QuickScan

Lite QW2100

General Purpose Corded Handheld

Linear Imager Bar Code Reader

Product Reference Guide

Summary of content (324 pages)

PAGE 1
QuickScan Lite QW2100 TM General Purpose Corded Handheld Linear Imager Bar Code Reader Product Reference Guide
PAGE 2
Datalogic ADC, Inc. 959 Terry Street Eugene, OR 97402 USA Telephone: (541) 683-5700 Fax: (541) 345-7140 ©2011-2014 Datalogic ADC, Inc. An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described therein may be reproduced or transmitted in any form or by any means without prior written permission of Datalogic ADC, Inc. or its subsidiaries or affiliates ("Datalogic" or "Datalogic ADC").
PAGE 3
Table of Contents Chapter 1. Introduction.................................................................................................................................................................... 1 About this Guide .....................................................................................................................................................................................................................1 Manual Overview ........................................................
PAGE 4
Flash Off Time ...............................................................................................................................................................................................................34 Stand Mode Sensitivity .............................................................................................................................................................................................35 Green Spot Duration ....................................................
PAGE 5
Label ID Symbology Selection ............................................................................................................................................................................... 72 Set Global Mid Label ID Character(s) ............................................................................................................................................................................ 80 Case Conversion ...........................................................................
PAGE 6
P5 Add-Ons Minimum Reads ............................................................................................................................................................................... 116 GS1-128 Add-Ons Minimum Reads ................................................................................................................................................................... 117 GS1 DataBarTM Omnidirectional ...............................................................................
PAGE 7
I 2 of 5 Decoding Level ........................................................................................................................................................................................... 157 I 2 of 5 Length Control ............................................................................................................................................................................................ 158 I 2 of 5 Set Length 1 .........................................................
PAGE 8
Standard 2 of 5 Length Control .......................................................................................................................................................................... 199 Standard 2 of 5 Set Length 1 ............................................................................................................................................................................... 200 Standard 2 of 5 Set Length 2 ....................................................................
PAGE 9
Code 4 and Code 5 Common Configuration Items ............................................................................................................................................... 234 Code 4 and 5 Decoding Level .............................................................................................................................................................................. 234 Code 4 and Code 5 Minimum Reads ................................................................................
PAGE 10
Appendix E. Keypad ............................................................................................................... 297 Appendix F. Scancode Tables ................................................................................................. 301 Control Character Emulation .........................................................................................................................................................................................
PAGE 11
Chapter 1 Introduction About this Guide This Product Reference Guide (PRG) is provided for users seeking advanced technical information, including connection, programming, maintenance and specifications. The Quick Reference Guide (QRG) and other publications associated with this product are downloadable free of charge from the website listed on the back cover of this manual. Typically, units are factory-programmed for the most common terminal and communications settings.
PAGE 12
Introduction ming bar codes necessary for configuring these features. Chapter 11, References provides details concerning programmable features. Appendix A, Technical Specifications lists physical and performance characteristics, as well as environmental and regulatory specifications. It also provides standard cable pinouts. Appendix B, Standard Defaults references common factory default settings for reader features and options.
PAGE 13
Technical Support Technical Support Datalogic Website Support The Datalogic website (www.datalogic.com) is the complete source for technical support and information for Datalogic products. The site offers product support, warranty information, product manuals, product tech notes, software updates, demos, and instructions for returning products for repair. Reseller Technical Support An excellent source for technical assistance and information is an authorized Datalogic reseller.
PAGE 14
Introduction NOTES 4 QuickScanTM Lite QW2100
PAGE 15
Chapter 2 Getting Started About the Reader One distinctive feature offered by the reader is a very wide scan angle which can read long linearbar codes, such as utlity bills. Whether used in Single Trigger or Continuous Mode, the ergonomic design of the reader will help to promote comfortable handling during extended periods of use. The reader can communicate using the following interfaces: RS-232 — The reader can communicate with a standard or Wincor-Nixdorf (W-N) RS- 232 host.
PAGE 16
Getting Started Setting Up the Reader Follow the steps provided in this section to connect and get your reader up and communicating with its host: 1. Install the Interface Cable 2. Select the Interface Type 3. Configure Interface Settings (only if not using factory settings for that interface) 4. Configure Other Features (if modifications are needed from factory settings) Install the Interface Cable The reader kit you ordered to match your interface should provide a compatible cable for your installation.
PAGE 17
Setting Up the Reader USB Connection — Connect the reader to a USB port on the terminal/PC using the correct USB cable for the interface type you ordered. Reference Figure 2. Keyboard Wedge Connection — The Keyboard Wedge cable has a ‘Y’ connection from the reader. Connect the female to the male end from the keyboard and the remaining end at the keyboard port at the terminal/PC. Reference Figure 2. B Figure 2. Other Interface Connections US Ke W M or... IB NOTE yb ed oard ge or...
PAGE 18
Getting Started Hands Free Stand — continued The holder cup can be positioned in any of the three angles shown in Figure 4. Grasp the holder cup as indicated and rotate to the desired position. Refer to Scan Mode on page 30 for information about programming the reader for use with the stand. Figure 4. Adjusting the Stand This accessory can also be used as a holder to mount the reader on a wall or other vertical position as shown in Figure 5. Figure 5.
PAGE 19
Setting Up the Reader Using the Programming Bar Codes This manual contains feature descriptions and bar codes which allow you to reconfigure your reader. Some programming bar code labels, like Resetting the Product Configuration to Defaults on page 10, require only the scan of that single label to enact the change. Most of the programming labels in this manual, however, require the reader to be placed in Programming Mode prior to scanning them. Scan an ENTER/EXIT bar code once to enter Programming Mode.
PAGE 20
Getting Started Software Version Transmission The software version of the device can be transmitted over the RS-232 and Keyboard interfaces by scanning the following label. Transmit Software Version Resetting the Product Configuration to Defaults If you aren't sure what programming options are in your reader, or you've changed some options and want to restore the Custom Default Configuration that may have been saved in the reader, scan the Restore Custom Default Configuration bar code below.
PAGE 21
Chapter 3 Interfaces Interface Selection Each reader model will support one of the following sets of host interfaces: USB Models (all are 2.0 full speed) USB KBD USB COM STD USB OEM RS-232 / Keyboard Wedge Models RS-232 (Standard, Wincor-Nixdorf, OPOS) Keyboard Wedge Configuring the Interface Scan the programming bar code from this section which selects the appropriate interface type matching the system the reader will be connected to.
PAGE 22
Interfaces Table 1. Available Interfaces RS-232 FEATURES $P,HA05,P RS-232 standard interface Select RS232-STD $P,HA12,P RS-232 Wincor-Nixdorf Set RS-232 Interface Features Select RS232-WN $P,HA13,P starting on page 37 RS-232 for use with OPOS/UPOS/JavaPOS Select RS-232 OPOS $P,HA13,P USB Com to simulate RS-232 standard interface Select USB-COM-STDa USB-OEM FEATURES $P,HA45,P USB-OEM (can be used for OPOS/UPOS/JavaPOS) Select USB-OEM a.
PAGE 23
Configuring the Interface KEYBOARD FEATURES $P,HA29,P AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding Select KBD-AT $P,HA11,P Keyboard Wedge for IBM AT PS2 with standard key encoding but without external keyboard Select KBD-AT-NK $P,HA26,P AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Alternate Key Set KEYBOARD WEDGE Interface Features starting on page 53 Select KBD-AT-ALT $P,HA10,P Keyboard Wedge for IBM AT PS2 with alternate key encoding but without exte
PAGE 24
Interfaces KEYBOARD — cont.
PAGE 25
Global Interface Features ENTER/EXIT PROGRAMMING MODE Global Interface Features The following interface features are configurable by all interface types. To set features specific to your interface, turn to that section of this manual: • RS-232 ONLY Interface on page 37 • RS-232/USB-Com Interfaces on page 43 • Keyboard Interface on page 53 • USB-OEM Interface on page 65 Host Commands — Obey/Ignore This option specifies whether the reader will obey or ignore host commands.
PAGE 26
Interfaces ENTER/EXIT PROGRAMMING MODE USB Suspend Mode This setting enables/disables the ability of USB interfaces to enter suspend mode.
PAGE 27
Chapter 4 General Features Double Read Timeout To prevent a double read of the same label, the Double Read Timeout sets the minimum time allowed between reads of labels of the same symbology and data. If the unit reads a label and sees the same label again within the Double Read Timeout, the second read of the label will be ignored. Double Read Timeout does not apply to scan modes that require a trigger pull for each label that is read. ENTER/EXIT PROGRAMMING MODE $CSNDR0A Double Read Timeout = 0.
PAGE 28
General Features ENTER/EXIT PROGRAMMING MODE Double Read Timeout — continued $CSNDR32 Double Read Timeout = 0.5 Second $CSNDR3C Double Read Timeout = 0.6 Second $CSNDR46 Double Read Timeout = 0.7 Second $CSNDR50 Double Read Timeout = 0.8 Second $CSNDR5A Double Read Timeout = 0.
PAGE 29
Label Gone Timeout ENTER/EXIT PROGRAMMING MODE Label Gone Timeout This feature sets the time after the last label segment is seen before the reader prepares for a new label. The timeout can be set within a range of 10 milliseconds to 2,550 milliseconds (2.55 seconds) in 10ms increments. Label Gone Timeout does not apply to scan modes that require a trigger pull for each label that is read. See Label Gone Timeout on page 244 for more detailed programming instructions.
PAGE 30
General Features ENTER/EXIT PROGRAMMING MODE Power Save Mode When this feature is enabled, the reader will enter Power Save Mode (a lower power consumption state) after being idle (no scanner activity) for one second. RS-232 and USB interfaces ONLY. NOTE A reader having a Scan Mode setting of Object Sense, Stand Mode, Flashing, or Always On will not enter Power Save Mode. (The reader is always internally active when in these modes.
PAGE 31
Sleep Mode Timeout ENTER/EXIT PROGRAMMING MODE Sleep Mode Timeout Specifies the timeout value for the reader to enter Sleep Mode (a very low power consumption state). RS-232 interface ONLY. NOTE A reader having a Scan Mode setting of Object Sense, Stand Mode, Flashing, or Always On will not enter Sleep Mode. (The reader is always internally active when in these modes.
PAGE 32
General Features ENTER/EXIT PROGRAMMING MODE LED and Beeper Indicators Power On Alert Disables or enables the indication (from the Beeper) that the reader is receiving power.
PAGE 33
LED and Beeper Indicators ENTER/EXIT PROGRAMMING MODE Good Read: When to Indicate This feature specifies when the reader will provide indication (beep and/or flash its green LED) upon successfully reading a bar code. Choices are: • Good Read = Indicate after decode • Good Read = Indicate after transmit • Good Read = Indicate after CTS goes inactive, then active This option, which uses CTS, is only valid for RS232 interfaces.
PAGE 34
General Features ENTER/EXIT PROGRAMMING MODE Good Read Beep Type Specifies whether the good read beep has a mono or bitonal beep sound.
PAGE 35
LED and Beeper Indicators ENTER/EXIT PROGRAMMING MODE Good Read Beep Frequency Adjusts the good read beep to sound at a selectable low, medium or high frequency, selectable from the list below. (Controls the beeper’s pitch/tone.) $CBPFR00 Good Read Beep Frequency = Low $CBPFR01 Good Read Beep Frequency = Medium $CBPFR02 DEFAULT Good Read Beep Frequency = High Good Read Beep Length Specifies the duration of a good read beep.
PAGE 36
General Features ENTER/EXIT PROGRAMMING MODE Good Read Beep Length — continued $CBPLE08 DEFAULT Good Read Beep Length = 80 msec $CBPLE0A Good Read Beep Length = 100 msec $CBPLE0C Good Read Beep Length = 120 msec $CBPLE0E Good Read Beep Length = 140 msec $CBPLE10 Good Read Beep Length = 160 msec $CBPLE12 Good Read Beep Length = 180 msec $CBPLE14 Good Read Beep Length = 200 msec 26 QuickScanTM Lite QW2100
PAGE 37
LED and Beeper Indicators ENTER/EXIT PROGRAMMING MODE Illumination Control Controls illumination during a good read beep. Setting this configuration item to turn off illumination during the beep reduces the peak current drawn by the reader in some scanning modes.
PAGE 38
General Features ENTER/EXIT PROGRAMMING MODE Good Read Beep Volume Selects the beeper volume (loudness) upon a good read beep. There are three selectable volume levels.
PAGE 39
LED and Beeper Indicators ENTER/EXIT PROGRAMMING MODE Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 0.1 to 25.5 seconds in 100ms increments. See Good Read LED Duration on page 245 for more detailed programming instructions. $CLAGL Select Good Read LED Duration Setting ~ Make a mistake? Scan the CANCEL bar code to abort and not save the entry string.
PAGE 40
General Features ENTER/EXIT PROGRAMMING MODE Scanning Features Scan Mode See Scan Mode on page 246 for more detailed programming instructions.
PAGE 41
Scanning Features ENTER/EXIT PROGRAMMING MODE Stand Mode Triggered Timeout This feature specifies the time to remain in Trigger Single mode after the trigger is pulled while in Autosense® Stand Mode. This timeout is only used when the Scan Mode is configured as Auto- sense® Stand Mode. NOTE $CSNOT01 DEFAULT Stand Mode Triggered Timeout = 0.5 Seconds $CSNOT03 Stand Mode Triggered Timeout = 1.
PAGE 42
General Features ENTER/EXIT PROGRAMMING MODE Stand Mode Triggered Timeout — continued $CSNOT0C Stand Mode Triggered Timeout = 6 Seconds $CSNOT10 Stand Mode Triggered Timeout = 8 Seconds $CSNOT00 Stand Mode Triggered Timeout = Switch back to Trigger Single on trigger pull 32 QuickScanTM Lite QW2100
PAGE 43
Scanning Features ENTER/EXIT PROGRAMMING MODE Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second increments. See Scanning Active Time on page 247 for more detailed programming instructions. $CSNET Select Scanning Active Time Setting ~ Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning.
PAGE 44
General Features ENTER/EXIT PROGRAMMING MODE Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. See Flash On Time on page 248 for more detailed programming instructions. $CSNFN Select Flash ON Time Setting ~ Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning.
PAGE 45
Scanning Features ENTER/EXIT PROGRAMMING MODE DEFAULT 06 = Flash is OFF for 600ms Stand Mode Sensitivity Sets the sensitivity level for stand mode wakeup. Choices are low, medium and high.
PAGE 46
General Features ENTER/EXIT PROGRAMMING MODE Green Spot Duration Specifies the duration of the good read pointer beam after a good read.
PAGE 47
Chapter 5 RS-232 ONLY Interface Introduction Use the programming bar codes in this chapter if modifications to the standard RS-232 interface settings are necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB interfaces are available in Chapter 6, RS-232/USB-Com Interfaces. RS-232 Standard Factory Settings Reference Appendix B, Standard Defaults for a listing of standard factory settings.
PAGE 48
RS-232 ONLY Interface ENTER/EXIT PROGRAMMING MODE Baud Rate — continued $CR2BA03 DEFAULT Baud Rate = 9600 $CR2BA04 Baud Rate = 19,200 $CR2BA05 Baud Rate = 38,400 $CR2BA06 Baud Rate = 57,600 $CR2BA07 Baud Rate = 115,200 38 QuickScanTM Lite QW2100
PAGE 49
Data Bits ENTER/EXIT PROGRAMMING MODE Data Bits This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and receiving data. $CR2DA00 7 Data Bits $CR2DA01 DEFAULT 8 Data Bits Stop Bits The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream.
PAGE 50
RS-232 ONLY Interface ENTER/EXIT PROGRAMMING MODE Parity This feature specifies parity required for sending and receiving data. A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. • Select None when no parity bit is required. • Select Odd parity and the parity bit value is set to 0 or 1, based on data, to ensure that an odd number of 1 bits are contained in the coded character.
PAGE 51
Handshaking Control ENTER/EXIT PROGRAMMING MODE Handshaking Control The data interface consists of an RS-232 port designed to operate either with or without the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS). Handshaking Control includes the following options: • RTS — RTS is asserted during transmissions. CTS is ignored. • RTS/CTS — RTS is asserted during transmissions. CTS gates transmissions. • RTS/XON/XOFF — RTS is asserted during transmissions. CTS is ignored.
PAGE 52
RS-232 ONLY Interface NOTES 42 QuickScanTM Lite QW2100
PAGE 53
Chapter 6 RS-232/USB-Com Interfaces Introduction The programming bar codes in this chapter allow modifications to the standard RS-232 and USB-Com interfaces. Standard Factory Settings Reference Appendix B, Standard Defaults for a listing of standard factory settings.
PAGE 54
RS-232/USB-Com Interfaces ENTER/EXIT PROGRAMMING MODE Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. See Intercharacter Delay on page 250 for more detailed programming instructions.
PAGE 55
Beep On ASCII BEL ENTER/EXIT PROGRAMMING MODE Beep On ASCII BEL When this parameter is enabled, the reader issues a beep when a character is detected on the RS-232 serial line. is issued to gain a user's attention to an illegal entry or other important event.
PAGE 56
RS-232/USB-Com Interfaces ENTER/EXIT PROGRAMMING MODE ACK NAK Options This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol. When configured, the reader and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error. Options are: • Disable • Enable for label transmission — The reader expects an ACK/NAK response from the host when a label is sent.
PAGE 57
ACK NAK Options ENTER/EXIT PROGRAMMING MODE ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See ACK Character on page 251 for more detailed programming instructions. NOTE Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits has been set as 7 Data Bits.
PAGE 58
RS-232/USB-Com Interfaces ENTER/EXIT PROGRAMMING MODE ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. See ACK NAK Timeout Value on page 253 for more detailed programming instructions.
PAGE 59
ACK NAK Options ENTER/EXIT PROGRAMMING MODE ACK NAK Retry Count This feature specifies the number of times the reader retries a label transmission due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries. See ACK NAK Retry Count on page 254 for more detailed programming instructions.
PAGE 60
RS-232/USB-Com Interfaces ENTER/EXIT PROGRAMMING MODE ACK NAK Error Handling This feature specifies the method the reader uses to handle receive errors detected while waiting for an ACK character from the host.
PAGE 61
Indicate Transmission Failure ENTER/EXIT PROGRAMMING MODE Indicate Transmission Failure This option enables/disables the reader’s ability to sound an error beep to indicate a transmission failure while in ACK/NAK mode. $CR2TF00 Indicate Transmission Failure = Disable Indication $CR2TF01 DEFAULT Indicate Transmission Failure = Enable Indication Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected.
PAGE 62
RS-232/USB-Com Interfaces ENTER/EXIT PROGRAMMING MODE Enable Character Specifies the value of the RS-232 host command used to enable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. See Enable Character on page 256 for more detailed programming instructions. NOTE Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits has been set as 7 Data Bits.
PAGE 63
Chapter 7 Keyboard Interface Introduction Use the programming bar codes in this chapter to select options for USB Keyboard and Wedge Interfaces. Standard Factory Settings Reference Appendix B, Standard Defaults for a listing of standard factory settings. Scancode Tables Information about control character emulation which applies to keyboard interfaces is listed in Appendix F, Scancode Tables.
PAGE 64
Keyboard Interface ENTER/EXIT PROGRAMMING MODE Country Mode This feature specifies the country/language supported by the keyboard.
PAGE 65
Country Mode ENTER/EXIT PROGRAMMING MODE Country Mode — continued $CKBCO02 Country Mode = English (British) $CKBCO11 Country Mode = Croatian $CKBCO0E Country Mode = Czech $CKBCO03 Country Mode = Danish $CKBCO04 Country Mode = French $CKBCO05 Country Mode = German $CKBCO0D Country Mode = Hungarian Product Reference Guide 55
PAGE 66
Keyboard Interface ENTER/EXIT PROGRAMMING MODE Country Mode — continued $CKBCO06 Country Mode = Italian $CKBCO0C Country Mode = Japanese 106-key $CKBCO07 Country Mode = Norwegian $CKBCO12 Country Mode = Polish $CKBCO08 Country Mode = Portuguese (Brazilian) $CKBCO10 Country Mode = Romanian $CKBCO0F Country Mode = Slovakian 56 QuickScanTM Lite QW2100
PAGE 67
Caps Lock State ENTER/EXIT PROGRAMMING MODE Country Mode — continued $CKBCO09 Country Mode = Spanish (Latin American) $CKBCO0A Country Mode = Swedish $CKBCO0B Country Mode = Swiss Caps Lock State This option specifies the format in which the reader sends character data. This applies to Keyboard Wedge interfaces. This does not apply when an alternate key encoding keyboard is selected.
PAGE 68
Keyboard Interface ENTER/EXIT PROGRAMMING MODE Numlock This option specifies the setting of the Numbers Lock (Numlock) key while in Keyboard Wedge interface. This only applies to alternate key encoding interfaces. It does not apply to USB Keyboard. $CKBNL00 DEFAULT Numlock = Numlock key unchanged $CKBNL01 Numlock = Numlock key toggled Keyboard Numeric Keypad This feature specifies if numeric characters will be sent using the standard keys or the numeric keypad.
PAGE 69
Keyboard Send Control Characters ENTER/EXIT PROGRAMMING MODE Keyboard Send Control Characters This feature is used by the Keyboard Wedge and USB Keyboard interfaces. It specifies how the reader transmits ASCII control characters to the host. Reference Appendix F, Scancode Tables for more information about control characters. Options are as follows: Send Ctrl+Key — ASCII characters from 00H to 0x1FH inclusive are transmitted in the format Ctrl+Key. Special keys are available in the range from 81H to A1.
PAGE 70
Keyboard Interface ENTER/EXIT PROGRAMMING MODE Wedge Quiet Interval This option specifies the amount of time to look for keyboard activity before the reader breaks the keyboard connection in order to transmit data to host. The selectable range for this feature is from 0 to 990ms in 10ms increments. See Wedge Quiet Interval on page 257 for more detailed programming instructions. This feature applies ONLY to the Keyboard Wedge interface.
PAGE 71
Intercharacter Delay ENTER/EXIT PROGRAMMING MODE Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. See Intercharacter Delay on page 258 for more detailed programming instructions. This feature applies ONLY to the Keyboard Wedge interface.
PAGE 72
Keyboard Interface ENTER/EXIT PROGRAMMING MODE Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is from 0 to 99 seconds. See Intercode Delay on page 259 for more detailed programming instructions. $CKBID Set Intercode Delay ~ Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning.
PAGE 73
USB Keyboard Speed ENTER/EXIT PROGRAMMING MODE USB Keyboard Speed This option specifies the USB poll rate for a USB Keyboard. This feature applies ONLY to the USB Keyboard interface.
PAGE 74
Keyboard Interface ENTER/EXIT PROGRAMMING MODE USB Keyboard Speed — continued $CKBSP06 USB Keyboard Speed = 6ms $CKBSP07 USB Keyboard Speed = 7ms $CKBSP08 USB Keyboard Speed = 8ms $CKBSP09 USB Keyboard Speed = 9ms $CKBSP0A USB Keyboard Speed = 10ms 64 QuickScanTM Lite QW2100
PAGE 75
Chapter 8 USB-OEM Interface Introduction Feature settings for USB interfaces differ depending upon which host type the reader will be connected with. Use the feature settings in this chapter to specifically configure for the USBOEM interface. Other USB interfaces are included in the approprite chapter for their host type. Standard Factory Settings Reference Appendix B, Standard Defaults for a listing of standard factory settings.
PAGE 76
USB-OEM Interface ENTER/EXIT PROGRAMMING MODE USB-OEM Device Usage The USB-OEM protocol allows for the reader to be identified as one of two different types of bar code readers. Depending on what other scanners you may already have connected to a USBOEM POS, you may need to change this setting to enable all devices to communicate. Options are: • Table Top Scanner • Handheld Scanner It may be necessary to switch device usage when connecting two readers/scanners of the same type to a POS system.
PAGE 77
Chapter 9 Data Editing Data Editing Overview When a bar code is scanned, additional information can be sent to the host computer along with the bar code data. This combination of bar code data and supplementary user-defined data is called a “message string.” The features in this chapter can be used to build specific userdefined data into a message string. There are several types of selectable data characters that can be sent before and after scanned data.
PAGE 78
Data Editing ENTER/EXIT PROGRAMMING MODE Please Keep In Mind... • Modifying a message string is not a mandatory requirement. Data editing is sophisticated feature allowing highly customizable output for advanced users. Factory default settings for data editing is typically set to NONE. • A prefix or suffix may be applied (reference the Symbologies chapter for these settings) across all symbologies (set via the Global features in this chapter).
PAGE 79
Global AIM ID ENTER/EXIT PROGRAMMING MODE Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. NOTE AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. See Global AIM ID on page 261 for more detailed programming instructions.
PAGE 80
Data Editing ENTER/EXIT PROGRAMMING MODE Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.
PAGE 81
Label ID ENTER/EXIT PROGRAMMING MODE Label ID: Set Individually Per Symbology This feature configures a Label ID individually for a single symbology. This setting requires the scanning of bar codes from multiple sections. See Label ID: Set Individually Per Symbology on page 264 for more detailed programming instructions. NOTE Label ID Control This option controls whether a Label ID is disabled, or sent as a prefix or suffix for a given symbology type.
PAGE 82
Data Editing ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 83
Label ID ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection — continued This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 84
Data Editing ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection — continued This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 85
Label ID ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection — continued This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 86
Data Editing ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection — continued This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 87
Label ID ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection — continued This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 88
Data Editing ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection — continued This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 89
Label ID ENTER/EXIT PROGRAMMING MODE Label ID — continued Label ID Symbology Selection — continued This option selects the symbology for which a Label ID is to be configured. See Label ID: Set Individually Per Symbology on page 264 for full instructions.
PAGE 90
Data Editing ENTER/EXIT PROGRAMMING MODE Set Global Mid Label ID Character(s) Specifies a mid-label ID that is added for transmission between the labels of a two label pair. The expected string is a maximum of 20 characters. When combining two label pairs into a single label for transmission to the host, this label ID can be added to the data, following the first label and preceding the second label. To set this feature... 1. Scan the ENTER/EXIT bar code. 2.
PAGE 91
Case Conversion ENTER/EXIT PROGRAMMING MODE Case Conversion This feature allows conversion of the case of all alphabetic characters to upper or lower case. Case conversion affects ONLY scanned bar code data, and does not affect Label ID, Prefix, Suffix, or other appended data.
PAGE 92
Data Editing ENTER/EXIT PROGRAMMING MODE Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to. If the character to convert in a pair is FF, then no conversion is done. See Character Conversion on page 266 for more detailed programming instructions.
PAGE 93
Chapter 10 Symbologies Introduction The reader supports the following symbologies (bar code types). Options for each symbology are included in this chapter.
PAGE 94
Symbologies ENTER/EXIT PROGRAMMING MODE Disable All Symbologies Scan this label to disable all symbologies. $AD Disable all symbologies Coupon Control This feature is used to control the method of processing coupon labels. Options are: • Allow all — allow all coupon bar codes to be decoded • Enable only UPC/EAN — enables only UPC/EAN coupon decoding • Enable only GS1 DataBar — enables only GS1 DataBar coupon decoding To set this feature: 1. Scan the Enter/Exit bar code. 2.
PAGE 95
UPC-A ENTER/EXIT PROGRAMMING MODE UPC-A The following options apply to the UPC-A symbology. UPC-A Enable/Disable When disabled, the reader will not read UPC-A bar codes. $CABEN00 UPC-A = Disable $CABEN01 DEFAULT UPC-A = Enable UPC-A Check Character Transmission Enable this option to transmit the check character along with UPC-A bar code data.
PAGE 96
Symbologies ENTER/EXIT PROGRAMMING MODE UPC-A — cont. Expand UPC-A to EAN-13 Expands UPC-A data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CAB3B00 DEFAULT UPC-A to EAN-13 = Don’t Expand $CAB3B01 UPC-A to EAN-13 = Expand UPC-A Number System Character Transmission This feature enables/disables transmission of the UPC-A number system character.
PAGE 97
UPC-A ENTER/EXIT PROGRAMMING MODE UPC-A — cont. In-Store Minimum Reads This feature specifies the minimum number of consecutive times an in-store label must be decoded before it is accepted as good read. In-store labels are defined as UPC-A labels with a number-system character of 2 or 4 as well as EAN 8 and EAN 13 labels with a Flag1 character of 2 or an EAN 13 label starting with the three characters '980'.
PAGE 98
Symbologies ENTER/EXIT PROGRAMMING MODE UPC-E The following options apply to the UPC-E symbology. UPC-E Enable/Disable When disabled, the reader will not read UPC-E bar codes. $CEBEN00 UPC-E = Disable $CEBEN01 DEFAULT UPC-E = Enable UPC-E Check Character Transmission Enable this option to transmit the check character along with UPC-E bar code data.
PAGE 99
UPC-E ENTER/EXIT PROGRAMMING MODE UPC-E — cont. Expand UPC-E to EAN-13 Expands UPC-E data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CEB3B00 DEFAULT UPC-E to EAN-13 = Don’t Expand $CEB3B01 UPC-E to EAN-13 = Expand Expand UPC-E to UPC-A Expands UPC-E data to the UPC-A data format.
PAGE 100
Symbologies ENTER/EXIT PROGRAMMING MODE UPC-E — cont. UPC-E Number System Character Transmission This feature enables/disables transmission of the UPC-E system number character. $CEBNS00 UPC-E Number System Character = Do not transmit $CEBNS01 DEFAULT UPC-E Number System Character = Transmit UPC-E Minimum Reads This feature specifies the minimum number of consecutive times a UPC-E label must be decoded before it is accepted as good read.
PAGE 101
EAN 13 ENTER/EXIT PROGRAMMING MODE EAN 13 The following options apply to the EAN 13 (Jan 13) symbology. EAN 13 Enable/Disable When disabled, the reader will not read EAN 13/JAN 13 bar codes. $C3BEN00 EAN 13 = Disable $C3BEN01 DEFAULT EAN 13 = Enable EAN 13 Check Character Transmission Enable this option to transmit the check character along with EAN 13 bar code data.
PAGE 102
Symbologies ENTER/EXIT PROGRAMMING MODE EAN 13 — cont. EAN-13 Flag 1 Character Enables/disables transmission of an EAN/JAN13 Flag1 character. The Flag 1 character is the first character of the label. $C3BF100 EAN-13 Flag 1 Char= Don’t transmit $C3BF101 DEFAULT EAN-13 Flag 1 Char= Transmit EAN-13 ISBN Conversion This option enables/disables conversion of EAN 13/JAN 13 Bookland labels starting with 978 to ISBN labels.
PAGE 103
EAN 13 ENTER/EXIT PROGRAMMING MODE EAN 13 — cont. ISSN Enable/Disable Enables/disables conversion of EAN/JAN13 Bookland labels starting with 977 to ISSN labels. $C3BIN00 DEFAULT ISSN = Disable $C3BIN01 ISSN = Enable EAN 13 Minimum Reads This feature specifies the minimum number of consecutive times an EAN 13 label must be decoded before it is accepted as good read.
PAGE 104
Symbologies ENTER/EXIT PROGRAMMING MODE EAN 8 The following options apply to the EAN 8 (Jan 8) symbology. EAN 8 Enable/Disable When disabled, the reader will not read EAN 8/JAN 8 bar codes. $C8BEN00 EAN 8 = Disable $C8BEN01 DEFAULT EAN 8 = Enable EAN 8 Check Character Transmission Enable this option to transmit the check character along with EAN 8 bar code data.
PAGE 105
EAN 8 ENTER/EXIT PROGRAMMING MODE EAN 8 — cont. Expand EAN 8 to EAN 13 Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13. $C8B3B00 DEFAULT Expand EAN 8 to EAN 13 = Disable $C8B3B01 Expand EAN 8 to EAN 13 = Enable EAN 8 Both Guards Substitution Enables/disables the ability of the reader to find an EAN/JAN8 guard pattern in caseswhere the EAN/JAN8 margin makes the guard look like a character.
PAGE 106
Symbologies ENTER/EXIT PROGRAMMING MODE EAN 8 — cont. EAN 8 Guard Insertion Enables/disables the ability to insert a guard into an otherwise full-strike EAN 8 segment. $C8BGI00 DEFAULT EAN 8 Guard Insertion = Disable $C8BGI01 EAN 8 Guard Insertion = Enable EAN 8 Guard Substitution Enables/disables the ability of the reader to substitute guard pattern for even parity 6 when an EAN/JAN8 label is presented.
PAGE 107
EAN 8 ENTER/EXIT PROGRAMMING MODE EAN 8 — cont. EAN 8 Minimum Segment Length Block Specifies the minimum number of characters necessary in an EAN/JAN8 label segment in order for the reader to accept the segment for decoding.
PAGE 108
Symbologies ENTER/EXIT PROGRAMMING MODE EAN 8 — cont. EAN 8 Minimum Segment Length Block — cont.
PAGE 109
EAN 8 ENTER/EXIT PROGRAMMING MODE EAN 8 — cont. EAN 8 Minimum Reads This feature specifies the minimum number of consecutive times an EAN 8 (Jan 8) label must be decoded before it is accepted as good read.
PAGE 110
Symbologies ENTER/EXIT PROGRAMMING MODE EAN 8 — cont. EAN 8 Stitch Exact Label Halves Enables/disables the abiliy to stitch exact EAN 8 label halves with no overlapping characters. The label halves being stitched together to assemble a complete label must have the structure GddddC and CddddG.
PAGE 111
EAN Two Label ENTER/EXIT PROGRAMMING MODE EAN Two Label EAN Two Label Enable/Disable When disabled, the reader will not read EAN two label bar codes. $CN2EN00 DEFAULT EAN Two Label = Disable $CN2EN01 EAN Two Label = Enable EAN Two Label Combined Transmission This feature enables/disables transmission of an EAN two label pair as one label. tHE LABEL TYPE FOR ean TWO LABEL PAIRS IS ean 13.
PAGE 112
Symbologies ENTER/EXIT PROGRAMMING MODE EAN Two Label Minimum Reads This feature specifies the minimum number of consecutive times an EAN two label bar code must be decoded before it is accepted as good read.
PAGE 113
UPC/EAN Global Settings ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings This section provides configuration settings for UPC-A, UPC-E, EAN 13 and EAN 8 symbologies, and affects all of these unless otherwise marked for each feature description. UPC/EAN Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 114
Symbologies ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings — cont. UPC/EAN Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 115
UPC/EAN Global Settings ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings — cont. UPC/EAN Price Weight Check This feature enables/disables calculation and verification of price/weight check digits.
PAGE 116
Symbologies ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings — cont. UPC-A Minimum Reads This feature specifies the minimum number of consecutive times a UPC-A label must be decoded before it is accepted as good read.
PAGE 117
UPC/EAN Global Settings ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings — cont. UPC/EAN Guard Insertion Enables/disables the ability to insert either a missing leading or trailing guard on an otherwise complete UPC-A/EAN-13 segment. The segment must have the structure GddddddCdddddd or ddddddCddddddG.
PAGE 118
Symbologies ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings — cont. UPC/EAN Stitch Unlike Label Halves Enables/disables the ability to stitch two UPC-A/EAN 13 label halves together that may have differing characters in them. The label half structures must have the structure GddddddC and CddddddG. The characters dCd must match between the two segments.
PAGE 119
UPC/EAN Global Settings ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings — cont. UPC/EAN Minimum Segment Length Specifies the minimum number of characters necessary in an UPC/EAN/JAN label segment in order for the reader to accept the segment for decoding.
PAGE 120
Symbologies ENTER/EXIT PROGRAMMING MODE UPC/EAN Global Settings — cont. UPC/EAN Minimum Segment Length — cont.
PAGE 121
Add-Ons ENTER/EXIT PROGRAMMING MODE Add-Ons The following features apply to optional add-ons. Contact Customer Support for advanced programming of optional and conditional add-ons. NOTE Optional Add-ons The reader can be enabled to optionally read the following add-ons (supplementals): • P2 • P5 • GS1-128 If a UPC/EAN base label and a an add-on are both decoded, the reader will transmit the base label and add-on.
PAGE 122
Symbologies ENTER/EXIT PROGRAMMING MODE Add-Ons — cont. Optional Add-ons — cont.
PAGE 123
Add-Ons ENTER/EXIT PROGRAMMING MODE Add-Ons — cont. Optional Add-On Timer This option sets the time the reader will look for an add-on when an add-on fragment has been seen and optional add-ons are enabled.
PAGE 124
Symbologies ENTER/EXIT PROGRAMMING MODE Add-Ons — cont. Optional Add-On Timer — cont.
PAGE 125
Add-Ons ENTER/EXIT PROGRAMMING MODE Add-Ons — cont. P2 Add-Ons Minimum Reads This feature specifies the minimum number of times a P2 add-on must be read before it is marked as valid and then combined with a base label.
PAGE 126
Symbologies ENTER/EXIT PROGRAMMING MODE Add-Ons — cont. P5 Add-Ons Minimum Reads This feature specifies the minimum number of times a P5 add-on must be read before it is marked as valid and then combined with a base label.
PAGE 127
Add-Ons ENTER/EXIT PROGRAMMING MODE Add-Ons — cont. GS1-128 Add-Ons Minimum Reads This feature specifies the minimum number of times an GS1-128 add-on must be read before it is marked as valid and then combined with a base label.
PAGE 128
Symbologies ENTER/EXIT PROGRAMMING MODE GS1 DataBar Omnidirectional TM The following options apply to the GS1 DataBar Omnidirectional (formerly RSS-14) symbology. GS1 DataBar Omnidirectional Enable/Disable When disabled, the reader will not read GS1 DataBar Omnidirectional bar codes.
PAGE 129
GS1 DataBar TM Omnidirectional ENTER/EXIT PROGRAMMING MODE GS1 DataBarTM Omnidirectional — cont. GS1 DataBar Omnidirectional Minimum Reads This feature specifies the minimum number of consecutive times a GS1 DataBar Omnidirectional label must be decoded before it is accepted as good read.
PAGE 130
Symbologies ENTER/EXIT PROGRAMMING MODE GS1 DataBar Expanded TM The following options apply to the GS1 DataBar Expanded (formerly RSS Expanded) symbology. GS1 DataBar Expanded Enable/Disable When disabled, the reader will not read GS1 DataBar Expanded bar codes. $CXBEN00 DEFAULT GS1 DataBar Expanded = Disable $CXBEN01 GS1 DataBar Expanded = Enable GS1 DataBar Expanded GS1-128 Emulation When enabled, GS1 DataBar Expanded bar codes will be translated to the GS1-128 label data format.
PAGE 131
GS1 DataBar TM Expanded ENTER/EXIT PROGRAMMING MODE GS1 DataBarTM Expanded — cont. GS1 DataBar Expanded Minimum Reads This feature specifies the minimum number of consecutive times a GS1 DataBar Expanded label must be decoded before it is accepted as good read.
PAGE 132
Symbologies ENTER/EXIT PROGRAMMING MODE GS1 DataBarTM Expanded — cont. GS1 DataBar Expanded Length Control This feature specifies either variable length decoding or fixed length decoding for the GS1 DataBar Expanded symbology. Variable Length— For variable-length decoding, a minimum length may be set. Fixed Length— For fixed-length decoding, two different lengths may be set.
PAGE 133
GS1 DataBar TM Expanded ENTER/EXIT PROGRAMMING MODE GS1 DataBarTM Expanded — cont. GS1 DataBar Expanded Set Length 1 This feature specifies one of the bar code lengths for GS1 DataBar Expanded Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 1 to 74 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 134
Symbologies ENTER/EXIT PROGRAMMING MODE GS1 DataBarTM Expanded — cont. GS1 DataBar Expanded Set Length 2 This feature specifies one of the bar code lengths for GS1 DataBar Expanded Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 1 to 74 characters. A setting of 00 specifies to ignore this length (only one fixed length).
PAGE 135
TM GS1 DataBar Limited ENTER/EXIT PROGRAMMING MODE GS1 DataBar Limited TM The following options apply to the GS1 DataBar Limited (formerly RSS Limited) symbology. GS1 DataBar Limited Enable/Disable When disabled, the reader will not read GS1 DataBar Limited bar codes. $CLBEN00 DEFAULT GS1 DataBar Limited = Disable $CLBEN01 GS1 DataBar Limited = Enable GS1 DataBar Limited GS1-128 Emulation When enabled, GS1 DataBar Limited bar codes will be translated to the GS1-128 label data format.
PAGE 136
Symbologies ENTER/EXIT PROGRAMMING MODE GS1 DataBarTM Limited — cont. GS1 DataBar Limited Minimum Reads This feature specifies the minimum number of consecutive times a GS1 DataBar Limited label must be decoded before it is accepted as good read.
PAGE 137
Code 39 ENTER/EXIT PROGRAMMING MODE Code 39 The following options apply to the Code 39 symbology. Code 39 Enable/Disable When disabled, the reader will not read Code 39 bar codes.
PAGE 138
Symbologies ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Check Character Calculation Enable this option to enable/disable calculation and verification of an optional Code 39 check character. When disabled, any check character in the label is treated as a data character.
PAGE 139
Code 39 ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Check Character Transmission Enable this option to transmit the check character along with Code 39 bar code data. $CC3CT00 Code 39 Check Character Transmission = Don’t Send $CC3CT01 DEFAULT Code 39 Check Character Transmission = Send Code 39 Start/Stop Character Transmission Enable this option to enable/disable transmission of Code 39 start and stop characters.
PAGE 140
Symbologies ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Full ASCII In Code 39 decoding, this enables/disables the translation of Code 39 characters to Code 39 full-ASCII characters.
PAGE 141
Code 39 ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Quiet Zones This feature specifies the number of quiet zones for Code 39 labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label.
PAGE 142
Symbologies ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Minimum Reads This feature specifies the minimum number of consecutive times a Code 39 label must be decoded before it is accepted as good read.
PAGE 143
Code 39 ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 144
Symbologies ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 39 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 145
Code 39 ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Set Length 1 This feature specifies one of the bar code lengths for Code 39 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 0 to 50 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 146
Symbologies ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Set Length 2 This feature specifies one of the bar code lengths for Code 39 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters. The length does not include start/stop characters. The length can be set from 1 to 50 characters.
PAGE 147
Code 39 ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Interdigit Ratio This feature specifies the ratio between an intercharacter space and module for Code 39 labels.
PAGE 148
Symbologies ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Interdigit Ratio — cont.
PAGE 149
Code 39 ENTER/EXIT PROGRAMMING MODE Code 39 — cont. Code 39 Character Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 150
Symbologies ENTER/EXIT PROGRAMMING MODE Code 32 (Italian Pharmaceutical) The following options apply to the Code 32 symbology. Code 32 Enable/Disable When disabled, the reader will not read Code 32 bar codes.
PAGE 151
Code 32 (Italian Pharmaceutical) ENTER/EXIT PROGRAMMING MODE Code 32 (Italian Pharmaceutical) — cont. Code 32 Check Character Transmission Enable this option to transmit the check character along with Code 32 bar code data. $CP3CT00 DEFAULT Code 32 Check Character Transmission = Don’t Send $CP3CT01 Code 32 Check Character Transmission = Send Code 32 Start/Stop Character Transmission This option enables/disable transmission of Code 32 start and stop characters.
PAGE 152
Symbologies ENTER/EXIT PROGRAMMING MODE Code 39 CIP (French Pharmaceutical) The following options apply to the Code 39 CIP symbology. Code 39 CIP Enable/Disable Enables/Disables ability of the reader to decode Code 39 CIP labels. $CCCEN00 DEFAULT Code 39 CIP = Disable $CCCEN01 Code 39 CIP = Enable Code 128 The following options apply to the Code 128 symbology. Code 128 Enable/Disable When disabled, the reader will not read Code 128 bar codes.
PAGE 153
Code 128 ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Expand Code 128 to Code 39 This feature enables/disables expansion of Code 128 labels to Code 39 labels. When enabled, the label identifier for a Code 128 label shall be set to Code 39 and all Code 39 formatting control shall be applied to the label.
PAGE 154
Symbologies ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Function Character Transmission Enables/disables transmission of Code128 function characters 1, 2, 3, and 4. $CC8TF00 DEFAULT Code 128 Function Character Transmission = Don’t Send $CC8TF01 Code 128 Function Character Transmission = Send Code 128 Sub-Code Change Transmission Enables/disables the transmission of “Sub-Code exchange” characters (NOT transmitted by standard decoding).
PAGE 155
Code 128 ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Quiet Zones This feature specifies the number of quiet zones for Code 128 labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label.
PAGE 156
Symbologies ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Minimum Reads This feature specifies the minimum number of consecutive times a Code 128 label must be decoded before it is accepted as good read.
PAGE 157
Code 128 ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 158
Symbologies ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 128 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 159
Code 128 ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Set Length 1 This feature specifies one of the bar code lengths for Code 128 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 1 to 80 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 160
Symbologies ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Set Length 2 This feature specifies one of the bar code lengths for Code 128 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 1 to 80 characters. A setting of 00 specifies to ignore this length (only one fixed length).
PAGE 161
Code 128 ENTER/EXIT PROGRAMMING MODE Code 128 — cont. Code 128 Character Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 162
Symbologies ENTER/EXIT PROGRAMMING MODE GS1-128 The following options apply to the GS1-128 symbology. (Also known as USS-128, GTIN-128, UCC-128.) GS1-128 Enable This option enables/disables the ability of the reader to translate GS1-128 labels to the GS1-128 data format. Options are: • Transmit GS1-128 labels in Code 128 data format. • Transmit GS1-128 labels in GS1-128 data format. • Do not transmit GS1-128 labels.
PAGE 163
Interleaved 2 of 5 (I 2 of 5) ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) The following options apply to the I 2 of 5 symbology. I 2 of 5 Enable/Disable When disabled, the reader will not read I 2 of 5 bar codes.
PAGE 164
Symbologies ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional I 2 of 5 check character.
PAGE 165
Interleaved 2 of 5 (I 2 of 5) ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Check Character Calculation — cont. $CI2CC20 I 2 of 5 Check Character Calculation = Check Italian Post I 2 of 5 Check Character Transmission Enable this option to transmit the check character along with I 2 of 5 bar code data.
PAGE 166
Symbologies ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Minimum Reads This feature specifies the minimum number of consecutive times an I 2 of 5 label must be decoded before it is accepted as good read.
PAGE 167
Interleaved 2 of 5 (I 2 of 5) ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Decoding Level This configuration item applies to Interleaved 2 of 5, Datalogic 2 of 5 and Standard 2 of 5. NOTE Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 168
Symbologies ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the I 2 of 5 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 169
Interleaved 2 of 5 (I 2 of 5) ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for I 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. The length includes the bar code’s check and data characters. The length can be set from 2 to 50 characters in increments of two.
PAGE 170
Symbologies ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for I 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. The length includes the bar code’s check and data characters. The length can be set from 2 to 50 characters. A setting of 0 specifies to ignore this length (only one fixed length).
PAGE 171
Interleaved 2 of 5 (I 2 of 5) ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Character Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 172
Symbologies ENTER/EXIT PROGRAMMING MODE Interleaved 2 of 5 (I 2 of 5) — cont. I 2 of 5 Stitching This option enables/disables stitching for I 2 of 5 labels. When parts of a I 2 of 5 bar code are presented to the reader with this feature enabled, the bar code parts will be assembled by the reader’s software, and the data will be decoded if all bar code proofing requirements are met.
PAGE 173
Datalogic 2 of 5 ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 The following options apply to the Datalogic 2 of 5 symbology. Datalogic 2 of 5 Enable/Disable When disabled, the reader will not read Datalogic 2 of 5 bar codes.
PAGE 174
Symbologies ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 — cont. Datalogic 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional Datalogic 2 of 5 check character. $CD2CC00 DEFAULT Datalogic 2 of 5 Check Character Calculation = Disable $CD2CC01 Datalogic 2 of 5 Check Character Calculation = Enable Datalogic 2 of 5 Check Character Transmission This option enables/disables transmission of an optional Datalogic 2 of 5 character.
PAGE 175
Datalogic 2 of 5 ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 — cont. Datalogic 2 of 5 Minimum Reads This feature specifies the minimum number of consecutive times an Datalogic 2 of 5 label must be decoded before it is accepted as good read.
PAGE 176
Symbologies ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 — cont. Datalogic 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Datalogic 2 of 5 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 177
Datalogic 2 of 5 ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 — cont. Datalogic 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Datalogic 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. The length includes the bar code’s check and data characters. The length can be set from 2 to 50 characters in increments of two. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 178
Symbologies ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 — cont. Datalogic 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Datalogic 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. The length includes the bar code’s check and data characters. The length can be set from 2 to 50 characters. A setting of 00 specifies to ignore this length (only one fixed length).
PAGE 179
Datalogic 2 of 5 ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 Interdigit Maximum Ratio This feature specifies the maximum ratio between intercharacter space and module for Datalogic 2 of 5.
PAGE 180
Symbologies ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 Interdigit Maximum Ratio — cont.
PAGE 181
Datalogic 2 of 5 ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 — cont. Datalogic 2 of 5 Character Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 182
Symbologies ENTER/EXIT PROGRAMMING MODE Codabar The following options apply to the Codabar symbology. Codabar Enable/Disable When disabled, the reader will not read Codabar bar codes. $CCBEN00 DEFAULT Codabar = Disable $CCBEN01 Codabar = Enable Codabar Check Character Calculation Enable this option to enables/disables calculation and verification of an optional Codabar check character. When disabled, any check characters in the label are treated as data characters.
PAGE 183
Codabar ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Check Character Transmission Enable this option to transmit the check character along with Codabar bar code data. $CCBCT00 Codabar Check Character Transmission = Don’t Send $CCBCT01 DEFAULT Codabar Check Character Transmission = Send Codabar Start/Stop Character Transmission Enable this option to enable/disable transmission of Codabar start and stop characters.
PAGE 184
Symbologies ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Start/Stop Character Set This option specifies the format of transmitted Codabar start/stop characters.
PAGE 185
Codabar ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Start/Stop Character Match When enabled, this option requires that start and stop characters match.
PAGE 186
Symbologies ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Quiet Zones This feature specifies the number of quiet zones for Codabar labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label.
PAGE 187
Codabar ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Minimum Reads This feature specifies the minimum number of consecutive times a Codabar label must be decoded before it is accepted as good read.
PAGE 188
Symbologies ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 189
Codabar ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Length Control This feature specifies either variable length decoding or fixed length decoding for the Codabar symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 190
Symbologies ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Set Length 1 This feature specifies one of the bar code lengths for Codabar Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s start, stop, check and data characters. The length must include at least one data character. The length can be set from 3 to 50 characters.
PAGE 191
Codabar ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Set Length 2 This feature specifies one of the bar code lengths for Codabar Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. The length includes the bar code’s start, stop, check and data characters. The length must include at least one data character. The length can be set from 3 to 50 characters.
PAGE 192
Symbologies ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Interdigit Ratio This feature specifies the ratio between an intercharacter space and module for Codabar labels.
PAGE 193
Codabar ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Interdigit Ratio — cont.
PAGE 194
Symbologies ENTER/EXIT PROGRAMMING MODE Codabar — cont. Codabar Character Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 195
ABC Codabar ENTER/EXIT PROGRAMMING MODE ABC Codabar The following options apply to the ABC Codabar symbology. ABC Codabar Enable/Disable Enables/Disables ability of reader to decode ABC Codabar labels. $CCBAB00 DEFAULT ABC Codabar = Disable $CCBAB01 ABC Codabar = Enable ABC Codabar Concatenation Mode Specifies the concatenation mode between Static and Dynamic.
PAGE 196
Symbologies ENTER/EXIT PROGRAMMING MODE ABC Codabar — cont. ABC Codabar Dynamic Concatenation Timeout Specifies the timeout in 10-millisecond ticks used by the ABC Codabar Dynamic Concatenation Mode.
PAGE 197
Code 11 ENTER/EXIT PROGRAMMING MODE ABC Codabar — cont. ABC Codabar Force Concatenation Forces labels starting or ending with D to be concatenated. $CCBFC00 DEFAULT ABC Codabar Force Concatenation = Disable $CCBFC01 ABC Codabar Force Concatenation = Enable Code 11 The following options apply to the Code 11 symbology. Code 11 Enable/Disable When disabled, the reader will not read Code 11 bar codes.
PAGE 198
Symbologies ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Check Character Calculation This option enables/disables calculation and verification of optional Code 11 check character.
PAGE 199
Code 11 ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Minimum Reads This feature specifies the minimum number of consecutive times a Code 11 label must be decoded before it is accepted as good read.
PAGE 200
Symbologies ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 11 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 201
Code 11 ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Set Length 1 This feature specifies one of the bar code lengths for Code 11 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s check and data characters. The length can be set from 2 to 50 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 202
Symbologies ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Set Length 2 This feature specifies one of the bar code lengths for Code 11 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check and data characters. The length can be set from 2 to 50 characters. A setting of 00 specifies to ignore this length (only one fixed length).
PAGE 203
Code 11 ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Interdigit Ratio This feature specifies the ratio between an intercharacter space and module for Code 11 labels.
PAGE 204
Symbologies ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Interdigit Ratio — cont.
PAGE 205
Code 11 ENTER/EXIT PROGRAMMING MODE Code 11 Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 206
Symbologies ENTER/EXIT PROGRAMMING MODE Code 11 — cont. Code 11 Character Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 207
Standard 2 of 5 ENTER/EXIT PROGRAMMING MODE Standard 2 of 5 The following options apply to the Standard 2 of 5 symbology. Standard 2 of 5 Enable/Disable When disabled, the reader will not read Standard 2 of 5 bar codes. $CS2EN00 DEFAULT Standard 2 of 5 = Disable $CS2EN01 Standard 2 of 5 = Enable Standard 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional Standard 2 of 5 check character.
PAGE 208
Symbologies ENTER/EXIT PROGRAMMING MODE Standard 2 of 5 — cont. Standard 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Standard 2 of 5 check character. $CS2CT00 Standard 2 of 5 Check Character Transmission = Don’t Send $CS2CT01 DEFAULT Standard 2 of 5 Check Character Transmission = Send Standard 2 of 5 Minimum Reads This feature specifies the minimum number of consecutive times a Standard 2 of 5 label must be decoded before it is accepted as good read.
PAGE 209
Standard 2 of 5 ENTER/EXIT PROGRAMMING MODE Standard 2 of 5 — cont. Standard 2 of 5 Decoding Level The Standard 2 of 5 Decoding Level feature is set using I 2 of 5 Decoding Level on page 157. NOTE Standard 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Standard 2 of 5 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 210
Symbologies ENTER/EXIT PROGRAMMING MODE Standard 2 of 5 — cont. Standard 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Standard 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s check and data characters. The length can be set from 1 to 50 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 211
Standard 2 of 5 ENTER/EXIT PROGRAMMING MODE Standard 2 of 5 — cont. Standard 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Standard 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check and data characters. The length can be set from 1 to 50 characters. A setting of 00 specifies to ignore this length (only one fixed length).
PAGE 212
Symbologies ENTER/EXIT PROGRAMMING MODE Standard 2 of 5 — cont. Standard 2 of 5 Character Correlation When correlation is enabled, the bar code reader will combine label data from multiple scans when decoding. Enabling correlation will help the reader read labels that have some spots and/or voids. It may also help read labels that have damaged areas. Enabling correlation will also increase the chances that a label will be read incorrectly.
PAGE 213
Industrial 2 of 5 ENTER/EXIT PROGRAMMING MODE Industrial 2 of 5 The following options apply to the Industrial 2 of 5 symbology. Industrial 2 of 5 Enable/Disable Enables/Disables ability of reader to decode Industrial 2 of 5 labels. $CU2EN00 DEFAULT Industrial 2 of 5 = Disable $CU2EN01 Industrial 2 of 5 = Enable Industrial 2 of 5 Check Character Calculation Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character.
PAGE 214
Symbologies ENTER/EXIT PROGRAMMING MODE Industrial 2 of 5 — cont. Industrial 2 of 5 Check Character Transmission Enables/disables transmission of an Industrial 2 of 5 check character. $CU2CT00 Industrial 2 of 5 Check Character Transmission = Disable $CU2CT01 DEFAULT Industrial 2 of 5 Check Character Transmission = Enable Industrial 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the Industrial 2 of 5 symbology.
PAGE 215
Industrial 2 of 5 ENTER/EXIT PROGRAMMING MODE Industrial 2 of 5 — cont. Industrial 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Industrial 2 of 5 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 1 to 50 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 216
Symbologies ENTER/EXIT PROGRAMMING MODE Industrial 2 of 5 — cont. Industrial 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for Industrial 2 of 5 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters. The length does not include start/stop characters. The length can be set from 1 to 50 characters.
PAGE 217
Industrial 2 of 5 ENTER/EXIT PROGRAMMING MODE Industrial 2 of 5 — cont. Industrial 2 of 5 Minimum Reads This feature specifies the minimum number of consecutive times an Industrial 2 of 5 label must be decoded before it is accepted as good read.
PAGE 218
Symbologies ENTER/EXIT PROGRAMMING MODE Industrial 2 of 5 — cont. Industrial 2 of 5 Stitching Enables/disables fixed length stitching for Industrial 2 of 5. $CU2ST00 DEFAULT Industrial 2 of 5 Stitching = Disable $CU2ST01 Industrial 2 of 5 Stitching = Enable Industrial 2 of 5 Character Correlation Enable/disables character correlation for Industrial 2 of 5.
PAGE 219
IATA ENTER/EXIT PROGRAMMING MODE IATA The following options apply to the IATA symbology. IATA Enable/Disable Enables/Disables the ability of the reader to decode IATA labels. $CIAEN00 DEFAULT IATA = Disable $CIAEN01 IATA = Enable IATA Check Character Transmission Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character.
PAGE 220
Symbologies ENTER/EXIT PROGRAMMING MODE ISBT 128 The following options apply to the ISBT 128 symbology. ISBT 128 Concatenation Enables/disables ISBT128 concatenation of 2 labels. $CI8CE00 DEFAULT ISBN 128 Concatenation = Disable $CI8CE01 ISBN 128 Concatenation = Enable ISBT 128 Concatenation Mode Specifies the concatenation mode between Static and Dynamic. This option is only valid when 210).
PAGE 221
ISBT 128 ENTER/EXIT PROGRAMMING MODE ISBT 128 — cont. ISBT 128 Dynamic Concatenation Timeout Specifies the timeout used by the ISBT 128 Dynamic Concatenation Mode.
PAGE 222
Symbologies ENTER/EXIT PROGRAMMING MODE ISBT 128 — cont. ISBT 128 Force Concatenation When enabled, this feature forces all ISBT 128 labels to be concatenated. This option is only valid when enabled. (see page 210).
PAGE 223
MSI ENTER/EXIT PROGRAMMING MODE MSI The following options apply to the MSI symbology. MSI Enable/Disable Enables/Disables ability of reader to decode MSI labels. $CMSEN00 DEFAULT MSI = Disable $CMSEN01 MSI = Enable MSI Check Character Calculation Enables/Disables calculation and verification of an optional MSI check character.
PAGE 224
Symbologies ENTER/EXIT PROGRAMMING MODE MSI — cont. MSI Check Character Transmission Enables/disables transmission of an MSI check character. $CMSCT00 MSI Check Character Transmission = Disable $CMSCT01 DEFAULT MSI Check Character Transmission = Enable MSI Length Control This feature specifies either variable length decoding or fixed length decoding for the MSI symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set.
PAGE 225
MSI ENTER/EXIT PROGRAMMING MODE MSI — cont. MSI Set Length 1 This feature specifies one of the bar code lengths for MSI Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 01 to 50 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 226
Symbologies ENTER/EXIT PROGRAMMING MODE MSI — cont. MSI Set Length 2 This feature specifies one of the bar code lengths for MSI Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters. The length does not include start/stop characters. The length can be set from 1 to 50 characters. A setting of 0 specifies to ignore this length (only one fixed length).
PAGE 227
MSI ENTER/EXIT PROGRAMMING MODE MSI — cont. MSI Minimum Reads This feature specifies the minimum number of consecutive times an MSI label must be decoded before it is accepted as good read.
PAGE 228
Symbologies ENTER/EXIT PROGRAMMING MODE MSI — cont. MSI Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 229
Code 93 ENTER/EXIT PROGRAMMING MODE Code 93 The following options apply to the Code 93 symbology. Code 93 Enable/Disable Enables/Disables ability of reader to decode Code 93 labels. $CC9EN00 DEFAULT Code 93 = Disable $CC9EN01 Code 93 = Enable Code 93 Check Character Calculation Enables/disables calculation and verification of an optional Code 93 check character.
PAGE 230
Symbologies ENTER/EXIT PROGRAMMING MODE Code 93 — cont. Code 93 Check Character Transmission Enables/disables transmission of an optional Code 93 check character. $CC9CT00 Code 93 Check Character Transmission = Disable $CC9CT01 DEFAULT Code 93 Check Character Transmission = Enable Code 93 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 93 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set.
PAGE 231
Code 93 ENTER/EXIT PROGRAMMING MODE Code 93 — cont. Code 93 Set Length 1 This feature specifies one of the bar code lengths for Code 93 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 01 to 50 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 232
Symbologies ENTER/EXIT PROGRAMMING MODE Code 93 — cont. Code 93 Set Length 2 This feature specifies one of the bar code lengths for Code 93 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters. The length does not include start/stop characters. The length can be set from 1 to 50 characters.
PAGE 233
Code 93 ENTER/EXIT PROGRAMMING MODE Code 93 — cont. Code 93 Minimum Reads This feature specifies the minimum number of consecutive times a Code 93 label must be decoded before it is accepted as good read.
PAGE 234
Symbologies ENTER/EXIT PROGRAMMING MODE Code 93 — cont. Code 93 Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 235
Code 93 ENTER/EXIT PROGRAMMING MODE Code 93 — cont. Code 93 Quiet Zones Enables/disables fixed length stitching for Code 93.
PAGE 236
Symbologies ENTER/EXIT PROGRAMMING MODE Code 93 — cont. Code 93 Stitching Disable/enable fixed or variable length stitching for Code 93. $CC9ST00 Code 93 Stitching = Disable $CC9ST01 DEFAULT Code 93 Stitching = Enable Code 93 Character Correlation Enables/disables Character Correlation for Code 93.
PAGE 237
Codablock F ENTER/EXIT PROGRAMMING MODE Codablock F The following options apply to the Codablock F symbology. Codablock F Enable/Disable Enables/Disables the ability of the reader to decode Codablock F labels. $CCFEN00 DEFAULT Codablock F = Disable $CCFEN01 Codablock F = Enable Codablock F EAN Enable/Disable Enables/Disables the Codablock F EAN subtype (code with FNC1 in the first position).
PAGE 238
Symbologies ENTER/EXIT PROGRAMMING MODE Codablock F AIM Check Specifies if Check Digit calculation algorithm is AIM compliant or not. $CCFAC00 Codablock F AIM Check = Not AIM compliant $CCFAC01 DEFAULT Codablock F AIM Check = AIM compliant Codablock F Length Control This feature specifies either variable length decoding or fixed length decoding for the Codablock F symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set.
PAGE 239
Codablock F ENTER/EXIT PROGRAMMING MODE Codablock F — cont. Codablock F Set Length 1 This feature specifies one of the bar code lengths for Codablock F Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 003 to 255 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 240
Symbologies ENTER/EXIT PROGRAMMING MODE Codablock F — cont. Codablock F Set Length 2 This feature specifies one of the bar code lengths for Codablock F Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters. The length does not include start/stop characters. The length can be set from 3 to 255 characters.
PAGE 241
Code 4 ENTER/EXIT PROGRAMMING MODE Code 4 The following options apply to the Code 4 symbology. Code 4 Enable/Disable Enables/Disables ability of reader to decode Code 4 labels. $CCREN00 DEFAULT Code 4 = Disable $CCREN01 Code 4 = Enable Code 4 Check Character Transmission This feature enables/disables transmission of an optional Code 4 check character.
PAGE 242
Symbologies ENTER/EXIT PROGRAMMING MODE Code 4 — cont. Code 4 Hex to Decimal Conversion This feature enables/disables the conversion of hexidecimal label data to decimal label data. $CCRHD00 Code 4 Hex to Decimal Conversion = Disable $CCRHD01 DEFAULT Code 4 Hex to Decimal Conversion = Enable Code 5 The following options apply to the Code 5 symbology. Code 5 Enable/Disable Enables/Disables ability of reader to decode Code 5 labels.
PAGE 243
Code 5 ENTER/EXIT PROGRAMMING MODE Code 5 — cont. Code 5 Check Character Transmission This feature enables/disables transmission of an optional Code 5 check character. $CC5CT00 Code 5 Check Character Transmission = Don’t Send $CC5CT01 DEFAULT Code 5 Check Character Transmission = Send Code 5 Hex to Decimal Conversion This feature enables/disables the conversion of hexidecimal label data to decimal label data.
PAGE 244
Symbologies ENTER/EXIT PROGRAMMING MODE Code 4 and Code 5 Common Configuration Items The following options apply to both Code 4 and Code 5 symbologies. Code 4 and 5 Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions. This configuration item applies to Code 4 and Code 5.
PAGE 245
Code 4 and Code 5 Common Configuration Items ENTER/EXIT PROGRAMMING MODE Code 4 and Code 5 Common Configuration Items — cont. Code 4 and Code 5 Minimum Reads This feature specifies the minimum number of consecutive times a Code 4 or Code 5 label must be decoded before it is accepted as good read.
PAGE 246
Symbologies ENTER/EXIT PROGRAMMING MODE Follett 2 of 5 The following options apply to the Follett 2 of 5 symbology. Follett 2 of 5 Enable/Disable Enables/Disables ability of reader to decode Follett 2 of 5 labels. $CF2EN00 DEFAULT Follett 2 of 5 = Disable $CF2EN01 Follett 2 of 5 = Enable BC412 The following options apply to the BC412 symbology. BC412 Enable/Disable Enables/Disables ability of reader to decode BC412 labels.
PAGE 247
BC412 ENTER/EXIT PROGRAMMING MODE BC412 — cont. BC412 Check Character Calculation Enable this option to enable/disable calculation and verification of an optional BC412 check character. When disabled, any check character in the label is treated as a data character.
PAGE 248
Symbologies ENTER/EXIT PROGRAMMING MODE BC412 — cont. BC412 Minimum Reads This feature specifies the minimum number of consecutive times a BC412 label must be decoded before it is accepted as good read.
PAGE 249
BC412 ENTER/EXIT PROGRAMMING MODE BC412 — cont. BC412 Decoding Level Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. See Decoding Levels on page 267 for more detailed programming instructions.
PAGE 250
Symbologies ENTER/EXIT PROGRAMMING MODE BC412 — cont. BC412 Length Control This feature specifies either variable length decoding or fixed length decoding for the BC412 symbology. Variable Length— For variable length decoding, a minimum and maximum length may be set. Fixed Length— For fixed length decoding, two different lengths may be set.
PAGE 251
BC412 ENTER/EXIT PROGRAMMING MODE BC412 — cont. BC412 Set Length 1 This feature specifies one of the bar code lengths for BC412 Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. The length can be set from 0 to 50 characters. See Set Length 1 on page 268 for more detailed programming instructions.
PAGE 252
Symbologies ENTER/EXIT PROGRAMMING MODE BC412 — cont. BC412 Set Length 2 This feature specifies one of the bar code lengths for BC412 Length Control. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and full-ASCII shift characters. The length does not include start/stop characters. The length can be set from 1 to 50 characters.
PAGE 253
Chapter 11 References This section contains explanations and examples of selected bar code features. See the programming sections for the actual bar code labels used to configure the reader.
PAGE 254
References Label Gone Timeout This feature sets the time after the last label segment is seen before the reader prepares for a new label. The timeout can be set within a range of 10 milliseconds to 2,550 milliseconds (2.55 seconds) in 10ms increments. Label Gone Timeout does not apply to scan modes that require a trigger pull for each label that is read Follow these instructions to set this feature: 1. Determine the desired setting in milliseconds. 2.
PAGE 255
Good Read LED Duration Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 0.1 to 25.5 seconds in 100ms increments. Follow these instructions to set this feature: 1. Determine the desired setting in milliseconds. A setting of 0 means that the good read LED stays on until the next time the trigger is pulled. 2. Divide the desired setting by 100 (setting is in 100ms increments).
PAGE 256
References Scan Mode Selects the scan operating mode for the reader. Selections are: Trigger Single— When the trigger is pulled, scanning is activated until one of the following occurs: - Scanning Active Time has elapsed - a label has been read - the trigger is released This mode is associated with typical handheld reader operation: when the trigger is pulled, scanning starts and the product scans until the trigger is released, or a label is read, or the maximum Scanning Active Time has elapsed.
PAGE 257
Scanning Active Time Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1. Determine the desired setting. 2. Pad the result with leading zeroes to yield three digits. For example: 0 = 000, 5 = 005, 20 = 020, etc. 3. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming Mode. 4.
PAGE 258
References Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1. Determine the desired setting in milliseconds. 2. Divide the desired setting by 100 (setting is in 100ms increments). Pad the result with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc. 3.
PAGE 259
Flash Off Time Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1. Determine the desired setting in milliseconds. 2. Divide the desired setting by 100 (setting is in 100ms increments). Pad the result with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc. 3.
PAGE 260
References Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. To set the delay: 1. Determine the desired setting in milliseconds. 2. Divide the desired setting by 10 (setting is in 10ms increments). Pad the result with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc. 3.
PAGE 261
ACK Character ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. NOTE Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits has been set as 7 Data Bits. To set this feature: 1. Determine the desired character or value. 2.
PAGE 262
References NAK Character This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex value from 0 to 0xFF can be selected. NOTE Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits has been set as 7 Data Bits. To set this feature: 1. Determine the desired character or value. 2.
PAGE 263
ACK NAK Timeout Value ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. To set this value: 1. Determine the desired setting in milliseconds. 2. Divide the desired setting by 200 (setting is in 200ms increments). Pad the result with leading zeroes to yield two digits.
PAGE 264
References ACK NAK Retry Count This feature specifies the number of times the reader retries a label transmission due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries. To set this feature: 1. Determine the desired setting. 2. Pad the number with leading zeroes to yield three digits. For example: 0 = 000, 5 = 005, 20 = 020, etc. 3.
PAGE 265
Disable Character Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. NOTE Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits has been set as 7 Data Bits. To set the value: 1. Determine the desired character or value.
PAGE 266
References Enable Character Specifies the value of the RS-232 host command used to enable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. NOTE Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits has been set as 7 Data Bits. To set this feature: Determine the desired character or value.
PAGE 267
Wedge Quiet Interval Wedge Quiet Interval This option specifies the amount of time to look for keyboard activity before the reader breaks the keyboard connection in order to transmit data to host. The selectable range for this feature is from 0 to 990ms in 10ms increments. This feature applies ONLY to the Keyboard Wedge interface. NOTE Follow these instructions to set this feature: 1. Determine the desired setting in milliseconds. 2. Divide the desired setting by 10 (setting is in 10ms increments).
PAGE 268
References Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. This feature applies ONLY to the Keyboard Wedge interface. NOTE To set the delay: 1. Determine the desired setting in milliseconds. 2. Divide the desired setting by 10 (setting is in 10ms increments).
PAGE 269
Intercode Delay Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is from 0 to 99 seconds. Follow these instructions to set this feature: 1. Determine the desired setting. 2. Pad the number with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc 3. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming Mode. 4. Scan the bar code: SELECT INTERCODE DELAY SETTING. 5.
PAGE 270
References Global Prefix/Suffix Up to 20 ASCII characters may be added as a prefix (in a position before the bar code data) and/ or as a suffix (in a position following the bar code data) as indicated in Figure 7. Figure 7. Prefix and Suffix Positions OR... Prefix Label ID AIM ID Bar Code Data Label ID Suffix 00 - 20 Characters (ASCII) AND OR Example: Setting a Prefix In this example, we’ll set a prefix for all symbologies. 1.
PAGE 271
Global AIM ID Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. NOTE AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. AIM label identifiers consist of three characters as follows: • A close brace character (ASCII ‘]’), followed by... • A code character (see the table below), followed by... • A modifier character (the modifier character is symbol dependent).
PAGE 272
References Label ID: Pre-loaded Sets The following table lists the pre-loaded label ID sets for the USA and Europe. Table 17.
PAGE 273
Label ID: Pre-loaded Sets Symbology USA Label ID set EU Label ID set Industrial 2 of 5 W 570000 W 570000 Interleaved 2 of 5 CIP HR e 650000 e 650000 ISBN I 490000 @ 400000 ISBT128 f 660000 f 660000 ISSN n 6E0000 n 6E0000 MSI @ 400000 Z 5A0000 S25 s 730000 P 500000 UPCA A 410000 C 430000 UPCA P2 A 410000 F 460000 UPCA P5 A 410000 G 470000 UPCA P8 A 410000 Q 510000 UPCE E 450000 D 440000 UPCE P2 E 450000 H 480000 UPCE P5 E 450000 I 49000
PAGE 274
References Label ID: Set Individually Per Symbology To configure a Label ID individually for a single symbology: 1. Scan the ENTER/EXIT bar code. 2. Select Label ID position as either BEFORE (Enable as Prefix) or AFTER (Enable as suffix) by scanning the appropriate bar code in the section Label ID Control on page 71. Reference Figure 9 for Label ID positioning options if multiple identification features are enabled. 3.
PAGE 275
Label ID: Set Individually Per Symbology Label ID: Set Individually Per Symbology — continued Table 18. Label ID Examples STEP ACTION EXAMPLES 1. Scan the ENTER/EXIT bar code (Reader enters Programming Mode) 2. Determine placement of the Label ID characters BEFORE or AFTER with regard to Enable as Prefix Enable as Suffix Enable as Prefix scanned data using Label ID Enable as Suffix Control on page 71 3. 4.
PAGE 276
References Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to. If the character to convert in a pair is FF, then no conversion is done.
PAGE 277
Decoding Levels Decoding Levels Decoding Levels are used to configure a bar code symbology decoder to be very aggressive to very conservative depending on a particular customer’s needs. • Choosing Level 1 results in a very conservative decoder at the expense of not being able to read poorly printed or damaged labels. • Choosing Level 5 results in a very aggressive decoder.
PAGE 278
References Set Length 1 This feature specifies one of the bar code lengths for a given symbology. Length 1 is the minimum label length if in Varible Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. Reference the Symbologies section to view the selectable range (number of characters) for the symbology being set. Follow these instructions to set this feature: 1. Determine the desired character length.
PAGE 279
Set Length 2 Set Length 2 This feature specifies one of the bar code lengths for a given symbology. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar code’s data characters only. Reference the Symbologies section to view the selectable range (number of characters) for the symbology being set.. A setting of 00 specifies to ignore this length (only one fixed length). Follow these instructions to set this feature: 1.
PAGE 280
References NOTES 270 TM QuickScan Lite QW2100
PAGE 281
Appendix A Technical Specifications Table 1 contains Physical and Performance Characteristics, User Environment and Regulatory information. Table 2 provides Standard Cable Pinouts. Table 1. Technical Specifications Item Description Physical Characteristics 2.8 in. H x 6.7 in. L x 2.6 in. W Dimensions (7.1 cm H x 17.1 cm L x 6.6 cm W) Weight (without cable) Approximately 4.2 oz. (119 g) Color Black or White Electrical Characteristics Voltage & Current 5.
PAGE 282
Item Decode Capability Description UPC/EAN/JAN, P2 /P5 GS1-128 add-ons; Code 39; Code 39 Full ASCII; Code 32 (Italian Pharmacode); Code 128; ISBT 128; I 2 of 5; Standard 2 of 5; Code 11; Codabar; GS1-128; Code 93; MSI; GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded; EAN 13 ISBN; Datalogic 2 of 5; Follet 2/5; Code 4, code 5. QW2120: USB Com Std., USB Keyboard, USB Alternate Keyboard, USB-OEM. Interfaces Supported QW2170: RS-232 Std.
PAGE 283
Standard Cable Pinouts Standard Cable Pinouts Figure 10 and Table 2 provide standard pinout information for the reader’s cable. Figure 10. Standard Cable Pinouts Bottom of Imager Cable Cable Strain Relief Interface Cable Port Pin 1 Pin 10 To Host Cable Clip (Latch) The signal descriptions in Table 2 apply to the connector on the reader and are for reference only. Table 2.
PAGE 284
NOTES 274 QuickScanTM Lite QW2100
PAGE 285
Appendix B Standard Defaults The most common configuration settings are listed in the “Default” column of Table 3. The settings in this table are as applied to a standard RS-232 interface. See Table 4 for a listing of default exceptions to this list as appled to other interface types. Page references are also provided for feature descriptions and programming bar codes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features.
PAGE 286
Parameter Default Your Setting Page Number Flash On Time 1 Second 34 Flash Off Time 600 ms 34 Stand Mode Sensitivity Medium 35 Green Spot Duration 300 ms 36 9600 37 Data Bits 8 Data Bits 39 Stop Bits 1 Stop Bit 39 None 40 Disable 41 Intercharacter Delay No Delay 44 Beep On ASCII BEL Disable 45 Beep On Not on File Enable 45 ACK Character ‘ACK’ 47 NAK Character ‘NAK’ 47 600 ms 48 3 Retries 49 Ignore Errors Detected 50 Enable 51 Disable Character ‘D’ 51 Ena
PAGE 287
Parameter Default Your Setting Page Number USB-OEM USB-OEM Device Usage Handheld Scanner 66 Ignore 66 No Global Prefix Global Suffix = 0x0D (CR) 68 Global AIM ID Disable 69 GS1-128 AIM ID Enable 69 Label ID Control Disable 71 No Characters 80 Disable 81 No Char Conversion 82 Enable only UPC/ EAN 84 UPC-A Enable/Disable Enable 85 UPC-A Check Character Transmission Enable 85 Don’t Expand 86 Transmit 86 2 87 Enable 88 Send 88 Expand UPC-E to EAN-13 Don’t Expand 89
PAGE 288
Parameter Default EAN-13 ISBN Conversion Disable 92 ISSN Enable/Disable Disable 93 1 93 Enable 94 Send 94 Expand EAN 8 to EAN 13 Disable 95 EAN 8 Both Guards Substitution Disable 95 EAN 8 Guard Insertion Disable 96 EAN 8 Guard Substitution Disable 96 EAN 8 Minimum Segment Length Block 8 97 EAN 8 Minimum Reads 1 99 EAN 8 Stitch Exact Label Halves Disable 100 EAN 8 Stitch Unlike Label Halves Disable 100 EAN Two Label Enable/Disable Disable 101 EAN Two Label Combined Tr
PAGE 289
Parameter GS1-128 Add-Ons Minimum Reads Default Your Setting Page Number 1 117 GS1 DataBar Omnidirectional Enable/ Disable Disable 118 GS1 DataBar Omnidirectional GS1-128 Emulation Disable 118 GS1 DataBar Omnidirectional Minimum Reads 1 119 GS1 DataBar Expanded Enable/Disable Disable 120 GS1 DataBar Expanded GS1-128 Emulation Disable 120 GS1 DataBar Expanded Minimum Reads 1 121 Variable 122 GS1 DataBar Expanded Set Length 1 1 123 GS1 DataBar Expanded Set Length 2 74 124 GS1 D
PAGE 290
Parameter Code 39 Stitching Default Your Setting Page Number Enable 139 Disable 140 Code 32 Check Character Transmission Don’t Send 141 Code 32 Start/Stop Character Transmission Don’t Transmit 141 Disable 142 Enable 142 Don’t Expand 143 Don’t Send 143 Auto 145 Code 128 Minimum Reads 1 146 Code 128 Decoding Level 3 147 Code 128 Length Control Variable 148 Code 128 Set Length 1 1 149 Code 128 Set Length 2 80 150 Code 128 Character Correlation Disable 151 Code 128 Stit
PAGE 291
Parameter Default Your Setting Page Number Interleaved 2 of 5 CIP Interleaved 2 of 5 CIP HR Enable/Disable Disable 162 Datalogic 2 of 5 Enable/Disable Enable 163 Datalogic 2 of 5 Check Character Calculation Disable 164 Datalogic 2 of 5 Check Character Transmission Don’t Send 164 2 165 Variable 166 Datalogic 2 of 5 Set Length 1 12 167 Datalogic 2 of 5 Set Length 2 100 168 4 169 Datalogic 2 of 5 Character Correlation Disable 171 Datalogic 2 of 5 Stitching Disable 171 Disable
PAGE 292
Parameter ABC Codabar Concatenation Mode Default Your Setting Page Number Static 185 ABC Codabar Dynamic Concatenation Timeout 200mS 186 ABC Codabar Force Concatenation Disable 187 Disable 187 Check C and K 188 Send 188 2 189 Variable 190 Code 11 Set Length 1 4 191 Code 11 Set Length 2 50 192 Code 11 Interdigit Ratio 4 193 Code 11 Decoding Level 3 195 Code 11 Character Correlation Disable 196 Code 11 Stitching Disable 196 Standard 2 of 5 Enable/Disable Disable 197
PAGE 293
Parameter Industrial 2 of 5 Length Control Default Your Setting Page Number Variable 204 Industrial 2 of 5 Set Length 1 1 Character 205 Industrial 2 of 5 Set Length 2 50 Characters 206 Industrial 2 of 5 Minimum Reads 1 Read 207 Industrial 2 of 5 Stitching Disable 208 Industrial 2 of 5 Character Correlation Disable 208 IATA Enable/Disable Disable 209 IATA Check Character Transmission Enable 209 Disable 210 ISBT 128 Concatenation Mode Static 210 ISBT 128 Dynamic Concatenation T
PAGE 294
Parameter Default Code 93 Decoding Level Your Setting Page Number Level 3 224 Auto 225 Code 93 Stitching Enable 226 Code 93 Character Correlation Enable 226 Codablock F Enable/Disable Disable 227 Codablock F EAN Enable/Disable Disable 227 Enable Check C 228 Variable 228 Codablock F Set Length 1 3 Characters 229 Codablock F Set Length 2 100 Characters 230 Code 4 Enable/Disable Disable 231 Code 4 Check Character Transmission Enable 231 Code 4 Hex to Decimal Conversion Ena
PAGE 295
Default Exceptions Default Exceptions Table 3 lists standard default settings as applied to a standard RS-232 interface. Table 4 provides a listing of default exceptions to that list as applied to the other interface types. Table 4.
PAGE 296
Parameter Default Excption EAN13/P2 Label ID Character(s) A EAN13/P5 Label ID Character(s) A EAN13/GS1-128 Label ID Character(s) A GS1 DataBar 14 (Omnidirectional) Label ID Character(s) E GS1 DataBar Expanded Label ID Character(s) E GS1 DataBar Limited Label ID Character(s) E Character Conversion CR to ` Interface: RS232-OPOS Baud Rate Transmission Label ID Code GS1-128 AIM ID 286 115200 Baud Prefix Disable UPCA Label ID Character(s) C UPCE Label ID Character(s) D EAN 8 Label ID Chara
PAGE 297
Default Exceptions Parameter Default Excption EAN13/P5 Label ID Character(s) M EAN13/GS1-128 Label ID Character(s) # GS1 DataBar 14 (Omnidirectional) Label ID Character(s) u GS1 DataBar Expanded Label ID Character(s) t GS1 DataBar Limited Label ID Character(s) v Product Reference Guide 287
PAGE 298
NOTES 288 QuickScanTM Lite QW2100
PAGE 299
Appendix C LED and Beeper Indications The reader’s beeper sounds and its LED illuminates to indicate various functions or errors on the reader. An optional “Green Spot” also performs useful functions. The tables below list these indications. One exception to the behaviors listed in the tables is that the reader’s functions are programmable, and may or may not be turned on. For example, certain indications, such as the power-up beep can be disabled using programming bar code labels.
PAGE 300
LED and Beeper Indications INDICATION DESCRIPTION LED BEEPER Reader beeps four times at highest frequency and volume upon power-up. Power-up Beep The reader is in the process of powering-up. Good Read Beep A label has been successfully scanned by the reader. ROM Failure There is an error in the reader's software/programming Flashes Reader sounds one error beep at highest volume. Limited Scanning Label Read Indicates that a host connection is not established when the USB interface is enabled.
PAGE 301
Error Codes Error Codes Upon startup, if the reader sounds a long tone, this means the reader has not passed its automatic Selftest and has entered FRU1 isolation mode. If the reader is reset, the sequence will be repeated. The following table describes the LED flashes/beep codes associated with an error found.
PAGE 302
NOTES 292 QuickScanTM Lite QW2100
PAGE 303
Appendix D Sample Bar Codes The sample bar codes in this appendix are typical representations for their symbology types.
PAGE 304
Sample Bar Codes — continued Code 32 Codabar Code 93 Code 11 294 QuickScanTM Lite QW2100
PAGE 305
GS1 DataBar (RSS) GS1 DataBar (RSS) GS1 DataBar variants must be enabled to read the bar codes below (see GS1 DataBar (RSS) on page 295).
PAGE 306
NOTES 296 QuickScanTM Lite QW2100
PAGE 307
Appendix E Keypad Use the bar codes in this appendix to enter numbers as you would select digits/characters from a keypad.
PAGE 308
6 7 8 9 A B C 298 QuickScanTM Lite QW2100
PAGE 309
D E F Product Reference Guide 299
PAGE 310
NOTES 300 QuickScanTM Lite QW2100
PAGE 311
Appendix F Scancode Tables Control Character Emulation Control character emulation selects from different scancode tables as listed in this appendix. Each of the control character sets below are detailed by interface type in the tables. These apply to Wedge and USB Keyboard platforms. Control Character 00 — Characters from 00 to 0x1F are sent as control character Ctrl+Keys, special keys are located from 0x80 to 0xA1.
PAGE 312
Interface Type PC AT PS/2 or USB-Keyboard Table 1.
PAGE 313
Interface Type PC AT PS/2 or USB-Keyboard — cont. Table 2. Scancode Set When Control Character is 02 x0 x1 x2 x3 x4 x5 X6 x7 x8 x9 xA xB xC xD xE xF 0x Ar Ar Al Al  Cl  Cl  Cr  Cr  BS Tab à S+ Tab Enter Keypd Enter Ins Pg Up 1x Pg Dwn Home ß â á F6 F1 F2 F3 F4 F5 ESC F7 F8 F9 F10 2x Space ! “ # $ % & ‘ ( ) * + , - .
PAGE 314
Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode Table 3.
PAGE 315
Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode — cont. Table 4.
PAGE 316
Digital Interface Table 5.
PAGE 317
Digital Interface — cont. Table 6. Scancode Set When Control Character is 02 X0 x1 x2 x3 0x 1x x4 x5 Cl Cl x6 x7 x8 x9 xA xB xC xD xE BS Tab à S+ Tab Enter Keypd Enter Ins xF ß â á F6 F1 F2 F3 F4 F5 ESC F7 F8 F9 F10 2x Space ! “ # $ % & ‘ ( ) * + , - .
PAGE 318
IBM XT Table 7.
PAGE 319
IBM XT — cont. Table 8. Scancode Set When Control Character is 02 X0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF 0x Ar Ar Al Al Cl Cl Cr Cr BS Tab à S+ Tab Enter Keypd Enter Ins Pg Up 1x Pg Dwn Home ß â á F6 F1 F2 F3 F4 F5 ESC F7 F8 F9 F10 2x Space ! “ # $ % & ‘ ( ) * + , - .
PAGE 320
Microsoft Windows Codepage 1252 Windows-1252 is a character encoding of the Latin alphabet, used by default in the legacy components of Microsoft Windows in English and some other Western languages.
PAGE 321
Index B bar codes RS-232 baud rate 63 RS-232 parameters parity 231, 232, 234, 236 barcodes cancel 297 numeric barcodes 297 RS-232 parameters parity 57 Beeper Pitch, Good Read 24, 25 Volume, Good Read 28 Beeper, Good Read 22 Pitch 24, 25 Volume 28 Good Read, Beeper – 22 Good Read, Beeper Pitch – 24, 25 Good Read, Beeper Volume – 28 Green Spot 289 H Handheld Scanner 66 I Indications 289 Interface Cable 6 Interface Type 9 Interfaces Supported 272 C Cable Pinouts 273 Clear to Send 41 Conversion, case 81 Con
PAGE 322
Print Contrast Minimum 271 Product Specifications 271 Programming Barcodes 9 X XON/XOFF 41 R Read, Beeper – Good 22 Read, Beeper Pitch – Good 24, 25 Read, Beeper Volume – Good 28 Request to Send 41 Roll (Tilt) Tolerance 271 RS-232 interface selection 12 RS-232 Serial Connection 6 RTS 41 S sample bar codes code 128 293 code 39 293 interleaved 2 of 5 294 select digits/characters 297 Serial Output 273 Skew (Yaw) Tolerance 271 Standard Cable Pinouts 273 Suffix 68, 260 Symbologies 243 symbology types 293 T T
PAGE 323
ASCII Chart ASCI I Char. Hex No. ASCI I Char. Hex No. ASCI I Char. Hex No. ASCI I Char. Hex No. NUL SOH STX ETX EOT ENQ ACK BEL BS HT LF VT FF CR SO SI DLE DC1 DC2 DC3 DC4 NAK SYN ETB CAN EM SUB ESC FS GS RS US 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F SP ! “ # $ % & ’ ( ) * + , .
PAGE 324
www.datalogic.com ©2011-2014 Datalogic ADC, Inc. All rights reserved. Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. Datalogic ADC, Inc. 959 Terry Street | Eugene |OR 97402 | USA Telephone: (1) 541-683-5700 | Fax: (1) 541-345-7140 820036414 (Rev.
