QuickScanTM i QD2100 General Purpose Corded Handheld Linear Imager Bar Code Reader Quick Reference Guide
Datalogic ADC, Inc. 959 Terry Street Eugene, OR 97402 USA Telephone: (541) 683-5700 Fax: (541) 345-7140 © 2008 - 2013 Datalogic, Inc. An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described therein may be reproduced or transmitted in any form or by any means without prior written permission of Datalogic ADC, Inc. or its subsidiaries or affiliates ("Datalogic" or “Datalogic ADC”).
Datalogic ADC, Inc. TM QUICKSCAN PRODUCT SERIES END USER LICENSE AGREEMENT Notice to End User: The Datalogic Product you have acquired contains embedded Software, which is integral to the product's operation. This Software is being provided to you under license, subject to the terms and conditions of this Agreement. If you use the Datalogic Product, you will be deemed to have accepted the terms and conditions of this Agreement.
2.2 receipt or use of the source code to any Software. End User shall not copy, modify, decompile, disassemble, reverse engineer, or otherwise reproduce or remanufacture the Software, whether modified or unmodified, nor sell, assign, sublicense, distribute, lend, rent, give, or otherwise transfer the Software to any other person or organization, for purposes other than as expressly provided in this Agreement, without Datalogic's prior written consent. 3. Transfers, Support. 3.1 3.2 3.
6.2 responding to End User's problem reports according to Datalogic's standard assistance practices. Datalogic does not warrant that the product will meet End User's requirements or that use of the product will be uninterrupted or error free, or that Datalogic's remedial efforts will correct any nonconformance.
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. 9. Government Restricted Rights; International Use. 9.1 9.2 Use, duplication, or disclosure of the Software by the U.S. Government is subject to the restrictions for computer software developed at private expense as set forth in the U.S. Federal Acquisition Regulations at FAR 52.227-14(g), or 52.227-19 or in the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013(c)(1)(ii), whichever is applicable.
Software Product Policy Software Product Policy Datalogic reserves the right to ship its products with the latest version of software/firmware available. This provides our customers with the very latest in Datalogic software technology. The only exception to this policy is when the buyer has a signed contract with Datalogic that clearly defines the terms and conditions for making software/firmware changes in products shipped to the buyer.
NOTES vi QuickScanTM i
Connect/Disconnect Cable 1 Connect/Disconnect Cable Connect Host Interface 2 Keyboard Wedge Interface RS-232 Interface USB Interface IBM 46xx Interface Quick Reference Guide 1
Aim and Scan 3 012345 012345 65° 65° 2 QuickScanTM i
Parts of the Imager Parts of the Imager LED Scan Window Trigger Nose Boot Scanning Modes The imager can operate in one of several scanning modes: Trigger Single — When the trigger is pulled, scanning is activated until one of the following occurs: - a programmable duration1 has elapsed - a label has been read - the trigger is released This mode is associated with typical handheld reader operation: when the trigger is pulled, scanning starts and the product scans until the trigger is released, or a label
Always On — No trigger pull is required to read a barcode. Scanning is continually on. If the trigger is pulled, the reader acts as if it is in Trigger Single Mode. Double Read Timeout1 prevents undesired multiple reads while in this mode. Stand Mode — No trigger pull is required to read a bar code. Scan- ning is turned on automatically when an item is placed in reader’s field of view. If the trigger is pulled, the reader acts as if it in Trigger Single mode.
Scanning Modes Scanning Modes — continued Scan Mode = Flashing Scan Mode = Always On Scan Mode = Stand Mode Scan Mode = Trigger Object Sense Quick Reference Guide 5
Troubleshooting Problem Possible Cause Nothing happens when the scan button is pulled. Possible Solutions No power to the imager. Check system power. Ensure power supply is connected. Interface or power cables are loose. Ensure all cable connections are secure. Imager not proLED comes on, but bargrammed for correct code does not decode. barcode type. Ensure imager is programmed to read the type of barcode scanned. Refer to the Product Reference Guide (PRG) for more information.
LED and Beeper Indications LED and Beeper Indications The imager’s beeper sounds and its LED illuminates to indicate various functions or errors on the reader. A “Green Spot” also lights to indicate a good read. The tables below list these indications. One exception to the behaviors listed in the tables is that the reader’s functions are programmable, and may or may not be turned on. For example, certain indications, such as the power-up beep can be disabled using programming barcode labels.
Programming Barcodes For your convenience, this guide includes the programming barcodes required to configure the imager for use with different interface (terminal/host) types. See the Product Reference Guide (PRG) for more complete information about programming and configurable features. You can download the latest version of the PRG and any other available publications for the imager from the website listed on the back cover of this manual.
Programming Barcodes RS-232 Interface To use an RS-232 interface, scan the barcode for the desired RS-232 host type.
USB Interface The imager attaches directly to a USB host, or a powered USB hub, and is powered by it. No additional power supply is required. When using a USB interface, the imager auto-detects the USB and defaults to the HID keyboard interface. Select USB-COM-STD1 (simulates RS-232 standard interface) Select USB Keyboard (with standard key encoding) Select USB Alternate Keyboard (with alternate key encoding) Select USB OEM Select USB-KBD-APPLE (for Apple computers) 1.
Programming Barcodes Keyboard Wedge Interface To use a Keyboard Wedge interface, scan the barcode for the desired keyboard type. Select KBD-AT (AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding) Select KBD-AT-NK (IBM AT PS2 with standard key encoding but without external kbd.
Keyboard Wedge Interface — continued Select KBD-XT (PC/XT w/Standard Key Encoding) Select KBD-IBM-3153 (for IBM Terminal 3153) Select KBD-IBM-M (for IBM Terminals 31xx, 32xx, 34xx, 37xx make only keyboard) Select KBD-IBM-MB (for IBM Terminals 31xx, 32xx, 34xx, 37xx make break keyboard) Select KBD-DIG-VT (for DIGITAL Terminals VT2xx, VT3xx, VT4xx) 12 QuickScanTM i
Ergonomic Recommendations Ergonomic Recommendations In order to avoid or minimize the potential risk of ergonomic injury follow the recommendations below. Consult with your local Health & CAUTION Safety Manager to ensure that you are adhering to your company’s safety programs to prevent employee injury.
Hinweis Benutzen Sie nur eine von Datalogic genehmigte Stromversorgung. Die Modelle erfordern eine Stromquelle der Klasse II oder III mit einer Leistungsbegrenzung (LPS). Für eine gültige Sicherheitszertifizierung müssen Klasse III Stromquellen am Eingang nach den Bestimmungen IEC/EN60950-1 (EN 60335-Serien, EN 60065 oder entsprechenden) zugelassen sein. Eingang: 100 - 240 VACAusgang: 5.2 VDC Max. Strom: 0.4 AmpsMax.
Replacing the Scan Window Replacing the Scan Window If the Scan Window becomes scratched, broken or contaminated with heavy dust, fix it by removing the Nose Boot and cleaning or installing a new window. Datalogic offers a replacement window as an orderable accessory. Nose Boot Scan Window To replace the Scan Window, first remove power from the imager then hold the imager with the Scan Window facing up. Gently pull off the Nose Boot and tilt the imager to one side to remove the window.
Imager Labeling Labels are shown here to illustrate their location only. Please view the labels on your product for actual details. S/N Laser & Regulatory Regulatory & Serial Number FOR LASER VERSION: COMPLIES WITH 21 CFR 1040.10 AND 1040.11 EXCEPT FOR DEVIATIONS PURSUANT TO LASER NOTICE NO. 50 DATED JUNE 24, 2007. IEC/EN60825-1:2007. SEE QRG FOR PATENT INFO.
Imager Labeling In order to obtain service under the Factory Warranty, Customer must notify Datalogic of the claimed defect before the expiration of the applicable Warranty period and obtain from Datalogic a return authorization number (RMA) for return of the product to a designated Datalogic service center. If Datalogic determines Customer’s claim is valid, Datalogic will repair or replace product without additional charge for parts and labor.
18 QuickScan TM i X ܝᄺ㒘ӊ ⬉䏃ᵓ㒘ӊ Assy, Module Printed Circuit Board Assy O O O O O O 叏 Hexavalent Chromium (Cr(VI)) O O O 六价卲 O O O 多ᄽ侶 O O O 多ᄽԲㅘ Polybrominated diphenyl ethers (PBDE) China RoHS Polybrominated biphenyls (PBB) 有毒有害物凝或元素 Cadmium (Cd) RoHS TABLE,CHINA,QUICKSCAN I QD2100 EFUP determined by “Look-up Method” (scanner).
DECLARATION OF CONFORMITY 13 EC-82 Rev.:1 Pag.: 1 di 1 Datalogic ADC, Inc. 959 Terry Street Eugene, Oregon 97402 USA La presente dichiarazione di conformità è rilasciata sotto la responsabilità esclusiva di Datalogic ADC, Inc. per: This Declaration of Conformity is issued under the sole responsibility of Datalogic ADC, Inc.
