OWNER’S MANUAL You can rely on Defy. To simplify TOUCH CONTROL CERAN HOB DHD 395 “770 TC” 2 2 2 2 3 4 4 5 7 Introduction. Unpacking. Cupboard design. Aperture size Installation. Safety installation. Electrical installation. The controls. Automatic fast heating & Timer, Ceran smooth top. 8 Recommendations & Error codes. 9 Technical specifications. 9 Safety advice. 9 Problem check. 9 Owner’s responsibility. 10 Defy Service Centres. 11 Warranty. 12 Purchase details to be filled in.
Introduction Congratulations on the purchase of this quality hob. We, the manufacturer, trust that you will enjoy many years of trouble free use. Please read these instructions carefully before using the hob. This book will provide you with information on how to operate and care for your hob in order that you gain the maximum benefit from it. Unpacking • • • • Please ensure that packaging material is disposed of in a responsible manner.
Installation Installation is the buyer’s responsibility. The manufacturer accepts no liability for this service. Any action that the manufacturer has to take as a result of an erroneous installation will not be covered by the warranty. • The hob is supplied with securing clips. A • • • • • • B C These fit into dedicated slots around the hob base . (see picture A) Insert the clips. (as shown in picture B) Lift the clips up until they click into place.
! VERY IMPORTANT SAFETY INSTRUCTION Safety installation for hob with control panel • • • • A removable horizontal board must be fitted below the hob and 75mm away from the worktop bottom face. Space between this board and the hob must be empty and no objects may be stored or kept there. This board will effectively shield the user from the base of the hob which gets hot during use. The board needs to be removable for service purposes as the hob, once installed, can only be loosened from below.
Controls Ceramic glass cooktop 1. 2. 3. 4. 5. Cooking zone Hi Light front left. Cooking zone Hi Light rear left. Cooking zone Hi Light rear right. Cooking zone Hi Light front right. Hob controls. Hob control elements A. B. B1. C. C1. D. E. F. On/Off sensor. Child lock On/Off sensor. Child lock signal light . Cooking zone expansion On/Off sensor. Cooking zone Expansion indicator light. Cooking zone selection and On/Off sensor (+). Sensor (-). Cooking zone power or remain heat displays. F1. G. H. I. I1.
Controls Switching a cooking zone off • Press the (-) sensor (E) and set the power level to ‘0’, the hotplate will switch off after 3 seconds. Shortly thereafter the hot surface indicator light on the hob will switch on, display (H) and remain on for 20 to 30 minutes after the plate is switched off. This is a reminder that the hob surface is still too hot to touch. • Fast deactivation. Press both + and - (D and E) touchpad sensors simultaneously to switch the hotplate off immediately.
The hob is fitted with a special mechanism which makes the hotplates operate at full power at the start of cooking regardless of the selected setting. After a certain amount of time the hotplate returns to the originally set value. Automatic fast heating Activation of automatic fast heating • Selected hotplate must be set to level “0” • Touch the sensor “E” and the display switches to the power setting 9.
Recommendations Recommendations (see also the enclosed ‘CERAN’ leaflet) • Use only pots with a solid level base. An uneven base will prolong cooking time and waste energy. • Use pots with a base diameter slightly larger than that of the thermal area. This will ensure even heat distribution and prevent spillage from dripping onto and staining the hot zone. • Always cover the pot with a lid. This will conserve energy and minimize spillage.
Technical Specifications Model DHD 395 “770 TC” Volts 220V –240V 50/60Hz~ Amperes 33 Plate power rating (ø, mm/ W) Front cooking zone left 210/120, 2200/750 Front cooking zone right 180, 1800 Rear cooking zone right 170 x265, 2400/1500 Rear cooking zone left 140, 1200 Total power ( W) 7600 Type of switch Electronic sensors Width Depth 770 mm 510 mm Safety advice • • • • • This hob is not intended for use by persons (including children) with reduced physical, sensory or mental capabilit
Defy Service Centres If you have followed the instructions and still have a problem, contact the nearest Defy Technical Support Centre. They will be able to advise you on any aspect of the product or send a qualified technician to repair it. BLOEMFONTEIN CAPE TOWN DURBAN EAST LONDON JOHANNESBURG Commercial Head Office, Administration, Distribution, National Groups, Tel. Sales, Contracts and Credit. POLOKWANE PORT ELIZABETH PRETORIA. 160 Long Street, Hilton, Bloemfontein 9301. Tel.
Warranty This certificate is issued by DEFY APPLIANCES (PTY) LTD manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance described on the certificate and shall constitute the only warranty given in respect of this appliance.
You can rely on Defy. To simplify For future reference, record the listed information in the space below. The Serial number may be found on the label attached to the hob base.
