Operating instructions

Dayton Operating Instructions and Parts Manual
3
Model 4E236C
Version B - For Reduction G016.J
®
Carbon monoxide
poisoning: Some
people are more affected by carbon
monoxide than others. Early signs of
carbon monoxide poisoning resemble
the flu, with headaches, dizziness,
and/or nausea. If you have these signs,
the heater may not be operating
properly. Get fresh air at once! Have
heater serviced.
Propane Gas: Propane gas is odorless.
An odor-making agent is added to
propane gas. The odor helps you detect
a propane gas leak. However, the odor
added to propane gas can fade.
Propane gas may be present even
though no odor exists.
• Install and use heater with care.
Follow all local ordinances and
codes. In the absence of local
ordinances and codes, refer to
ANSI/NFPA 58. This instructs on the
safe storage and handling of propane
gases.
• This heater is equipped with a thermo-
stat. Heater may start at anytime.
• Check heater for damage before each
use. Do not use a damaged heater.
• Use only propane gas set up for
vapor withdrawal.
• The electrical connections and
grounding of the heater shall follow
the National Electric Code,
ANSI/NFPA70.
• Keep propane tank(s) below 100 ° F.
• Do not use heater below ground
level. Propane gas is heavier than air.
If a leak occurs, propane gas will sink
to the lowest possible level.
• Use only the electrical voltage and
frequency specified on model plate.
• Electrical grounding instructions —
This appliance is equipped with a
three-prong (grounding) plug for
your protection against shock hazard
and should be plugged directly into
a properly grounded three-prong
receptacle.
• Use only a three-prong, grounded
extension cord.
• Use only the hose and factory
regulator provided with the heater.
• Inspect hose before each use of
heater. If highly worn or cut, replace
before using heater. Use the replace-
ment hose assembly specified in this
manual.
• Keep heater at least six feet from
propane tank(s). Do not point heater
at propane tank(s) within 20 feet.
• Minimum heater clearances from
combustibles:
Outlet: 8 Ft. Sides: 2 Ft.
Top: 6 Ft. Rear: 2 Ft.
• Locate heater on stable and level
surface if heater is hot or running.
• For indoor use
only. Provide
adequate ventilation.
• Use only in well-vented areas. Before
using heater, provide at least a
three-square-foot opening of fresh,
outside air for each 100,000 BTU/Hr
of rating. This heater produces
carbon monoxide, which is listed by
the State of California as a reproduc-
tive toxin under Proposition 65.
• Do not use heater outdoors or in
occupied dwellings.
• Do not use heater in living or
sleeping quarters.
• Keep appliance area clear and free
from combustible materials, gaso-
line, paint thinner, and other
flammable vapors and liquids. Do
not use heater in areas with high
dust content.
• Keep heater away from strong
drafts, water spray, rain, or dripping
water.
General Safety Information
(Continued)
• Keep children and animals away
from heater.
• Turn off propane supply and unplug
heater when not in use.
• Never block air inlet (rear) or air
outlet (front) of heater.
• Never move, handle, or service a hot,
operating, or plugged-in heater.
Severe burns may result. You must
wait 20 minutes after turning heater
off.
• Do not alter heater. Keep heater in
its original state.
• Do not use heater if altered.
• Never attach duct work to front or
rear of heater.
• Use only original replacement parts.
This heater must use design-specific
parts. Do not substitute or use
generic parts. Improper replacement
parts could cause serious or fatal
injuries.
• Do not adjust regulator below 7 psiG
or above 20 psiG.
