Installation Guide

7
Accessories Required (sold separately)
Solid Surface for Bend Unit (CAD-BND-T) ■
For alternate type and color of the Solid Surface, contact your local manufacturer and provide drawing below
(Fig. 24).
Accessories Optional
BND-CNR Corner Bracket ■
Provides additional counter space with leg room
underneath. Mounts to (2) CAD-BND Bend Units in
standard orientation around a CAD-30 and (2) other
outdoor products on outer ends (Fig. 25).
CAD-LVL ■
For use with the CAD carts, these legs replace the
standard casters and allow for easy height adjustment.
29.32
A
A
15.95
2X
10.00
25.44
2X
45°
2X
90°
2X
67.5°
2X
C
L
SYMM
R.250 ON ALL CORNERS
AND TOP EDGES
SEAMS TO BE LOCATED
ON SIDE FA CES
.500 ALL WALLS
29.59
1.30
SECTION A-A
Fig. 24
Fig. 25
