Specification Guide

MERIDIAN SERIES
®
SOLID DOOR REACH IN FREEZERS
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES
®
Solid Door Reach In Freezers
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Approval _________________
Date ____________________
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum.
Facing of shroud shall be easily removable without
the use of tools. Cabinet interior shall be anodized
aluminum. Bottom & top of liner shall be die-stamped
to provide radius corners and a recessed bottom. Base
shall be fully insulated with high-density foamed in
place polyurethane.
Interior: Shall have three epoxy-coated wire shelves
per door section. Shelf support pilasters shall be
heavy-duty with shelves adjustable at 1.0” (2.5 cm)
increments. Units are mounted on 6” (15.24cm) metal
legs.
Doors: Solid doors shall have a 22-gauge stainless
steel exterior & anodized aluminum interior liner.
Doors shall be fully insulated with high density foamed
in place polyurethane. Each door shall have two
self-closing, cam-lift style hinges. Doors shall be easily
removable without use of tools. Door gaskets shall be
magnetic snap-in style to allow simple replacement. Door
handles shall be recessed.
• Specify right or left hand hinging at time of order.
Mechanical controls shall be located behind a removable
shroud facing.
Freezers: All components are mounted to the
exterior cabinet ceiling, outside the food zone and are
assembled as one piece and can be removed as one
piece. Environmentally friendly R404A refrigerant is
used. System has the capability of maintaining between
-5˚F and 0˚F in heavy use food service operations.
Refrigerant is metered using a highly responsive
thermostatic expansion valve. Evaporator defrost is
automatic using a time initiated, time/temperature
terminated system with electric heaters. Evaporator
condensate is eliminated using an energy efficient hot
gas system.
Single Voltage Models Only: Electrical connections
shall be 115 volt, 60 hertz, single phase, with an
eight feet (2.4m) long electrical cord & plug as shown
on reference chart. Cord & plug shall be wired to the
junction box on top of the unit.
Dual Voltage Models Only: Electrical connections
shall be 115/208-230 volt, 60 hertz, single phase, and
must be hard-wired to the junction box located on top
of the unit.
MODELS:
 MFR1-S Single section  MFR2-S Two section  MFR3-S Three section
Full height door Full height doors Full height doors
 MFR1R-S Remote  MFR2R-S Remote  MFR3R-S Remote
 MFR1-SH Single section  MFR2-SH Two section  MFR3-SH Three section
Half height door Half height doors Half height doors
 MFR1R-SH Remote  MFR2R-SH Remote  MFR3R-SH Remote
MFR1-S
Optional fourth shelf and
left-hand hinging.
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to find, don’t intrude into
kitchen traffic
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with minimal
energy cost
• Exterior digital thermometer with high/low temperature
alarm
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Epoxy coated shelves—corrosion resistant, 300-lb. capacity.
Flexible placement on 1” centers allows maximum storage
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven floors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters
