Dx30/Mx30 C C HEX AND NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE 186 char hex char hex char hex NUL SOH STX ETX EOT ENQ ACK BEL BS HT LF VT FF CR SO SI DLE DC1 DC2 DC3 DC4 NAK SYN ETB CAN EM SUB ESC FS GS RS US SPACE ! " # $ % & ' ( ) 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 20 21 22 23 24 25 26 27 28 29 * + , .
HEX AND NUMERIC TABLE C OPEN THIS PAGE TO READ THE DESIRED HEX AND NUMERIC SELECTIONS 187
HEX AND NUMERIC TABLE C HEX / NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE char hex char hex char hex € 80 81 82 83 84 85 86 87 88 89 8A 8B 8C 8D 8E 8F 90 91 92 93 94 95 96 97 98 99 9A 9B 9C 9D 9E 9F A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 ª « ¬ ® ¯ ° ± ² ³ ´ µ ¶ · ¸ ¹ º » ¼ ½ ¾ ¿ À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ï Ð Ñ Ò Ó Ô AA AB AC AD AE AF B0 B1 B2 B3 B4 B5 B6 B7 B8 B9 BA BB BC BD BE BF C0 C1 C2 C3 C4 C5 C6 C7 C8 C9 CA CB CC CD CE CF D0 D1 D2 D3 D4 Õ Ö × Ø Ù Ú Û Ü Ý Þ ß à á â ã ä å æ ç è é ê ë ì í î ï
GRYPHON™ Dx30/Mx30 Reference Manual 90ACC1930
